Purmo Unisenza User manual

Installation
and user manual
Unisenza - Wiring Centre
EN
Riscal./raffred.
Heat /Cool
Heating and
Cooling
Alarm function
Alarm
function
Boiler or HP
compatibility
Boiler or HP
compatibility
Pump exercise
function
Pump exercise
function


Unisenza - Wiring Centre
Installation and user manual
EN
Index
1 SAFETY WARNING ..................................................................................................................................................................................................4
2 TECHNICAL SPECIFICATIONS.............................................................................................................................................................................4
3 REFERENCE STANDARDS....................................................................................................................................................................................4
4 LIST OF CONTENTS.................................................................................................................................................................................................5
4.1 Wiring Center with DIN rail - (230 V)................................................................................................................................................................5
4.2 Wiring Center with DIN rail - (24 V)...................................................................................................................................................................5
4.3 Wiring Center without DIN rail - (230 V / 24 V)............................................................................................................................................6
5 DIMENSIONS.............................................................................................................................................................................................................6
6 INSTALLATION ..........................................................................................................................................................................................................7
7 MAIN WIRING DIAGRAM.......................................................................................................................................................................................9
7.1 Fuse (A) ........................................................................................................................................................................................................................9
7.2 Main supply and earth connection....................................................................................................................................................................9
7.3 Pump terminals.......................................................................................................................................................................................................10
7.4 Generator terminals .............................................................................................................................................................................................. 12
7.5 Changeover output terminals............................................................................................................................................................................ 12
7.6 Changeover input terminals............................................................................................................................................................................... 12
7.7 Alarm terminals ...................................................................................................................................................................................................... 13
7.8 Thermostat + actuator zone terminals .......................................................................................................................................................... 14
7.9 Dip Switch .................................................................................................................................................................................................................15
7.10 Lights........................................................................................................................................................................................................................... 15
8 USER’S GUIDE......................................................................................................................................................................................................... 16
8.1 Functions...................................................................................................................................................................................................................16
8.1.1 NSB (Night Setback)..............................................................................................................................................................................................16
8.1.2 Change Over.............................................................................................................................................................................................................16
8.1.3 Pump delay...............................................................................................................................................................................................................16
8.1.4 Pump exercise function .......................................................................................................................................................................................16
8.2 Wiring diagrams...................................................................................................................................................................................................... 17
8.2.1 Diagram 1: Heating only.......................................................................................................................................................................................18
8.2.2 Diagram 2: Heating only with NSB by WiFi thermostat..........................................................................................................................18
8.2.3 Diagram 3: Heating only with NSB by external clock.............................................................................................................................. 19
8.2.4 Diagram 4: Heating only with all WiFi thermostats..................................................................................................................................19
8.2.5 Diagram 5: Heating and cooling with change over by thermostats ..................................................................................................20
8.2.6 Diagram 6: Heating and cooling with NSB by WiFi thermostat and change over by thermostats........................................ 21
8.2.7 Diagram 7: Heating and cooling with change over by thermostats or by Wiring Centre COin............................................... 22
8.2.8 Diagram 8: Heating and cooling with NSB by WiFi thermostat and change over by thermostats or by Wiring
Centre COin.............................................................................................................................................................................................................. 23
8.2.9 Diagram 9: Heating and cooling with all WiFi thermostat and change over by thermostats ................................................. 24
8.2.10 Diagram 10: Heating and cooling with all Dial thermostat and change over only by Wiring Centre COin......................... 25
9 WEEE DIRECTIVE APPLICATION ................................................................................................................................................................... 26


Unisenza - Wiring Centre
Installation and user manual
EN 1 SAFETY WARNING
During installation and operation of the device, it is neces-
sary to comply with the following instructions:
1) The device must be installed by a skilled person, in strict
compliance with the connection diagrams.
2) Do not power on or connect the device if any part of it is
damaged.
3) After installation, inaccessibility to the connection termi-
nals without appropriate tools must be granted.
4) The device must be installed and activated in compliance
with current electric systems standards.
5) Before accessing the connection terminals, verify that the
leads are not live.
2 TECHNICAL SPECIFICATIONS
• Purpose of control: electronic thermostat;
• Supply voltage:
 230 Vac version: 230 V~ ±10 % - 50/60 Hz
 24 Vac version: 24 V~ ±10 %;
• Fuse: 5x20, 5 A 250 V;
• Power consumption: depends on the loads connected;
• Capacity of the contacts:
 Pump output: 10 A 250 V~ (Live and neutral for 230 Vac
Wiring centre version and free contact for 24 Vac Wiring
Centre version);
 Generator output: 10 A 250 V~ (voltage free);
 Change output (COout): 10 A 250 V~ (voltage free);
 Zones: The maximum output power of each zones
depends of the thermostat connecting on this zone but
for easy installation we recommend:
- 230 Vac - 10 zones version: a maximum of 10 actua-
tors by zones and maximum 20 actuators for the
Wiring Centre;
- 230 Vac - 5 zones version: a maximum of 10 actuators
by zones and maximum 20 actuators for the Wiring
Centre;
- 24 Vac - 10 zones version: a maximum of 4 actuators
by zones and maximum 10 actuators for the Wiring
Centre;
• Construction: Class II;
• Ingress protection: IP 20;
• Operating temperature: 0 °C…40 °C;
• Operating humidity: 20 %...90 % rH non condensing;
• Storage temperature: -20 °C…60 °C;
• Shock load voltage: 2,5 KV;
• Temperature for Ball Pressure Test: 90° C;
• Pollution degree: 2 (normal).
3 REFERENCE STANDARDS
Conformity with EU directives:
2014/35/EU (LVD)
2014/30/EU (EMCD)
2011/65/EU (ROHS)
is declared with reference to the following standard:
EN 60730-1, EN 60730-2-9, EN 60669-2-1, EN 61000-3-2,
EN 61000-3-3, EN 50581.


Unisenza - Wiring Centre
Installation and user manual
EN
4 LIST OF CONTENTS
4.1 Wiring Center with DIN rail - (230 V)
Wiring Centre - 1 Pcs
DIN rail - 1 Pcs
Cable (1.5 m) with Schuko plug - 1 Pcs
Grommet plug - 13 Pcs
Cable clamps - 2 Pcs Screws -18 Pcs
Note. Cable with Schuko plug, the shorter cable clamp, one grommit plug and three screws are already installed
in the Wiring Center at the factory.
4.2 Wiring Center with DIN rail - (24 V)
Wiring Centre - 1 Pcs
DIN rail - 1 Pcs
Grommet plug - 13 PcsCable clamps - 2 Pcs Screws -18 Pcs


Unisenza - Wiring Centre
Installation and user manual
EN 4.3 Wiring Center without DIN rail - (230 V / 24 V)
Wiring Centre - 1 Pcs
Grommet plug - 13 PcsCable clamps - 2 Pcs Screws -18 Pcs
5 DIMENSIONS
280 mm 60 mm
120 mm


Unisenza - Wiring Centre
Installation and user manual
EN
6 INSTALLATION
Remove the protective film from the cover.
To remove the front cover of the Purmo Unisenza Wiring Centre, turn the white screw (not remove it) on the bottom counter
clockwise and pull the cover off.
3
4
12345
CLIK
56
89
7
1 2
Remove only the plastic covers for the cables that are necessary for the installation.
Use a scissors to remove them. Insert the rubber plug, present in the package, in the holes.
3
4
12345
CLIK
56
89
7
1 2
The Unisenza Wiring Centre can mounted directly to the wall using the two screw holes in the back (screws and plugs not
included), or altenatively, the Wiring Centre can be DIN rail mounted as shown below (DIN rail is included in UNISENZA
Wiring Centre with DIN rail version):
3
4
12345
CLIK
56
89
7
1 2


Unisenza - Wiring Centre
Installation and user manual
EN Cut the grommet plug.
Plug the cable in the grommet plug.
3
4
12345
CLIK
56
89
7
1 2
Use cable size 0,75 - 1,5 mm2for solid core cable. For the cable supply cable use cable type H05VV-F 3x0,75mm2.
The wires lenghtsshould be measured according to the distance of the terminals from the cable clamp.
After fixing the wires in the relative terminals, screw the screws of the cable clamp to lock the cable. Insert the grommet
plug into the hole
3
4
12345
CLIK
56
89
7
1 2
Put the front cover on like shown below.
Turn the white screw clockwise to fix the front cover.
3
4
12345
CLIK
56
89
7
1 2


Unisenza - Wiring Centre
Installation and user manual
EN
7 MAIN WIRING DIAGRAM
A
B
J
I
C G HFED
12345
A= Fuse B= earth connector C= power supply terminal D= Pump terminal E= Generator terminal
F= Changeover output terminal G= Changeover input terminal H= alarm input terminal
I= Thermostat and actuator terminals J= Dip switch
7.1 Fuse (A)
5 Amp, 20mm anti-surge fuse. This fuse supplies power to all 230v outputs from the Wiring Centre.
The fuse also protects the zone & pump outputs.
7.2 Main supply and earth connection
Power supply terminals (C.):
230 Vac Wiring Centre version 24 Vac Wiring Centre version
B
C
230 V
LNPE
C
230 V
LNPE
230 - 24 Vac
60 VA
24V~
L: Live 230 Vac 50/60 Hz
N: Neutral
Connect the earth wire to the earth connector (B.)
L: Live 24 Vac
N: Neutral 24 Vac


Unisenza - Wiring Centre
Installation and user manual
EN 7.3 Pump terminals
Power supply terminals for the pump (D.):
One Pump < 100 W
230 Vac Wiring Centre version 24 Vac Wiring Centre version
B
D
D
24V~
230 V
LNPE
L: Live 230 Vac 50/60 Hz
N: Neutral
L: Live 24 Vac
N: Neutral 24 Vac
Connect the earth wire to the earth connector (B.)
One Pump > 100 W
230 Vac Wiring Centre version 24 Vac Wiring Centre version
230 V
LNPE
D
230 V
LNPE
D
24V~
Live, Neutral and Earth supply (230 Vac 50/60 Hz) external from the wiring centre.
Use a suitable relay and connect it as shown in the example according to the version of the wiring center.
