1. INTRODUCTION
1.1 About the clock
Nixie clock type ‘Frank 3’ is a compact design with all components and
tubes mounted on a single PCB. The efficient use of board space is
achieved by using a multiplex design to drive the display tubes. Only a
single high-voltage binary-to-decimal decoder IC (74141) is required,
and each tube is switched on in sequence very quickly to give the illusion
that all the tubes are actually lit.
The larger tubes for hours and minutes are type IN-12 with a digit height
of 18mm. The smaller tubes for the seconds are type IN-17 with a digit
height of 9mm. These tubes are Russian in origin and were produced
during the 1980’s, when the technology was at it’s most advanced. It is
expected that the tubes will last for very many years and should not need
replacing.
The optional wooden case and hardware pack (rear cover, screws),
supplied rough-machined, can be finished to give a very attractive clock
for everyday living spaces. The quality of the final finish will reflect the
time and care that is taken to finish the wood with successively finer
grades of sandpaper. Alternatively, you may wish to design your own
enclosure for the clock.
1.2 Clock Features
Nixie clock type ‘Frank 3’ has the following features:
- Hours, Minutes and Seconds display
- 12 or 24 hour modes
- Date display in either DD.MM.YY or MM.DD.YY format
- Alarm, with programmable snooze period
- Programmable date display each minute
- Attractive ED tube lighting
- Uses a Quartz Crystal Oscillator as the timebase
- Optional DCF/WWVB/ MSF/GPS synchronisation with status ED
- Supercapacitor backup. Keeps time during short power outages
- Simple time setting using two buttons
- Programmable leading zero blanking
- Five programmable neon colon settings (Flashing AM/PM indication,
illuminated AM/PM indication, both flashing, both on, both off)
- Seconds can be reset to zero to precisely the set time
- Programmable night mode - blanked or dimmed display to save tubes
or prevent sleep disturbance
- Separate modes for colon neons during night mode
- Standard or fading change of digits
- ‘Slot Machine’ Cathode poisoning prevention routine
- All user preferences stored to non-volatile memory

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
4
-
1.3 SAFETY
DANGER: The clock pcb includes a switched-mode voltage booster
circuit. This generates nominally 170 Volts DC, but is capable of
generating up to 300 Volts before adjustment. Assembly may only be
undertaken by individuals who are suitably qualified and experienced in
electronics assembly, and are familiar with safe procedures for working
with high voltages. If in doubt, refer to a suitably qualified engineer
before proceeding.
The voltages generated b this circuit can give a potentiall
LETHAL ELECTRIC SHOCK.
DISC AIMER: This product is supplied as a kit of parts, intended only for
suitably qualified electronic engineers, who are suitably qualified and
experienced in electronics assembly, and are familiar with safe
procedures for working with high voltages. The supplier, his agents or
associates accept no liability for any damage, injury or death arising from
the use of this kit of parts.
This is not a finished product, and the person assembling the kit is
responsible for ensuring that the finished product complies with any
applicable local regulations governing electrical equipment, eg. U , CE,
VDE.

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
5
-
2. TOOLS AND EQUIPMENT REQUIRED
2.1 Tools required to assemble the PCB
The following tools will be required to assemble the PCB:
- Soldering iron with a small tip (1-2 mm)
- Wire cutters (TIP: A small pair of nail clippers works very well for this
function)
- Wire strippers (TIP: A small pair of scissors is quite suitable)
- Multimeter
- Small flat screwdriver for adjusting the high voltage supply
2.2 Materials ou will need
Solder – lead / tin solder is preferred. ead free solder, as now required
to be used in commercial products in Europe, has a much higher melting
point and can be very hard to work with.
Desoldering wick (braid) can be useful if you accidentally create solder
bridges between adjacent solder joints.
2.3 Other items ou will need
The clock kit does not include a power adapter. This is because the kit is
sold to many countries around the world, each with very different
household mains outlet socket types. It is more efficient for the user to
buy a suitable adapter locally. This saves shipping a heavy adapter with
the kit, and also the extra costs of managing stocks of many varied
power adapters. If you are using a WWVB, DCF or MSF receiver avoid
cheap Chinese switching power supplies, as they can cause interference
problems.
The type of power adapter can be obtained at very low cost. The
following type of adapter should be obtained and used with the kit:
Output 12V DC
Minimum power output capability of 250 mA
Output plug: 2.1mm pin, centre positive.

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
6
-
3. LIST OF COMPONENTS
3.1 Table of components
Circuit Designation Part Description
Resistors
R1 390K, ¼ Watt
R2 4K3, ¼ Watt
R3 100R, ¼ Watt
R4 4K3, ¼ Watt
R5 – R7 560R, ¼ Watt
R8 - R10 10K, ¼ Watt
R11 560R, ¼ Watt
R12, R13 10K, ¼ Watt
R14 - R17 2K7, ¼ Watt
R18, R19 5K6, ¼ Watt
R20 – R25 390K, ¼ Watt
R26 – R33 10K, ¼ Watt
R34, R35 390K, ¼ Watt
R36 – R41 560R, ¼ Watt
Capacitors
C1 470uF, 16-25V, Electrolytic
C2 100uF, 16-25V, Electrolytic
C3 1uF, 250V, Electrolytic
C4 33pF Ceramic
C5 33pF Ceramic
C6 0.1F
C7 100nF Ceramic
Transistors
Q1 IRF730 or IRF630 MOSFET
Q2, Q3 MPSA42 NPN
Q4 – Q9 MPSA92 PNP
Q10 – Q18 MPSA42 NPN
Diodes
D1 – D3 1N5817 or 1N5819
D4 UF4004
D5 Not installed
D6 – D8 1N4148
D9 5mm Green ED
D10 5mm Orange ED
D11 – D16 3mm Blue ED
Integrated Circuits
IC1 7805 5V voltage regulator
IC2 PIC16F1936 8-bit microcontroller
IC3 74141 / K155N Nixie driver
Miscellaneous
1 100uH – 220uH inductor
NE1, NE2 4mm wire ended neon lamp
SW1, SW2, SW3 Miniature vertical push button
VR1 1K Potentiometer
IC Socket 28 Way IC socket for IC2

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
7
-
J1 2.1mm Chassis power socket
GPS / RFT 6 way mini DIN PCB socket
S1 Piezo sounder
FUSE 500mA fuse
SKT1-44 1mm PCB Sockets
Insulation Clear insulation for neons
X1 32.768KHz watch crystal

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
8
-
3.2 Parts list / Packing sheet
Part Description Quantit
Resistors
100R, ¼ Watt 1
560R, ¼ Watt 10
2K7, ¼ Watt 4
4K3, ¼ Watt 2
5K6, ¼ Watt 2
10K, ¼ Watt 13
390K, ¼ Watt 9
Capacitors
470uF, 16-25V, Electrolytic 1
100uF, 16-25V, Electrolytic 1
1uF, 250V, Electrolytic 1
100nF, Ceramic 1
33pF, Ceramic 2
0.1F 1
Transistors
IRF730 or IRF630 MOSFET 1
MPSA92 PNP 6
MPSA42 NPN 11
Diodes
1N581x 3
UF4004 fast recovery diode 1
1N4148 3
5mm Green ED 1
5mm Orange ED 1
3mm Blue ED 6
Integrated Circuits
7805 5V voltage regulator 1
PIC16Fxxxx 8-bit microcontroller 1
74141 / K155N Nixie driver 1
Miscellaneous
100uH – 470uH inductor 1
4mm wire ended neon lamp 2
Miniature vertical push button 3
1K potentiometer 1
28 way IC Socket for IC2 1
2.1mm Chassis power socket 1
6 way mini DIN PCB socket 1
Piezo sounder 1
500mA fuse 1
6 cm clear insulation 1
32.768KHz watch crystal 1
It is recommended that the kit is checked against the list above, to
ensure all parts are present before commencing assembly. Don’t be
alarmed if there are some extra components, as some component
bags are shared between different kit types.

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
9
-
The resistors used in the kit are 1% tolerance metal film. They are
marked with 4 coloured bands to identify the value. However it is
sometimes unclear in which direction the bands should be read.
Therefore, we recommend that the resistors be identified with a
multimeter.
The fuse component may be one of two types, so may not look like
the fuse in the pictures later in this guide. From August 2011, the
fuse will look like the picture below:

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
10
-
4. ASSEMBLY OF THE PCB
4.1 1mm Sockets For Nixie Tubes
There are 44 individual sockets that need to be soldered in. The
best method is a follows. Place all sockets into the holes, noting
that for each tube there is one hole that has no socket as show
below. When all sockets have been placed, place a flat and hard
object over the top of the sockets, and turn the PCB over so you
can solder from the underside. Be sure to insert the sockets FROM
the component side of the PCB – the side with the white
component markings. The photo below shows the component side
of the PCB after all the sockets have been inserted and soldered in.
4.2 Capacitor C7
Mount C7 on the same side of the PCB as the white cross-hatched
markings for Q1 and IC1. See below.
Clip the leads on the main component side very short, as the IC
socket for IC2 will need to fit over the trimmed leads.

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
11
-
4.3 Low Voltage Power components:
J1, FUSE, D1-D3, IC1, C1, C2
Start by installing D1-D3. Align the white band on the components
with the band marked on the PCB.
Continue to mount C1, C2, J1 and FUSE Note that C1 and C2 are
polarised. The longer lead goes in the hole marked (+). J1, the DC
power input connector and IC1 are mounted on the opposite side of
the PCB to the other components in this step.
See the picture below. IC1 is mounted vertically at this stage - do
not bend it over the marked area yet.

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
12
-
4.4 Testing Stage 1 Power Components.
Identify the test GND, 5V and 170V test points as shown below.
Plug in the power supply, and then test using a DC voltmeter or a
multimeter on DC setting: Touch the black probe on the GND test
point and the red probe on the 5V test point. The voltage should
measure between 5.1 and 5.3 Volts. If not, disconnect power and
check your work. Do not proceed with the assembly until the error
is corrected. Once the test is completed, disconnect the power.
4.4 High Voltage Generator components.
R1, R2, R3, R4, R9, R10,
Q1, D4, C3, VR1, L1, Socket for IC2
Pay attention to mount D4 with the white band aligned with the
PCB marking. Insert the 28 way IC socket into the PCB at the IC2
position, ensuring that the notch at one end is aligned with the
corresponding marking on the PCB.

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
13
-
Resistors R1-R4, R9 and R10, indeed all the resistors on the board
need to be mounted upright to save space. The leads need to be
formed as shown below. Bend the leads of each resistor as shown
and solder in to the correct postion, making sure the component
body is as close to the board as possible.
After installation of step 4.4 components, this is how the PCB
should look on the component side:
And this is the view on the ‘solder side’ – note that Q1 is mounted
on this side.

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
14
-
4.5 High Voltage Generator Test.
- Refer to the warnings on page 4
- Insert IC2 into its socket. Orient the notch on the IC with the
notch on the IC socket and the PCB marking.
- Power up the PCB, and using the GND and 170V test points,
measure the high voltage generated using a multimeter or
voltmeter on DC setting.. It should be initially between 150 and
190V. Using the VR1 brass screw, slowly adjust the screw until the
voltage is between 170 and 175V. Disconnect the power supply.
- Finally, remove IC2 from its socket and replace on its static-
protective foam. It is best kept safe until needed for the tube tests
later in the assembly.
4.6 C4, C5, X1.
These are the timekeeping components: 32.768KHz crystal and
two load capacitors. See below:
4.7 D6 - D8, C6.
C6 is a high capacity ‘Super Capacitor’, intended to keep the
processor powered for short periods in the event of a main power
failure. It is vital that it is placed in the correct orientation. See
below. There are arrows on the component that need to be
pointing the same way as the arrows on the PCB.

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
15
-
4.8 IC3 – 74141 / K155N Nixie Driver IC.
Align the notch on the IC body with the corresponding PCB mark.
See below:
4.9 Q2, Q3, Q10 – Q18 (All MPSA42)
After placement of these 11 transistors, the board should look like
this:
4.10 Q4 – Q9 (All MPSA92)
See below:

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
16
-
4.11 R14 – R17 (2K7)
R18, R19 (5K6)
R20 – R25 (390K)
R26 – R31 (10K)
See picture below:
4.12 R12, R13, R32, R33 (10K)
R34, R35 (390K)
R8 (10K), R5, R6, R7, R11 (560R)
See picture below:

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
17
-
4.13 R36 – R41 (560R)
These are the current-limiting resistors for the ED tube
underlights. If you don’t want to have ED tube underlighting you
can omit this step. Note that you can also now bend back Q1 and
IC1 as shown below:

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
18
-
4.14 IN-17 Nixie tubes NX5, NX6
To facilitate easy insertion of the flying leads into the small holes, it
helps enormously to trim the flying leads at an angle with a pair of
scissors as shown below
Feed all the wires in progressively. It is not as hard as it seems at
first. Ensure the tubes are the correct way up. The part marking
IN-17 should be to the RIGHT, but also check to see if you can tell
that the 5 and 3, which are visible, are the correct way up. After
soldering in, trim flying leads.

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
19
-
4.15 SET, ADJ, ALARM
Push buttons SET, ADJ and A ARM are mounted on the solder side
of the PCB, so that the clock is adjusted from the back. You can
choose to mount them on the front face if you wish, depending on
your own particular clock case design.
4.16 NE1, NE2
The 2 neons can now be mounted at a suitable height. Use small
lengths of the clear insulation supplied on the leads to prevent
shorts.
4.17 RFT/GPS LED D9 (Green)
ALARM LED D10 (Orange)
These should be mounted on the solder side of the PCB if you are
using one of our cases. Otherwise they can be mounted as you
prefer. The longer leads go into the holes maked (+)
4.18 RFT / GPS Connector.
If you will not be using a time synchronisation source, you may
omit this connector. Also, if you are connecting a time receiver
module close to the clock PCB without using the connector you
may omit this connector.
The connector is mounted on the solder side of the PCB:
The connector is a tight fit into its holes, It may be necessary to
place the PCB on a flat surface and push the connector into place
with your thumb. Then solder the 6 pins and the 2 guide pins.

Nixie Tube Clock ‘Frank 3’
Issue 5 (1 Jan 2012)
www.pvelectronics.co.uk
-
20
-
4.19 LS1 – Piezo Sounder.
There are two sets of holes for this component, as two different
types may be supplied depending on component availability.
If you are using one of our cases, mount this on the solder side of
the PCB.
