PVI MTRX User manual

Digital Tuner Streamer
This Manual Apply to the MTRX 4/8 Tuner To IPTV Systems
On 8 Tuners Systems, The inputs are all assigned to the 8 Tuners Only and no asi
Web-NMS Version: 1.03
Software: 1.00
Hardware: 0.40

4 in 1 IRD User’s Manual
DIRECTORY
Chapter 1 Product Outline ............................................................................1
1.1 Outline ....................................................................................................................1
1.2 Features..................................................................................................................1
1.3 Specifications .........................................................................................................2
1.4 Principle Chart........................................................................................................4
1.5 Appearance and description...................................................................................4
Chapter 2 Installation Guide .........................................................................6
2.1 Acquisition Check...................................................................................................6
2.2 Installation Preparation...........................................................................................6
2.3 Wire’s Connection ..................................................................................................8
2.4 Signal Cable Connection........................................................................................9
Chapter 3 Operation ....................................................................................11
3.1 LCD Menu Class Tree..........................................................................................11
3.2 General Setting.....................................................................................................14
Chapter 4 Web-based NMS Management ..................................................23
4.1 login......................................................................................................................23
4.2 Operation..............................................................................................................24
Chapter 5 Troubleshooting...............................Error! Bookmark not defined.
Chapter 6 Packing List ......................................Error! Bookmark not defined.

1 / 38
Chapter 1 Product Outline
1.1 Outline
MTRX IRD is PVI’s new design which integrates demodulation (DVB-C, T/T2, S/S2
optional), de-scrambler and multiplexing in one case to convert RFsignals into TS output.
It is a 1-U case which supports 4 tuner inputs, 1 ASI and 4 IP inputs. The 4 CAMs/CIs
accompanied can descramble the programs input from encrypted RF, ASI and IP. The
CAM requires NO unsightly external power cords, cables, or additional remote control
device.
To meet customers’ various requirements, MTRX is also designed to de-mux programs
from any input, and output TS over 48 SPTS.
1.2 Features
4 Tuner inputs (DVB-C, T/T2, S/S2 Optional)
1 ASI & 4 IP (UDP) input for de-mux
One CAM can decrypt multiple programs from Tuners/ASI/IP
IP (48 SPTS) over UDP and RTP/RTSP output;
4 groups of independent ASI out for tuner/IP passthrough (one-to-one)
Support maximum 128 PID mapping per input
LCD display, Remote control and Firmware, web NMS management
Updates via web
Best quality and breakthrough price

2 / 38
1.3 Specifications

4-in-1 IRD User’s Manual
3 / 38
Input
4x RF (DVB-C, T/T2, S/S2 optional), F type
1×ASI input for de-mux, BNC interface
4xIP input for de-mux (UDP)
Tuner Section
DVB-C
Standard
J.83A(DVB-C), J.83B,
J.83C
Input Frequency
47 MHz~860 MHz
Constellation
16/32/64/128/256 QAM
DVB-T/T2
Input Frequency
44MHz ~1002 MHz
Bandwidth
6/7/8 M
DVB-S
Input Frequency
950-2150MHz
Symbol rate
2-45Msps
Signal Strength
- 65- -25dBm
Constellation
1/2, 2/3, 3/4, 5/6, 7/8
QPSK
DVB-S2
Input
Frequency
950-2150MHz
Symbol rate
QPSK 1~45Mbauds;
8PSK 2~30Mbauds
Code rate
1/2, 3/5, 2/3, 3/4, 4/5, 5/6,
8/9, 9/10
Constellation
QPSK, 8PSK
Output
IP
48*SPTS over UDP, RTP/RTSP.
1000M Base-T Ethernet interface
(unicast / multicast)
ASI
4 groups BNC interface
System
Local interface
LCD + control buttons
Remote
management
Web NMS Management
Language
English
General
Power supply
AC 100V~240V
Dimensions
482*400*44.5mm
Weight
3 kgs
Operation
temperature
0~45℃

4-in-1 IRD User’s Manual
4 / 38
1.4 Principle Chart
IP (48 SPTS) Out
ASI Out 4
4 x CAM/CI
ASI Out 1
ASI Out 2
ASI Out 3
MUX
SAT RF 1
IP 1
SAT RF 2
IP 2
SAT RF 3
IP 3
SAT RF 4
IP 4
ASI
choose 4 channels from all inputs to descramble
CI 1 & 2 are designed to descramble tuner 1/2, ASI or IP 1-4.
CI 3 & 4 are designed to descramble tuner 3/4, ASI or IP 1-4.
1.5 Appearance and description
1
LCD Display
2
Indicators Area (Lock 1-4: they light up when the tuner signal
are properly connected. Descram 1-4: they light up when the
CI cards are properly inserted.
3
Up/Down/Left/Right Buttons
Enter Key for confirmation
Menu Key for backward
Lock Key
Rear Panel Illustration

4-in-1 IRD User’s Manual
5 / 38
1
CAM/CI Slots 1 & 2 (Applied to descramble tuner 1 & 2, ASI input
and IP input 1 to 4)
2
Tuner Input 1 & 2
3
CAM/CI Slots 3 & 4 (Applied to descramble tuner 3 & 4, ASI input
and IP input 1 to 4)
4
Tuner Input 3 & 4
5
ASI output groups 1-4
6
ASI input port for de-mux
7
NMS Port (connect to PC for device management)
8
DATA Port (for IP stream input & output, 1000M)
9
Power switch/Fuse/Socket/Grounding Wire

4-in-1 IRD User’s Manual
6 / 38
Chapter 2 Installation Guide
2.1 Acquisition Check
When user opens the package of the device, it is necessary to check items according
to packing list. Normally it should include the following items:
MTRX 4-in-1 IRD 1pcs
Power Cord 1pcs
If any item ismissing or mismatching with the list above, please contact our company.
2.2 Installation Preparation
When users install device, please follow the below steps. The details of installation
will be described at the rest part of this chapter. Users can also refer rear panel chart
during the installation.
The main content of this chapter including:
Checking the possible device missing or damage during the transportation
Preparing relevant environment for installation
Installing modulator
Connecting signal cables
Connecting communication port (if it is necessary)
2.2.1 Device's Installation Flow Chart Illustrated as following：
Connecting
Grouding
Wire and
Power
Cord
Acquisition
Check Fixing Device Setting Parameter Running Device
Connecting
Signal Wire
2.2.2 Environment Requirement

4-in-1 IRD User’s Manual
7 / 38
Item
Requirement
Machine Hall Space
When user installs machine frame array in one
machine hall, the distance between 2 rows of machine
frames should be 1.2~1.5m and the distance against
wall should be no less than 0.8m.
Machine Hall Floor
Electric Isolation, Dust Free
Volume resistivity of ground anti-static material:
1X107~1X1010，Grounding current limiting
resistance: 1M (Floor bearing should be greater than
450Kg/㎡)
Environment
Temperature
5~40℃(sustainable )，0~45℃(short time)，
installing air-conditioning is recommended
Relative Humidity
20%~80% sustainable 10%~90% short time
Pressure
86~105KPa
Door & Window
Installing rubber strip for sealing door-gaps and dual
level glasses for window
Wall
It can be covered with wallpaper, or brightness less
paint.
Fire Protection
Fire alarm system and extinguisher
Power
Requiring device power, air-conditioning power and
lighting power are independent to each other. Device
power requires AC power 100-240V 50-60Hz. Please
carefully check before running.
2.2.3 Grounding Requirement
All function modules’ good grounding is the basis of reliability and stability of
devices. Also, they are the most important guarantee of lightning arresting and
interference rejection. Therefore, the system must follow this rule.
Coaxial cables outer conductor and isolation layer should keep proper electric
conducting with the metal housing of device.

4-in-1 IRD User’s Manual
8 / 38
Grounding conductor must adopt copper conductor in order to reduce high
frequency impedance, and the grounding wire must be as thick and short as
possible.
Users should make sure the 2 ends of grounding wire well electric conducted and
be antirust.
It is prohibited to use any other device as part of grounding electric circuit
The area of the conduction between grounding wire and device’s frame should
be no less than 25mm2.
2.2.4 Frame Grounding
All the machine frames should be connected with protective copper strip. The
grounding wire should be as short as possible and avoid circling. The area of the
conduction between grounding wire and grounding strip should be no less than
25mm2.
2.2.5 Device Grounding
Connecting the device’s grounding rod to frame’s grounding pole with copper wire.
2.3 Wire’s Connection
The grounding wire conductive screw is located at the right end of rear panel, and the
power switch, fuse, power supply socket is just beside ,whose order goes like this,
power switch is on the left ,power supply socket is on the right and the fuse is just
between them.
Connecting Power Cord
User can insert one end into power supply socket, while insert the other end to
AC power.
Connecting Grounding Wire
When the device solely connects to protective ground, it should adopt
independent way, say, share the same ground with other devices. When the
device adopts united way, the grounding resistance should be smaller than 1Ω.
Caution:
Before connecting power cord to MTRX IRD, user should set the power switch

4-in-1 IRD User’s Manual
9 / 38
to “OFF”.
2.4 Signal Cable Connection
The signal connections include the connection of input signal cable and the
connection of output signal cable. The details are as follows:
2.4.1 MTRX 4-in-1 IRD Cables Illustration:
IP Input/output Cable Illustration:
Tuner Cable Illustration:
ASI Input/output Cable Illustration:

4-in-1 IRD User’s Manual
10 / 38

4-in-1 IRD User’s Manual
11 / 38
Chapter 3 Operation
The front panel of MTRX 4-in-1 IRD is the user-operating interface and the equipment
can be conveniently operated and managed according to the procedures displayed
on the LCD:
Keyboard Function Description:
LEFT/RIGHT: Choose and set the parameters.
UP/DOWN: Modify activated parameter or paging up/down when parameter is
inactivated.
ENTER: Activate the parameters which need modifications, or confirm the change
after modification.
MENU: Cancel current entered value, resume previous setting; Return to previous
menu.
LOCK: Lock the screen/cancel the lock state. After pressing the lock key, the LCD
will display the current configuring state.
3.1 LCD Menu Structure
(See next page :)

4-in-1 IRD User’s Manual
12 / 38
Initializing
4 in 1 IRD
Bitrate: 70.865Mbps
1 Status Alarm
Uptime
2 Input Sets 2.1 Tuner DVBS/S2
2.4 Tuner DVBS/S2
3 CI Card 3.1 Card A
3.2 Card B
Tuner Parameters
Mux Program
Satellite frequency
LNB frequency
Symbol rate
LNB voltage
22K
Signal Lock
TS Lock
Parse Program
Select Program
3.1.1 Max Birate
3.1.2 Input TS Mode
3.1.3Card Error Check
3.1.4 Parse Program
3.1.5 Descramble Program
3.1.6 Rom Version
3.1.7 Card Status
3.1.8 Descramble Error
(Same content with ‘ Tuner 1 ’ above)
(Same content with ‘ Card A ’ above)
Input IP
Input Port
Multicast
IGMP Snooping
Service IP
2.5: ASI 2.5.1 TS Lock
2.5.2 Parse Program
2.5.3 Select Program
2.6 IP 2.6.1 IP Config
2.6.2 Mux Program TS Lock
Parse Program
Select Program
2.3 Tuner DVBS/S2
2.2 Tuner DVBS/S2
2.7 IP
2.8 IP
2.9 IP
3.3 Card C
3.4 Card D
(Same content with ‘ Card A ’ above)
(Same content with ‘ Card A ’ above)
(Same content with ‘ Tuner 1 ’ above)
(Same content with ‘ Tuner 1 ’ above)
(Same content with ‘ IP 1 ’ above)
(Same content with ‘ IP 1 ’ above)
(Same content with ‘ IP 1 ’ above)

4-in-1 IRD User’s Manual
13 / 38
7 System 7.1 Save Config
7.2 Load Saved CFG
7.3 Factory Reset
7.4 LCD Time-out
7.6 Lock Keyboard
7.7 Product ID
7.8 Language
4 TS Config
4.10 TSID
4.11 ONID
4.2 ASI 1 out select
7.5 Key Password
6 Network 6.1 NMS IP
6.2 Subnet Mask
6.3 Gateway
6.4 MAC Address
6.6 Reset Password
6.5 Web NMS Port
4.1 TS output bitrate
5 IP Stream
5.4 Output Protocol
5.5 SPTS 1
5.3 Gateway
Data Enable
Null PKT Filter
Output IP
Output Port
Bitrate
5.1 Service IP
5.2 Subnet Mask
5.6 SPTS 2
5.52 SPTS 48
(SPTS 2-48 have the
same submenus with
‘ SPTS 1 ’ above)
7.9 Version
4.3 ASI 1 out bitrate
4.4 ASI 2 out select
4.5 ASI 2 out bitrate
4.6 ASI 3 out select
4.7 ASI 3 out bitrate
4.8 ASI 4 out select
4.9 ASI 4 out bitrate

4-in-1 IRD User’s Manual
14 / 38
3.2 General Setting
Switch on the device and after a few seconds’ initialization, it presents start-up
pictures as below:
4 in 1 IRD: Device’s name
Bitrate: xx.xxx Mbps indicates the current output bitrate.
Press LOCK key on the front panel to enter the main menu. The LCD will display the
following pages where user can configure the parameters for the device:
User could do all the settings according to the 7 directions displayed on the LCD.
User can press UP/DOWN and RIGHT/LEGT buttons to specify menu item, and then
press ENTER to enter the submenus as below:
3.2.1 Status
Alarm: The alarm indicator will turn on if there is no signal inputting or outputting bit
rate overflows. User then can enter this menu to check the error type. Otherwise it
shows the ‘system is normal’.
Uptime: It displays the working time duration of the device. It times upon power on.
Start up…
Start OK…
4 in 1 IRD
Bitrate: xx.xxx Mbps
1 Status 2 Input Sets
3 CI Card 4 TS Config
Alarm
System is normal
Uptime
1 Day(s) 03:30:02
5 IP Stream 6 Network
7 System

4-in-1 IRD User’s Manual
15 / 38
3.2.2 Input Sets
MTRX supports 4 tuners input, 1 ASI input and 4 IP stream input. Users can enter
‘Input Sets’ to configure the tuner/ASI/IP parameters to receive the transport streams
and select programs to output via IP (SPTS) packages. It displays as below:
Tuner DVB-S/S2 (Submenus 2.1 – 2.4)
Press ENTER key to enter ‘2.1 Tuner DVBS/S2’ (or 2.2/2.3/2.4) to configure the
corresponding tuner input according to rear panel. It displays as below:
Tuner Parameters:
Users can enter this menu to configure the tuner parameters separately to receive
the tuner programs.
Mux Program:
Users can parse the Tuner input program list and select programs to out in this menu.
NOTE: Multiplexed programs can only be output through IP (48 SPTS).
Tuner Parameters:
Satellite frequency
LNB frequency
Symbol rate
LNB Voltage
22K
Signal Lock
For checking signal status and quality etc
18V, 13v and 0v Optional
2.1 Tuner DVBS/S2 2.2 Tuner DVBS/S2
2.3 Tuner DVBS/S2 2.4 Tuner DVBS/S2
2.5 ASI 2.6 IP
2.7 IP 2.8 IP
2.9 IP
2.1.1Tuner Para 2.1.2Mux Prog

4-in-1 IRD User’s Manual
16 / 38
ASI (Submenus 2.5)
Users can parse ASI input programs and select program(s) to outputunder this menu.
The operating method is same with what explained above.
IP (Submenus 2.6 – 2.9)
Press ENTER key to enter ‘2.6 IP’, it displays as below:
Mux Program
TS Lock
Parse Program
Select Program
TS Locked
Bitrate: 4.040 Mbps
Searching Program
Get 7 Programs
For reading the input
bitrate
For reading the number
of programs from
Tuner 1 (or 2)
Mux Program (0/7)
1: TV 1 X
‘1/7’represents there are all 7 programs in the list and 1 program has been selected to mux out through ASI.
Mux Program (0/7)
1: TV 1 [←]
Mux Program (0/7)
1: TV 1 [→]
Mux Program (1/7)
1: TV 1 √
Process of selecting programs to
output through front panel:
[←]: to cancel program output;
[→]: to output the program
“√”: a symbol indicating the
corresponding program has been
selected to output;
“X”: a symbol indicating the
corresponding program has not
been selected to output
Press ENTER key
Press RIGHT/LEFT
key to shift arrow
Press ENTER key to
confirm
2.5.1 TS Lock 2.5.2 Parse Program
2.5.3 Select Program
2.6.1 IP Config 2.6.2 Mux Program

4-in-1 IRD User’s Manual
17 / 38
IP Config:
Users can enter this menu to configure IP parameters according to the IP source to
receive the IP programs.
Mux Program:
Users can parse the IP input program list and select programs to output in this menu.
The operating method is same with what explained above.
3.2.3 CI Card
MTRX IRD supports 4 CI cards (Card A, B, C and D) to descramble encrypted
programs from RF, ASI or IP. Users can press ENTER key to enter ‘3 CI Card’ to
configure the 4 cards respectively.
Press ENTER key to enter Card A (or Card B/C/D):
Max Bit rate
CI Max Bitrate options range from 48-108Mbps. Move the triangle to select a value
as principle: Actual Input Bitrate≤ Max Bitrate≤CI Max decrypting capacity
Off, V2 and V3 Optional
Max Bitrate
►48 Mbps
Input IP
Input Port
Multicast
IGMP Snooping
Service IP
2.5.1 TS Lock 2.5.2 Parse Program
2.5.3 Select Program
3.1 Card A 3.2 Card B
3.3 Card C 3.4 Card D
3.1.1 Max Bitrate 3.1.2 Input TS Mode
3.1.3 Card Error 3.1.4 Parse Program
3.1.5 Descra Prog 3.1.6 Rom Version
3.1.7 Card Status 3.1.8 Descramble Error

4-in-1 IRD User’s Manual
18 / 38
Input TS Mode
MTRX has 9 signal sources: Tuner 1-4, ASI, and IP1-4. One CI card can applied to
descramble one channel input signal from the 9 signal sources. ‘Skip CI card’ means
to skip the card which is used for FTA stream.
NOTE: Card A & B are designed to descramble tuner 1 & 2, ASI input and IP
input 1 to 4, while card C & D A are designed to descramble tuner 3 & 4, ASI input
and IP input 1 to 4.
Card Error Check
Users can decide whether to enable or disable the card error check function in this
menu.
Parse Program
Users can read the quantity of programs parsed from the de-scrambled channel.
Descramble Program
Users can select program(s) from the searched out programs to descramble. The
quantity to be descrambled depends on the CAM/CI performance you apply to.
Input TS Mode
►Skip CI Card
Tuner 1
Tuner 2
ASI
IP 1
IP 2
IP 3
IP 4
Card Error Check
►Enable
Searching Program
Get 8 Programs
►1 CETV 1 √
2 TV 4A X
