PYLE Audio PLVW1040R User manual

10.4" Overhead TFT-LCD Monitor
PLVW1040R

1
1. Table of Contents------------------------------------------------------ 1
2. Warning ---------------------------------------------------------------- 1
3. Usage Notice ---------------------------------------------------------- 2
4. Package ---------------------------------------------------------------- 3
5. Remote Control --------------------------------------------------------3
6. User Controls --------------------------------------------------------- 4
7. Start Your Installation ------------------------------------------------ 4
8. Setting Up The Dome Lamps ---------------------------------------- 5
9. Installation Your Monitor -------------------------------------------- 6
10. Closing Monitor ----------------------------------------------------- 7
11. Operatingthe Monitor -----------------------------------------------7
12. OSD Menus in A/V Source ------------------------------------------8
13. Quick Adjustment OSD Menus -------------------------------------8
14. Function Descriptions -----------------------------------------------9
15. Specifications -------------------------------------------------------10
16. Appendix-------------------------------------------------------------11

Usage Notice
Follow all warnings, precautions and maintenance as
recommended in this user's manual to maximize the life of your
LCD monitor
To avoid the damage of the LCD monitor and risk of electronic
shock, do not permeate the LCD monitor with water or any
drink.
When this happens, turn off the power, unplug the power cord
and send the LCD monitor to your local dealer or our service
cen-ter as soon as possible.
Use a regular power specification of DC 12V . Do not use any
other power supply different from the regularity.
Do not place objects on or suspend them with the power cord.
This will make the power cord damaged.
Do not assemble or twist the power cord arbitrarily. And do not
put it together with heated object.
Do not try to repair the power cord when it is damaged or
broken, change a new one immediately.
Avoid any metal objects or inflammable dropping into the LCD
monitor from ventilation slots.
Do not attempt to open or disassemble the LCD monitor
yourself as this may cause electronic shock.
When there is smile or peculiar smell in use, unplug the power
cord immediately and send it to your local dealer or our service
center.
When there is damage or breach on the LCD monitor casing,
send it to your local dealer or our service center.
Do not use this LCD monitor in the areas susceptible to
excessive dust, dirt, and humid.
Do not setup the LCD monitor in direct sunlight, extremely hot,
and cold environment.
Do not expose the LCD monitor to rain or moisture.
2

3
Package
This LCD monitorcomes with allthe items below. Check tomake sure yourunit
complete. Contact your dealer immediately if anything is missing.
PLVW1040R
* 10.4" High RES TFT-LCD Monitor
* Overhead Console Mounting Bracket
* Credit Card Size Remote Control with Batteries
* Interface Cable with RCA jacks for Audio / Video
Connection and 12V DC
* User's Manual
Remote Control
1234
5678
90
Number Pad
POWER
MUTE
TV/AV
TV/CATV
SETUP
FM/AM
Monitor
FUNC
UP
+
MODE
DN
-
CHVOL
Power
MUTE
SETUP
Monitor
TV/CATV interchange
TV/AV
Channels convertible(CH)
Volume control buttons

User Controls
User Control Overview
* Panel Control
Start Your Installation
Wiring
* Monitor connection
4

Setting Up The Dome Lamps
*Operating the dome Lamps
1. There are three function buttons for the Dome lamps operation: OFF,
DOOR, and ON. (Refer to the following figure)
A. OFF: To turn off the lamps.
B. DOOR: To make the lamps turned on
only when car doors are
opened.
C. ON: To turn on the lamps.
* The electric circuit figure
Point Power Cord Color Connection
R
W
B
Red
White
Black
Connecting With Power Supply
Connecting With Sensor of Car Doors
For Ground Connection
* Remarks:
1. There would be no any power cord puling out from "B" point as
"B" have been connected with a ground connection by screws.
2. Power supply should be used in 12 Voltages.
W
B
OFF
DOOR
ON
LAMPS R
BATTERY +
ON
DOOR
OFF
5

Installation your Monitor
Take care to select a suitable fitting location and securing method for
the monitor:
*The unit should not distract or obstruct the driver.
*The installation should not inhibit the entry to, or the exit from the
vehicle.
*The unit should not interfere with other vehicle components e,g
(sliding sunroof).
*Make sure the unit is installed to a secure, robust mounting location
and cannot become dislodged in the event of an emergency stop.
*Do not support the unit using only the vehicle interior roof lining.
*If driving is required, take care not to penetrate through the other
sheet metal of the vehicle.
*Avoid prolonged use of the monitor when the engine is not running
to prevent draining the vehicle battery.
*Place the mounting metal plate with the nuts facing upward, then,
mount the monitor by screws included
6

Closing Monitor
1. Return the monitor to the central viewing position.
(Refer to the following figure)
2. Push the monitor/TV back into the monitor base unit until
the screen engages with the release button.
Operating the Monitor
* Powering up the monitor
The monitor will be automatically turned on when releasing the
monitor from the base unit and "OFF" when it is closed.
Operating Instructions
Opening the Monitor
1. Press the monitor release button to lower the LCD screen.
2. Lower the monitor until is fixed 90 from the monitor base
unit for viewing (Refer to the following figure.)
7

* OSD Menus in A/V Source
MAIN MENU
CUBS.1 = NTSC
H. SYNC = +15.7K Hz
V. SYNC = -60.0Hz
BRIGHTNESS
CONTRAST
COLOR
HUE
SOURCE
AUDIO
RECALL
EXIT
CONTRAST
COLOR
BRIGHTNESS
VOLUME
* Quick Adjustment OSD Menus
1. By pressing the "SELECT" button, you may open the following OSD
menus directly. Use "+" or "-" key to make adjustment.
2. Press "+" or "-" button directly to adjust speaker volume.
1
2
SOURCE
AUTO DETECT
S-VIDEO
VIDEO 1
VIDEO 2
RETURN
AUDIO
MUTE
VOLUME
RECALL
RETURN
Press the "+" key to enter the
sub-menu. Press "MENU" button
to go back to the main menu.
A. Source Selection Menu
B. Audio Input Selection Menu
8

Function Descriptions
Panel Control
* Menu: Pop up the OSD menus. Press the "Menu" button again
to exit the OSD menus. When in sub-menu, press "MENU"
again to go back to the main menu.
* Select: 1. Switch among each function items in OSD menus.
2. Make quick adjustment of "brightness" and "contrast".
* +/- Keys: 1. Press the "+/-" key to increase or decrease volume.
2. Make item selection in OSD menus to increase or
decrease parameters as well.
Remote Control
9
* Mute: Press the "Mute" button from the remote control
to still the sound of the LCD monitor.
* Volume: 1. When the OSD menu function is turned off, press
the " up/down " buttons directly from the remote
control to adjust volume.
2. Make item selection in OSD menus to increase
or decrease parametersas well.
Brightness: Adjust brightness. ( under OSD menu )
Contrast: Adjust contrast. ( under OSD menu )
Color: Adjust picture color: ( under OSD menu )
* Power: When the power switch on the side unit is pushed
to "1" position, you may also turn on or off the
monitor by this "Power" button.
* Function:

Specifications
Screen Size 10.4" diagonal
Resolution 800 (H) x 600 (V) pixels
Number of colors 262, 144 colors
Pixel pitch & Format 0.264 (H) x 0.264 (V) mm
Vertical Stripe Arrangement
Brightness 150 cd/m2
Maximum Contrast Ratio 200
Operating Temperature 0 C ~ 50 C
Storage Temperature -25 C ~ +60 C
Back light Cold cathode Filament Tube
View Angle L/R 45/45 Degrees
View Angle U/D 15/35 Degrees
Monitor Dimension 236(W) x 174.3(H) X 5.7(D) mm
Monitor Weight 1.5KG
Graphic Mode VESA standard mode ( 75Hz)
On Screen Display Supported
Power Saving mode 450mA
Power Consumption 2.25A @ DC 12V
A/V Video input CVBS, RCAx 1
Video Input level 1.0V p-p 0.5Vp-p
Video Input Impedance 75 Ohms
Audio Input Level 1.0Vp-p 0.2Vp-p
Audio Input Impedance 600 Ohms
Speaker Rating 1W x 2
10

Appendix
Changing the New Battery in Remote Control
1. Push the cassette button to wards the right. (As shown # 1 in below
figure)
2. Pull the all battery cassette away from the remote control. As shown
# 2 in below figure) Change a new battery.
Cassette Button
1
2Battery
11
