The design and manufacture of this player takes personnel
safety in to consideration. However, any improper operation may
result in electric shock, fire and other hazard. So Please adhere
tofollowingprecautions.
There is dangerous voltage inside this product, do not open the
cabinet by yourself to prevent electric shock. Any service please
contact professional technician to perform. Replacement shall
applythecomponentsrecommendedbythemanufacturer;
Safetyprecautions
Operatingprecautions
To prevent electricity leakage or damage, do not spill
liquid,alcoholintheproduct;
Do not drop anything into the product from ventilation hole of
thecabinetoranyotheropening,topreventelectricityordamage;
To power the player must be in line with the mark in the rear
panel;
When the plug of the unit is commented to the mains outlet, the
unitwillbestillconnectedtoACevenof thepoweristurnedoff.
To prevent damage caused by lightening, when you are not
goingtousethisproduct,pleaseshutoffthepower;
You should clean the cabinet with dry, soft cloth only after the
poweristurnedoff.
Place the product levelly where there is little dust and good
ventilationcondition;
Prevent the product and its supplied remote control from
moisture,heating,vibrationordirectsunlight;
Condensation caused by moisture may happen to the lens
inside the product, it will affect the play effect. In such case
please turn on the power (unload the disc) to operate it for 1~ 2
hours,vaporizethecondensationwiththehome-grownheat;
Do not turn on/off the product frequently. After you turning off
the product, please wait for about 10 seconds prior reopening it.
Donotplaythebroken,scratchedortwisteddiscs;
Pleasedonotputanythingotherthandiscsintothetray;
Whenthediscisimproperlyloaded,pleasedonot force.
Table of content
1 _ ______________
2 ______________
3 ________
__
5 _____________
6 _______________
DVD features
Names of parts
Preparation before operation
Frequent operations
System setting
2.1 Frontal panel _________________
2.2 Rear panel __________________
2.3 Remote control ________________
3.1 unpacking and check_______________
3.2 assembling batteries of remote control _______
3.3 connections ____________ ____
Play _____________________
Example 1:Set TV screen ratio mode________ __
Example 2:Set sound mix output mode _______ __
4 ____________ __Basic operations
Mute ______________________
Stop playing ___________________
The use of REMOTE SENSOR___________
Select content to be played with menu _______ _
Play fast forward _________________
Play fast backward ________________
Slow play _____________________
Skip to next chapter/track_____________ _
Skip to previous chapter/track ____________
Select track ___________________ _
Display track List ________________ _
Repeat play_________________
Select Subtitle language _____________ _
Program play ________________ __
Display playing time and state____________
MP3 operations __________________
Example 3:Coaxial output ______________
Example 4:Set age control grade _______ _____
Example 6:Set operation indication or menu display language_
2
2
2
3
4
4
4
5
8
8
9
9
10
10
10
11
11
11
11
11
11
12
12
12
13
13
15
15
16
17
18
18
9
Important Precautions
1

DVD features
1. DVD features
7 ____
8 ______________
9 ______________
10 _______ ________
Functions of buttons in remote contro
Technical terms
Troubleshooting
Specification
l
1
Table of content
20
24
24
25
It provides this multi-media disc player high-resolution image
with, high-quality sound and surround sound effect. The DVD
player can play not only DVD discs of various versions, but
alsoVCD,SUPER-VCD,DVCD,CD,MP3,etc.
1. It is compatible to DVD, VCD, SUPER-VCD, DVCD,CD,
MP3,etc.
2. Multi languageonscreenmenu.
3. High quality image with over 500 lines horizontal
pesolution.
1. Dtsdigitaloutput,provideshigh-fidelitystereointerface.
3. Multi-angle. The user can select different angle at their
optiontowatch,e.g.closerangle,full view, etc.
4. Multi-image ratio. multi-image ratio mode enables the
product tomatchdifferent typesofTVscreen.
Features
Other features
2. Multi-language support. DVD supports up to 32-
languagecaptionand8-languagedub.

3
Names of parts Names of parts
2.3 Remote control
2
2.2 Rear panel
2. Names of parts
1.COAXIAL
2.S-VIDEO
3.VIDEO
4.AUDIO L
5.AUDIO R
6.REMOTE
SENSOR INPUT
7.DC 12V IN
8.12V REMOTE
OUT
9.ANT IN
1.MENU PBC
2.POWER
3.NUMBER
4.SUBTITLE
5.DISPLAY
6.AUDIO
7.ANGLE
8.SETUP
9.ENTER/SELECT
10.DIRECTION KEYS
11.DVD GAME
12.VOLUME
13.TITLE
14.EJECT
15.CLEAR
16.SLOW
17.PROGRAM
18. MUTE
20.ZOOM
24.BACKWARD
25.NEXT
26.PREVIOUS
19.REPEAT
21.PLAY PAUSE
22.STOP
23.FORWARD
1
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
22
21
23
24
25
26
2
1
2 3 4 568 9
10
2.1 Front panel
1.POWER
ON/OFF
2.DISK TRAY
3.OPEN/CLOSE
4.LCD DISPLAY
5.PAUSE/PLAY
6.PHONE
7.STOP
8.AUDIO R
9.AUDIO L
10.VIDEO
11.MENU
12.PREVIOUS
13.NEXT
14.DIRECTION
KEYS
1
2
7 5
3
6
4
8
9
10
11 12 13
14

4
Preparation before operation
3. Preparation before operation
3.1 Unpacking and check
Check for the following Accessories:
S-videoterminal
Plug one end of S-video cable into S-VIDEO socket in back panel
of the product, the other end into TV S-VIDEO socket, then
connect audio cable to TV (notes:do not connect video cable) .
Seediagramblow.
3.3Connections
The video signal is output through s-video or video output
terminal, while audio signal is output by mixing channel terminal,
coaxial terminal, dts signal is only output through or coaxial
terminal. There are many solutions to connect TV and this
product, user can select one according to the condition of the
apparatus to be connected. However, be aware to shut off all
powerpriorconnection.
Names of parts
3.2Assembling batteries of remote control
Open battery compartment , Insert two 7#A batteries, make sure
to match "+" and "-" of the batteries to the marks in the battery
compartment. While operating remote control, please point it to
thefrontalpaneloftheDVDplayer.
Remote control 1
choke 1
Hanger 2
Screw
Battery 2
Audio/Video cord
Owner's manual 1
Remote sensor
5
-
-
-
DVDPlayer
DVD+TV
DVD player+TV
TV
TV
WHITE RED
YELLOW
LRVIDEOS-VIDEO
WHITE RED
LRVIDEOS-VIDEO

Note:
It is recomended to connect
to+12V ignitionsource.
67
Preparation before operation Preparation before operation
DVD+AMPDVD+AC
Power connection drawing while operating in room
Connect AC adapter to +12V input
DVD+CHOKE
Power connection for automotive application
DVD WITH TV TUNER + ANTENNA (THIS CONNECTED
ONLY USE IN DVD WITH TV TUNER MODEL)
AMP
WHITE RED
YELLOW
LRVIDEOS-VIDEO
-110V 60Hz
ADAPTOR
CAR DC12V
+12V
Ground
+RED
-BLACK
CHOKE
ANT

89
Mute
Stopplaying EJECT
(available to analog audio output
Signalonly)
Push [MUTE] to silence the sound of the
player, press it again to return to normal
state.
1.Push[EJECT]
2.Push[EJECT]toclosethetray
3.Press[POWER]toturnoffthe player.
unload the disc until the tray is
ejected. After stopping playing, unload
thediscuntilthetrayisejected.
Then turn off power of all connected
equipment.
The use of REMOTE SENSOR
If you want to put the DVD player in
where you can not see, please insert
REMOTE SENSOR in the REMOTE
SENSOR INPUT, and put REMOTE
SENSOR on where you can see in
automobile, you can control the DVD
player so long as let REMOTE
CONTROLtowardREMOTESENSOR.
4. Basic operation
Basic operation Basic operation
Ifyouhaveconnectedtheproductto TV,
all power lines have been plugged into
receptacles, and loaded the batteries
into remote control, so you can play the
player.
Turnon TV power
Play
1.Push[POWER]intheplayer.
2. Push open/close eject player or [
EJECT] buttons on the remote control
tothetray.
3.Push[ ] PLAY/PAUSE
If you have connected amplifier, you
should also turn it on, and select proper
amplifier mode according to the type of
discstobeplayed.
Control TV remote control to shift TV
topropervideoinputmode(VIDEOIN).
Load a disc in the tray, with label side
upward (see following figure), place
singlediscinthetray,
The player will close the tray
automatically and begin to read it, It can
identify different disc format then
display it on the screen of DVD frontal
panel, afterwards if automatically plays
disc, If directory or menu picture disply
in the screen, you can push the
direction buttons [UP], [DOWN],[LEFT]
and [RIGHT] buttons in the remote
control to move lighting band to desired
track, You can directly push number
buttonstoselecttrack.
While playing push [ ] to pause the
playback, push [ ] again to resume
play
Attention:
Whileplayingifyoufindthe
picture is not shown in full
screenorsomeparthiddenor
black and white image
occur,youneed to the system,
pleaseselect right TV system
(PAL or NTSC), Please refer
to instructions of [SYSTEM]
IN CHAPTER 6 or examples
inchapter6.
When the symbol
shows in TV screen, it
signifies invalid operation or
your operation is not
acceptedbytheplayer.
REMOTE
SENSOR

10 11
Playfast backward
Slowplay
While playing you can push [FB] button to play fast backward.
Four speed are available to play forward, press it once the speed
grows by one shift, when the speed reaches maximum speed,
press[FB]againto return to normal state.
While playing push [SLOW] to play slowly at different speed. You
can play slow forward or backward, three shift speed are
available for either of them. Push [SLOW] once, press it once the
speeddecreasesbyone shift, finally it returns to normal state.
Skipto next chapter/track
Skipto previous chapter/track
Select track
Display the track list
Whileplayingpush[NEXT] button.
Whileplayingpush[PREV] button.
Therearemorethan one operation procedure available
A.Push [NEXT] or [PREV] to skip to the next or the previous
trackandplay.
B.For those discs with track numbered directly push number
buttons to enter the No. of desired track to play. If the moment
the screen displays , so there may be three possible
reasons:(1) the track in the disc is not numbered; (2) the
number entered beyond the scope; (3) PBC is on (push [PBC] to
shiftPBCstate);
C.Selectamongthesong track list (refer to the next chapter).
For DVD discs, when PBC is on, push [MENU] to display the tradk
list, the moment firstly push [UP], [DOWN] to select a track then
push[ENTER]toplay,
For non-DVD discs, when PBC is on, while playing push
[RESUME] to display the track list, the moment you can directly
enterNo.toselect.
!
We will introduce some regular
operations of different types of function,
the user can perform one or more
operations as you like, In addition
chapter 7details purposes and
operationsofall buttons
If DVD disc to be played has menu, when
PBC. state is on you can display the
menu by pushing [MENU/PBC] or
[TITLE], whereon you select a popular
part to play. you can operate following
procedures
1.Push[MENU/PBC]
The screen display menu picture, the
content to be selected varies with
differentdisc.
2.Push[UP],[DOWN],[LEFT], [RIGHT]
Move the lighting band to the desired
itemorMadeby pushing these buttons
3. Push [ENTER] to confirm selecting
theitem
This moment the screen may display a
submenu. You can also push [UP],
[DOWN]. [LEFT], [RIGHT] to confirm
selecting the push [ENTER] to comfirm
theselection
While playing you can push [FF] button
to play fast forward. Four speed are
available to play forward, press it once
the speed grows by one shift, when the
speed reaches maximum speed, press
[FF]againto returnto normal state.
Select part to be played with
menu
Play fast forward
Frequent operation
5. Frequent operation
MENU PBC
ENTER
Frequent operation

Select subtitle Language
Programplay
(subject the Type
ofdisc)
(subjectto thetypeof Disc)
For DVD disc, you can push [SUBTITLE] to
select the language of caption.e.g. English.
Press it once, the screen will display
availablelanguagealternatively.
WhenPBCisoff, in the stopping state:
1.Push[PROGRAM]
The screen display following figure,
programmingoperationisavailable.
2.Push number buttons to enter the number
OfChapterortrack
Example:of the user want to firstly play track
5, then track 3,finally track 6, so you can enter
5,3,6 orderly. (You can push [CLEAR] button
toescapetheentered number).
3.Push[PLAY]
Program: P00:00
Theplayerwillplay orderly as the user Defined.
Push [DISPLAY] button, TV screen will display current play time
state, i.e.playing time, remaining time, press [DISPLAY] each
time, the screen will show a time alternatively (the time displayed
in the frontal panel accordingly changes), the content to be
displayedeachtimewill subject to the type of the disc.
Displayplaying time and state
Frequent operation Frequent operation
12 13
Mp3operation
MP3 is recently introduced disc, which is recorded with MP3
format audio program. This DVD player supports MP3 disc, you
canoperatefollowingthese procedures:
Push [EJECT] to eject tray, load MP3 disc, push [EJECT] again,
TVscreenwilldisplay following pictures
Use Direction key to move the cursor and use
Enter key or PLAY key to enter the corresponding
directory or select the corresponding file for
playing. The option list of play modes lists some
play modes. When LEFT/RIGHT key is used to
move the cursor to a certain option, UP/DOWN key
may be used to select a play mode. After the
selection is completed, LEFT/RIGHT key may be
used again to move the cursor to the directory or
file to be played. And then press PLAY key (if it is
in the directory, it is probably required to press the
key twice) to start playing the disc.
You can push [MENU/PBC] to change PBC
state.
Attention:whether the above procedures
workwillbesubject to the type of disc.
While playing you can push [REPEAT] to
selectdifferentrepeat content.
1 For DVD discs.push [REPEAT] to repeat
chapter push [REPEAT] again to repeat title,
push[REPEAT] again to exit.
2 For non-DVD discs, when PBC is off, push
[REPEAT] to repeat the track content, push
[REPEAT] again to repeat all disc, push
[REPEAT] again to exit.
Repeat play
ROOT ROOT
CAST
XTRAS
PIC
SONGS
FOLDER
0
1
4
2
3
SMART NAVI
PLAY MODE
ENTER

Push [SETUP], the screen will display system setting menu, the
moment you can push [UP], [DOWN] to move the high lighting
band to the desired item, push [ENTER] to display sub-menu. In
the sub-menu push [RIGHT] to enter inferior sub-menu. You can
push [UP], [DOWN] to move the high lighting band in all menu
pictures. Push [ENTER] your selection will be valid. Push [LEFT]
to escape the sub-menu in the right of the screen. Any time push
[SETUP]or[EXITSETUP] you will escape system setting state.
The high lighting band
indicatescurrent item
The explanation to the
current item
6. System setting
System setting
Following are some examples of frequent setting the user can
settingotheritemsfollowing their instructions.
1.Push [SETUP] to enable the screen display the system
setting picture, make sure the high lighting band has been
located in GENERAL SETUP push [ENTER], TV screen will
displayfollowing picture.
Example1:Set TV screen ratio mode
Frequent operation
14 15
Attention:
While playing, you can
push[PREVIOUS]or[NEXT]
to play the previous track or
thenextone.
While playing you can
push [STOP] to back to the
menupicture.
There are two kinds of file disc play mode:1. No-menu play mode.2.
Menu play mode. The factory default play mode of this unit is no-menu
play mode. Please refer to the description on [SETUP] setting menu for
the information on the switching of play modes.
In the first play mode, after a disc is put into the player and the player
reads the disc, the player will go into [STOP] state and display [STOP]
on DVD display panel.
At this time, you can press a numerical key to select a file and play the
disc starting with the selected file or press [PLAY] key to play the disc
starting with the first file of this disc. This file may be either an MP3 file
or [MPEG] file. When an MP3 is being played, you can press [DISPLAY]
key to view file play time.
Note:1.If you are not quite familiar with thisunitand press [PROG] key
Or select programming function through the menu when the discs
described above are played,error operations will be caused.
2. If your disc contains files of multiple formats, press [STOP] key after
the play of the disc is finished and display the picture that you can`t
usage [UP]or[DOWN ]key controled the menu.But you may press
Previous or Next key to view track numbers in the list on the right side or
directly press a numerical key to select a track to play.
After a JPEG file disc is read out, you can press PLAY key to start
playing.
GOTO GENERAL SETUP PAGE
SETUP MENU MAIN PAGE
GENERAL SETUP
SPEAKER SETUP
AUDIO SETUP
PREFERENCES
EXIT SETUP
TV DISPLAY
PIC MODE
NORMAL/PS
GENERAL PAGE
ANGLE MARX
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
NORMAL/LB
WIDE
GENERAL SETUP

Example3: Coaxial output
If the user use coaxial terminal to output audio signal, you need to
set the audio output "SPDIF/RAW' or "SPDIF/PCM", you can
operatefollowingtheseprocedures:
Push [SETUP] to enable TV screen display system setting menu
picture, please firstly enter general setting sub-menu,then
select the item "AUDIO OUTPUT" in the menu, then push
[ENTER],TVscreenwill display:
2.Push [RIGHT] to enter the sub-menu in the sub-menu in the
right screen. If you want to set the screen to "WIDE", firstly push
[DOWN] twice to move the high lighting band to "WIDE' item, then
push[ENTER],
3.Push[MAINPAGE] to exit system setting.
Notes:threescreenratiomodes,i,e,16:9WIDE,4:3PS, 4:3 L are
available for your selection to enable different discs to match TV.
the relationship between the video of disc and screen ratio mode
areasfollows:
Example2:Set sound mix output mode
1. Push [SETUP] to enable TV screen display system setting
menu picture, push [DOWN] to move the high lighting band to the
item"SPEAKERSETUP",push [ENTER], TV screen will display
2. Push [RIGHT] to enter the sub-menu in the right screen, If you
2.Push [RIGHT] to enter the sub-menu in the right screen, push
[DOWN] to move the high lighting band to the item "SPDIF/RAW"
or"SPDIF/PCM",thenpush[ENTER].
3.Push[MAINPAGE] to exit system setting.
Special indications: if you are not going to use coaxial output
audio signal, you need to set audio output to "ANALOG' output, so
there will be no audio signal to set audio output to "ANALOG"
output, so there will be no audio signal to be output in the
mixchannel.
Video of disc normal 4:3PS 4:3LB 16:9
16:9 16:9
4:3
want to set the sound mode to "STEREO", firstly push [DOWN]
once to move the high lighting band to "STEREO" item, then
push[ENTER].
3,Push[MAINPAGE] to exit system setting page.
System setting
System setting
16 17
AUDIO OUT ANALOG
AUDIO SETUP
DYNAMC RANGE COMPRESSION
SPDIF/RAW
SPDIF/PCM
OP MONO
DUAL MONO
DYNAMC
PRO LOGIC
LPCM OUTPUT
MAIN PAGE

Example4: Set age control grade
For original DVD disc, parents can prohibit the those content
inadvisable to children to be played, you can operate following
theseprocedurestoset age control grade:
1.Push[POWER]
2.Push [SETUP] to enable TV screen display system setting
menu picture, push [DOWN] till the high lighting band move to the
item "PREFERENCE", push [ENTER], then push [DOWN] till the
high lighting band move to the item "PARENTAL", TV screen will
display:
3. Push [RIGHT] to enter the sub-menu in the right of the screen, if
you want to change the age control grade to 3, push [DOWN] till
the high lighting band move to the item "3PG", the player will
indicate you to enter password, if the ex-factory password has
never been modifiied, you can push number buttons "4408" in the
remotecontrol.
4.Push [SETUP]toexitsystem setting.
1.Push [SETUP] to enable TV screen display system setting
picture, push [ENTER], push [DOWN] till the high lighting band
movetotheitem "OSD LANG", TV screen will display:
Example 5: Set Operation indication or menu display
language
2. Push [RIGHT] to enter the sub-menu in the right of the screen. If
you want to set the language of operation indication or menu
display to English, you can push "UP" or "DOWN" to move the high
lighting band to "English", then push [ENTER], the language of the
menuinthescreen will turn into English.
3.Push[MAINPAGE] to exit system setting.
System setting
System setting
18 19
3. The submenu SMART NAV in PREFERENCES item is used to set
whether there is a menu when an MP3, MPEG file disc or JPEG file disc
is played.
For other description of this menu, please refer to the User Manual
provided at an earlier time.
12Vremote out
It provides the power
of DC 12V/0.5A when
power of the product
is on. If you turn off
power of the product,
itwill have nooutput.
OUT
12V REMOTE
12V REMOTE
OUT
DC IN
12V
12V 3A +
_
TV DISPLAY
PIC MODE
ENGLISH
GENERAL PAGE
ANGLE MARX
OSD LANG
CAPTIONS
SCR SAVER
MAIN PAGE
SET OSD LANGUAGE
FRENCH
GERMAN
SPANSH
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAUL TS
SMART NAV
NO MENU
WITH MENU
PREFERENCES PAGE
SMART NAV TYPE
TV TYPE
AUDIO
SUBTITLE
DISC MENU
PARENTAL
PASSWORD
DEFAUL TS
SMART NAV NO PARENTAL
PREFERENCES PAGE
SMT PARENTAL CONTROL
2
3PG
4PG13
5
6 PG-R
7 NC-17
8 ADUL T

This chapter will detail the functions and operation procedures of
all buttons in the remote control, for users' instant reference. Most
operation procedures can be referred to relevant content of
chapter4,5.
When the DVD player is in stop, pause, slow play, fast forward,
fastreversestate,you can push [ ] to resume normal playback.
Push[ ]again,theDVDplayerwillbepause,push[ ]again,
itwillplay.
Push [TITLE] to display the title menu included in DVD disc. In the
menu picture, you can push [UP], [DOWN], [LEFT], [RIGHT] to
move the cursors to define desired item, then push [ENTER] to
selectthe part to be played (or the sub-menu, this momentyou can
also push [UP], [DOWN], [LEFT], [RIGHT] to move the cursors to
definedesireditem,then [ENTER] to play).
Whether it works depends on the type of disc, push [PROGRAM]
toenableusersto change the playing order.
Push the button once,the tray will be ejected, press it again to
close the tray. When you want to load or unload disc, you can use
thisbutton.
While playing push this button to zoom out the image, push the
button once to enlarge the image by two times, push it twice to
enlarge it by four times, press it another time to resume normal
playback.
While playing DVD, push this button to display the option menu
included in the disc (whether it works depends on the type of the
disc). Push this button to shift PBC state. For DVD/SVCD disc,
8.1[ ]
8.2[TITLE]
8.3[PROGRAM]
8.4[EJECT]
8.6[ZOOM]
8.7[MENU/PBC]
(whetherif worksdependson thetypeofdisc)
8.5[REPEAT]
Pushthisbuttonto repeat chapter,title & disc.
7. Functions of buttons in remote control
Functions of buttons in
remote control
Functions of buttons in
remote control
when PBC is off, while playing you should firstly push [STOP]
button,then[PBC]to open yet.
8.8[ ]
8.9[ANGLE]
8.10[MUTE]
8.11[ ]
8.12[ ]
8.13[SLOW]
8.14[DISPLAY]
8.15[ ]
8.16[ENTER]
()
()
whetherit worksdependon thetypeofdisc
whetherit worksdependon thetypeofdisc
While playing DVD disc, push the button to skip to next chapter;
while playing SVCD and other discs, push this button to skip to
nexttrack
while playing DVD disc with multi-angle function, push [ANGLE]
to play the video in different angles at your option. Push the button
eachtime,theplayer will be shift to a scene in another angle.
Push this button to silence the sound output through analog
channel.
Pushthisbuttontoplayfastforward silently, pressitonce,thedisc
forward atanewspeed and finally return to normal playing state.
Push this button to play fast backward silently, press it once, the
disc backward at a new speed and finally return to normal playing
state.
Push this button to play slow silently, it can be played slow forward
or backward, press it once to shift a speed and finally return to
normalplayingstate.
Push the button to display some data of time, e, g. the current
playingtime,remainingtime, etc.
While playing DVD disc, push the button to skip to previous
chapter; while playing SVCD and other discs, push this button to
skiptoprevioustrack.
Pushthebuttonto execute the entered or the selected item.
20 21

8.17[UP], [DOWN], [LEFT], [RIGHT]
8.18NUMBER BUTTONS
8.19[10+]
8.20 [CLEAR]
8.21[SETUP]
8.22[ ]
8.23[SUBTITLE]
8.24 [AUDIO]
When the screen display the menu of DVD disc or system menu,
the player is in waiting state, you can push these buttons to move
thecursorthenselect the desired item.
[0], [1].... [9] number buttons are used to enter number, e.g. No. of
track,DVDchapterNo., time data, etc.
When the No. of a track or a chapter is over 9, firstly push [10+]
thenpushrelevant number buttons. The button is used to enter the
number in decade of the No., press it each time, the number in
decadewillincreaseby 1.
When entering the programmed No., push [CLEAR] to cancel the
enterednumber.
Push the button, the screen will display system setting picture, the
user can select some relative constant parameters. The user also
can set it as needed. Detailed operation procedures please refer
tochaptersix.
While playing DVD, push the button once to pause playing, push it
twice to completely stop playing. Whether this function works
subjecttothe type of disc.
While playing VCD/SVCD and PBC being on,push [STOP], you
canreturnmenu.
Push this button to select caption indication language, e.g.
English, etc. Press it once to change a caption Language.(This
operationworksonlyfor the disc with multi subtitle encoded).
Push this key to select the language of sound on the disc, push it
once to change to another language. (This operation works only
forthediscwith multi language audio).
Functions of buttons in
remote control
Functions of buttons in
remote control
22 23
1234
5678
910+
CLEAR
8.25 [DVD/GAME]
8.26 [VOL+,VOL-]
Push [DVD/GAME] again, the unit will turn to "GAME"state,you
can watch other program or play game by LINE INPUT on front
panel.
PushVOL+toincrease volume, push VOL- to lower to volume.
NOTE:DVD WITH TV TUNER MODEL,THE [DVD/GAME]
KEYIS EXCHANGED BY [DVD/TV/GAME]
1.Push [DVD/TV/GAME] one time,the unit will turn to ``TV``
state,then push [SETUP],and choose AUTO SEARCH,push
[RIGHT] of direction key,and choose ON by direction key.
Then push [RIGHT].This time,the unit will search and
rememberTV proram automatically.
2.You can choose TV program by [UP] and [DOWN] of
directionkey.
3.You can choose TV programbynumber key.
Fox example,if you want to choose 18 CH, please push [10
]thenpush[8].
4.You can tune finely by[LEFT]and[RIGHT]of direction key.
5.Push [DVD/TV/GAME] again,the unit will turn to
``INput``state,you can watch other program or play game by
LINEINPUT on front panel.
0/10
+

TITLE:For DVD disc it is defined as a long complete segment of
image or music or a movie. Each title has a number that makes it
easytosearch.
TRACK: The image or music of a VCD or CD. Each track has a
numberforsearch.
CHAPTER:It is smaller than title among the units of a DVD, it is
defined as a long complete segment of image or music or a movie.
A title is made up of several chapters, and each chapter has a
numberforsearch.
CAPTION:The literature in TV screen bottom, generally it is
translationordialogue,also recorded in the disc.
ANGLE:For some DVD discs, they record pictures filmed from
different angles, the user can watch a same picture from different
anglesatyour option.
Check if the unit is connected securely with other systems
includingamplifierorTV;.
Makesurethedisc has been properly in the tray.
Checkwhetherthebatteries energy is sufficient.
9. Troubleshooting
Nosound
Disccan not be played
.
.Remotecontrol does not work
Twistingimage
Makesureyouoperate the TV or amplifier correctly.
Makesurethesystem setting is correct.
Checkwhetherthereis only disc in the tray.
Makesurethedisc is clean
Removebarriersfromtheremotecontrol.Replacethe batteries
withnewones.
Pointtheremotecontrol at the remote control sensor of the unit.
10. Specifications
Playable discs:
Videoformat:
Audio format:
Signaloutput:
Functionaloperation:
Output interface:
Powervoltage:
Powerconsumption:
Frequencyresponse:
Audiosignal/noise ratio:
Weight
Productdimension: (mm)
Accessories:
:
DVD/SVCD/DVCD/VCD1.0,1.1,2.0(micro laser
video/audio disc) CD - DA (common music laser
CD), MP3audiodisc,CD-R,CD-RW
MPEG1,MPEG2,PCM,DOLBY DIGITAL,DTS;
MPEG1,MPEG2,PCM, DOLBY DIGITAL,
DTS;analogstereo,
videosignal:NTSCor PAL
video:1.0Vp-p
audio:mixstereo 2Vp-p
pleaserefertochapter 7.
RCA output, high-resolution system (S-VIDEO)
output,coaxialdigitaloutput
DC9.5-24v
15W
DVD:20Hz-20KHz
90dB
1.2kg
audio/video cable, remote control (with
batteries),user'smanual,videoCABLE.
178x168x50
Checkwhetherthedisc is scratched or there is dirt whereof.
This player is controlled by micro computer,if any trouble occurs,
please turn off the power, reopen it till 10 minutes later, when there
isnotroublethemoment, you can normally operate the player.
This may caused by unstable electricity current or other abnormal
trouble,pleaseturnoff the power,reopen it till10minuteslater.
Buttondoes not work
8. Technical terms
Technical terms
Notes:
Any change to the
design and
specifications will
notbe advised.
Specifications
24 25

Howto hold disk
Whenthere are stains on the faceof disk
Don'ttouch the face carving information.
wipegenitallywitha wet cloth and then with a dry one.
When a disk is brought from a cold environment to a hot one, there
could be steam on the face of disk. wipe with a dry, soft, smooth
clothbeforeusing.
How To Deal With Disk
How To Deal With Disk
26
Attention
Don't write on the labeled
side.
Don't use pickup cleaning
preparation. phenyl,
chemical solution,
dispersing solution, anti-
static electricity solution or
any other kind of solutions to
cleandisk
Don't stick label or glue-
based note on disk (Don't use
disks with remaining glue or
damagedglueylable)
Don't use scratching-
preventingmaterialsorcover,
unlessit is assigned to use on
thismachine.
Don't put or store disk at
following environments.
straight under the sunshine.
/at moist or dusty places at
the exit of hot air or beside
heatinginstallation.
