Pyle PYLE View Series PLVSMN7 User manual

7" SUN VISOR TFT-LCD MONITOR
PLVSMN7

1. SPECIFICATION
* OPICAL
- SCREEN SIZE ----------------------------------- 7" DIAGONAL
- DISPLAY FORMAT ---------------------------- 1440(H) x 234(V)
- COLOR CONFIGURATION ------------------ RGB Stripe
- DOT PITCH -------------------------------------- 0.107(H) x 0.372(V)
- VIEWING ANGLE ------------------------------ Top: 50 deg. / Bottom: 20 deg.
Left: 45 deg. / Right: 45 deg.
* ELECTRICAL
- COLOR SYSTEM ------------------------- NTSC/PALAuto Switch
- VIDEO INPUT ----------------------------- 1 Vp-p, 75ohms
- POWER CUNSUMPTION ---------------- DC12V 1A MAX. 6VA
- AUDIO OUTPUT POWER---------------- 0.5W(MAX)
POWER
MENU
MODE
UP
DOWN
SPEAKER
* POWER: Press the "Power" button once it will be power ON.
Press it again, will be power OFF.
* UP/DOWN: Press UP or DOWN directly is to adjust volume.
Using MENU button together can adjust the other functions.
- BRIGHTNESS-----------------------------250 CD/M2
Menu Function
CONTRAST: Press or to adjust Contrast.
BEIGHTNESS: Press or to adjust Brightness.
COLOR: Press or to adjust Color.
SHARPNESS:
VOLUME: Press or to adjust Volume.
MODE: 16:9 / 4:3
LEFT RIGHT: Left/Right Revolving
RESET: The Display will Return to The
Original by Factory.
EXIT: Exit Menu Mode.
Press or to adjust Sharpness.
2. FUNCTION KEYS AT FRONT PANEL:

3. FUNCTION
5. DIMENSION
6. SUN VISOR KIT
DC 12V INPUT B+ (RED)
GROUND (BLK)
AUDIO INPUT (WHITE)
VIDEO INPUT (YELLOW)
4. REMOTE CONTROL
MUTE
POWER
FUNCTION/ODS MANU
UP
DOWN
1234
5678
90
21.2
109
168
223
22.5
127
