Pyle Pdwmkhrd23 User manual

PDWMKHRD23

Optical/CoaxialInputKaraokeMixer

with2UHFWirelessMicrophone

8 Channels Home Theater Karaoke Mic System, BT,

Connects to TV, Receiver,Amplifier, Speaker,

Includes Wireless Mics & More

www.PyleUSA.com

CONTENTS

IMPORTANT SAFETY INSTRUCTIONS ---------------------------------------

FUNCTIONS DESCRIPTIONS ------------------------------------------------

PACKAGE LIST --------------------------------------------------------------

INSTRUCTIONS -------------------------------------------------------------

OPERATION ----------------------------------------------------------------

CONNECTIONS INSTRUCTIONS ---------------------------------------------

TROUBLESHOOTING -------------------------------------------------------

FCC ADVISORY -------------------------------------------------------------

FEATURES AND TECHNICAL SPECS ----------------------------------------

www.PyleUSA.com

Important Safety Instructions

1. Do not use this apparatus near water

2. Do not install near any heat sources such as radiators, heat register stoves, or

other devices that produce heat

3. Do not defy the safety purpose of the polarized grounding type plug. A polarized

plug has two blades with one wider than the other A grounding type plug had

two blades and a third grounding prong. The wide blade or third prong is provided

for your safety. If the provided prong does not t your outlet consult an electrician

for possible replacement of obsolete outlet.

4. Protect the power cord from being walked on or pinched particularly at plugs

receptacles and or the point where they exit from the device.

5. Only use attachments accessories specied or included

6. Unplug this device during lightning storms or when not in use for prolonged

periods

7. Refer any or all servicing to quality service center or personel Servicing is required

when the device has been damaged to a point of malfunctions such as liquid

spillage exposure to rain moisture excessive heat or dropping of the device.

Functions

• 3.5mm stereo outputs to connect to amplier, Computer, etc.

• Optical/Coaxial Inputs to connect to LCD TV player, Set-Top Box, etc.

• 3.5mm stereo inputs connect to CD player, Smart phone, atc.

• Adjustable tone control for all microphones.

• Rotary knob for control music volume.

• Middle of upper panel with blue light, blue light to indicate the power status, left

and right blue light to indicate the wireless microphone status.

• MIC 1,MIC 2 rotary knob simultaneously control wireless microphone volume.

• 2 UHF Wireless microphones are included, powered by 2 pcs 2A battery.

www.PyleUSA.com

Package List

1. Main Device (1pc)

2. Wireless Mic (2pcs)

3. USB Charger (1pc)

4. USB Charging Cable

5. 3.5mm/3.5mm Audio Cable (1pc)

6. 3.5mm/2RCA Audio Cable (1pc)

7. Optical cable (1pc)

8. AA Dry Battery (4pcs) for wireless

Optical Cable User Manual

Battery USB Cable

3.5/3.5mm Cable 3.5/2RCA Cable

Main Device Wireless Mic

www.PyleUSA.com

INSTRUCTIONS

Front Panel

Rear Panel

Wireless Microphone

DC :5V

3.5mm Input3.5mm Output

ANT ANT

AUX OUT AUX IN OPTICAL IN COAXIAL IN DC 5V

Optical Input

Coaxial Input

Tone

Power Switch

Echo

Music Volume

MIC B

Volume

MIC A

Volume

RF A LED

RF B LED

Power LED

LED Display

ON/OFF Battery Lid

www.PyleUSA.com

Operation

1. Connect the receiver to a power outlet through the power adapter provided and

turn on the receiver.

2. Put two alkaline AA batteries into the battery compartment of the microphone.

Please ensure the positive and negative ends are positioned in the correct direction

3. Power on the handhold microphone. In case of any frequency interference, quick

press the power button on the microphone will be turn to a dierent frequency.

There are up to eight frequencies for you to choose .

4. Please note that it will take a few seconds for the receiver to automatically

syndicate the frequency with the microphone each time the power button is

pressed.

5. When the product is delivered from the factory, ID of receiver and handheld are

not matched. The handheld and receiver between the two sets of products can

be used interchangeably. But 2 sets of products can not be used in the same

environment at the same time. You need match the product ID if 2 sets of products

are used at the same time.

6. The matching operation is as follow. Connect the power cable of the receiver and

turn o the power switch. After turn o the handheld, press and hold the power

button of handheld for 5 seconds until the ID is displayed on the display.

Immediately release the power switch and quick press the power switch again

within 1 second.

7. To connect the receiver to a device such as a computer, TV, and speaker, etc.,

please refer to the connection diagram section.

8. Note that in order to protect the battery, the handheld will automatically turn

o if there is no sound input to the microphone for exceed 5 minutes. Turn on

the handheld again if you need to work.

Note:

Wireless BT Connection

The product comes with built-in Wireless BT function and you can choose to

pair the receiver with your Wireless BT device as well.

1. Once you power on the receiver, the receiver will become discoverable as Pyle BT.

2. In the settings of your Wireless BT enabled devices, set it to 'discover'. From the

Wireless BT device list. Select the Pyle BT device. When Wireless BT is used to

connect a device (Say a Wireless BT enabled cellphone) Please connect the

receiver via audio out port to the sound output device (speaker or sound bar)

www.PyleUSA.com

570 . 6

CHA MHZ

P0WER

ANT A NT

AUX OU T AUX I N OP TI C AL I N CO AXI AL IN DC 5V

570 . 6

CHA MHZ

P0WER

ANT A NT

AUX O UT A UX IN OP TI C AL I N CO AXI AL I N DC 5 V

570 . 6

CHA MHZ

P0WER

570 . 6

CHA MHZ

P0WER

Connection Instructions

1. PC Karaoke Mode (Desktop PC & Notebook PC )

2. Sound Mode

www.PyleUSA.com

570.6

CHA MHZ

P0WER

ANT A NT

AUX OUT AUX IN OP TIC AL I N COAX IAL INDC 5V

570.6

CHA MHZ

P0WER

Optical

Coaxial

3. Connect with TV

4. Connect with Mobilephone through Wireless BT

57 0. 6

CHA MHZ

P0WER

ANT A NT

AUX OUT AUX I N OP TIC AL I N COAX IAL INDC 5V

57 0. 6

CHA MHZ

P0WER

bluetooth

www.PyleUSA.com

5. Small Meeting Connection

6. Connect with blueray player

570. 6

CHA M HZ

P0W ER

ANT ANT

AUX OU T AUX IN OPT ICA L IN COAXI AL IN DC 5 V

570. 6

CHA M HZ

P0W ER

57 0. 6

ZHMAHC

P0WER

ANT ANT

AUX OUT AUX IN OPT IC AL IN COAXIA L IND C 5V

57 0. 6

ZHMAHC

P0WER

www.PyleUSA.com

Troubleshooting

If you are having problems operating the karaoke player, or suspect something

is wrong with it, please check the troubleshooting list below to resolve any

issues of incorrect operation. If you suspect an equipment malfunction and are

unable to resolve the problems, please contact the service center.

1. No light on power indicator

Solutions: Check the power adaptor and cable

2. Power indicator is lit but no sound is present.

Solutions: Check the source device and disable any mute settings.

3. Sound is harsh or distorted.

Solutions: Reduce source volume.

Change placement angle between Mic and speaker

Change distance between Mic and Speaker

4. TV has no sound output when playing Optical/Coaxial Output.

Solutions: Check whether TV digital audio mode is selected as PCM. Check whether TV

audio output mode is selected as Optical/Coaxial output.

FCC Statement (United States Only)

1. This equipment has been tested and found to comply with the limits for a Class

B digital device pursuant to part 15 of the FCC Rules. These limits are designed to

provide reasonable protection against harmful interference in a residential

installation. This equipment generates uses and can radiate radio frequency

energy and if not installed and used in accordance with the instructions may

cause harmful interference to radio communications. However there is no

guarantee that interference will not occur in a particular installation If this

equipment does cause harmful interference to radio or television reception

which can be determined by turning the equipment o and on the user is

encouraged to try correcting the problem by one or more of the following

measures:

• Increasing the distance between the radio TV equipment and the main device

• Connecting the radio TVequipment to an outlet on a diﬀerent circuit than the one

into which the receiver is plugged

• Consult the dealer or an experienced radio/TV technician for help.

2. IMPORTANT: When connecting the main device to audio equipment, use only

high-quality, shielded cables such as what is supplied with this product. Follow

all installation instructions and do not modify the equipment in any way as this

could void your FCC authorization to use the device in the U.S.
