Pyle PWMA220BM User manual

PortableKaraokePASpeakerAmplifier
andMicrophoneSystem
PWMA220BM
Wireless BT Streaming, Built-in Rechargeable Battery
(Includes Belt Pack Transmitter, Headset, Lavalier & Wired Handheld Microphone)

www.PyleUSA.com www.PyleUSA.com
*Wireless Microphone Operating Frequency Range: 203.4 - 215.2 MHz
FEATURES
1. Built-in Wireless BT Streaming MP3 player.
2. Built-in one channel wireless microphone and one 6.35mm MIC in socket to
connect wired dynamic MIC. Two persons can speak or sing at the same time.
3. One 3.5mm keyboard in socket to connect electronic device. And one 3.5mm
cassette in socket to connect cassette player or other audio player.
4. One 3.5mm REC out socket can be connected to a recording device or to the
input jack of a power amplier to further amplify and enlarge the audio power.
5. Master power/volume control. Bass,Treble and Echo controls.
Suitable for karaoke.
6. Powered externally with AC, 12V DC or internally with built-in 12V/1.8A
lithium battery or (6) x 'D' Batteries. Suitable for both indoor and outdoor use.
7. Ideal for many applications, including use in classrooms, conference/meeting
rooms, churches, health clubs and small auditoriums.
CAUTION
1. This unit is with speaker inside which can cause magnetic eld.
Keep this unit at least 60cm away from computer or TV.
2. This unit is with built-in rechargeable battery. Please recharge the battery
every 2 months if you are not going to use the unit for a long period of time
or the battery may be damaged.
3. If the battery is damaged please replace with same specications battery
and dispose the damaged battery environment friendly.
4. Free from high temperature. Don't expose the device to the hot equipment.
5. Don't place the device in the environment of humidity and dirts.
6. Place the device in the ventilated environment.
7. Don't pull the power cord while you pull out the plug. Hold the plug tightly
to pull it out.
8. Pull out the AC power if you will not use the device for a long time.
9. Your operation must be subjected to the specied voltage marked near the
AC in jack and complied with this guide.
1 2
PARTS DESCRIPTION
1. Echo control
2. Treble control
3. Bass control
4. Power/volume switch
5. MIC IN socket
6. DC IN socket
7. Power indicator
8. Battery charging indicator
9. Wireless receiver RF indicator
10. Wireless receiver antenna
11. MP3 LED display
12. MP3 mode
13. MP3 play/pause/repeat
14. MP3 previous/volume down
15. MP3 next/volume up
16. USB port
17. Microphone holder
18. Speaker
19. Keyboard in socket
20. Cassette in socket
21. REC out socket
22. Battery compartment for
(6) x 'D' Batteries
18
1 2 3 4 5 6 7 8 9
12
13
14
15
16
17
10
11
19
20
21
22

www.PyleUSA.com www.PyleUSA.com
OPERATION ON AC POWER
Plug one end of provided AC cord into the AC input jack on the left side
of the amplier. Then plug the other end of AC cord into AC power outlet. Turn
on the unit using the power/volume switch.
NOTE: To avoid damaging your unit, make sure AC power is same as that
marked near AC input jack)
OPERATION ON DC POWER
This unit can be powered also using external 12V DC power. Connect external
12V DC power to DC input jack on the front of the amplier. Observe the
correct polarity as following.
OPERATION ON RECHARGEABLE BATTERY
This unit can be powered internally using the built-in rechargeable battery.
When AC power is connected, if battery charging indicator lights red, the
rechargeable battery is not fully charged and will be allowed to charge while
the unit is powered by the AC power. (Note: Turning o the unit power switch
will allow the battery to recharge more quickly.) If the battery charging indica-
tor lights green, the battery is fully charged and ready to power the unit alone.
Shut o the power switch and disconnect the AC power. Turn the unit back on
and the rechargeable battery will power the unit alone.
OPERATION ON 'D' BATTERIES
This unit can also be powered internally with (6) x 'D' Batteries. Insert the
batteries while observing the correct polarity as marked. For longest operation
use only alkaline or rechargeable batteries. Replace the batteries when the
output volume drops or the range of the wireless decreases.
Note: This unit does not recharge batteries. When using 'D' Batteries, do not
connect AC or DC power.
3 4
CONNECTION
• The KEYBOARD IN socket can be connected to a electronics device.
• The CASSETTE IN socket can be connected to a cassette player or other
audio player.
• The REC OUT socket can be connected to a recording device or to the input
jack of a power amplier to further amplify and enlarge the audio power.
• The MIC IN socket can be connected to wired dynamic MIC. Keep MIC head
away from the speaker of main unit to avoid feedback.
BLUETOOTH/MP3 OPERATION
1. Insert ash drive into USB port or Micro SD Memory Card into Micro SD
card slot, system will play the music in ash drive or Micro SD Card
automatically. If both ash drive and Micro SD Memory Card are inserted,
system will play the music in ash drive. To play music in Micro SD Memory
Card press MODE button to switch to SD mode.
2. To play music from your mobile phone etc via bluetooth, press MODE button
to switch to BT mode. Turn on bluetooth function of your mobile phone and
search for Pyle Audio and connect. Then you can play your music in mobile
phone.
ATTENTION
1. If feedback (howling sound) occurs, try rst turning down the treble control.
If feedback still is present, try turning down the volume or repositioning this
unit with respect to the wired or wireless microphone being used.
2. Extend the antenna fully whenever using the wireless microphone to ensure
optimum performance and maximum range.
BELT PACK TRANSMITTER OPERATION
Parts Description
1. Power On/O/Mute switch
2. MIC input socket
3. Power/low battery Indicator
4. Gain adjustment
5. Battery compartment/cover
6. Lapel MIC
7. Headset MIC
5
41 2 3
6
7

www.PyleUSA.com www.PyleUSA.com
OPERATION
1. Open battery cover and install 2PCS AA batteries into battery compartment
with correct polarity. And then close the cover.
2. Plug in either the clip-on or the headset microphone.
3. To use the clip-on MIC, attach it at chest level. Do not place too close to the
mouth- a distance of about six inches usually works best. To use the headset
MIC, place it on the head and adjust the MIC boom so that the MIC is about
one inch to the side of the front of the mouth.
Note: The clip-on or headset MIC wire is also the transmitting antenna. Rolling
up or shortening the wire may reduce the eective operating range. Extend
the wire fully during use and keep it as straight as possible.
4. Turn on the transmitter by sliding the power switch to ON position. Power
indicator will give a single quick ash, indicating usable battery strength. In
the case of a dead or low battery, the power indicator either will not go on at
all or will stay on continuously, indicating that the battery should be
replaced with a fresh one.
5. The RF indicator on the amplier should now be lit.
6. Adjust the volume control of body pack and/or volume control of the
amplier to a comfortable listening level as desired.
7. If the transmitter is not going to be used for any length of time, slide power
switch to OFF position and remove the battery.
PWMA220BM
Portable Karaoke PA Speaker Amplier and Microphone System
Wireless BT Streaming, Built-in Rechargeable Battery (Includes Belt Pack
Transmitter, Headset, Lavalier & Wired Handheld Microphone)
Features:
• Versatile Public Address Microphone & Speaker
• Bluetooth Wireless Music Streaming Ability
• Lightweight, Portable & Powerful
• Integrated Wired Handheld Microphone
• USB Flash Drive Memory Reader
• MP3 Digital Audio File Compatibility
• Built-in Rechargeable Battery, 10+ Hour Operation
• 1/4'' Microphone Input Jack
5 6
• Audio (3.5mm) Output, Connect External Devices
• Full Range Stereo Sound Reproduction
• Impressive Bass Response
• Convenient Carry Handle
• Echo, Bass, Treble Audio Conguration Controls
• Perfect for Karaoke, Crowd Control, House Parties
*Ability to be Powered by External Wall Power Adapter (Not Included)
Bluetooth Connectivity:
• Wireless Music Streaming Audio
• Works with All of Your Favorite Devices
(Smartphone, Tablet, Computer, Laptop, MP3 Player, etc.)
• Bluetooth Version: V3.0
• Bluetooth Network Name: Pyle Audio
• Bluetooth Wireless Range: 30' ft.
What's in the Box:
• PA Speaker Amplier
• Wired Handheld Microphone
• Headset Microphone
• Lavalier Microphone
• Belt Pack Transmitter
• Shoulder Carry Strap
• Power Cable
• (2) x ‘AA’ Batteries
Technical Specs:
• Power Output: 60 Watt MAX
• Speaker Impedance: 4 Ohm
• Frequency Response: 25Hz-15kHz
• Maximum USB Flash Memory Support: 32GB
• Digital Audio File Support: MP3
• Main Unit Rechargeable Battery, 11.1V Li-iOn, 1800mAh - 19.98Wh
• *Main Unit Speaker Optionally Battery Powered, Requires (6) x 'D' Batteries,
Not Included
• Battery Operated Belt Pack, Requires: (2) x 'AA' Batteries (Included)
• Power: DC 12V, AC 120V
• Dimensions (L x W x H): 9.7'' x 5.2'' x 9.5'' -inches
*Wireless Microphone Operating Frequency Range: 203.4 - 215.2 MHz
