REMOTE CONTROL
1. Standby
2. MP3 last song/FM last frequency
3. MP3 pause, Play/FM scan frequency
4. Increase sound volume "+" of main channel
5. EQ mode adjustment
6. Decrease sound volume "-" of main channel
7. AUX/USB/SD/FM/BT Input selected
8. MP3 next song
9. Mute
10. Repeat
11. 0-9: through selected song
BACKBOARD FUNCTION
1. AUX input
2. 110V and 220V voltage switch
3. Electricity supply AC110V/60Hz,
AC 220V/50Hz
4. FM antenna
5. LED power ON/OFF
6. Power ON/OFF
www.PyleUSA.com2www.PyleUSA.com 3
We recommend that you read this manual carefully so that you can fully take
advantage of the advanced and convenient functions of the PA Loudspeaker
Karaoke Entertainment System. We also recommend that you keep this manual
in a safe and handy place for future reference.
CAUTION
TO PREVENT THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER OR BACK.
NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
SAFETY INSTRUCTION
1. Read this manual carefully before using. Retain for future reference.
2. All warnings on the speaker and in the operating instructions should be adhered to.
3. Do not use this apparatus near water.
4. Do not block any of the ventilation openings. Install in accordance with the
manufacturers instructions. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including ampliers) that produce heat.
Do not install the speaker in an airtight location.
5. Protect the power cord from being walked on or pinched particularly at plugs,
convenience receptacles, and the point where they exit from the apparatus.
6. Switch OFF and unplug then use a soft cloth to clean the exterior of the unit if it
becomes dirty. If necessary, use a damp cloth that has been wrung out well to
wipe it.
7.Unplug this apparatus during lightning storms or when unused for long periods of
time.
8. Keep foreign objects and liquid from entering the unit to avoid a short circuit, re
and electrical accidents.
9. Place the speaker in a dry location.
10. Refer all servicing to qualied service personnel. Servicing is required when the
apparatus has been damaged in any way, such as power-supply cord or plug is
damaged, liquid has been spilled or objects have fallen into the apparatus, the
apparatus has been exposed to rain or moisture , does not operate normally, or
has been dropped.
4
5
6
1
2
3

www.PyleUSA.com4www.PyleUSA.com 5
CONTROL PANEL
Front board Function:
1. Volume adjustment
2. Treble adjustment
3. Bass adjustment
4. MIC echo adjustment
5. MIC volume adjustment
6. MP3 pause or play
WIRELESS MICROPHONE OPERATION
1. Replace the battery when noise occurs during
use, staccato, or distortion.
2. Turn o the power switch after use.
3. If the microphone is not to be used for a long
period of time, remove the batteries to prevent
damage or injury from possible battery leakage.
4. When you turned ON the power switch and the
power indicator does not light, check the polarity
of the battery installation.
Wireless BT Streaming:
• Instantly Stream Music from Your Wireless BT Devices
• Works with All Your Favorite Wireless BT Devices
(iPhone, Android, Smartphone, iPad, Tablet, PC, etc.)
• Bluetooth Version: 5.0
• Wireless BT Range: 50'+ Feet
• Wireless BT Network Name: 'Pyle Audio'
What's in the Box:
• Active Speaker Tower
• Wireless Microphone
• Power & Audio Connection Cables
• Detachable Rolling Wheels
• Remote Control
7. MP3 next song/FM next frequency/VOL+
8. USB/SD/MMC card connector
9. AUX/DVD/MP3/FM/BT input select
10. MP3 last song/FM last frequency/Volume-
11. MIC input jack
1
2
3
4
5
6
7
8
9
10
11

www.PyleUSA.com6www.PyleUSA.com 7
TROUBLESHOOTING
Try the troubleshooting steps below if you are having problems while using your
speaker. If problems still exist, please look for a qualied technician or contact our
company. To prevent electric shock or expand the scope of the malfunction, do
not repair by yourself.
Features:
• All-in-One Karaoke Entertainment System
• High-Powered Active Speaker Tower
• Multi-Colored DJ Flashing LED Lights
• Bluetooth Wireless Music Streaming
• USB Flash & SD Memory Card Readers
• Digital Audio File Support
• Includes Wireless Handheld Microphone
• FM Radio with Auto Station Scan
• (2) 1/4'' Microphone Inputs
• RCA (L/R) & Aux (3.5mm) Inputs
• Connect & Stream Audio from External Devices
• Convenient Carry Handles & Detachable Rolling Wheels
• Treble, Bass, Echo, Volume Controls
• DJ Party Lights ON/OFF Switch
Technical Specs:
• MAX Power Output: 2000 Watt
• Sound System: Dual 10'' Woofers, Dual 3'' Tweeters
• Frequency Response: 45Hz-20kHz
• Sensitivity (1w/1m): 92dB
• Impedance: 4 ohm
• Maximum SPL: 128dB
• Dispersion (@6dB): H90°X V50°
• Crossover: 3 KHZ
• Power Supply: 110/220V
• Microphone Battery Operated: Requires (2) x 'AA' Batteries, Not Included
• Maximum USB Flash / SD Memory Card Support: 32GB
• Dimensions: 16.1'' x 15.1'' x 42.0'' -inches
SYMPTOM POSSIBLE PROBLEM SOLUTION
No function light
and No sound
1. Plug is not well connected
2. Speaker power button is
not turned on.
1. Insert the plug into electrical
outlet.
2. Turn on the power button
Function light is
turned on but no
sound
1. Cable misconnected
2. Speaker are not connected
or misconnected
3. Audio signal is not trans-
mitted to speaker
1. Turn o the power, check the
input jack to ensure proper
audio signal is connected to
relevant input jack
2. Power o, then check and
conm the cable connection
again.
3. Check all the speaker if there
is audio signal output
Remote control
does not work
1. Before you press any function button, rst select the correct
source with the remote control instead of the main unit
2. Reduce the distance between the remote control and unit
3. Insert the battery with its polarities (+/-signs) aligned as
indicated
4. Replace the battery
5. Aim the remote controldirectly at the sensor on the front
of the unit.
If the problem exists after checking related procedures above, please refer to
the appointed service ... Do not attempt to open the cover, otherwise we
assumes no responsibility
