Pyle PLHRQD9B User manual

Pyleaudio.com
PLHRQD9B
PLHRQD9B
PLHRQD9W
8.7"
5.7"
0.8"

PLHRQD9B
Function keys panel
1 2 3 4 5
1. Video input selection
2. Menu
3. Power on/off
4. Analog variable decrease
5. Analog variable increase
Methods of remote using
Power ON/OFF
Switch for mode
Upward
Leftward
Menu
Downward
Video 1 input
Video 3 input
Rightward
Video 2 input
Video 4 input
Video Input 1
Video Input 2
Video Input 3
Video Input 4
Red '+'
Black 'GND'
Blue 'Reverse' Line
Wire diagram
