Pyle PM15LCD User manual

Model PM15LCD：
4:3 DIGITAL LCD-Monitor
OPERATING MANUAL
15 LCD MONITOR

2
2
6
SAFETY
PRECAUTIONS
2
1PREFACE
FRONT BACK/SIDE
CONNECTIONS
OF LCD
4
3
INSTALLTION
DRAWINGS
4
5
5
6
6
Y Pb Pr Connection
7
REMOTE CONTROL
FUNCTIONS
5
8
ConnectionS-Video
PC-RGB Connection
7
CONFIGURATION
OF THE LCD
12
13
1
Contents
Power Cable Connection
Connecting Antenna
Video Connection
Remote control instructions in TV mode
Battery Installation
Battery Usage Caution
9
9
TROUBLESHOOTING
AND ADVICE
SPECIFICATIONS
9
10
10
10
11
11
Enter picture menu
Enter sound menu
Enter Timer menu
Enter other setting menu

2
1. PREFACE
Thank you for buying this TV ! Please read this manual thoroughly before operating the monitor.
Make sure the monitor was not damaged in transit. Should the monitor is damaged, do no install
it and contact your dealer. Check that you have all the accessories according to the model.
2. SAFETY PRECAUTIONS
Preparation
Power cord and cables must be properly routed and protected to prevent
people from stepping on them and causing the monitor to fall.
Minimum distances
10cm
20cm
10cm 5cm
Put the monitor on a stable surface.
Do not place any material on the monitor.
Do not block or cover the ventilation openings on the monitor
If you have a wall mount, check that it is steady
Connexion cables

3
Heating sources and humidity
Keep the monitor dry and away from humidity.
Keep the monitor away from heat sources
Cleaning and maintenance
Unplug the monitor before cleaning it. Do not use solvents or liquids
to clean the monitor.
Only clean the monitor with a soft and dry cloth.
In case of troubleshooting, do not use spare parts other than those
suggested by
the manufacturer. Using inadequate spare parts can lead to electric
shocks, short-circuits fire or other incidents.
Departure in holidays
Unplug the LCD during lighting storms or when unused for long periods
of time.

4
Front View
Back View and Control Connections
3. FRONT BACK/SIDE CONNECTIONS OF LCD
1.Press POWER Switch on the LCD TV when“”
at standby mode or vice versa.
2.Press UP or DOWN to“”“ ”select option in
menu
3.Press V+ or V- to increase or decrease“”“”
the sound level.
4.Press MENU to bring up the main menu to“”
the screen
5.Press SOURCE to select the input source“”
1.DC 12V IN: DC input socket
2.VGA: Connect the PC-RGB output jack of PC
3.YPbPr: Connect the DVD YPbPr output jack of
the DVD Player
4.PC AUDIO INPUT: Connect the Audio output
jackofPC
5.VIDEO: Connect the Video output jack of DVD
or VCR
6.AUDIO LR INPUT: Connect the left and right
Audio output jacks of DVD or VCR for VIDEO /
S-VIDEO / YPbPr
7.S-VIDEO: Connect the S-VIDEO output jack
ofDVDorVCR
12 3 456 7

Power Cable Connection
Connect the power cord correctly as shown.
Press the POWER switch of your LCD VT to switch on the LCD TV. The power indicator on the front
panel lights up in green.
4. TV INSTALLTION DRAWINGS
To ensure good picture and sound, TV antenna system needs to be installed. The antenna system as
shown can be sourced from TV equipment shops, which will provide service for correct installation
and connection. After installation, insert the 75-ohm antenna plug into the antenna jack as shown.In
case of signal of closed circuit TV,
75 OHM
ANTENNA
PLUG
POWER PLUG OF
ANTENNA
AMPLIFIER
OUTDOOR
ANTENNA
AMPLIFIER
VHF ANTENNA VHF ANTENNA
INDOOR
ANTENNA
AMPLIFIER
5
Connecting Antenna
DC IN 12V

6
Connection S-Video
1
1
TV BackTV Back
RL
AUDIO
Connect the S-VIDEO output of the DVD or VCR to the S-VIDEO input on the set. The picture quality
is improved; compared to connecting a regular VCR to the video input. Connect the Audio output of the
DVD or VCR to the Audio input jacks on the set using the RCA cable.
Select S-VIDEO input source with using the SOURCE button on the remote control.
Video Connection
Connect the VIDEO and AUDIO output jack of the DVD or VCR to the AV IN jacks on the set using
the RCA cable.
Select the AV input source with using the SOURCE button on the remote control.
DVD BackDVD Back
TV BackTV Back
AUDIO
VIDEO IN
AUDIO L R IN
DVD BackDVD Back

PC-RGB Connection
VGA Cable
Stereo Audio CableStereo Audio Cable
AUDIORGB-PC OUTPUTRGB-PC OUTPUT
PC INPUT1
Connect the RGB output of the PC to the VGA in jack on the set Connect the PC AUDIO output of the
PC to the PC AUDIO in jack on the set Select the VGA input source with using SOURCE button.
7
L
Y
YPb Pr L R
Connect the YPbPr output of the DVD or VCR to the YPbPr input on the set. The picture quality is
improved; compared to connecting a regular VCR to the video input. Connect the Audio output of
the DVD or VCR to the Audio input jacks on the set using the RCA cable.
Select HD input source with using the SOURCE button on the remote control.
Y Pb Pr Connection
DVD BackDVD Back
1
TV BackTV Back
AUDIO L R IN
YPbPrIN

8
5. REMOTE CONTROL FUNCTIONS5. REMOTE CONTROL FUNCTIONS
1
4
3
2
5
1. Switch on LCD TV when at standby mode or vice versa.POWER
2. Press to cycle through the input source in following.SOURCE
3. Press to mute the sound. Press again or press V+ to unmated.MUTE
4. Brings up the main menu to the screen.MENU
5. Allows you to navigate the on-screen menus and adjust
the system settings to your preference.
THUMBSTICK(▲/▼/◄/►/ENTER)
6.1 Remote control instructions in TV mode

9
5.2 Battery Installation
a)Open the cover
b)A size batteries, When inserting the batteries, make sure correct polarities as per”+“and ”-“marksA
on the batteries and within the battery compartment
c)Replace the battery cover
To prevent battery leakage which may result in bodily injury or damage to the remote:
1.Install all batteries correctly, and as marked on the remote control.
2.Do not mix batteries:(OLD and NEW or CARBON and ALKALINE, etc)
3.Remove batteries when the remote is not used for a long time.
5.3 Battery Usage Caution
