Pyle PLH9SP User manual

Color TFT LCD 9.2 Monitor
PLH9SP
Accessories
1.Power on/off
4.Brightness-
5.Brightness+
6.Color-
7.Color+
8.Contrast-
9.Contrast+
2.Volume-
3.Volume+
-
-
-
-
LCD MONITOR
1
3
5
7
9
2
4
6
8
10 11
10 Video Input 1
11 Video Input 2
PLH9SP
(1) Connecting Cable x1
(2) Headrest Shroud x1
(3) Release Key x1
(4) Operation Manual x1
(5) Stand Bracket x1
(6) Remote Control x1
(7) Front AV Cable x1
WWW.PYLEAUDIO.COM
All manuals and user guides at all-guides.com
all-guides.com

Warning
CAUTION
1. The driver must notbe able toview operational monitorwhile driving the
vehicle . This is illegalin most states. CHECK with yourlocal law enforcement
officials for details .
2. Alwayscheck polarity when connecting wire toavoid damage to the unit and
/or vehicle.
3. Do notopen the housing of the monitor,Servicing must be done at our factory
by authorized techniciansto maintain the warranty.
Function
(1/10) Speaker
(2) AV IN(Direct Connectionof AlternateAudio/Video
Source throughAux Line Input Jack)
(3) Receiving Window of theremote control
(4) Power
(5) Menu
(6) Adjust Down
(7) Adjust Up
(8) AV1/AV2
(9) Headphone Connection
Specifications
System
Power Input/Consumption
Video Input
Audio Input
Operating Temperature
Storage Temperature
Screen Size(Diagonal)
Display Method
Resolution(Dot)
Back Light
ViewingArea
ViewingAngle
Monitor Overall Dimension
Monitor Weight
IR Transmitter
The Specifications aresubject to changewithout prior notice
NTSC/PAL Auto Switch
DC(10.5~15V) 10% ,<700mA
Composite Video Signal 1Vp-p 75Ohm
0.5W 8 Ohm at 300mv input
-5 ~+50
-20 ~+60
9.2
TFT Active Matrix System
800(H)xRGBx480(V)
Cold Cathode Filament Tube
203(W)x122(H)mm
Left ,Right:45 Top:35 ,Down:10
240(W)x174(H)x30(D)mm
<1.5kg
(2.3MHz/2.8MHz)(3.2MHz/3.8MHz)
2 3 4 5 6 7 8 9 10
1
1 2 3 4 5
Fuse
Fuse
(1) (RED)
(2) (BLACK)
(3)(RCA)Audio Input L(WHITE)
(4)(RCA)Audio Input R(RED)
(5)Video In(YELLOW)
+12 Volt Accessory
(-) Negative Ground
PLH9SP
