Pyle PHP28DJT User manual

Questions? Issues?
We are here to help!
Phone: [phone]
Email: suppor[email protected]
PHP28DJT
Dual8’’PortableWirelessBTSpeakerSystem
TWS Function, Built-in Rechargeable Battery, LED Display,
FM/Aux/MP3/USB/SD w/ ¼’’Input Jack for Microphone

WARNING
Illegal operation may cause personal injury, which could be fatal and may cause
damage to property. For safety, we do not suggest to charge unit and use micro-
phone together.
1. DO NOT place objects on top of the device, as objects may
scratch the device.
2. DO NOT expose the device to dirty or dusty environments.
3. DO NOT insert any foreign objects into the device.
4. DO NOT expose the device to strong magnetic or electrical eld.
5. DO NOT use the device in the rain
6. Please check with your Local Authority or retailer for proper
disposaI of electronic products.
7. DO NOT disassemble the device. Only a certied service
technician should perform repair.
8. The device has apertures to disperse heat. DO NOT block the
device ventilation, the device may become hot and malfunction
as a result.
CONTROL BOARD FUNCTIONS
1. Play/stop music on USB/Micro SD/BT mode, scan FM channel on FM mode
2. USB and micro SD memory card input jack
3. Press and hold to decrease music volume, short press to choose last channel
4. 3.5MM AUX input jack
5. 6.5MM microphone input jack
6. Power switch button
7. Mode button: short press to select USB/Micro SD/AUX/BT/FM mode
8. Menu button: short press to select Bass (b) or Treble ( ) or main volume (U),
and then use Prev (-) or Next (+) button to decrease or increase
9. Charge LED indicator: Red light in charge, blue light full charge
10. DC 9V charge input jack
11. Increase bass eect button
12. LED mode and switch button
13. TWS Function button: Two unit both on Wireless BT mode, press this TWS button
to start TWS pairing.
14. 4 kinds of DJ eect selecting button
15. Microphone volume knob
16. Microphone echo knob
17. Press and hold to increase music volume, short press to choose next channel
www.PyleUSA.com
2www.PyleUSA.com 3
1
3
17
11
13 15 16 14
12
8
7
6
5
4
2
10
9

TROUBLESHOOTING
Wireless BT Connectivity:
• Built-in BT for Wireless Music Streaming
• Simple & Hassle-Free Pairing
• Works with All of Today’s Latest Devices
• Smartphones, Tablets, Laptops, Computers, etc.
• Wireless BT Version: 5.0
• Wireless BT Network Name: ‘PYLEUSA’
• Wireless Range: Up to 32’ ft.
REMOTE CONTROL FUNCTIONS
1. Standby button
2. Choose input AUX/FM/BT/USB signal
3. Mute button
4. Play/Stop button on Mp3 mode, scan function on FM mode
5. Next song on USB/Micro SD Card, next channel on FM mode
6. Previous song of USB/Micro SD Card, last channel on FM mode
7. EQ eect on Mp3 mode
8. Increase speaker volume
9. Choose song number directly on Mp3 mode
10. Stop button
11. Decrease music volume
12. Repeat song on USB/Micro SD Card
www.PyleUSA.com
4www.PyleUSA.com 5
1
2
6
11
9
3
10
7
4
12
5
8
1. The audio format in the USB
is incorrect.
2. Improper operation has caused
a process disorder.
3. USB disc is disconnected.
1. Convert audio format into Mp3
format.
2. Reboot the machine.
3. Insert USB disc properly.
MP3
does not
play
Fault Possible Cause Solution
No sound
Distortion
of sound
Karaoke
does not
work
1. No input sound source.
2. Volume is too low.
1. Volume too high.
2. Speaker may be damaged
1. Microphone plug is not fully
inserted.
2. Microphone switch is not on.
3. Microphone volume knob is at
the lowest position.
1. Use a better music signal.
2. Adjust volume.
1. Turn down the volume.
2. If speaker is damaged, repair
or replace it.
1. Plug microphone properly into
the socket.
2. Turn on microphone switch.
3. Adjust microphone volume
properly.

Features:
• True Wireless Stereo System
• High-Powered Speaker System
• Wireless & Portable Speaker System
• Wireless BT Music Streaming Ability
• Includes Wireless Microphone for Karaoke Fun
• Multi-Color Flashing Ring LED Lights
• Built-in LED Lights for Stunning Visuals
• FM Radio with Digital LED Display
• Built-in Rechargeable Battery
• Aux (3.5mm) Input
• MP3 Digital Audio File Support
• Connect & Stream Audio from External Devices
• USB Flash Drive Memory Reader
• Micro SD card reader
• 1/4’’Input Jacks for Microphone
• Ported Enclosure for Extended Bass Response
• Integrated Extending Carry Handle
• Treble & Bass sound performance adjustment
• Convenient trolley and wheels
• X-Bass button for more powerful bass
• Many kinds of DJ sound eects selection for more fun
• Perfect for the Backyard or Park Visits - Instant Party Anytime, Anywhere!
What's in the Box:
• Speaker System
• Wireless Microphone
• Remote Control
• Power Adapter
• AUX Cable
• Tablet stand
Technical Specs:
• Power: 700 Watts MAX
• Sound System: 2x8'' Subwoofer + 1.5”Tweeter
• Selectable LED Light Modes: Many kinds of LED lights modes
• Digital Media File Compatibility: MP3, WMA (USB 2.0)
• Maximum USB Flash Drive Support: Up to 64GB 、
• Housing Construction Material: ABS+ Iron Net + Wooden
• Built-in Rechargeable Battery: Li-ion 3600mAh, 7.4V
• Battery Operated Remote Control: 1 Piece Button Cell Battery CR-2025 (Included)
• Power Supply: 110/240V (9V Power Adapter)
• AUX Cable Length: 3.94 ft.
• Dimensions (L x W x H): 11.2’’ x 11.4 ’’ x 27’’ -inches
• Tablet Stand Dimensions (L x W x H): 6.9’’ x 4.3’’ x 2.7’’ -inches
www.PyleUSA.com
6www.PyleUSA.com 7
This product can expose you to a chemical or group of chemicals, which may include
“Lead and lead compounds” which is known in the state of California to cause cancer, birth
defects, or other reproductive harm. For more info, go to https://www.p65warnings.ca.gov/.
