Pyle PPHP1243B User manual

PPHP1243B
12''PortableWirelessBTPASpeakerSystem
Karaoke Speaker with Latest DJ LED Lights,
USB/FM/BT/Aux/Remote Control/Mic Inputs,
Built-in Rechargeable Battery (800 Watt)
Questions? Issues?
We are here to help!
Phone: [phone]
Email: [email protected]

www.PyleUSA.com
2
www.PyleUSA.com
3
PLEASE READ THE INSTRUCTION MANUAL CAREFULLY
AND KEEP IT FOR FUTURE REFERENCE
WARNING
Illegal operation may cause personal injury, which could be fatal and may
cause damage to property.
REMOTE CONTROL Functions
1. STANDBY BUTTON
2. CHOOSE INPUT AUX/FM/BT/USB SIGNAL
3. MUTE BUTTON
4. PLAY/STOP BUTTON ON MP3 MODE,
SCAN FUNCTION ON FM MODE
5. NEXT SONG ON USB/MICRO SD MEMORY CARD,
NEXT CHANNEL ON FM MODE
6. PREVIOUS SONG ON USB/MICRO SD
MEMORY CARD, LAST CHANNEL ON FM MODE
7. EQ EFFECT ON MP3 MODE
8. INCREASE SPEAKER VOLUME
9. CHOOSE SONG NUMBER DIRECTLY ON MP3 MODE
10. STOP BUTTON
11. DECREASE MUSIC VOLUME
12. REPEAT SONG ON USB/MICRO SD MEMORY CARD
TWS-TRUE WIRELESS STEREO SETUP
1. Turn on two same PA speaker that you’re attempting to pair together and
switch both units to Wireless BT mode.
2. Choose one of units to begin to pairing process.
3. Press down on the PLAY button for 3 seconds until you hear a chiming
sound; This means the unit is ready to pair with another unit.
4. Move onto the second unit and repeat step 3.
5. Now begin playing your music through Wireless BT enabled mobile device.
The speakers will begin to play your music simultaneously.
Control Board Functions
1. DO NOT place objects
on top of the device, as
objects may scratch
the device.
2. DO NOT expose the
device to dirty or
dusty environments.
3. DO NOT insert any
foreign objects into
the device.
4. DO NOT expose the
device to strong
magnetic or electrical
eld.
5. DO NOT use the device in the
rain
6. Please check with your Local
Authority or retailer for proper
disposaI of electronic products.
7. DO NOT disassemble the
device. Only a certied service
technician should perform
repair.
8. The device has apertures to
disperse heat. DO NOT block
the device ventilation, the device
may become hot and malfunction
as a result.
7
8
2
1
5
4
3 6
11
9
10

www.PyleUSA.com
4
www.PyleUSA.com
5
Troubleshooting and Warning
PPHP1243B
12'' Portable Wireless BT PA Speaker System
Karaoke Speaker with Latest DJ LED Lights, USB/FM/BT/Aux/Remote
Control/Mic Inputs, Built-in Rechargeable Battery (800 Watt)
Features:
• True Wireless Stereo Function
• Portable PA Speaker System
• High-Powered Loudspeaker Design
• Wireless BT Music Streaming Ability
• Multi-Color Flashing LED Party Lights
• Built-in Rechargeable Battery
• LED Display
• USB/FM/Remote Control/Microphone Inputs
• Master Volume, Mic Volume, and Mic Echo Adjustable
This products can expose you to a chemical or group of checmicals, which
may include ”Lead and lead compounds” which is known in the state of
California to cause cancer, birth defects, or other reproductive harm. For
more info, go to https://www.p65warnings.ca.gov/.
1. USB Control Board
2. USB and Micro SD Memory card Input Jack
3. Master Volume Control Knob
4. 3.5MM AUX Input Jack
5. Short press to choose input signal, press and hold to turn OFF/ON light
6. Turning to the end left is power o, then turn it to the right end is power on
7. Echo Volume Control Knob
8. Microphone Volume Control Knob
9. Charge LED Indicator, RED color is charging mode, BLUE color is full charge
10. DC 5V Input Jack
11. 6.5MM Microphone Input Jack
Fault Possible Cause Solution
No sound
Distortion
of sound
Karaoke
does not
work
MP3
does not
play
1. No input sound source
2. Volume is too low
1. Volume too high
2. Speaker may be damaged
1. Microphone plug is not fully
inserted.
2. Microphone switch is not on
3. Microphone volume knob is
at the lowest position
1. The song format in the U disc
is incorrect
2. Improper operation has caused
a process disorder
3. USB disc is disconnected
1. Use a better music signal
2. Adjust volume
1. Turn down the volume
2. If speaker is damaged,
Repair or replace it
1. Plug microphone properly into
the socket
2. Turn on microphone switch
3. Adjust microphone volume
properly
1. Transform song format into
Mp3 format
2. Reboot the machine
3. Insert USB disc properly
