Pyle PPHP109WMU User manual

PPHP109WMU
Wireless & Portable BT PA Speaker
Active-Powered Loudspeaker System, Built-in Rechargeable Battery,
USB/SD Readers, Includes Handheld Microphone,
Recording Ability, FM Radio (1000 Watt, 10'' Subwoofer)

www.PyleUSA.com
2
INDEX
Operation ............................................................................................................................... 2
User’s General Instructions ................................................................................................ 3
Controls and Connections ................................................................................................. 4
Specications ........................................................................................................................ 6
NO USER-SERVICEABLE PARTS INSIDE, REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL
OPERATION
1. Prior to switching ON, turn volume down to minimum.
2. Connect the audio source to the appropriate input socket.
3. Connect to the mains supply.
4. Switch ON the audio source followed by the active speaker.
5. Set the volume with the applicable control.
6. Adjust the bass +treble.
7. When using the speaker using the built-in battery, if you nd the MP3 screen
ickering which indicates the battery voltage is low, turn OFF the speaker box
and charge battery.
8. If you don't use the unit frequently, please do remember to charge the unit
every three months to keep the battery in good condition.
Note: Please turn OFF the product when fully charged.
CAUTION: TO REDUCE THE RISK OF
ELECTRIC SHOCK, DO NOT REMOVE
COVER [OR BACK]
THIS PRODUCT MUST BE EARTHED

www.PyleUSA.com
3
INSTRUCTIONS
• Do not overload the box to avoid damage to the speakers.
• Do not place to an open re (candles etc) on top or next to the box- FIRE HAZARD
• Only connect to an earthed mains outlet of 110Vac/60Hz.
• For indoor use only. If the box will be used outdoors, you need to make sure
that no humidity can enter the box.
• When not in use, unplug the unit from the mains.
• Unplug the unit from the mains prior to checking or replacing the fuse.
• Make sure that the box is placed on a stable, strong surface.
• The boxes can be hung. Use only strong and approved mounting material.
During the mounting, make sure that nobody is standing below the mounting
area.
• Do not place liquids on the box and protect it against humidity. Humidity can
shorten the life time considerably.
• Only use suitable means of transportation if you want to move the box -
USE EXTRA CAUTION HANDLING THE BACK PANEL.
• Always unplug the unit during a thunderstorm or when it is not in use.
• If the unit has not been used for a long period of time, condensation can occur
inside the housing. Please let the unit reach room temperature prior to use.
• Never try to repair the unit yourself.
It does not contain any user serviceable parts.
• Run the mains lead in such a way that nobody can fall over it and nothing can
be put in it
• Set the unit to the lowest volume prior to switching it on.
• Keep the unit out of the reach of children.

www.PyleUSA.com
4
Controls and Connections
1. LED Screen
2. Mp3 control
3. SD Card Slot
4. USB PORT
5. Treble Control
6. Volume Control:
Used to adjust the signal level from the Mp3/Line input/Microphone
7. Bass control
8. Mic VOL: Used to adjust the signal level from MIC1, MIC2 and VHF
9. ECHO EFFECT FOR MICROPHONE
10/11. Mic Input: 6.35mm Jack for a microphone input
12. RCA line output
13. Power ON/OFF LED
14. Battery charging LED
15. RCA line input
16. Wireless microphone antenna
17. Wireless microphone antenna
18. External Power: DC 12V Input
19. Voltage switch
20. FUSE
21. AC Power: Connect the incorporated AC power cord
22. ON/OFF Power switch

www.PyleUSA.com
5
Controls and Connections
2
1
2
3
4
5
7
6
8
9
10
16
11
1
17
13
14
15
18
19
21
22
20

www.PyleUSA.com
6
PPHP109WMU
Wireless & Portable BT PA Speaker
Active-Powered Loudspeaker System, Built-in Rechargeable Battery,
USB/SD Readers, Includes Handheld Microphone, Recording Ability,
FM Radio (1000 Watt, 10'' Subwoofer)
Features:
• Versatile High-Powered Mobile Cabinet Speaker System
• Rugged, Durable, and Reliable Sound
• Wireless BT Music Streaming Ability
• Speaker System: 10'' Woofer, 1.34'' Tweeter
• Compression Driver with Titanium Diaphragm
• Built-in Rechargeable Battery
• 2-Way Full Range Audio Projection
• Built-in Digital Audio Amplier
• RCA (L/R) Stereo Line Input Connectors
• RCA (L/R) Stereo Line Output Connectors
• Connect & Stream Audio from External Devices
• USB Flash Drive & SD Memory Card Readers
• USB Reader Doubles as Device Charging Port
• FM Radio with Digital LCD Display
• ID3 Tag Song Readout Info: LCD Displays Song Title/Song Artist
• Rear Panel Rotary Dial & Button Control Center
• Master Volume, Mic Volume, Echo, Treble, Bass Setting
• (2) 1/4'' Microphone Inputs
• Convenient Carry Handles
• 35mm Speaker Stand Mount
• Engineered Heavy Duty ABS Housing
MP3 Audio Recording Ability:
• It's Easy: One Button Record Activation
• Record Audio as Streamed through the Speaker System
• Ability to Record Vocals via Microphone
• Can Also Record Audio via Line & Aux Inputs
• Records to USB Flash & SD Memory Card
• Easy Transfer to PC & Mac

www.PyleUSA.com
7
Wireless BT Streaming:
• Simple & Hassle-Free Pairing
• Works with All of Today’s Latest Wireless BT Devices
(Smartphones, Tablets, Laptops, Computers, etc.)
• Wireless BT Version: 5.0
• Wireless BT Network Name: 'Pyle Audio'
• Wireless Range: 100'+ ft.
What's in the Box:
• PA Speaker
• Wireless Handheld Microphone
• Headset Microphone
• Beltpack Transmitter
• Power Cable
• Remote control
Technical Specs:
• Power Output: 1000 Watt MAX
• Amplier Class: AB
• Impedance: 4 Ohm
• T.H.D.: <1%
• Sensitivity: 95dB (+/-2dB)
• Mic Input Level: <15mV
• Line Input/output Level: >250mV
• Frequency Response: 100-18kHz
• Digital Audio File Compatibility: MP3, WMA
• Maximum SD/USB Flash Memory Support: 32GB
• Battery Operated Mic / Beltpack,Requires (4) x '5A', -Each (Included)
• Power Supply: 110/220V
• Dimensions (L x W x H): 10.2'' x 12.5'' x 19.3'' –inches
