Pyle PDIC3FR User manual

Aluminum Framed Speaker Pairs
Models: PDIC3FR - PDIC35 - PDIC4
Speaker Pairs with Built-in LED Lights
Models: PDICLE3FR - PDICLE35 - PDICLE4
Models: PDICBTL3F - PDICBTL35 - PDICBTL4
4-Channel Kits with Built-in LED Lights + Bluetooth
2-Channel Kits with Built-in LED Lights + Bluetooth
Models: PDIC4CBTL3B - PDIC4CBTL35B - PDIC4CBTL4B
IN-WALL / IN-CEILING UNIVERSAL MOUNTABLE
ALUMINUM ALLOY-FRAMED SPEAKER SYSTEMS
INSTALLATION MANUAL

Aluminum Framed Speaker Pairs
Models: PDIC3FR - PDIC35 - PDIC4
Speaker Pairs with Built-in LED Lights
Models: PDICLE3FR - PDICLE35 - PDICLE4
Connect the red and black cables to their respective positive and negative terminals.
- Speakers ‘A’ and ‘B’ connect to an amplifier source ‘C’
Speaker Wiring
After connecting the red and black cables to their respective positive and negative terminals, connect
the LED Driver Unit to an external power source. The speakers feature integrated wiring cables with
clip connectors -- be sure to observe proper power requirements (LED Driver Input).
- Speakers ‘A’ and ‘B’ connect to an amplifier source ‘C’
- LED Power Driver ‘D’ connects the speakers to the EXTERNAL room’s power supply
- Integrated wiring with clip connector ‘E’ for LED Power Driver connection
Speaker + LED Light Power Wiring
E
E

Models: PDICBTL3F - PDICBTL35 - PDICBTL4
2-Channel Kits with Built-in LED Lights + Bluetooth
Speaker + LED Light Power Wiring + Bluetooth Control
• Bluetooth Verslon:4.0
• Bluetooth Network Name:Pyle
• Bluetooth Network Password:'0000'
• Bluetooth Wireless Range:30'+Feet
Bluetooth Wiring
Connect the speakers to the Bluetooth Receiver Controller with the included speaker wire -- be
sure to properly connect the speaker wire to their respective positive and negative terminals,
as indicated by the speaker connection terminal. Then, the included power supply adapter cable
connects and provides powers the Bluetooth Receiver Controller.
LED Light Wiring
Connect the LED Driver Unit to an external power source. The speakers feature integrated wiring
cables with clip connectors -- be sure to observe proper power requirements (LED Driver Input).
- Speakers ‘A’ and ‘B’ connect to the Bluetooth Receiver Controller ‘C’
- LED Power Drivers ‘D’ connect the speakers to the EXTERNAL room’s power supply
- Integrated wiring with clip connector ‘E’ for LED Power Driver connection
- Included speaker wires ‘F’ connect the speakers to the speaker connection terminal
- The power adapter ‘H’ connects to the DC 12V power input on the Bluetooth Controller
- The Bluetooth Controller also features an Audio AUX Input Connector ‘G’ -- which allows
you to connect and stream audio from external devices
H
EE
G

Bluetooth Wiring
Connect the speakers to the Bluetooth Receiver Controller with the included speaker wire -- be
sure to properly connect the speaker wire to their respective positive and negative terminals,
as indicated by the speaker connection terminal. Then, the included power supply adapter cable
connects and provides powers the Bluetooth Receiver Controller.
LED Light Wiring
Connect the LED Driver Units to an external power source. The speakers feature integrated wiring
cables with clip connectors -- be sure to observe proper power requirements (LED Driver Input).
- Speakers ‘A, B, C and D’ connect to the Bluetooth Receiver Controller ‘E’
- LED Power Drivers ‘J’ connect the speakers to the EXTERNAL room’s power supply
- Integrated wiring with clip connector ‘K’ for LED Power Driver connection
- Included speaker wires ‘F’ connect the speakers to the speaker connection terminals that
are located on the Bluetooth Receiver Controller
- The power adapter ‘H’ connects to the DC 12V power input on the Bluetooth Controller
- The Bluetooth Controller also features an Audio AUX Input Connector ‘G’ -- which allows
you to connect and stream audio from external devices
• Bluetooth Version:4.0
• Bluetooth Network Name:Pyle
• Bluetooth Network Password:`0000'
• Bluetooth Wireless Range:30'+Feet
Models: PDIC4CBTL3B - PDIC4CBTL35B - PDIC4CBTL4
4-Channel Kits with Built-in LED Lights + Bluetooth
G
H
J
J J
J
K
K
K
K

Thank you for purchasing the PYLE Aluminum Alloy-Frame speaker system. These speakers were designed and manufactured for your installation needs and have been thoroughly tested to ensure consistent and reliable performance. For further information, installation assistance or product troubleshooting visit us on PyleUSA.com
Additional Aluminum Frame Speakers & Options:
Model Number Amount of
Speakers
Speaker
Size
MAX Output
Power
Aluminum
Housing
Built-in
Tweeter
LED Light
Bulb
Bluetooth
Receiver Aux In Cut-Out
Diameter
Mounting
Depth
PDIC3FR PDICLE3FR PDICBTL3F PDIC4CBTL3B PDIC35 PDICLE35 PDICBTL35 PDIC4CBTL35B PDIC4 PDICLE4 PDICBTL4 PDIC4CBTL4B
2 2 2 4 2 2 2 4 2 2 2 4
3.0" 3.0" 3.0" 3.0" 3.5" 3.5" 3.5" 3.5" 4.0" 4.0" 4.0" 4.0"
100 Watt 100 Watt 100 Watt 200 Watt 140 Watt 140 Watt 140 Watt 280 Watt 160 Watt 160 Watt 160 Watt 320 Watt
3.7" 3.7" 3.7" 3.7" 4.2" 4.2" 4.2" 4.2" 4.5" 4.5" 4.5" 4.5"
2.2" 2.4" 2.4" 2.4" 2.5" 2.7" 2.7" 2.7" 2.7" 3.0" 3.0" 3.0"

1600-63rd Street
Brooklyn,NY 11204 USA
