Exibel BTX80 User manual

Bluetooth högtalare ·Bluetooth-høyttaler
Bluetooth-kaiutin ·Bluetooth-Lautsprecher
Ver. 20230831
English 2
Svenska 8
Norsk 14
Suomi 21
Bluetooth Speaker
Art.no. Model
38-8874-1 BTX80 V.3

2
English
Exibel Bluetooth Speaker
Art.no 38-8874-1 Model BTX80
Please read the entire instruction manual before using the product and then save it for
future reference. We reserve the right for any errors in text or images and any neces-
sary changes made to technical data. In the event of technical problems or other que-
ries, please contact our Customer Services (see address details on the back).
Safety
• Do not place the speaker in constant sunlight or near naked flames such as
wood-burning stoves or lit candles.
• Never subject the speaker to high temperatures, dusty environments, heavy
vibrations or impacts.
• Protect your hearing. Listening on high volume for prolonged periods can lead to
permanent hearing loss.
• The speaker must only be repaired by qualified service technicians.
Buttons and functions
Change tracks, increase volume
On/off, play/pause, ma-
nage calls
Change tracks, decrease volume

3
English
Charging
1. Connect the included charging lead to the USB-C port and to
a USB charger or computer.
2. The LED indicator will shine red when charging is in progress.
The LED indicator will go out once the battery is fully charged.
When the LED indicator flashes red and the speaker emits an audible signal,
it means that the battery power is low and the battery needs to be charged.
Dividing the speaker into two
The speaker can be separated into two speakers for better stereo sound or you can
play music from two different external devices on each speaker.
Connecting the speakers in stereo mode "TWS"
(True Wireless Stereo)
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
1. Turn off Bluetooth on your device.
2. Press and hold [
]for two seconds
on each speaker. The speakers will
emit a short audible signal and the
LED indicator will flash blue.
When one of the speakers stops flashing they are paired
with each other and are waiting to be connected to
Bluetooth from an external device.

4
English
3. Activate Bluetooth on the device
to be connected to the speaker.
4. Select “BTX80” when the device
appears on the Bluetooth list. The
speaker will emit an audible signal
and the LED indicator will shine a
steady blue once contact has been
established.
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
Turn the speakers on
Press and hold [
]for two seconds. The speaker will emit a short audible signal and
the LED indicator will flash blue.
2s
LR
2s
Turn the speakers off
Press and hold [
]for two seconds on either speaker.
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
Connecting to a speaker
1. Press and hold [
]for two seconds.
The speaker will emit a short
audible signal and the LED indicator
will flash blue.
2. Activate Bluetooth on the device to be
paired with the speaker.
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR

5
English
3. Select “BTX80” when the device appears on
the Bluetooth list. The speaker will emit an audible
signal and the LED indicator will shine a steady
blue once contact has been established.
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
Audio playback
1. Start playback on the connected device.
2. You can control playback from your device or using the buttons on the speaker:
1×
1×
1×
1× 2s
1×
1×
1×
1×
2s
1×
1×
1×
1×
2s
1×
1×
1×
1×
2s
Press [
]to start and
pause music playback.
Press [ ] or [ ] to raise
or lower the volume.
Press and hold [ ] or
[ ] for 2 seconds to
change tracks.
Call management
If you have connected a mobile phone to the speaker via Bluetooth and receive a call
whilst you are listening to music, the the music will be switched off automatically and
the call will be played through the speaker. When the call has ended, audio playback
resumes.
1×
2×
1×
2×
Press [
]once to
answer the call.
Press [
]once again to
end the call.
Use [ ] or [ ] to adjust
the volume on the call.
Press [
]twice to
reject a call.

6
English
Light effects
1×
1×
1×
1×
LR
LR
LR
1×
1×
1×
1×
LR
L
R
LR
1. Increase the volume on the external audio device to start the light effects.
2. Press both arrows at the same time to change between fixed blue light or light that
pulses in time with the music.
3×
1. Press [
]three times in quick succession on one of the
speakers. Playback continues on one speaker while the
indicator light flashes blue on the other speaker, TWS stereo
mode has now been exited.
2. The other speaker can now be connected to another
external device.
Exiting stereo mode TWS
Factory Reset
If one of the speakers looses contact with the bluetooth device and playback stops
you can perform a factory reset.
1×
1×
1×
1×
2s
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
1. Turn off Bluetooth on your device. 2. Turn on both speakers. Press and
hold [ ] or [ ] for 2 seconds on
either speaker.

7
English
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
3. Activate Bluetooth on the device to
be paired with the speaker.
4. Select “BTX80” when the device
appears on the Bluetooth list. The
speaker will emit an audible signal
and the LED indicator will shine a
steady blue once contact has been
established.
Specifications
Connections
Bluetooth
ID Shale
Output power 0.44 dBm
Frequency response 2402–2480 MHz
Range approx. 10 m
AUX 3.5 mm audio jack
USB USB flash drive. Supports: MP3, WMA, MAV, APE, FLAC
Other
Built-in battery 1800 mAh lithium, 3.7 V
Charging time approx. 2.5 hours
Playback time approx. 15 hours
IP rating IPX7
Speaker 2 x 10 W
Dimensions Ø 78.5 mm, height 206.5 mm
Weight 2×430 g

8
English
Care and maintenance
• The speaker is resistant to water and moisture so you can leave it outdoors.
• Clean the speaker using a lightly moistened cloth. Use only mild cleaning agents,
never solvents or corrosive chemicals.
Responsible disposal
This symbol indicates that the product should not be disposed of with
general household waste. This applies throughout the entire EU. In order
to prevent any harm to the environment or health hazards caused by
incorrect waste disposal, the product must be handed in for recycling
so that the material can be disposed of in a responsible manner. When
recycling your product, take it to your local collection facility or contact the
place of purchase. They will ensure that the product is disposed of in an
environmentally sound manner.

9
Svenska
Bluetooth högtalare Exibel
Art.nr 38-8874-1 Modell BTX80 V.3
Läs igenom hela bruksanvisningen före användning och spara den sedan för framtida
bruk. Vi reserverar oss för ev. text- och bildfel samt ändringar av tekniska data. Vid
tekniska problem eller andra frågor, kontakta vår kundtjänst.
Säkerhet
• Placera inte högtalaren i ihållande solljus eller i närheten av öppen eld, som
vedspis/kamin eller levande ljus.
• Utsätt aldrig högtalaren för höga temperaturer, dammig miljö, starka vibrationer
eller stötar.
• Skydda din hörsel. Lyssning med hög volym under lång tid kan leda till bestående
hörselskador.
• Högtalaren får endast repareras av kvalificerad servicepersonal.
Knappar och funktioner
Höj volymen, byt spår
På/av, spela upp/pausa,
samtalsstyrning
Sänk volymen, byt spår

10
Svenska
Laddning
1. Anslut medföljande laddkabel till USB-C-anslutningarna och till valfri
USB-laddare eller dator.
2. LED-indikatorn lyser med fast rött sken när laddning pågår.
När batteriet är fulladdat släcks indikatorn.
När LED-indikatorn blinkar rött och högtalaren avger en ljudsignal är
batterikapaciteten låg och batteriet behöver laddas.
Dela till två högtalare
Man kan dela högtalaren till två och placera ut dem för ett bredare stereoljud eller
spela upp från två olika externa enheter på varsin högtalare.
Anslut högtalarna i stereoläge "TWS" (True Wireless Stereo)
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
Bluetooth
OFF
Bluetooth
ON
Bluetooth
Devices
BTX80
L
L
R
R
LR
1. Stäng av bluetooth på din enhet.
2. Tryck och håll in [
]i två sekunder på
båda högtalarna. Högtalarna ljuder
och LED-indikatorn blinkar i blått.
När den ena högtalaren slutat blinka är de
ihopkopplade med varandra och inväntar bluetooth
sammankoppling från en extern enhet.
