Pyle PSW119ST1 User manual

Warning: Some TV require two people to lift, as we are not responsible for any
personal injury or product damage due to mishandling.
Warning:
Step 3: Hanging display
Firstly lift the bracket mounted display over the wall mount. And then hook the
brackets over the top of the wall mount. Rotate the display let the bottom of the
brackets hook over the bottom of wall mount, as shown in Fig.3a. Then put safe
bolts into the bottom of the brackets and lock it, as shown in Fig.3b.
Step 3: Hanging display
Thank you for choosing our productsThank you for choosing our products
-8- IMPORTANT: If don’t understand about right install ways, please
consult to normal installing specialist.
IMPORTANT:
Item No.:PSW119ST1Item No.:PSW119ST1
Multifunctional double deck wall mount
Tilt Flat Panel TV Bracket
Easy installing: Just hang up the display
Safety: locking by spinning bolt on the bottom
Max load capacity:60kg/132lbs
TV size range: 26 ~36
Adjustable angle: 5 15
""
-~
Inside has balance adjust system
Bulit in leveler system
INSTALLATION GUIDE
4
Fig 3a
2,3
1
Fig 3b
UP
UP
www pyleaudio com..
MADE IN CHINA
Pyle Audio
1600 63rd st , Brooklyn, NY, 11204
(718)236-8000
After determining the height of stand, follow the installation instructions in below
to install wall mount to different kinds of wall -wooden, concrete.
Using a awl or nail to make where the nails are located, as shown as fig.2b. Distance
between two nails for fixing wall mount must not less than 12”. Pre-drill these holes
with a 5mm drill bit to at least 50mm in deep hole. Please make sure these holes are
level and located at center. Use wall mount as a template to mark the location of other
three holes and drill the same holes. Fix the wall mount to the wall with 4 long bolts(H)
and washers(J).
Wooden wall:
Wooden wall:
-2- -7-
Hardware List: Actual parts appearance and the quantity may different
with illustrated.
Hardware List:
6
6
H
I
J
K
6
4
Square washer
Long bolt
Wall anchor
Long bolt washer
Spacer
ID Description
1
2
A
3
B
C
1
1
4
1
4
4
Wall mount
Left bracket
Right bracket
M4 mm×12 bolt
M4 mm×16 bolt
M5× mm16 bolt
M6×16mm bolt
M5×36mm bolt
M6×36mm bolt
Qty
D4
4
4
4
E
F
G
42
Safe bolt
A-F J
GI
HK
ID Description
Qty
Fig 2b Fig 2c
Concrete wall:
Using the wall mount as template to mark 6 holes location on the wall. There holes are
located at the top row of the slots and three more are located at the bottom row. The
outer holes must be fall to the left and right of the two holes in the middle of the
mount. Please make sure these holes are level and at least 6” between any two lines.
Pre-drill these holes with a 10mm drill bit to at least 50mm deep hole. Insert wall
anchors(I) into each of these holes. Attach the wall mount to the wall using 6 long
bolts(H) and washers(J).
Concrete wall:
1
23
4
J
1
H
Balance-adjusting
Using balance-adjusting system on the plate, make sure whether wall plate is installed
balance. If not, then slide the wall plate let pointer level in the center position.
UP
UP
-6- -3-
b
15 degree
viewing angle
eyelevel
a
Fig 2a
Step 2: mount to wall
First, determine the height of stand
The best height of stand is parallel to eyelevel of a person who sitting on a couch.
Normally, the horizontal distance of eyelevel is about 4’ from ground level.
The following two conditions are for determining the perfect height of stand:
1) the distance between wall and couch(Fig 2a).
2) the distance of eyelevel from ground level plus the distance measured from
eyelevel of a person sitting on couch with viewing angle of 15 (Fig 2a).
For example:
1) the distance of ‘a’ is 5’-7’, the distance of ‘b’ is about 1’
2) the distance of ‘a’ is 8’-13’, the distance of ‘b’ is about 3’
3) the distance of ‘a’ is 14’-17’, the distance of ‘b’ is about 4’
The perfect height of stand centre will be anywhere within b, where you feel
comfortable for viewing.
°
AttachStep 2: Attach mount to wall
WARNING
We are not responsible for any personal injury or product damage due to mishandling,
incorrect mounting, incorrect assembly or incorrect use of this product.
The supplied wall mounting hardware is not for use on steel stud walls or cold
cinder block walls. If you are uncertain about the nature of your wall, please consult a
qualified contractor. If the hardware you required is not included please contact your
local hardware store.
Note:
Caution:This Product LCD /Plasma Wall Mount Bracket is intended for use only
with the maximum weights indicated .See apparatus instructions .Use with products
heavier than the maximum weights indicated may result in instability causing possible
injury .
Caution:
Fig.1
Step 1: Attach bracket to TV
CheckyourTVmanualtoconfirmthediameterofbolttobeusedorchoosean
appropriate bolt according to size, height and position of the holes on your TV. See
pages 4-5 of these instructions for examples.
For correct installing, make sure that hook of every bracket must facing down. Use
selected bolts, spacers and washers for installing bracket at the back of display.
Adjust two brackets to equal heights and level. Once aligned, tightly secure the
bolts. As shown in Fig.1.
Don't force the bolt into the hole, which will cause a damage of
equipments and injure of person. Don't use electric drill to fasten any bolts.
Note:the UP side on the top"" .
IMPORTANT:
Step 1: Attach bracket to TV
IMPORTANT
Note:
UP
UP
2. Some displays have curved backs with
recessed mounting lands(Fig.a). It will
require the use of spacer. For this display,
install a spacer(K) between display and
thebracket.AsshowninFig1b.
Fig a
-4-
-5-
Following examples shows how to use bolts, spacers and square washers.
1.Some displays have vertical backs. No spacer is required. Install the bracket directly
to the back of display by using bolts and square washers provided. As shown in Fig.1a.
Fig 1a
Fig 1b
M6 Fig bitM5 Fig bit
E
3G
K
M5 Fig bitM4 Fig bit
M6 Fig bit
A,B
3
G
2C
G
D
G
3
K
F
G
3
