Pyle PSW601AT User manual

Item No.:PSW601ATItem No.:PSW601AT
TV Size Range: 32 50
Maximum Weight Capacity: 60kg/132lbs
Adjustable angle: 5 15
"～ "
-～°°
Balance adjust system is included
This product was designed to be installed on wood stud walls and solid concrete walls.
Before installing make sure the supporting surface will support the combined load of the
equipment and hardware. Never exceed the Maximum Load Capacity. This product is
intended for indoor use only. Use of this product outdoors could lead to product failure or
personal injury.
CAUTION
INSTALLATION GUIDE
-8-
This product contains small items that could be a choking hazard if swallowed. Keep
these items away from young children
1.Make sure these instructions are read and completely understood before attempting
installation. If you are unsure of any part of this installation, contact a professional
installer for assistance.
2.The wall or mounting surface must be capable of supporting the combined weight of
the mount and the display; otherwise the structure must be reinforced
3.Safety gear and proper tools must be used. A minimum of two people are required
for this installation. Failure to use safety gear can result in property damage, serious
injury or death.
!
.
Warning
Thank you for choosing our productThank you for choosing our product
±90° ±180°
±90°
Part 5-Adjusting display and using cord management
Route cords along articulating arms using cord management s(5).
Articulating arms can be adjusted to position display into desired location.
Use6x6and5x5wrenchtotightenandloosenthetensionscrew.Donot
overtighten and do not loosen to the point the screws come out.
clip
Part 5-Adjusting display and using cord management
UP
UP
5x5 wrench
6x6 wrench
www pyleaudio com..
MADE IN CHINA
Pyle Audio
1600 63rd st , Brooklyn, NY, 11204
[phone]

-2-
Hardware Kit:Hardware Kit:
-7-
Warning: Some TV require two people to lift, as we are not responsible
for any personal injury or product damage due to mishandling.
Warning:
Part 4- Hanging display
Firstly lift the bracket mounted display over the mount. And then hook
the brackets over the top of the mount. Rotate the display let the
bottom of the brackets hook over the bottom of mount. Then put safety
bolts into the bottom of the brackets and lock it.
Part 4- Hanging display
Plastic cover
Lock open
2,3
1
Knob
Lock closed
Part 3-Attaching p cover to wall platelastic
Secure plastic cover over wall plate by pushing them toward each other
untiltheylockinplace.
Part 3-Attaching pcoverto wall platelastic
1
2
43
7
6
5
A-H LI K
JM
Right bracket
6
6
6
4
I
J
K
L
M
Square washer
Long bolt
Wall anchor
Long bolt washer
Spacer
Description
Arm assembly
Left bracket
M4 mm×12 bolt
M4 mm×16 bolt
M5× mm16 bolt
M6× mm16 bolt
M8×16mm bolt
M ×36mm5 bolt
M6×36mm bolt
M ×36mm8 bolt
D4
4
4
4
4
4
E
F
G
H
ID Description
Qty
Plastic cover
6×6mm wrench
5×5mm wrench
ID
1
2
4
A
3
5
B
C
1
1
2
4
1
3
4
4
Qty
7
62
2
Cable management clip
9
88
4
Tapping screw
Side plastic cover
8
9

-6- -3-
Wood stud
J
L
Bubble level
Part 1a-Wood Stud Mounting
.
Use wall plate as a template, make sure it is level, and mark four mounting
holes along the center lines of the wood studs. Drill four 3/16
)) ..
”
”
(5mm)dia
holes 2 (50mm) deep. Level wall plate and attach to wall with four long
bolts(J and four washers(L . Tighten screws firmly Do not overtighten
Part 1a-Wood Stud Mounting
2 50mm)”(
Φ3/16 (5mm)”
I
M
F-H
Part 2b-Attaching brackets to screen with recessed back
Center brackets vertically on back of screen. Select the medium(F or G) or
large(H) screws. Attach brackets to screen using four selected screws,four
square washers(I) and four spacers(M) at the top and bottom of each bracket.
Tighten screws firmly. Do not overtighten.
Part 2b-Attaching brackets to screen with recessed back
Square washer(I)
Medium hole for
M5andM6screws
Large hole for
M8 screws

-4-
-5-
Part 1b-Concrete Wall Mounting
.
Level wall plate and use it as a template to mark six holes. Drill six 3/8
(10mm) dia. holes 2 (50mm) deep. Insert six anchors(K) into holes and
secure wall plate with six long bolts(J) and six washers(L).Tighten screws
firmly. Do not overtighten
”
”
Part 1b-Concrete Wall Mounting
Concrete Wall
2(”50mm)
Φ3/8 (10mm)”
A-E
I
.
Part 2a-Attaching Brackets To Screen With Flat Back
Center brackets vertically on back of screen. Select the small(A or B),medium
(C or D) or large(E) screws. Attach brackets to screen using four selected
screws and four square washers(I) at the top and bottomof each bracket.
Tighten screws firmly. Do not overtighten
Part 2a-Attaching Brackets To Screen With Flat Back
Square washer(I)
Small hole for
M4 screws
Medium hole for
M5 and M6 screws
Large hole for
M8 screws
J
L
Bubble level
K
