Pyle PSWLE81 User manual

TV Size Range: 26 42
Maximum Weight Capacity: 25kg/55lbs
VESA: 400X400
Safety automatic lock
Unlock cord
"～ "
CAUTION
-8-
This product contains small items that could be a choking hazard if swallowed. Keep
these items away from young children
1.Make sure these instructions are read and completely understood before attempting
installation. If you are unsure of any part of this installation, contact a professional
installer for assistance.
2.The wall or mounting surface must be capable of supporting the combined weight of
the mount and the display; otherwise the structure must be reinforced
3.Safety gear and proper tools must be used. A minimum of two people are required
for this installation. Failure to use safety gear can result in property damage, serious
injury or death.
!
.
Warning
This product was designed to be installed on wood stud walls and solid concrete walls.
Before installing make sure the supporting surface will support the combined load of the
equipment and hardware. Never exceed the Maximum Load Capacity. This product is
intended for indoor use only. Use of this product outdoors could lead to product failure or
personal injury.The depth of this mount(1.3 ) may not provide sufficient space for proper
ventilation on some screens. Please refer to the manufacturer’s requirements for mounting
your screen befourinstallation.
"
Wrench 4x4
±180°
±180°
±180°
Part 5-Adjusting display and using cord management
Route cords along articulating arms using cord management s.
Articulating arms can be adjusted to position display into desired location.
Use wrench(8) to tighten and loosen the tension screw. Do not overtighten
or overloosen to make the screws come out.
clip
Part 5-Adjusting display and using cord management
-5 15°~ °
±5°
Thank you for choosing our productThank you for choosing our product
Item No.:PSWLE81Item No.:PSWLE81
INSTALLATION GUIDE
www pyleaudio com..
Pyle Audio
1600 63rd st , Brooklyn, NY, 11204
[phone]

-2-
Hardware Kit:
Hardware Kit:
-7-
1
2
3
4
Part 4-Mounting the flat panel screen
NOTE:
Hook the top of brackets onto the top flange of wall plate(1). Then
swing the screen down. Fixed slide block into wall plate by screw.
(2)
Always use an assistant or mechanical lifting equipment to safely lift
and position heavy equipment.
Part 4-Mounting the flat panel screen
NOTE:
5
Magnetic removable
bubble level
A-D H
EG F
6
7
6
7
2
8
ID Description
1
2
6
3
B
1
2
2
4
Screw
M5 mm×16 bolt
Qty Description
Square washer
Long bolt
Wall anchor
Long bolt washer
M8×16mm bolt
M6× mm16 bolt
4
2
ID Qty
3
3
F
G
H3
D4
4
E
C4
Ribbon
Wall plate
Bracket
5
1TV plate
2Plastic cover
72Slide block(Position lock)
A4M4 mm×16 bolt
81Wrench(4x4)
Before installation, please attach these two decorative end caps to the two
sides of TV plate.(FIG.A)
FIG.A

-3-
Wood stud
Part 1a-Wood Stud Mounting
.
Usewallplate(1)asatemplate,makesureitislevel,andmark
mounting holes on the wood studs. Drill 3/16
)
)..
three
three (4.5mm)dia holes 50
mm deep. Level wall plate(1) and attach to wall with three long bolts(G and
three washers(F . Tighten screws firmly Do not overtighten
”
Part 1a-Wood Stud Mounting
Stud finder
50mm
Φ3/16 (4.5mm)”
-6-
.
Part 3-Attaching brackets to screen
Center brackets vertically on back of screen. Select the
Attach brackets to screen using four selected
screws and four square washers(E) at the top and bottom of each bracket.
small(A),medium
(B or C) or large(D) screws.
Tighten screws firmly. Do not overtighten
Part 3-Attaching brackets to screen
A-D
E
Square washer(E)
Small hole for
M4 screws
Medium hole for
M5andM6screws
Large hole for
M8 screws
Magnetic removable
bubble level
G
F

5
Part 2-Attaching plastic covers to wall plate
Secure plastic covers over wall plate by pushing them toward each other
until they lock in place.
Part 2-Attaching plastic covers to wall plate
-4-
-5-
Part 1b-Concrete Wall Mounting
.
Level wall plate and use wall as a template to mark three holes. Drill three
7/16 (10.5mm) dia. holes 58mm deep. Insert three anchors(H) into holes
and secure wall plate with three long bolts(G) and three washers(F).Tighten
screws firmly. Do not overtighten
”
Part 1b-Concrete Wall Mounting
Concrete Wall
G
58mm
Φ7/16 (10.5mm)”
F
H.
If you think the ribbon is too long, You can hide it at the back of the
televesion,once you want to uninstall the TV, it can help you to take out the
brackets
Magnetic removable
bubble level
3
