Q.PEAK DUO-G10.X solar module series

INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X2 3
Table of contents 1 Introduction
With solar modules from Hanwha Q CELLS GmbH (hereafter
referred to as "Qcells") you can directly transform the sun’s
limitless energy into environmentally-friendly solar electricity.
In order to ensure the maximum performance of your Qcells
solar modules, please read the following instructions carefully
and observe all guidelines. Non-compliance may result in
damage and / or physical injury.
This installation and operation manual (hereafter also referred to
as the “Manual”) provides instructions for the safe installation and
operation of crystalline solar modules.
Please read these instructions carefully before proceeding with
your installation.
Please retain these instructions for the life of the solar modules.
Please ensure that this Manual is available to the operator at all
times.
This Manual should be given to all subsequent owners or users
of the solar modules.
All supplements received from the manufacturer should be
included.
Please observe all other applicable documents.
If your questions are not satisfactorily answered in the manual,
please contact your system supplier.
Additional information can be found on our website at www.
qcells.com/.
Intended use
This manual is valid for Africa, Asia, Europe, Latin America, South
America. These instructions contain information regarding the
safe handling and use of quality crystalline solar modules from
Qcells and their installation, mounting, wiring, maintenance and
disposal.
Symbols and Labels
The following symbols and labels are used throughout the
Manual for ease of use.
SYMBOL DESCRIPTION
Procedure with one or more steps.
Lists of items.
Ensure that when carrying out a procedure,
you check the results of said procedure.
Prohibited.
Beware of possible danger or damage.
Categories:
■Danger: Risk of fatal injury
■Attention: Risk of serious injury or damage to
property
■Note: Risk of damage to product
Safety Regulations
In particular the installer as well as the operator of a module
is responsible for compliance with all applicable statutory
requirements and regulations.
Unless otherwise specified by any laws or regulations, the
following stipulations must be upheld at all times during the
installation, operation, and maintenance of the solar modules:
■This manual.
■Other applicable stipulations (such as country-specific
regulations for pressure equipment, operational safety,
hazardous goods, and environmental protection).
■Regulations and requirements specific to the system.
■Any applicable laws and requirements, in particular
international, country specific, regional laws and stipulations
governing the planning, installation, and operation of solar
power systems and work on roofs.
■Any valid international, national and regional regulations
governing work with direct current, especially those
applicable to the installation of electrical devices and
systems, and regulations issued by the respective energy
provider governing the parallel operation of solar power
systems.
■Any international, country specific and regional accident-
prevention regulations.
■Other applicable stipulations provided by the relevant
national institutions regarding safety in the installation and
operation of electrical items.
Qualified and Skilled Personnel
Both, the installer and operator are responsible for ensuring that
the installation (including connection to the grid), maintenance
and dismantling are carried out by trained and qualified
specialists with approved training certificates (issued by a state
or federal organization) for the respective specialist trade.
Electrical work may only be performed by an officially certified
tradesperson in accordance with the stipulations applicable in
the relevant country with regard to standard and regulations
(in Germany e. g. DIN standards, VDE regulations) and the
stipulations of the local grid operator and / or energy provider.
DOCUMENT REVISION 01
This Manual is valid for Africa, Asia, Europe, Latin America and South America as of June 1st 2022 for Q.PEAK DUO-G10.X solar modules, and replaces all earlier versions.
DISCLAIMER
This manual is subject to change. The data sheets and customer information valid at the point in time when the relevant module was manufactured apply to the installation, mounting,
and maintenance procedures for the respective solar modules, as far as no updated document is provided.
1 Introduction 3
2 Planning 5
2.1 Technical specifications 5
2.2 Requirements 6
2.3 Mounting options 7
2.4 Electrical layout 10
3 Installation 11
3.1 Safety and transport 11
3.2 Preparation of installation 13
3.3 Module installation 14
4 Electrical connection 15
4.1 Safety 15
4.2 Electrical installation safety 16
4.3 Connection of modules 17
4.4 After installation 18
5 Grounding 19
6 Faults and defects 19
7 Disposal 19
8 Maintenance and cleaning 20

INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X4 5
1 Introduction
Validity
These instructions are only valid for crystalline solar modules
from the company Qcells as specified at chapter "2.1 Technical
specifications". Qcells assumes no liability for damage resulting
from failure to observe these instructions.
Please observe the wiring and dimensioning of the system.
The installer of the system is responsible for compliance with
all necessary safety regulations during set-up and installation.
Qcells assumes no liability on the basis of these instructions.
Qcells is only liable in the context of contractual agreements or
in the context of accepted guarantees. Qcells accepts no other
responsibility for the functionality and safety of the modules.
Please observe the instructions for any other system
components that may be part of the complete solar power
system. It may be necessary to carry out a structural analysis
for the entire project.
Additional information for the Operator
Please keep this manual for the entire life of the solar power
system.
Please contact your system supplier for information concerning
the formal requirements for solar power systems.
Please be sure to contact the relevant local authorities
and energy providers regarding regulations and permit
requirements prior to installation of the solar power system.
Your financial success depends on the fulfillment of these
requirements.
Other applicable documents
In addition to this Manual following technical information are
relevant:
Document type
Product data sheet
Packaging and transport information
MISUSE OR INCORRECT USE OF SOLAR MODULES VOIDS
THE LIMITED WARRANTY AND MAY CREATE A SAFETY
HAZARD AND RISK PROPERTY DAMAGE. THIS INCLUDES
IMPROPER INSTALLATION OR CONFIGURATION, IMPROPER
MAINTENANCE, UNINTENDED USE, AND UNAUTHORIZED
MODIFICATION.
2 Planning
2.1 Technical specifications
For additional information see the relevant datasheet of the module provided at www.qcells.com/.
PRODUCT LINE
Q.PEAK DUO-G10
Q.PEAK DUO-G10+
Q.PEAK DUO-G10.a
Q.PEAK DUO-G10.a+
Q.PEAK DUO BLK-G10
Q.PEAK DUO BLK-G10+
Q.PEAK DUO BLK-G10.a
Q.PEAK DUO BLK-G10.a+
Q.PEAK DUO-G10.4
Q.PEAK DUO-G10.4+
Q.PEAK DUO BLK-G10.4
Q.PEAK DUO BLK-G10.4+
Type Q.ANTUM DUO Z Q.ANTUM DUO Z Q.ANTUM DUO Z
Length 1717 mm 1717 mm 1717 mm
Width 1045 mm 1045 mm 1045 mm
Frame height 32 mm 32 mm 32 mm
Area 1.79 m² 1.79 m² 1.79 m²
Weight 19.9 kg 19.9 kg 19.9 kg
Max. system voltage VSYS 1000 V 1000 V 1000 V
Max. reverse current 20 A 20 A 20 A
Permissible temperature range –40 °C to +85 °C (–40 °F to +185 °F)
Junction box protection class IP67 with bypass diode
Connector protection class IP68
Fire rating based on ANSI /
UL 61730 C / Type 2 C / Type 2 C / Type 2
Max. test load Push / Pull18,100 Pa / 4,000 Pa 8,100 Pa / 4,000 Pa 8,100 Pa / 4,000 Pa
Max. design load Push / Pull15,400 Pa / 2,660 Pa 5,400 Pa / 2,660 Pa 5,400 Pa / 2,660 Pa
Certificates CE-compliant; IEC 61215:2016; IEC 61730:2016; PV module classification: Class II;
UL 61730; QCPV
1Test and design load in accordance with IEC 61215:2016, depending on mounting options (see section "2.3 Mounting options")
DETAIL A 16 mm
8.5 mm
21.25 mm
980 mm
1717 mm
4 × Mounting slots
(DETAIL A)
Frame
1045 mm
32 mm
8 × Drainage holes
368.5 mm
EN
4 × Grounding points ø 4.5 mm
Label
≥ 1150 mm
≥ 1150 mm
1002.5 mm
Fig. 1: External dimensions and components for Q.PEAK DUO-G10, Q.PEAK DUO-G10+, Q.PEAK DUO-G10.a,
Q.PEAK DUO-G10.a+, Q.PEAK DUO-G10.4, Q.PEAK DUO-G10.4+, Q.PEAK DUO BLK-G10, Q.PEAK DUO BLK-G10+,
Q.PEAK DUO BLK-G10.a, Q.PEAK DUO BLK-G10.a+, Q.PEAK DUO BLK-G10.4 and Q.PEAK DUO BLK-G10.4+.
Attention!
This marking indicates that this product should not be disposed
of with other household waste within the EU. Recycle this product
properly to prevent possible damage to the environment or
a risk to human health via uncontrolled waste disposal and in
order to promote the sustainable reuse of material resources.
Please return your used product to an appropriate collection
point or contact the retailer where you purchased this product.
Your retailer will accept used products and return them to an
environmentally-sound recycling facility.

INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X6 7
2 Planning
2.2 Requirements
Installation Site
Please note the following guidelines that apply to the installation
site:
■Solar modules are not explosion-proof and are not suitable for
use in explosive environments.
Do not operate solar modules near highly flammable gas and
vapors (e.g. gas tanks, gas stations).
Do not install modules in enclosed space.
Do not install modules in locations where they may be
submerged in water (e.g. floodplains).
Do not use modules as a substitute for the normal roofing (e.g.
modules are not watertight).
Do not install modules in close proximity to air conditioning
systems.
Do not install modules above 4000 m (13120 ft) altitude above
sea level.
Contact with saline water (e.g. spray water from the sea) and
salt aggregation on the modules must be avoided.
Do not bring any chemical substance (e.g. oil, solvent etc.) into
contact with any part of the panel. Only substances, which are
released by Qcells, are allowed to be used during installation,
operation and maintenance.
Any installation of modules on surfaces of water is prohibited.
This includes installations on floating as well as pile-based
platforms. Qcells may extend the coverage of its warranty to
such installations, based on a case by case assessment of
the system design and location. A prior written consent by the
warrantor is required in any case.
The solar modules are designed for the following applications:
■Operating temperatures from –40 °C to +85 °C
(–40 °F to +185 °F).
■Pull loads up to max. 4,000 Pa and push loads up to max.
8,100 Pa (see chapter "Mounting options").
■Installation using a mounting structure for solar modules.
Prevention of Shadowing Eects
Optimal solar irradiation leads to maximum energy output:
For this reason, install the modules so that they face the sun.
Avoid shadowing (due to objects such as buildings, chimneys
or trees).
Avoid partial shading (for example through overhead lines, dirt,
snow).
Mounting Structure Requirements
The Modules shall be installed and operated on mounting
structures that comply with any applicable laws and stipulations
as well as with the following:
■Conform to the necessary structural requirements.
■Compliant with local snow and wind loads.
■Properly fastened to the ground, the roof, or the façade.
■Forces acting on the module are relayed to the mounting
substructure.
■Ensures sucient rear ventilation of the module.
■Avoid the usage of different metals to prevent contact
corrosion.
■Allows for stress-free expansion and contraction due to
temperature fluctuations.
Ensure that no additional forces are applied through the
mounting system into the module except for the wind and snow
loads. Additional forces and moments of torque at the mounting
positions caused by torsions, displacements or vibrations in the
mounting system are not allowed.
Ensure that the clamps and the mounting frame are compatible.
Clamp System Recommendations
Use customary clamps that satisfy the following requirements:
■Clamp width: ≥ 40 mm.
■Clamp height compliant with a 32 mm frame height.
■Clamp depth: 7-12 mm. (applicable for all CL clamping mounting
options at section "2.3 Mounting options")
■Clamps are not in contact with the front glass.
■Clamps do not deform the frame.
■Clamps that satisfy the structural requirements based on the
conditions of the installation site according to the applicable
regulations and technical standards.
■Long-term stable clamps that securely ax the module to the
mounting frame.
Module Orientation Requirements
■Vertical or horizontal installation is permitted.
Ensure that rain and melting snow can run o freely. No water
accumulation.
Ensure that the drainage holes in the frame are not covered.
No sealing.
75°
3°
Maintain the permissible angle of inclination.
■Minimum angle of inclination: 3°
■Inclination angles above 75° may be limited by
local regulations
Standing water on the modules glass needs to be
avoided.
2 Planning
2.3 Mounting options
Fig. 2: Installation options for crystalline Qcells modules. All dimensions are given in mm. Also observe the maximum test loads and
clamping range as specified on the following page.
The illustrated installation options apply for both horizontal and vertical module orientation.
Module Clamp Subconstruction Mounting profile
TYPE OF
INSTALLATION POINT MOUNTING SYSTEM LINEAR MOUNTING SYSTEM
Installation
with clamps
300 - 500
EUROPE
ASIA
CL1a
20 - 650
CL1b
15 - 210
300 - 500
EUROPE
ASIA
CL1a
20 - 650
CL1b
15 - 210
CL2a
20 - 300
CL2b
20 - 300
CL2a
20 - 300
CL2b
20 - 200
xxx - xxxx
EUROPE
xxx - xxx
CL6b
560 - 1160
20 - 400
CL6a
EUROPE
CL6c
20 - 400
CL6d
20 - 250
560 - 1160 560 - 1160
EUROPE
CL6c
20 - 400
CL6d
20 - 250
560 - 1160 560 - 1160
CL3 CL4
240 - 350
200 - 350
0 - 300
0 - 300
CL3 CL4
CL4
0 - 200
ROW
CL3
200 - 350
Hybrid clamping
300 - 450
EUROPE
20 - 100
CL5

INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X8 9
2 Planning
2.3 Mounting options
TYPE OF
INSTALLATION POINT MOUNTING SYSTEM LINEAR MOUNTING SYSTEM
Installation
on mounting
points
EN
4 x Mounting
points
368.5
FB1
EN
4 × Mounting
points
368.5
FB2
Installation
with insertion
profiles
not permitted
IP1 IP2
IP1 IP2
Specifications
MOUNTING
OPTION
POSITION OF
CLAMPS* [MM]
TEST LOAD
PUSH / PULL** [Pa]
DESIGN LOAD
PUSH / PULL** [Pa]
SAFETY
FACTOR
CL1a
130 - 350 5400 / 4000 3600 / 2660
1.5
20 - 450 5400 / 3600 3600 / 2400
20 - 650 2400 / 2400 1600 / 1600
CL1b 300 - 500 2400 / 2400 1600 / 1600
CL2a
(with rails) 20 - 300*** 3600 / 2400 2400 / 1600
CL2b
(without rails) 20 - 200 2400 / 2400 1600 / 1600
CL3 240 - 350 4000 / 4000 2660 / 2660
FB1 368.5 5400 / 4000 3600 / 2660
FB2 368.5 4000 / 4000 2660 / 2660
IP1 -
3600 / 3300 2400 / 2200
CL5 short side: 20 - 100
long side: 300 - 450
CL6a outer clamps: 20 - 400
middle clamps: 560 - 1160*** 8100 / 4000 5400 / 2660
CL6c outer clamps: 20 - 400
middle clamps: 560-1160*** 3600 / 3600 2400 / 2400
CL6d short side: 20 - 250
long side: 560-1160*** 4000 / 3600 2660 / 2400
*
**
***
Distance between outer edge of module and middle of the clamp; consider further details below.
Loads according to IEC 61215-2:2016 and UL 61730.
Rails must not be under the junction box.
MOUNTING OPTIONS REQUIREMENTS
All The loads in the table are related to the mechanical stability of the solar modules. The
mechanical stability of the mounting system including clamps has to be evaluated by the system
supplier. The listed test load values have been determined with the following clamp parameters:
clamp width = 40 mm and clamp depth = 10 mm.
The system installer is responsible for the determination of location-specific load requirements.
Ensure that the connection cables of the junction box do not run between laminate and
mounting rails.
Modules bend under load. Therefore, sharp objects (e.g. screws, ballast stones, rail ends, rails
with burrs or sharp corners) must not be placed near the module backside so as not to touch
the laminate under load.
Ensure that the junction boxes do not touch the mounting structure (e.g. shorts rails, ballast, etc.)
or the rooftop under load. Clamps or insertion profiles etc. must not touch the glass (even under
load).
Unbalanced loads (e.g. snow overhangs, snowdrifts) which result in locally significantly
increased loads must be removed or avoided by technical measures.
CL1a, CL2a, CL3,
CL6a, FB1, FB2
Ensure that module frame is fixed directly on the rail of the substructure (no spacer allowed
between the module and substructure).
CL1a At push test loads of 5400 Pa: The clamp position is variable in the given range but the distance
between the clamps along the long side of the module (span) must not be larger than 1250 mm.
CL1b Using of short mounting rails are permissible, if they overlap under the module less than
210 mm. Minimum clearance between frame bottom edge and roof top must be ≥ 35 mm.
CL1b, CL2b, CL3,
FB2, CL6c, CL6d A minimum support depth of 15 mm is required on the back side of the module.
CL5 The minimum required support depth on the module backside is 10 mm on long frame side and
15 mm on short frame side.
IP1 Ensure minimum support depth of 15 mm on the backside and 10 mm on the front side of the
module.
FB1, FB2 Use M8 corrosion-proof screws and washers (diameter ≥ 15.8 mm) for mounting slots (Detail A,
Fig.1). Mounting screws and washers should have the same material properties.
CL6c, CL6d Use of short mounting rails under the modules are permissible, if they do not touch the laminate
under load.
2 Planning
2.3 Mounting options

INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X10 11
3 Installation
3.1 Safety and transport
Leave modules in their original packaging until
installation.
Store the modules securely in cool and dry rooms.
The packaging is not weatherproof.
Inspect the packaging for damages.
Contact the transport company regarding any
damage to the packaging and follow their
instructions.
Follow any instructions on the packaging.
Ensure that all personnel are aware of and adhere to
accident-prevention and safety regulations.
While working wear clean gloves.
§
GB
§
I
§
D
Danger! Risk of fatal injury due to electric shock!
Do not install damaged modules.
Inform your distributor of any damages immediately.
Warning! Fire Risk!
Do not install modules indoors.
Do not install modules on moving objects.
2 Planning
2.4 Electrical layout
Module Selection
For detailed key electrical data, please refer to the actual data
sheet referring to the relevant Module (available at www.qcells.
com/).
For maximum energy yields, mismatches of specified electric
current (IMPP) of more than 5 % should be avoided for all
modules connected in series.
Safety Factor
For detailed key electrical data, please refer to the actual data
sheet referring to the relevant Module (available at www.qcells.
com).
■During normal operation, a module may generate a greater
current and / or higher voltage than that determined under
standardized test conditions. Please use a safety factor of 1.25
for the following:
■Calculating the voltage measurement values (VOC) of
components
■Calculating the current measurement values (ISC) of conductors
■Sizing of control systems connected to the outlets of the solar
modules
Please follow the valid national guidelines for the installation of
electrical systems.
Series Connection
Connection of modules in series is only permitted up to the
maximum system voltage as listed in the applicable data sheet of
all the relevant modules to be installed.
Take into account all possible operating situations and all
relevant technical norms and regulations when designing the
system. It has to be ensured that the maximum system voltage,
including all necessary safety margins, is not exceeded.
Take the voltage limit of the inverter into account when
determining the maximum number of modules in the string.
Parallel Connection
Modules may be damaged by the occurrence of reverse currents
(caused by module defects, ground leaks, or defective insulation).
Ensure that the maximum reverse current load capacity
indicated in the data sheet is met.
In order to limit reverse currents that may occur, we recommend
using the following safety options:
1) Layout with a limited number of parallel connected strings :
Without undertaking further current blocking measures, a
maximum of two module strings may be operated in parallel on a
single inverter or MPP tracker.
2) Layout with string fuses :
Use overcurrent devices (e.g. fuses) according to the relevant
standards in each string. Use gPV-fuses according to IEC
60269-6. Observe the maximum permitted number of strings as
indicated in the specifications provided by the respective string
fuse manufacturer and the technical guidelines.
NOTE!
When installing different product versions, the lowest minimum
permitted reverse current load capacity applies.
Inverters
Inverters with or without transformers may be used.

INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X12 13
3 Installation
3.2 Preparation of installation
Danger! Risk of fatal injury due to electric shock!
Block o the installation zone.
Keep children and unauthorized individuals away
from the solar power system.
Danger! Risk of fatal injury due to electric shock!
Ensure that modules and tools are not subject to
moisture or rain at any time during installation.
Warning! Risk of injury due to falling modules!
Secure modules during installation.
Do not install modules in windy or wet weather.
Danger! Risk of fatal injury due to electric shock!
Only use dry, insulated tools.
Do not carry out the installation alone.
■Only install undamaged modules and components.
Do not modify the module
(e.g. do not drill any additional holes).
3 Installation
3.1 Safety and transport
Note! Module damage may occur!
Do not stack modules.
Note! Module damage may occur!
Do not install modules near flammable gas / vapors.
Do not install modules in close proximity to air
conditioning systems.
Note! Module damage may occur!
Do not drop modules.
Note! Module damage may occur!
Only make modifications to the module which have
been confirmed in writing by Qcells.
confirmation
letter
Note! Module damage may occur!
Never lift or move the module with the connection
cables or junction box.
Carry modules upright and horizontally as shown.
Note! Module damage may occur!
Never step on modules.
Do not subject modules to any mechanical stress.
Do not allow any objects to fall onto modules

INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X14 15
10 mm
5 mm
EU
4 Electrical connection
4.1 Safety
Danger!
Risk of fatal injury due to electric shock!
When disconnecting an electric circuit carrying direct current,
electric arcs can occur that may result in life-threatening injuries.
Do NOT unplug the cable when under load.
Do NOT connect any exposed cable ends.
Electrical work may only be performed by qualified and skilled
personnel (see page 3).
A solar module generates electrical current and voltage even
at a low intensity of illumination. Sparks and electric arcs may
result from the separation of a closed circuit. These can result
in life-threatening injuries. The danger increases when several
modules are connected in series.
Please be aware of that the entire open circuit voltage is active
even at low levels of solar irradiation.
Please follow the valid national regulations and safety
guidelines for the installation of electrical devices and systems.
Please make sure to take all necessary safety precautions. With
module or phase voltages of more than 120 V, the safety extra-
low voltage range is exceeded.
Carry out work on the inverter and the wiring with extreme
caution.
Ensure that the modules are disconnected at the inverter prior
to separation.
Be sure to observe the time intervals specified by the inverter
manufacturer after switching o the inverter.
Make sure that the plugs can not be connected unintentionally.
Before working on the contacts, check them for safety extra-
low voltage.
Danger! Risk of fatal injury due to electric shock!
Only use dry, insulated tools for electrical work.
Danger! Risk of fatal injury due to electric shock!
Never open the junction box.
Do not remove bypass diodes.
Danger! Risk of fatal injury due to electric shock!
Never touch live contacts with bare hands.
Cover connectors by suitable protective caps until
installation.
Danger! Risk of fatal injury due to electric shock!
Insulate any exposed cable ends.
Only connect cables with plugs.
3 Installation
3.3 Module installation
Option 1:
Fasten the module with 4 clamps in the specified
clamping range, see Fig. 2 , p. 7.
Tighten clamps according to manufacturer’s
instructions.
Maintain an interval of at least 10 mm between two
modules along the short side and 5 mm along the
long side.
Note! Module damage may occur!
Do not subject modules to mechanical tension. Max.
torsion 10 mm / m.
Option 2:
Install the module at the 4 mounting points,
see Fig. 2 , p. 7.
Tighten screws according to manufacturer’s
instructions.
Option 3:
Install the module at the 4 mounting points,
see Fig. 2 , p. 7.

INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X16 17
4 Electrical connection
4.3 Connection of modules
Use solar cables for the connection at the junction
box outlet.
Only interconnect connectors of the same type and
manufacturer.
Use minimum 4 mm2copper wires insulated for a
minimum of 90 °C for field connections.
Note! Module damage may occur!
Ensure that the cabling is not under mechanical stress
(Comply with bending radius of ≥ 60 mm).
Ensure that the cables do not run between module
and mounting rail or structure (danger of pinch).
Do not connect modules with dierent orientations or
angles of inclination in the same string.
Ensure for a tight connection between the plugs.
Plugs click together audibly.
EN
click
Danger! Risk of fatal injury due to electric shock!
Ensure that all electrical components are in a proper,
dry, and safe condition.
To avoid complex cabling arrangements, it is often
advantageous to rotate some modules 180°.
Module orientation can clearly be identified from the
front side by the serial number and barcode labelled
behind the module glass on the side with negative
connection cable.
SOLAR
4 Electrical connection
4.2 Electrical installation safety
Danger! Risk of fatal injury due to electric shock!
Be sure to maintain the time intervals as specified by
the inverter manufacturer between switching o the
inverter and beginning any further work.
Danger! Risk of fatal injury due to electric shock!
Never plug or unplug the cable when under load.
Modules must not carry any current.
1. Switch o the inverter.
OFF
EN
2. Switch o the DC circuit breaker.
3. Measure shutdown in DC String.
(no DC current flow).
4. Disconnect plugs by the use of appropriate
and qualified tools of the manufacturer.
5. When connecting the modules proceed in reverse
order.
Danger! Risk of fatal injury due to electric shock!
Electrical work may only be performed by qualified
and skilled personnel (see page 3).
Ensure correct polarity.
EN
Inverter
180° 180°

INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X18 19
5 Grounding
Protective Grounding
The modules must be grounded in accordance with the local
statutory regulations.
6 Faults and defects
Danger!
Risk of fatal injury due to electric shock!
Do not attempt to fix any problems yourself (e.g., glass cracks,
damaged cables).
Please contact an installer or Qcells Technical Customer
Service Department.
7 Disposal
Do not disconnect modules by yourself.
Please contact an installer or Qcells Technical Customer
Service Department.
Dispose of modules in accordance with the local disposal
regulations.
4 Electrical connection
4.4 After installation
Ensure that all necessary safety and functional tests
have been carried out according to applicable
standards.
Note! Module damage may occur!
Ensure that the plug connections are secured away
from any water-channelling surface.
Integrate the system into the existing lightening
protection system in accordance with the applicable
local regulations.
Warning! Fire Risk!
Do not use light concentrators (e.g. mirrors or lenses).
Ensure that the cabling is not exposed and / or
hanging and is protected from dirt, moisture and
mechanical friction.

INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X INSTALLATION AND OPERATION MANUAL SOLAR MODULES Q.PEAK_DUO-G10.X20 21
8 Maintenance and cleaning
Qcells solar modules are known for a long operating life and
minimal maintenance eort and expense. Dirt and grime are
usually washed away by rain. If the module is fully or partially
shaded by dirt or debris (e.g., plants, bird droppings), it needs
to be cleaned to prevent a loss of performance.
Maintenance
The PV system has to be inspected regularly by certified
personnel
The time intervals and extent of the inspection can depend
on local circumstances (e.g. salt, ammonia content in the air,
high humidity etc.). The customer / operator must inform himself
about time intervals and extend of necessary inspections.
Inspections have to be performed especially after extraordinary
events (e.g. storm, hail, high snow loads etc.)
During the inspections it has to be checked that the
components are secure, undamaged and clean
Cleaning
WARNING!
Risk of injury due to hot and live modules!
Only clean modules that have cooled down.
Do not carry or wear any electrically conductive parts.
WARNING!
Risk of falling due to unsecured access!
Never access the installation area alone or without taking
adequate security precautions.
Please commission a trade specialist.
NOTE!
Module surface damage may occur!
Remove snow and ice carefully without force (e.g. with a very
soft broom).
Do not scratch o dirt.
Module cleaning has to be done by qualified personnel
according to the state of the art and taking into account all
relevant safety issues and general product properties, e.g., but
not restricted to:
■electrical safety
■mechanical stability (load limits depending on the actual
mounting options)
■chemical suitability (no effect to any of the module‘s
components, e.g. cable, connector, silicone)
■no abrasive materials.
NOTE!
Dust and dirt are abrasive materials!
The situation for each individual project (or type of dirt) must
always be professionally evaluated.
Wrong cleaning may cause damages such as, but not limited
to, damages to the glass surface (e.g. scratches) and AR
coating, power loss, delamination, loss of frame-to-laminate
bond, reduced snow and wind load capability etc.
Apart from the above, each customer is free to choose the
method of cleaning. However, possible damages, caused by
the cleaning or related to the cleaning tools or agents shall
not be covered by the module‘s Product and Performance
Warranty. Therefore it is recommended to use only the tools
and agents which have already been successfully tested and
used with PV modules, to prevent possible damage.
Isopropyl alcohol (IPA) can be used selectively to remove
stubborn dirt and stains within one hour after emergence.
Free the substructure from any dirt and debris (leaves,
bird nests, etc.).
Note! Module damage may occur!
Do not clean modules with water if there is a risk of
frost.
0°

Subject to change without notice. © Qcells Installation manual solar modules Q.PEAK_DUO-G10.X_2022-06_Rev02_EN
Hanwha Q CELLS GmbH
OT Thalheim Sonnenallee 17 – 21 06766 Bitterfeld-Wolfen Germany
EMAIL
WEB
TEL
FAX
[email protected]
www.qcells.com
[phone] – 23222
[phone] – 23000
