Qsan Technology XCubeFAS 2026 User manual

XCubeFAS 2026
Hardware Manual
September 2021

XCubeFAS 2026
Hardware Manual
Announcement
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
i
ANNOUNCEMENT
Copyright
© Copyright 2021 QSAN Technology, Inc. All rights reserved. No part of this document may be
reproduced or transmitted without written permission from QSAN Technology, Inc.
QSAN believes the information in this publication is accurate as of its publication date. The
information is subject to change without notice.
Trademarks
QSAN, the QSAN logo, QSAN.com, XCubeFAS, XCubeSAN, XCubeNXT, XCubeNAS, XCubeDAS,
XEVO, SANOS, and QSM are trademarks or registered trademarks of QSAN Technology, Inc.
Microsoft, Windows, Windows Server, and Hyper-V are trademarks or registered
trademarks of Microsoft Corporation in the United States and/or other countries.
Linux is a trademark of Linus Torvalds in the United States and/or other countries.
UNIX is a registered trademark of The Open Group in the United States and other countries.
Mac and OS X are trademarks of Apple Inc., registered in the U.S. and other countries.
Java and all Java-based trademarks and logos are trademarks or registered trademarks of
Oracle and/or its affiliates.
VMware, ESXi, and vSphere are registered trademarks or trademarks of VMware, Inc. in the
United States and/or other countries.
Citrix and Xen are registered trademarks or trademarks of Citrix Systems, Inc. in the United
States and/or other countries.
Other trademarks and trade names used in this document to refer to either the entities
claiming the marks and names or their products are the property of their respective owners.

XCubeFAS 2026
Hardware Manual
Announcement
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
ii
TABLE OF CONTENTS
Announcement........................................................................................................................... i
Notices......................................................................................................................................ix
Regulatory Statements...............................................................................................................x
FCC Statement ........................................................................................................................... x
CE Statement ............................................................................................................................. x
UL Statement............................................................................................................................. x
Preface.....................................................................................................................................xv
About This Manual....................................................................................................................xv
Related Documents ..................................................................................................................xv
Technical Support....................................................................................................................xvi
Information, Tip, and Caution .................................................................................................xvi
Conventions............................................................................................................................xvii
1. Product Overview............................................................................................................. 1
1.1. Introduction to XCubeFAS Series....................................................................................1
1.2. Hardware Specifications.................................................................................................1
1.3. Package Contents ...........................................................................................................4
2. System Components Overview ......................................................................................... 5
2.1. Front Panel......................................................................................................................5
2.2. Rear Panel.......................................................................................................................9
2.3. Power Supply Units.......................................................................................................13
2.4. Fan Modules .................................................................................................................15
2.5. Cache-to-Flash Memory Protection .............................................................................16
2.6. (Optional) Host Cards ...................................................................................................20
3. Installing the System Hardware........................................................................................28
3.1. Installation Checklist.....................................................................................................28
3.2. Installing Disk Drives into the Trays..............................................................................29

XCubeFAS 2026
Hardware Manual
Announcement
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
iii
3.3. Installing the Slide Rails ................................................................................................32
3.4. Installing the Trays into the System .............................................................................35
3.5. Connecting the System to a Host .................................................................................36
3.6. Connecting Power Cords ..............................................................................................37
3.7. Powering ON the System..............................................................................................38
3.8. Discover and Carry Out the System..............................................................................39
3.9. Powering OFF the System.............................................................................................39
3.10. (Optional) Connecting a UPS ........................................................................................40
3.11. (Optional) Connecting the USB LCM.............................................................................40
3.12. (Optional) Wake-on-LAN / Wake-on-SAS.....................................................................41
4. Quick Maintenance..........................................................................................................42
4.1. Removing / Installing Controller Module .....................................................................42
4.2. Installing Optional Memory Modules...........................................................................46
4.3. Removing / Installing Power Supply Unit .....................................................................49
4.4. Removing / Installing Fan Module................................................................................51
4.5. Removing / Installing Cache-to-Flash Module..............................................................54
4.6. Removing / Installing Optional Host Cards...................................................................56
5. Deployment Types and Cabling........................................................................................62
5.1. Deployment Types........................................................................................................62
5.2. Cabling the System .......................................................................................................62
6. Support and Other Resources ..........................................................................................73
6.1. Getting Technical Support ............................................................................................73
6.2. Online Customer Support.............................................................................................75
6.3. Accessing Product Updates ..........................................................................................79
6.4. Documentation Feedback.............................................................................................80
Appendix..................................................................................................................................81
End-User License Agreement (EULA).......................................................................................81

XCubeFAS 2026
Hardware Manual
Announcement
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
iv
FIGURES
Figure 1-1 XF2026 Form Factors.....................................................................................................2
Figure 2-1 System Controls and Indicators.....................................................................................5
Figure 2-2 Disk Drive Numbering....................................................................................................7
Figure 2-3 Disk Drive Indicators of SFF Disk Drive Tray ..................................................................8
Figure 2-4 Rear Panel Layout..........................................................................................................9
Figure 2-5 Components of Controller Module .............................................................................10
Figure 2-6 Controller LEDs ............................................................................................................12
Figure 2-7 Location of the Power Supply Unit..............................................................................13
Figure 2-8 Components of the Power Supply Unit.......................................................................14
Figure 2-9 Location of Each Fan Module Installed .......................................................................15
Figure 2-10 Mechanical Components of the Fan Module..............................................................16
Figure 2-11 Location of the Cache-to-Flash Module ......................................................................17
Figure 2-12 Cache-to-flash Module Pack........................................................................................17
Figure 2-13 Components of Cache-to-Flash Modules....................................................................17
Figure 2-14 Cache-to-Flash Workflow............................................................................................18
Figure 2-15 Flash Module LEDs and Button....................................................................................19
Figure 2-16 Host Card Installation Slots .........................................................................................20
Figure 2-17 2-port 32Gb Fibre Channel Host Card (SFP28) LEDs ...................................................22
Figure 2-18 4-port 16Gb Fibre Channel Host Card (SFP+) LEDs .....................................................23
Figure 2-19 2-port 16Gb Fibre Channel Host Card (SFP+) LEDs .....................................................24
Figure 2-20 2-port 25GbE iSCSI Host Card (SFP28) LEDs ................................................................25
Figure 2-21 4-port 10GbE iSCSI Host Card (SFP+) LEDs ..................................................................26
Figure 2-22 2-port 10GBASE-T iSCSI Host Card (RJ45) LEDs...........................................................27
Figure 3-1 Front Side Components of SFF Disk Drive Trays..........................................................30
Figure 3-2 Unlock and Open the Carrier Handle of a Disk Drive Tray (SFF) .................................31
Figure 3-3 Hold the Carrier Handle and Pull out the Disk Drive Tray (SFF) ..................................31

XCubeFAS 2026
Hardware Manual
Announcement
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
v
Figure 3-4 Align a Disk Drive & Install into a Tray (SFF-to-SFF) ....................................................32
Figure 3-5 First Step of the Slide Rails Installation .......................................................................33
Figure 3-6 Second Step of the Slide Sails Installation...................................................................34
Figure 3-7 Third Step of the Slide Rails Installation......................................................................34
Figure 3-8 Fourth Step of the Slide Sails Installation....................................................................35
Figure 3-9 Install a Tray into the System and Lock the Release Button Lock (SFF) ......................36
Figure 3-10 Cabling Example ..........................................................................................................37
Figure 3-11 The Location of Connecting Power Cords ...................................................................38
Figure 3-12 Press the Power Button One Time to Power on the System ......................................38
Figure 3-13 Power off the System via Web UI................................................................................39
Figure 3-14 Power off the System by Power Button......................................................................39
Figure 3-15 Location for the UPS System Connection....................................................................40
Figure 4-1 Controller Module Failure Warning.............................................................................43
Figure 4-2 Display Warning of the Controller Module through Status LED .................................43
Figure 4-3 Mechanical Components of the Controller Module....................................................43
Figure 4-4 Steps of Removing the Controller Module..................................................................44
Figure 4-5 Installing the Controller Module .................................................................................45
Figure 4-6 Controller Module Installed Successfully ....................................................................45
Figure 4-7 Change Operation Mode to Dual Controller ...............................................................46
Figure 4-8 Memory Module Slot Number ....................................................................................47
Figure 4-9 PSU Failure Warning....................................................................................................49
Figure 4-10 Mechanical Components of the PSU...........................................................................50
Figure 4-11 PSU Installed Successfully............................................................................................51
Figure 4-12 Fan Module Failed Warning ........................................................................................52
Figure 4-13 Mechanical Components of the Fan Module..............................................................52
Figure 4-14 Fan Module Installed Successfully...............................................................................53
Figure 4-15 Pressing Attention Button of the Flash Module..........................................................55
Figure 4-16 Dummy Cage Screw Location of Cache-to-Flash Module ...........................................55

XCubeFAS 2026
Hardware Manual
Announcement
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
vi
Figure 4-17 Cache-to-Flash Module Installed Successfully ............................................................56
Figure 4-18 Example of a Failed Port on the 10GbE iSCSI Host Card .............................................57
Figure 4-19 Removing the Host Card..............................................................................................58
Figure 4-20 Pull out the Host Card and Install the Dummy Host Card Cage ..................................58
Figure 4-21 The Finished Installed Dummy Host Card Cage ..........................................................58
Figure 4-22 Procedures of Removing the Host Card Dummy Cage................................................59
Figure 4-23 Procedures of Installing the Host Card........................................................................60
Figure 4-24 Connection and Status of the Host Cards ...................................................................61
Figure 5-1 One Host / One XCubeFAS / Single Path .....................................................................64
Figure 5-2 One Host / One XCubeFAS / One XCubeDAS / Single Path .........................................64
Figure 5-3 One Host / One HBA / Two Switches / One XCubeFAS / Dual Path ............................65
Figure 5-4 One Host / One HBA / One XCubeFAS / One XCubeDAS / Dual Path..........................66
Figure 5-5 Two Hosts / One HBA per Host / Two Switches / One XCubeFAS / Dual Path............67
Figure 5-6 Ten Hosts / One HBA per Host / One XCubeFAS / Dual Path......................................68
Figure 5-7 Cascade Topology: One XCubeFAS / One XCubeDAS / Dual Path...............................69
Figure 5-8 Cascade Topology: One XCubeFAS / Two XCubeDAS / Dual Path...............................70
Figure 5-9 Reverse Topology: One XCubeFAS / Two XCubeDAS / Dual Path ...............................71
Figure 5-10 Tree Topology: One XCubeFAS / Two XCubeDAS / Dual Path.....................................72
Figure 6-1 Download Service Package..........................................................................................74
Figure 6-2 Appearance of a Console Cable...................................................................................75
Figure 6-3 Connect the Console Cable..........................................................................................75
Figure 6-4 The Procedures of Setup Serial Console by HyperTerminal........................................77
Figure 6-5 The Procedures of Setup Serial Console by PuTTY......................................................79

XCubeFAS 2026
Hardware Manual
Announcement
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
vii
TABLES
Table 1-1 XF2026 Hardware Specifications ....................................................................................2
Table 2-1 Descriptions of the System Controls and Indicators LEDs..............................................6
Table 2-2 Descriptions of Disk Drive LEDs ......................................................................................8
Table 2-3 Rear Panel Layout ...........................................................................................................9
Table 2-4 Description of Controller Module Components ...........................................................10
Table 2-5 Descriptions of Controller LEDs ....................................................................................12
Table 2-6 Location of the Power Supply Unit ...............................................................................13
Table 2-7 Components of the Power Supply Unit ........................................................................14
Table 2-8 Descriptions of the Power Supply Unit LED..................................................................14
Table 2-9 Location of Each Fan Module Installed.........................................................................15
Table 2-10 Mechanical Components of the Fan Module ...............................................................16
Table 2-11 Location of the Cache-to-Flash Module .......................................................................17
Table 2-12 Components of Cache-to-Flash Modules .....................................................................18
Table 2-13 Descriptions of Flash Module LEDs and Button ...........................................................19
Table 2-14 Host Card Installation Slots of a Controller ..................................................................21
Table 2-15 Descriptions of 2-port 32Gb Fibre Channel Host Card (SFP28) LEDs ...........................22
Table 2-16 Descriptions of 4-port 16Gb Fibre Channel Host Card (SFP+) LEDs .............................23
Table 2-17 Descriptions of 2-port 16Gb Fibre Channel Host Card (SFP+) LEDs .............................24
Table 2-18 Descriptions of 2-port 25GbE iSCSI Host Card (SFP28) LEDs........................................25
Table 2-19 Descriptions of 4-port 10GbE iSCSI Host Card (SFP+) LEDs ..........................................26
Table 2-20 Descriptions of 2-port 10GBASE-T iSCSI Host Card (RJ45) LEDs...................................27
Table 3-1 Installation Checklist.....................................................................................................28
Table 3-2 Optional Items for Installation......................................................................................29
Table 3-3 Front Side Components of SFF Disk Drive Trays...........................................................30
Table 4-1 Mechanical Components of the Controller Module.....................................................44
Table 4-2 Optional Memory Module Installation Sequence ........................................................48

XCubeFAS 2026
Hardware Manual
Announcement
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
viii
Table 4-3 Mechanical Components of the PSU ............................................................................50
Table 4-4 Mechanical Components of the Fan Module ...............................................................53
Table 5-1 Deployment Types ........................................................................................................62
Table 5-2 System and Expansion Enclosure Configuration Rules.................................................63

XCubeFAS 2026
Hardware Manual
Notices
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
ix
NOTICES
This user manual is applicable to the following XCubeFAS models:
XCubeFAS Storage System 2U 19”Rack Mount Models
MODEL NAME
CONTROLLER TYPE
FORM FACTOR, BAY COUNT, RACK UNIT
XF2026D
Dual Controller
SFF 26-disk 2U Chassis
XF2026S
Single Controller
SFF 26-disk 2U Chassis
Information contained in this manual has been reviewed for accuracy. But it could include
typographical errors or technical inaccuracies. Changes are made to the document periodically.
These changes will be incorporated in new editions of the publication. QSAN may make
improvements or changes in the products. All features, functionality, and product specifications
are subject to change without prior notice or obligation. All statements, information, and
recommendations in this document do not constitute a warranty of any kind, express or implied.
Any performance data contained herein was determined in a controlled environment.
Therefore, the results obtained in other operating environments may vary significantly. Some
measurements may have been made on development-level systems and there is no guarantee
that these measurements will be the same on generally available systems. Furthermore, some
measurements may have been estimated through extrapolation. Actual results may vary. Users
of this document should verify the applicable data for their specific environment.
This information contains examples of data and reports used in daily business operations. To
illustrate them as completely as possible, the examples include the names of individuals,
companies, brands, and products. All of these names are fictitious and any similarity to the
names and addresses used by an actual business enterprise is entirely coincidental.

XCubeFAS 2026
Hardware Manual
Regulatory Statements
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
x
REGULATORY STATEMENTS
FCC Statement
This device has been shown to be in compliance with and was tested in accordance with the
measurement procedures specified in the Standards and Specifications listed below.
Technical Standard: FCC Part 15 Class A
IC ICES-003
This device complies with Part 15 of the FCC rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
この装置は、クラス A情報技術装置です。この装置を家庭環境で使用すると電波妨害
を引き起こすことがあります。この場合には使用者が適切な対策を講ずるよう要求され
ることがあります。VCC1-A
警告：這是甲類的資訊產品。在居住的環境中使用時，可能會造成射頻干擾，在這種情況
下，使用者會被要求採取某些適當的對策。
CE Statement
This device has been shown to be in compliance with and was tested in accordance with the
measurement procedures specified in the Standards and Specifications listed below.
Technical Standard: EMC DIRECTIVE 2014/30/EU
(EN55032 / EN55035)
UL Statement
Rack Mount Instructions - The following or similar rack-mount instructions are included with
the installation instructions:

XCubeFAS 2026
Hardware Manual
Regulatory Statements
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
xi
1. Elevated Operating Ambient - If installed in a closed or multi-unit rack assembly, the
operating ambient temperature of the rack environment may be greater than room
ambient. Therefore, consideration should be given to installing the equipment in an
environment compatible with the maximum ambient temperature (Tma) specified by the
manufacturer.
2. Reduced Air Flow - Installation of the equipment in a rack should be such that the amount
of air flow required for safe operation of the equipment is not compromised.
3. Mechanical Loading - Mounting of the equipment in the rack should be such that a
hazardous condition is not achieved due to uneven mechanical loading.
4. Circuit Overloading –Careful consideration should be given to the connection of the
equipment to the supply circuit and the effect that overloading of the circuits might have on
overcurrent protection and supply wiring. Appropriate consideration of equipment
nameplate ratings should be used when addressing this concern.
5. Reliable Earthing - Reliable earthing of rack-mounted equipment should be maintained.
Particular attention should be given to supply connections other than direct connections to
the branch circuit (e.g. use of power strips).
CAUTION
The main purpose of the system left and right ears are for 19” rack use only.
Do NOT use those ears to carry or transport the system.
The ITE is not intended to be installed and used in a home, school or public area accessible to
the general population, and the thumbscrews should be tightened with a tool after both initial
installation and subsequent access to the panel.
Warning: Always remove all power supply cords before service
This equipment intended for installation in restricted access locations.
Access should only be allowed by qualified SERVICE PERSONS or by USERS who have been
instructed about the reasons for the restrictions applied to the location and about any
precautions that shall be taken.
Access is through the use of a TOOL or lock and key, or other means of security, and is
controlled by the authority responsible for the location.
Recommended operation temperature: 0 ~ 35℃(31.99 ~ 95°F); operation rating (100-127
Vac, 50-60Hz, 10.0A; 200-240 Vac, 50-60Hz, 5.0A)

XCubeFAS 2026
Hardware Manual
Regulatory Statements
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
xii
CAUTION
CAUTION: (English)
Risk of explosion if battery is replaced by incorrect type. Please replace the
same or equivalent type battery use and dispose of used batteries according
to the instructions.
ATTENTION: (French)
IL Y A RISQUE D'EXPLOSION SI LA BATTERIE EST REMPLACEE PAR UNE
BATTERIE DE TYPE INCORRECT. METTRE AU REBUT LES BATTERIES USAGEES
CONFORMEMENT AUX INSTRUCTIONS.
VORSICHT: (German)
Explosionsgefahr bei unsachgemasem Austausch der Batterie. Entsorgung
gebrauchter Batterien nach Anleitung.
ADVERTENCIA: (Spanish)
Las baterias pueden explotar si no se manipulan de forma apropiada. No
desmonte ni tire las baterias al fuego. Siga las normativas locales al desechar
las baterias agotadas.
警告: (Simplified Chinese)
电池如果更换不正确会有爆炸的危险，请依制造商说明处理用过之电
池。
警告: (Traditional Chinese)
電池如果更換不正確會有爆炸的危險，請依製造商說明處理用過之電
池。

XCubeFAS 2026
Hardware Manual
Regulatory Statements
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
xiii
CAUTION
Replacing incorrect type of battery will have the risk of explosion. Please
replace the same or equivalent type battery use and dispose of used
batteries according to the instructions.
CAUTION RESTRICTED ACCESS LOCATION
This system is intended for installation only in restricted access locations as
defined where both these conditions apply:
Access can only be gained by service persons or by users who have been
instructed about the reasons for the restrictions applied to the location
and about any precautions that shall be taken.
Access is through the use of a tool or lock and key, or other means of
security, and is controlled by the authority responsible for the location.
Warning
Electric shock hazard
The system may have one or more power supply unit (PSU) cords. To avoid
serious injuries, it is recommended that all PSU power cords must be
disconnected by trained service technicians before installing or replacing
system components.

XCubeFAS 2026
Hardware Manual
Regulatory Statements
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
xiv
INFORMATION
QSAN provides limited warranty for QSAN-branded hardware products:
System hardware and peripheral product (s): 3 years limited warranty
from date of original purchase.
Battery Backup Module or super capacitor module (applies for cache-to-
flash module): 1-year limited warranty from date of original purchase.
For more detail warranty policy, please refer to QSAN official web site:
https://www.qsan.com/warranty

XCubeFAS 2026
Hardware Manual
Preface
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
xv
PREFACE
About This Manual
This manual provides technical guidance for designing and implementing QSAN XCubeFAS
series flash-based array system, and it is intended for use by system administrators, SAN
designers, storage consultants, or anyone who has purchased these products and is familiar
with servers and computer networks, network administration, storage system installation and
configuration, storage area network management, and relevant protocols.
CAUTION
Do NOT attempt to service, change, disassemble or upgrade the
equipment’s components by yourself. Doing so may violate your warranty
and expose you to electric shock. Refer all servicing to authorized service
personnel. Please always follow the instructions in this owner’s manual.
Related Documents
There are related documents which can be downloaded from the website.
XCubeFAS QIG (Quick Installation Guide)
XCubeFAS Hardware Manual
XCubeFAS XEVO Software Manual
Compatibility Matrix
White Papers
Application Notes

XCubeFAS 2026
Hardware Manual
Preface
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
xvi
Technical Support
Do you have any questions or need help trouble-shooting a problem? Please contact QSAN
Support, we will reply to you as soon as possible.
Via the Web: https://www.qsan.com/technical_support
Via Telephone: [phone]
(Service hours: 09:30 - 18:00, Monday - Friday, UTC+8)
Via Skype Chat, Skype ID: qsan.support
(Service hours: 09:30 - 02:00, Monday - Friday, UTC+8, Summer time: 09:30 - 01:00)
Via Email: [email protected]om
Information, Tip, and Caution
This manual uses the following symbols to draw attention to important safety and operational
information.
INFORMATION
INFORMATION provides useful knowledge, definition, or terminology for
reference.
TIP
TIP provides helpful suggestions for performing tasks more effectively.
CAUTION
CAUTION indicates that failure to take a specified action could result in
damage to the system.

XCubeFAS 2026
Hardware Manual
Preface
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
xvii
Conventions
The following table describes the typographic conventions used in this manual.
CONVENTIONS
DESCRIPTION
Bold
Indicates text on a window, other than the window title,
including menus, menu options, buttons, fields, and labels.
Example: Click the OK button.
<Italic>
Indicates a variable, which is a placeholder for actual text
provided by the user or system.
Example: copy <source-file> <target-file>.
[ ] square
brackets
Indicates optional values.
Example: [ a | b ] indicates that you can choose a, b, or nothing.
{ } braces
Indicates required or expected values.
Example: { a | b } indicates that you must choose either a or b.
| vertical bar
Indicates that you have a choice between two or more options
or arguments.
/ Slash
Indicates all options or arguments.
underline
Indicates the default value.
Example: [ a | b ]

XCubeFAS 2026
Hardware Manual
Product Overview
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
1
1. PRODUCT OVERVIEW
Thank you for purchasing QSAN Technology, Inc. products. XCubeFAS is the leading entry-level
flash storage array developed to allow all enterprises to easily enter the era of flash storage. It
offers native flash architecture with the exclusive optimization for solid state drive storage, and
delivers the best flash data experience of the next generation.
1.1. Introduction to XCubeFAS Series
QSAN XCubeFAS series is a flash-based array system, the system is composed of system
hardware and the XEVO operating system, the system hardware is a modular design and FRU
(Field Replacement Unit) optimized. All the hardware modules are inside the rack mount
chassis including: system controllers, front panel, rear panel, redundant power supply units and
fan modules, cache-to-flash modules, and expansion slots for optional Fibre Channel or
Ethernet high-speed host cards. This manual will direct you step by step to familiarize you with
the hardware components, how to install the system, carry out the initial configuration, and
provide you with some quick maintenance guidelines.
INFORMATION
For how to use the XEVO operating system, please refer to the XCubeFAS
XEVO Software Manual.
1.2. Hardware Specifications
Following tables are hardware specifications of XF2026.

XCubeFAS 2026
Hardware Manual
Product Overview
© 2021 QSAN Technology, Inc. All rights reserved.
www.qsan.com
Official
Document
2
Figure 1-1 XF2026 Form Factors
Table 1-1 XF2026 Hardware Specifications
MODEL NAME
XF2026D
XF2026S
Form Factor
2U 26-bay, SFF
RAID Controller
Dual-active controller
Single-upgradable controller
Processor
Intel Xeon 4-core processor (8-core processor mode is also available)
Memory (per Controller)
DDR4 ECC 32GB UDIMM, up to 128GB (four DIMM slots, insert two
DIMMs or more will boost performance)
Host Connectivity
(per Controller)
Optional Host Cards at Slot 1 (PCIe Gen3 x 8)
2 x 32Gb FC (SFP28)ports
4 x 16Gb FC (SFP+) ports
2 x 16Gb FC (SFP+) ports
2 x 25GbE iSCSI (SFP28)ports
4 x 10GbE iSCSI (SFP+) ports
2 x 10GbE iSCSI (RJ45) ports
Optional Host Cards at Slot 2 (PCIe Gen2 x 4)
2 x 32Gb FC (SFP28)ports1
4 x 16Gb FC (SFP+) ports1
2 x 16Gb FC (SFP+) ports1
2 x 25GbE iSCSI (SFP28)ports1
4 x 10GbE iSCSI (SFP+) ports1
2 x 10GbE iSCSI (RJ45) ports
