Quadra-Fire REMINGTON QFP40 User manual

1445 North HIghway
Colville, WA 99114
SAVE THESE INSTRUCTIONS
INSTALLATION, VENTING, OPERATION AND MAINTENANCE MANUAL
FOR YOUR SAFETY
DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or
any other appliance.
REMINGTON QFP40
Direct Vent Gas Fireplace
Part #250-4721 (842-3291) 06/2001
www.aladdinhearth.com
[email protected]
This appliance may be installed in an aftermar et permanently located, manufactured
(mobile) home where not prohibited by local codes.
This appliance is only for use with the type of gas indicated on the rating plate.
This appliance is not convertible for use with other gases, unless a certified it is used.
Installation and service m st be performed by a q alified installer, service agency, or the gas s pplier.
WARNING!
If the information in these instructions is not followed exactly a fire or explosion may
result causing property damage, personal injury or death.
WHAT TO DO IF YOU SMELL GAS
NExtinquish any open flame.
NOpen windows.
NDo not try to light any appliance.
NDo not touch any electric switch.
NDo not use any telephone in your build-
ing.
Nmmediately call your gas supplier from a
neighbor’s phone.
NFollow the gas supplier’s instructions.
Nf you cannot reach your gas supplier, call
the fire department.

REM NGTON QFP40 Direct Vent F REPLACE
Page 2 250-4721 JUNE 2001
Aladdin Hearth Products welcomes you to our tradition of excellence! In choosing a Quadra-
Fire appliance, you have our assurance of commitment to quality, durability, and performance.
This commitment begins with our research of the market, including ‘ oice of the Customer’
contacts, ensuring we make products that will satisfy your needs. Our Research and
Development facility then employs the world’s most advanced technology to achieve the
optimum operation of our stoves, inserts and fireplaces. And yet we are old-fashioned when it
comes to craftsmanship. During manufacturing each unit is meticulously fabricated and gold
surfaces are hand-finished for lasting beauty and enjoyment. Our pledge to quality is
completed as each model undergoes a quality control inspection. Additionally, we feel it is
important to offer you several finishing options and accessories to compliment your home’s
décor, individualize the use of your appliance, and provide financial options in acquiring a
quality hearth appliance. Ask your Quadra-Fire Dealer for information on these options. From
design, to fabrication, to shipping: Our guarantee of quality is more than a word, it’s Quadra-
Fire tradition, and we proudly back this tradition with a Lifetime Warranty.
Prior to installation, we ask you to take a few moments to read this manual. It has been our
experience that your overall enjoyment of your new appliance will be greatly enhanced by
becoming familiar with its’ installation, operation and maintenance requirements. We wish you
and your family many years of enjoyment in the warmth and comfort of your hearth appliance.
Thank you for choosing Quadra-Fire.
With warm regards,
President .P. R&D
Controller Operations Mgr. .P. Marketing
Western Sales Mgr. Central Sales Mgr. Eastern Sales Mgr.
Manufacturing Engineer Sr. Purchasing Agent Technical Support Mgr.
Order Fulfillment Mgr. Quality Assurance Mgr Human Resources
WELCOME
CONGRATULATIONS!

Page 3
REM NGTON QFP40 Direct Vent F REPLACE
250-4721 JUNE 2001
MODEL NAME Quadra Fire REMINGTON QFP40
SERIAL NUMBER
Located on front, lower ledge of control panel.
DATE PURCHASED
DEALERSHIP WHERE PURCHASED
DEALER PHONE
ADDITIONAL INFORMATION
After completing your warranty card, attach your sales receipt and
warranty stub here for future reference.
NOTES
NOTES

REM NGTON QFP40 Direct Vent F REPLACE
Page 4 250-4721 JUNE 2001
CONTENTS
CONTENTS
SAFETY & CLEARANCES:
Ratings Plate................................................................................................. 6
Standards Listing & Clearances Label.......................................................... 7
Safety Notices ............................................................................................... 9
SPEC F CAT ONS:
Heating Specifications .................................................................................. 10
ZC Appliance Dimensions............................................................................. 10
Minimum Cabinet Dimensions ...................................................................... 11
NSTALLAT ON PREPARAT ON:
nstallation Terminology ................................................................................ 12
Preparation ................................................................................................... 13
Overview of nstallation to Operation ............................................................ 13
LP Conversion nstructions ........................................................................... 14
NSTALLAT ON:
Minimum Framing Dimensions ..................................................................... 16
Corner nstallations ....................................................................................... 17
Raised Fireplaces ......................................................................................... 18
Hearth Requirements .................................................................................... 20
Mantel Requirements .................................................................................... 21
Arched Fascia Dimensions ........................................................................... 22
Acid Wash Alert............................................................................................. 22
Rectangular Fascia Dimensions ................................................................... 23
Facing Requirements .................................................................................... 24
Facing Over 1" Thick..................................................................................... 25
VENT NG NSTRUCT ONS:
General Venting nstructions......................................................................... 26
Simpson Dura-Vent Parts List & Kits ............................................................ 27
Venting nstallation Options & Guidelines .................................................... 28
Vertical Termination Rule .............................................................................. 28
Termination Cap Requirements .................................................................... 28
Venting nstallation Examples:
Horizontal ........................................................................................... 29
Vertical ............................................................................................... 29
Class A Metal Chimney ...................................................................... 30
Masonry Chimney .............................................................................. 31
How to use Vent Graph................................................................................. 32
Horizontal Termination Requirements........................................................... 33
Horizontal nstallation nstructions ................................................................ 34
Vertical nstallation nstructions .................................................................... 38

Page 5
REM NGTON QFP40 Direct Vent F REPLACE
250-4721 JUNE 2001
CONTENTS
COMPLET NG NSTALLAT ON:
Gas Line Requirements ................................................................................ 46
Electrical Connection ................................................................................... 47
Optional Thermostat Connection ................................................................. 47
Optional Brick nstallation............................................................................. 48
Logset and Nugget nstallation .................................................................... 50
Glass nstallation .......................................................................................... 53
Fascia nstallation ........................................................................................ 53
Leak Test ...................................................................................................... 54
nitial Start-up Normal Occurrences ............................................................. 54
Lighting nstructions ..................................................................................... 55
Shutter Adjustment ....................................................................................... 56
Damper Adjustment...................................................................................... 56
Flame Height Adjustment ............................................................................. 56
Adjusting Blower Speed ............................................................................... 56
Normal Operating Sounds ........................................................................... 56
High Altitude Operation & Adjustment.......................................................... 57
OPERAT ON:
Control Panel ................................................................................................ 58
MA NTENANCE:
General Maintenance ................................................................................... 59
Yearly Servicing ............................................................................................ 60
Glass Replacement ...................................................................................... 61
Blower Replacement .................................................................................... 62
Electrical Schematic ..................................................................................... 63
TROUBLESHOOT NG ............................................................................................ 64
PARTS & ACCESSOR ES ....................................................................................... 66
WARRANTY ............................................................................................................ 67
CONTENTS

REM NGTON QFP40 Direct Vent F REPLACE
Page 6 250-4721 JUNE 2001
1999 2000 2001 JAN FEB MAR MAY JUN JUL AUG SEP OCT NOV DEC
SAFET LABEL
Location: Serial No. portion on lip below control panel. Lower portion behind access door on
baseplate to right of control panel.
1445 N. High ay
Colville, WA 99114
LP NG
Input Rate on “HI” (BTU/Hr) 40,000 40,000
Input Rate on “LO” (BTU/Hr) . 32,000 27,000
Maximum Output (BTU/Hr) 34,400 34,400
Main Burner Orifice Front (DMS)** #56 #47
Main Burner Orifice Rear (DMS)** #53 #42
Minimum Inlet Pressure (Inches W.C.) 11" 4.5"
Maximum Inlet Pressure (Inches W.C.) 14" 7.0"
Manifold Pressure on “HI” (Inches W.C.) 10" 3.5"
**Equipped for installation in Canada for altitudes of 0 - 4500' (1370M); and in USA for alti-
tudes of 0 - 2000' (610M). In USA for altitudes above 2000' the vent configuration, orifice, or
combination of both may need to be changed. See O ner’s Manual for information on making
these changes.
061-S-14-5
APPROVED FOR CANADA AND USA TO:
ANSI Z21.88-1998/CSA 2.33-M1998 Vented Gas Fireplace Heaters and applicable sections of UL307b
Gas Burning Heating Appliances for Mobile Homes and recreational vehicles, CAN/CGA 2.17-M91
“Gas-Fired Appliances for use at High Altitudes”.
SERIAL NO.
FAN TYPE VENTED CIRCULATOR Thermal Efficiency* 84% NG (blo er on)
Blo er Electrical Rating: 86% LP (blo er on)
115V., 1.5 Amps, 60 Hz, 150 atts
* With Maximum horizontal length.
MODEL: REMING ON
MODEL: REMING ON
SERIAL NO.
RATINGS PLATE

Page 7
REM NGTON QFP40 Direct Vent F REPLACE
250-4721 JUNE 2001
Install fireplace in accordance ith all local codes, if any; if none, follo The National Fuel Gas
Codes ANSI Z223.1-1992 and NFPA 54(88); or Canadian Installation Codes CAN/CGA-B149.
Manufactured or Mobile Home Installation This appliance is only for use ith the type of gas indi-
cated on the rating plate and may be installed in an aftermarket, permanently located, manufactured (mo-
bile) home here not prohibited by local codes. Installations must conform ith: USA: Manufactured
Home Construction and Safety Standard, Title 24 CFR, Part 3280. CANADA: CSA Z240.4 and Gas-
Equipped Recreational Vehicles and Mobile Housing.
MODEL: REMINGTON QFP40
VENTED GAS FIREPLACE HEATER
NO FOR USE WI H SOLID FUEL - NO FOR USE WI H AIR FIL ERS
The “Remington QFP40” is factory equipped for natural gas (NG) and is field convertible to pro-
pane gas (LP), hen equipped ith the Conversion Kit #842-4470 available from an Aladdin Hearth
Products dealer. This appliance uses a millivolt-type control system consisting of a gas control valve/
regulator, a standing pilot burner assembly, a thermopile, a piezo ignitor, and the ON/OFF s itch. THIS
UNIT DOES NOT REQUIRE 110 VOLT POWER TO OPERATE. All exhaust gases must be vented
outside the structure of the living area. Combustion air is dra n from outside the living area structure.
WARNINGS:
This appliance should be inspected before use and at least annually by a qualified service person. More
frequent cleaning may be required here excessive lint from material like carpeting and bedding is present.
The control compartment, the burner compartment and all circulating air passage ays of the appliance
must be kept clean and clear at all times. Due to high temperatures, the appliance should be located out
of traffic and a ay from furniture and draperies. This appliance must not be connected to a chimney flue
servicing a separate solid fuel burning appliance. Children and adults should be alerted to the hazards of
high surface temperature and should stay a ay to avoid flesh burns or clothing ignition. Young children
should be carefully supervised at all times hen they are in the same room as the appliance.
CAU ION: All safety screen or guard components removed for servicing, must be replaced prior to
operating the appliance. Clothing or other flammable material should not be placed on or near the appli-
ance. Risk of electrical shock. S itch the household breaker off or remove fuse before servicing unit.
Use Simpson DURA-VENT direct vent system (Model GS) to vent this appliance to the exterior (direct
discharge only ithout duct connection).
Minimum Clearances to Combustibles
To Adjacent Wall:
From glass edge ....................................... 7 3/4"
From side of Rectangular fascia .............. 3"
From side of Arched fascia ...................... 3"
Back to enclosure (from stand-offs) ............. 0"
Top to enclosure (from stand-offs) ............... 0"
Sides to enclosure (from stand-offs)............. 0"
Hearth Extension:
Does not require hearth extension or
non-combustible floor beneath appliance.
To Mantel:
From top of glass edge............................. 30 1/2"
From top of Rectangular Facia ................ 24"
From top of Arched Facia ........................ 22 5/8"
To maximum 1/2" top front facing:
From top of glass edge............................. 20 1/4"
From Arched Facia .................................. 12 1/4"
From Rectangular Facia .......................... 14"
Flue Vent....................................................... 1"
* See O ner’s Manual For Additional Mantel
Clearances and Options
STANDARDS/CLEARANCES LABEL
SAFET LABEL

REM NGTON QFP40 Direct Vent F REPLACE
Page 8 250-4721 JUNE 2001
WARNING!
Improper installation, adjustment, alteration, service or maintenance can cause injury
or property damage. Refer to this manual for correct installation and operational pro-
cedures. For assistance or additional information consult a qualified installer, service
agency, or the gas supplier.
WARNING!
Do not operate appliance with the glass front removed, cracked or broken. Replace-
ment of the glass should be done by a licensed or qualified service person.
WARNING!
Operation of this appliance when not connected to a properly installed and maintained
venting system or tempering with the blocked vent shutoff system can result in carbon
monoxide (CO) poisoning and possible death.
SAFET NOTICES
Caution and Warning label located on chain behind access door to right of control panel.
Due to high temperatures, the appliance should be located out of traffic and away
from furniture and draperies. Children and adults should be alerted to the haz-
ards of high surface temperature and should stay away to avoid burns or cloth-
ing ignition. Young children should be carefully supervised when they are in the
same room as the appliance. Clothing or other flammabale material should not
be placed on or near the appliance. The appliance area must be ept clear and
free from combustible materials, gasoline and other flammable vapors and liq-
uids.
CAUTION: HOT WHILE IN OPERATION. DO NOT TOUCH. KEEP CHILDREN,
CLOTHING, FURNITURE, GASOLINE AND OTHER LIQUIDS HAVING FLAM-
MABLE VAPORS AWAY.
CAUTION: DO NOT OPERATE THE APPLIANCE WITH GLASS REMOVED,
CRACKED OR BROKEN. REPLACEMENT OF THE GLASS SHOULD BE DONE
BY A LICENSED OR QUALIFIED SERVICE PERSON.
FOR USE WITH NATURAL GAS AND PROPANE (LP).
A CONVERSION KIT, AS SUPPLIED BY THE MANUFACTURER, SHALL BE
USED TO CONVERT THIS ROOM HEATER TO THE ALTERNATE FUEL.
WARNING: IMPROPER INSTALLATION ADJUSTMENT, ALTERATION, SERVICE
OR MAINTENANCE CAN CAUSE INJURY OR PROPERTY DAMAGE. REFER
TO THE OWNER’S INFORMATION MANUAL PROVIDED WITH THIS APPLI-
ANCE. FOR ASSISTANCE OR ADDITIONAL INFORMATION CONSULT A QUALI-
FIED INSTALLER, SERVICE AGENCY OR THE GAS COMPANY.

Page 9
REM NGTON QFP40 Direct Vent F REPLACE
250-4721 JUNE 2001
SAFETY NOTICES
IF YOU SMELL GAS!
☛Do not light any appliance
☛Extinguish any open flame
☛Do not touch any electrical switch or plug or unplug anything
☛Open windows and vacate building
☛Call gas supplier from neighbor’s house, if not reached, call fire depart-
ment
✔Installation must be done by a qualified installer
✔Strict ad erence to t e instructions in t is manual must be followed. Improper installation will void t e
warranty and safety listing.
✔T is appliance is manufactured to operate on natural gas (NG). It is field convertible to propane (LP)
wit t e manufacturers’ conversion kit. Burning incorrect fuel voids t e warranty and safety listing and
may cause an extreme safety azard.
✔Contact local building officials to obtain a permit and information on installation restrictions or require-
ments in your locale. It is also important to notify your omeowner’s insurance company of t e installa-
tion of t is appliance as well.
✔Control compartments, screens, and circulating air passageways of t e appliance must be kept clean
and free of obstructions.
✔Do not store or use gasoline or ot er flammable liquids in t e vicinity of t e appliance.
✔Keep all furniture or ot er combustible items at least 36" away from t e front of t e eater.
✔If t e flame becomes sooty, dark orange in color, or extremely tall, DO NOT operate t e appliance.
Contact your dealer and arrange for servicing immediately.
✔DO NOT operate t e appliance if it is not operating properly in any manner. Contact your dealer for
assistance.
✔DO NOT operate t e appliance if any portion was submerged in water or if any corrosion occurs.
✔Do not place clot ing or ot er flammable items on or near t e appliance at any time. Due to t ermo-
static control, t e possibility exists for t e appliance to turn on, igniting any items on or near it.
✔Open viewing glass for servicing only.
✔Replace any safety screen or guards removed for servicing prior to operating t e appliance.
✔Operate t e appliance in accordance wit t e instructions contained in t is manual.
✔If t e main burners do not start correctly, turn t e gas off at t e gas control valve and contact your dealer
for service.
✔T is unit is not for use wit solid fuel. DO NOT place anyt ing inside t e firebox (ot er t an t e included
fiber logs, embers and nuggets, or t e optional brick set).
✔If t e fiber logs become damaged refer to Parts and Accessories page of t is manual for replacement.
✔Face surfaces can become extremely ot during operation. Instruct your family and guests of t is
danger and supervise young c ildren w en t ey are in t e same room as t e eater.
✔Instruct everyone in t e ouse ow to s ut t e gas off to t e appliance and also at t e main gas s ut-off
valve. T e gas main s ut-off valve is usually next to t e gas meter or propane tank and requires a
wrenc to s ut off.
✔Use t e built-in piezo igniter to lig t t e appliance. Do not use matc es or any ot er external device.
✔DO NOT remove, replace, modify or substitute any part of t e appliance unless instructions are given in
t is manual. All ot er work must be done by a trained tec nician.
✔Allow t e appliance to cool before carrying out any maintenance or cleaning.
✔T e pilot flame must contact t e t ermopile and t ermocouple. If it does not, turn t e gas control valve
to “OFF” and call your Dealer.
✔DO NOT t row t is manual away. Important operating and maintenance instructions are included.
SAFET NOTICES

REM NGTON QFP40 Direct Vent F REPLACE
Page 10 250-4721 JUNE 2001
ZC APPLIANCE DIMENSIONS
29 1/16"
41"
45
4"
7"
1"
Gas Inlet - 1 1/4" above
base of unit, accessible
from either side.
Electrical
Connection
Nail Down Plate
37 1/8"
1/2" Stand-offs
(3 per side)
32 1/32" 4 1/8"
42"
HEATING SPECIFICATIONS
Natural Gas Propane
BTU nput 27,000 - 40,000 32,000 - 40,000
BTU Output on “H ” (with Fan - without Fan) 34,400 34,400
Efficiency** (with Fan) 84% 86%
**Efficiency rating is the thermal efficiency rating of the product determined under con-
tinuous operation, and independent of an installed system at maximum horizontal vent-
ing (30').
SPECIFICATIONS

Page 11
REM NGTON QFP40 Direct Vent F REPLACE
250-4721 JUNE 2001
SPECIFICATIONS
MINIMUM CABINET DIMENSIONS
Width 54 9/16"
Depth 20 1/2"
Height 56 1/2"
Minimum
1/2" trim.
Maximum mantel depth is
12"
The following minimum cabinet dimensions are the minimal allowances for clearance to
combustibles, as referenced on page 7 of this manual. See page 21 for additional
mantel information.

REM NGTON QFP40 Direct Vent F REPLACE
Page 12 250-4721 JUNE 2001
Access Door
Mantel
Fascia
Framing
Simpson-DuraVent
Venting
Z
Appliance
ombustible Wall
(See learances, Page 7)
Gas line
Electrical
line
Horizontal
Termination ap
INSTALLATION TERMINOLOGY
DuraRock,
Tile, etc.
Stand-
offs
Glass
Header
PREPARATION

Page 13
REM NGTON QFP40 Direct Vent F REPLACE
250-4721 JUNE 2001
AN OVERVIEW: INSTALLATION TO OPERATION
1. Remove door by releasing four spring clips (2 upper and 2 lower). See Pg. 53.
2. Remove logset, lava rock, embers and packaging materials from firebox.
3. Familiarize yourself with this manual.
4. Finalize your installation decisions and requirements.
5. Convert to LP gas if applicable to your installation. (Kit not included.) See Pgs. 14-15.
6. Set unit in place and install venting per your installation requirements. Secure unit to
floor using naildown plates.
7. Connect the gas line. See Pg. 46.
8. Complete electrical connections. See Pg. 47.
9. Run thermostat lines to TH & TPTH connectors on valve, if applicable. See Pg. 47.
10. Leak test gas line to manual shutoff valve. See Pg. 54.
11. Install brick (optional accessory), lava rock, embers and logset. See Pg. 48.
12. Turn on manual shutoff valve; leak test. See Pg. 46.
13. Light pilot with door off and smell for gas (see Lighting Instructions). See Pg. 55.
14. Re-attach door with latches. See Pg. 53.
15. Adjust gas control knob to “ON” (again, follow Lighting Instructions).
16. Check flames. See Pg. 55.
17. Adjust damper position, if applicable. See Pg. 56.
18. Attach fascia. NOTE If using Gold or Brushed Nickel Fascia - Clean thoroughly with
glass cleaner and non-abrasive towel prior to lighting unit. See Pg. 53.
19. Set Thermostat or turn control panel switch to the “On” position. See Pg. 58.
PREPARATION
PREPARATION
✔Failure to follow all of the required installation procedures may result in
property damage, bodily injury or even death.
✔This appliance must be installed in accordance with all local codes, if any;
if not, follow ANSI Z223.1-1992 and NFPA 54(88).
✔Manufactured Home or Mobile Home installation may occur only after the
home is site located and must conform to: USA, Manufactured Home Con-
struction and Safety Standard, Title 24 CFR, Part 3280; Canada, CSA Z240.4
and Gas-Equipped Recreational Vehicles and Mobile Housing standards.
✔The Reminington is manufactured to operate on Natural Gas (NG), it is con-
vertible to Liquid Propane Gas (LP) when the manufacturer’s conversion
it, part #842-4470 is used.
✔All exhaust gases must be vented outside the structure of the living-area.
Combustion air is drawn from outside the living-area structure.
✔Notify your insurance company prior to connecting gas to this fireplace.
✔Installation requirements diagrammed and explained in this manual are
grouped into segments for ease of procedure. While these requirements
must be met fully, the order of installation may be subject to the procedure
best suited for your specific placement of the fireplace.

REM NGTON QFP40 Direct Vent F REPLACE
Page 14 250-4721 JUNE 2001
NOTE: If converting this unit to propane, do so at this point of installation.
LP CONVERSION INSTRUCTIONS
Part # 842-4470 is required for this procedure.
AUTION: DIS ONNE T ANY ELE TRI AL ORDS AND TURN OFF
GAS SUPPLY TO UNIT BEFORE PRO EEDING.
Valve Regulator Tower
1. Turn control knob to the OFF position and shut off the gas supply to the valve.
2. Using a Torx TH20, or slotted screwdriver, remove the three pressure regulator
mounting screws (A), pressure regulator tower (B), and diaphragm (C). (You may
wish to retain these items for converting back to original gas if necessary.)
3. nsure that the rubber gasket (D) is properly positioned and install the new H /LO
pressure regulator assembly to the valve using the new screws (E) supplied with
the kit. Tighten screws securely. (Reference torque = 25 in/lb)
4. nstall the enclosed identification label (F) to the valve body where it can be seen.
WARNING !
The installation of this conversion kit must only be undertaken by a quali-
fied and certified gas appliance installer.
LP CONVERSION
A
B
C
E
D
F

Page 15
REM NGTON QFP40 Direct Vent F REPLACE
250-4721 JUNE 2001
Burner Orifice Replacement
5. If logset is installed, remove logs and embers at this time.
6. Use a Phillips screwdriver to remove pilot lighting channel and front log rack.
7. Remove the two Phillips head screws that secure the front and rear burner pans in place.
8. Remove the burner pans by sliding to the right and lifting out. (Shutters may need to be
adjusted ‘closed’ to make this easier).
9. Slide shutters out of the way. Using a 3/8" wrench or socket, remove the orifice inserts and
replace with proper orifices for the specified gas. See below.
10. Reinstall burner pans and adjust shutters to ‘open’ position.
NOTE: THe right phillips screw holding front and rear burners in place should be left
slightly loose to allow for e pansion.
CAUTION The correct orifice placement is critical for proper appliance performance .
Natural Gas Propane
Main Burner Orifice Front (DMS) #47 #56
Main Burner Orifice Rear (DMS) #42 #53
CONVERSION INSTRUCTIONS, (CONT.)
LP CONVERSION
Note: Logs and burners will be reinstalled following pilot orifice replacement.
Pilot Orifice Replacement:
13. Lift pilot hood and remove. See Fig. A
14. Remove existing pilot orifice with a 5/32” allen wrench. See Fig. B
15. Replace pilot orifice with the correct orifice for your gas type as follows:
LP = .016 NG = .025
11. Replace pilot hood: Ensure that the notches are aligned and snap hood into place.
12. Reinstall Log Rack, pilot lighting channel, burners, lava rock and logs.
13. Install LP conversion label inside the apliance beneath the firebox, to the left of the control
panel.
FIG. A
FIG. B

REM NGTON QFP40 Direct Vent F REPLACE
Page 16 250-4721 JUNE 2001
INSTALLATION
MINIMUM FRAMING DIMENSIONS
❖The 1/2" stand-offs on the back and sides and 4" stand-offs on the top of the
fireplace separate the fireplace from the framing members (see page 12,
nstallation Terminology). These stand-offs may contact the framing mem-
bers but no material may be placed between the stand-offs and the framing.
❖nstallation requires a level surface capable of supporting the weight of the
fireplace (240 lbs.) and vent.
❖Fireplace must be placed directly on wood or non-combustible surface (not on
linoleum or carpet).
❖HOT WH LE N OPERAT ON! nstallation location must be out of traffic and
away from furniture and draperies.
NOTE: Framing dimensions shown below reflect an 1/4" overage on top
and 1/8" overage to each side.
Route Gas Line 6 7/16" behind the framing opening (on either side of can).
For hardpipe connection, allow 1 1/4" above the base of fireplace.
Route electrical
line to the right
rear of fireplace.
45 1/2"
19 5/8"
43"
56 1/2"

Page 17
REM NGTON QFP40 Direct Vent F REPLACE
250-4721 JUNE 2001
INSTALLATION
CORNER INSTALLATIONS
The usual 45º installation uses the minimum framing dimensions shown in the illustration
below. PLEASE NOTE: All clearances as referenced on page 7 still apply.
13 13/16"
45 3/16"
12 1/16"
43"
10 7/16"
19 5/8"

REM NGTON QFP40 Direct Vent F REPLACE
Page 18 250-4721 JUNE 2001
INSTALLATION
RAISED FIREPLACE
The fireplace and it’s hearth, if desired, may be placed on a platform designed to support
the fireplace weight (240lbs.) and venting.
Hearth
Raised Platform

Page 19
REM NGTON QFP40 Direct Vent F REPLACE
250-4721 JUNE 2001
INSTALLATION
Raised Platform
Raised Hearth
RAISED FIREPLACE WITH RAISED HEARTH

REM NGTON QFP40 Direct Vent F REPLACE
Page 20 250-4721 JUNE 2001
INSTALLATION
HEARTH REQUIREMENTS
No clearances to combustible flooring are required for installation of the Remington QFP40,
as referenced in the Clearances to Combustibles on page 7 of this manual.
NOTE: Ensure the depth of your flooring material does not exceed the 1" height at
bottom front flange of the ZC Appliance, illustrated below. Clearance of this area is
necessary in order to allow freedom of movement of the control panel access door when
installed later.
Flooring
(tile, wood, carpet)
must lie beneath this edge.
Lower front
edge of Z
Appliance
1"
Right Side of
Z
Appliance
Left Side of
Z
Appliance
