Quadra-Fire 31I-ACC User manual

1 7044-225B April 9, 2014
3100-I ACC WOOD INSERT
Automatic Combustion Control (ACC)
Model(s):
31-I ACC
O-T L
Tested and
Listed by
Portland
Oregon USA
OMNI-Test Laboratories, Inc.
CUS
HOT SURFACES!
Glass and other surfaces are hot
during operation AND cool down.
Hot glass will cause burns.
• Do not touch glass until it is cooled
• NEVER allow children to touch glass
• Keep children away
• CAREFULLY SUPERVISE children in same room as
replace.
• Alert children and adults to hazards of high temperatures
• High temperatures may ignite clothing or other
ammablematerials.
• Keepclothing,furniture,draperiesandotherammable
materials away.
WARNING
If the information in these instruc-
tions is not followed exactly, a
remayresultcausingproperty
damage, personal injury, or death.
• Donotstoreorusegasolineorotheram-
mablevaporsandliquidsinthevicinityof
this or any other appliance.
• Donotoverre-Ifheaterorchimneycon-
nectorglows,youareoverring.Overring
willvoidyourwarranty.
• Complywithallminimumclearancesto
combustiblesasspecied.Failureto
complymaycausehousere.
WARNING
Fire Risk.
For use with solid wood fuel only.
Otherfuelsmayoverreandgenerate
poisonousgases(i.e.carbonmonoxide).
Installationandserviceofthisapplianceshould
beperformedbyqualiedpersonnel.Hearth&
HomeTechnologiesrecommendsNFIcertied
professionals,ortechnicianssupervisedbyan
NFIcertiedprofessional.
WARNING
Installation Manual
Installation & Appliance Set-Up
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT DISCARD THIS MANUAL
NOTE
ToobtainaFrenchtranslationofthismanual,pleasecontact
yourdealerorvisitwww.quadrare.com
Pourobtenirunetraductionfrançaisedecemanuel,s’ilvous
plaîtcontactervotrerevendeurouvisitezwww.quadrare.com

2 7044-225B April 9, 2014
31-I ACC
1 Important Safety Information
A.InsertCertication.............................................................3
B.BTU&EfciencySpecications........................................3
C.MobileHomeApproved .................................................... 3
D.GlassSpecications .........................................................3
E.Non-CombustibleMaterials ...............................................3
F.CombustibleMaterials........................................................3
2 Getting Started
A . Design and Installation Considerations ..................................4
B. Draft ..............................................................................4
C.NegativePressure............................................................5
D.ToolsAndSuppliesNeeded..............................................5
E. Inspect Appliance and Components ..................................5
F. Install Checklist ..................................................................6
3 Dimensions and Clearances
A. Appliance Dimensions ......................................................7
B.ClearancestoCombustibles..............................................8
C. Calculating Alternate Floor Protection ..............................9
D.LocatingYourStove&Chimney .......................................10
E.ChimneyTerminationRequirements.................................10
F. 2-10-3 Rule .......................................................................11
4 Chimney Systems
A. Venting Systems ...............................................................12
B. Inspections........................................................................12
C. Larger Chimneys ..............................................................12
D. Masonry Chimney.............................................................12
E.MetalHeatCirculatingMasonry........................................14
F.PrefabricatedMetalChimney ............................................14
G. Securing Chimney Components.......................................15
H.AlteringtheFireplace........................................................15
I. Zero-Clearance Fireplace ..................................................16
J.OvalizingRoundStainlessSteelLiners ............................16
K.ChimneyHeight/RiseandRun .......................................16
5 Appliance Set-Up
A.OutsideAirKitInstallation..................................................17
B.DisassembleFireboxandOuterCan................................18
C.SecuringStovePipe/LinertoFlueCollar..........................19
D.OptionalOffsetAdapterInstallation ..................................19
E.InstallingOuterCan&LevelingBolts ...............................20
F.Surround&TrimKitInstallation.........................................20
G.InstallingFireboxintoOuterCan......................................21
H.SecuringAppliancetoStovePipe/Liner ...........................21
I.LevelingLegs....................................................................21
J. Snap Disc and Side Panel Installation ..............................22
K. Blower Installation.............................................................22
L. Blower Cord Installation on Left Side................................23
M.ZeroClearanceAdjustableTrimSupport,2”to10”.........24
6 Mobile Home Installation
7 Accessory List
TABLE OF CONTENTS
Safety Alert Key:
• DANGER! Indicatesahazardoussituationwhich,ifnotavoidedwill result in death or serious injury.
• WARNING!Indicatesahazardoussituationwhich,ifnotavoidedmay result in death or serious injury.
• CAUTION! Indicatesahazardoussituationwhich,ifnotavoided,may result in minor or moderate injury.
• NOTICE: Indicates practices which may cause damage to the appliance or to property.

April 9, 2014 7044-225B 3
31-I ACC
Model: 3100-I(ACC)Insert
Laboratory: OMNITestLaboratories,Inc.
Report No: 061-S-74-6.2
Type: SolidFuelType,ListedRoomHeater
Standard: UL1482 and ULC S628-93 and
(UM)84-HUD,MobileHome
Approved.
EPACertied: 2.0 grams per hour
Efciency: up to 79.8%
EPA BTU Output: 11,800 to 32,000
Heating Capacity: upto1800sqftdepending
on climate zone
Vent Size: 6 inches
Firebox Size: 1.9cubicfeet
Max Wood Length: 18 inches
Max First Hour BTUs: 57,100 @ 75.3% B415
TestedEfcienty
Fuel: Cord Wood
Shipping Weight: 345lbs
TheQuadra-Fire3100WoodInsert(ACC)meetstheU.S.Environ-
mentalProtectionAgency’s1990particulateemissionstandards.
1 Important Safety Information
A.InsertCertication
NOTE:Hearth&HomeTechnologies,manufacturerof
thisappliance,reservestherighttoalteritsproducts,their
specicationsand/orpricewithoutnotice.
NOTE:Thisinstallationmustconformwithlocalcodes.Inthe
absenceoflocalcodesyoumustcomplywiththeUL1482,(UM)
84-HUDandNPFA211intheU.S.A.andtheULCS628-93and
CAN/CSA-B365InstallationCodesinCanada.
C. Mobile Home Approved
 • Thisapplianceisapprovedformobilehomeinstalla-
tions when not installed in a sleeping room and when
anoutsidecombustionairinletisprovided.
 • Thestructuralintegrityofthemobilehomeoor,ceil-
ing,andwallsmustbemaintained.
 • Theappliancemustbeproperlygroundedtotheframe
ofthemobilehomewith#8coppergroundwire,and
chimneymustbelistedtoUL103 HToralistedUL-
1777fulllengthsixinch(152mm)diameterlinermust
beused.
 • OutsideAirKit,partOAK-ACCmustbeinstalledina
mobilehomeinstallation.
Improper installation, adjustment, alteration, service or
maintenance can cause injury or property damage.
Forassistanceoradditionalinformation,consultaqualied
installer,serviceagencyoryourdealer.
Quadra-FireisaregisteredtrademarkofHearth&Home
Technologies.
• Installationanduseofanydamagedappliance.
• Modicationoftheappliance.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installationand/oruseofanycomponentpartnotapprovedby
Hearth&HomeTechnologies.
• Operatingappliancewithoutfullyassemblingallcomponents.
• Operatingappliancewithoutlegsattached(ifsuppliedwithunit).
• DoNOTOverre-Ifapplianceorchimneyconnectorglows,you
areoverring.
Anysuchactionthatmaycausearehazard.
WARNING
Fire Risk.
Hearth&HomeTechnologiesdisclaimsany
responsibilityfor,andthewarrantywillbevoided
by,thefollowingactions:
B.BTU&EfciencySpecications
D.GlassSpecications
Thisstoveisequippedwith5mmceramicglass.Replace
glass only with 5mm ceramic glass. Please contact your
dealer for replacement glass.
Hearth&HomeTechnologiesWILLNOTwarrantystoves
thatexhibitevidenceofover-ring.Evidenceofover-ring
includes,butisnotlimitedto:
 • Warpedairtube
 • Deterioratedrefractorybrickretainers
 • Deterioratedbafeandotherinteriorcomponents
E. Non-Combustible Materials
Materialwhichwillnotigniteandburn,composedofany
combinationofthefollowing:
- Steel - Plaster
- Brick - Iron
 -Concrete  -Tile
- Glass - Slate
Materials reported as passing ASTM E 136, Standard
Test Method for Behavior of Metals, in a Vertical Tube
Furnace of 750° C.
F. Combustible Materials
Materialmadeof/orsurfacedwithanyofthefollowingma-
terials:
- Wood - Compressed Paper
 -PlantFibers  -Plastic
 -Plywood/OSB  -SheetRock(drywall)
Anymaterialthatcanigniteandburn:ameproofedornot,
plastered or un-plastered.

4 7044-225B April 9, 2014
31-I ACC
Install Guide
2 Getting Started
A . Design and Installation Considerations
Beforeinstalling,determinethefollowing:
• Typeofchimneyconnectortobeused
· singlewall,6inch(152mm)diameter,stainlesssteel,or
·doublewall,6inch(152mm)diameter,stainlesssteel
• Consultpage28forclearancestocombustibles
• Poweroutletlocatedclosebyforoptionalblower
Draftisthepressuredifferenceneededtoventappliances
successfully. When a appliance is drafting successfully, all
combustion byproducts are exiting the home through the
chimney.
Considerationsforsuccessfuldraftinclude:
• Preventingnegativepressure
• Locationofapplianceandchimney
T obesurethatyourapplianceburnsproperly:
• Duringalowburn,thechimneydraft(staticpressure)should
beapproximately-.04inchwatercolumn(W.C.)
• Duringahighburnthechimneydraftshouldbeapproximately
-.10inch(W.C.)
• MeasuretheW.Cat6inches(152mm)abovethetopofthe
applianceafteronehourofoperationateachburnsetting.
B. Draft
Checkbuildingcodespriortoinstallation.
• Installation MUST comply with local, regional, state and
national codes and regulations.
• Consult insurance carrier, local building, re ofcials or
authoritieshavingjurisdictionaboutrestrictions,installation
inspection, and permits.
CAUTION
WARNING
• DONOTCONNECTTHISUNITTOACHIMNEY
FLUESERVICINGANOTHERAPPLIANCE.
• DONOTCONNECTTOANYAIRDISTRIBUTION
DUCTORSYSTEM.
Mayallowuegasestoenterthehouse.
Asphyxiation Risk.
• Installationanduseofanydamagedappliance.
• Modicationoftheappliance.
• Installation other than as instructed by Hearth & Home
Technologies.
• Installationand/oruseofanycomponentpartnotapproved
byHearth&HomeTechnologies.
• Operatingappliancewithoutfullyassemblingallcomponents.
• Operatingappliancewithoutlegsattached(ifsuppliedwith
unit).
• DoNOTOverre-Ifapplianceorchimneyconnectorglows,
youareoverring.
Anysuchactionthatmaycausearehazard.
WARNING
Fire Risk.
Hearth&HomeTechnologiesdisclaimsany
responsibilityfor,andthewarrantywillbe
voidedby,thefollowingactions:
NOTICE: Hearth & Home Technologies assumes no
responsibility for the improper performance of the
appliancesystemcausedby:
• Inadequatedraftduetoenvironmentalconditions
• Downdrafts
• Tightsealingconstructionofthestructure
• Mechanicalexhaustingdevices
• Overdraftingcausedbyexcessivechimneyheights
• Idealperformanceiswithheightofchimneybetween
14-16feet(4.26-4.88m)measuredfromthebaseof
the appliance.

April 9, 2014 7044-225B 5
31-I ACC
C. Negative Pressure
Negative pressure results from the imbalance of air avail-
ablefortheappliancetooperateproperly. Itcanbestron-
gestinlowerlevelsofthehouse.
Causesinclude:
• Exhaustfans(kitchen,bath,etc.)
• Rangehoods
• Combustionairrequirementsforfurnaces,waterheaters
andothercombustionappliances
• Clothesdryers
• Locationofreturn-airventstofurnaceorairconditioning
• ImbalancesoftheHVACairhandlingsystem
• Upperlevelairleakssuchas:
- Recessed lighting
- Attic hatch
- Duct leaks
Tominimizetheeffectsofnegativeairpressure:
• Installtheoutsideairkitwiththeintakefacingprevailing
winds during the heating season
• Ensureadequateoutdoorairforallcombustionappliances
andexhaustequipment
• Ensurefurnaceandairconditioningreturnventsarenot
locatedintheimmediatevicinityoftheappliance
• Avoid installing the appliance near doors, walkways or
small isolated spaces
• Recessedlightingshouldbea“sealedcan”design
• Attichatchesweatherstrippedorsealed
• Atticmountedductworkandairhandlerjointsandseams
taped or sealed
• Basementinstallationsshouldbeavoided
WARNING
• Negativepressurecancausespillageofcom-
bustionfumes,sootandcarbonmonoxide.
• Applianceneedstodraftproperlyforsafety.
Asphyxiation Risk.
D. Tools And Supplies Needed
Beforebeginningtheinstallationbesurethefollowingtools
andbuildingsuppliesareavailable:
Reciprocating saw Framing material
Pliers Hightempcaulkingmaterial
Hammer Gloves
Phillipsscrewdriver Framingsquare
Flatbladescrewdriver Electricdrillandbits
Plumbline Safetyglasses
Level Tapemeasure
1/2-3/4in.length,#6or#8self-drillingscrews
Misc. screws and nails
• Removeapplianceandcomponentsfrompackagingand
inspect for damage.
• Vent system components and doors are shipped in
separate packages.
• Reporttoyourdealeranypartsdamagedinshipment.
• Read all the instructions before starting the
installation. Follow these instructions carefully during
theinstallationtoensuremaximumsafetyandbenet.
E. Inspect Appliance and Components
Inspect appliance and components for damage.
Damaged parts may impair safe operation.
WARNING
• DoNOTinstalldamagedcomponents.
• DoNOTinstallincompletecomponents.
• DoNOTinstallsubstitutecomponents.
Report damaged parts to dealer.
Fire Risk.

6 7044-225B April 9, 2014
31-I ACC
ATTENTION INSTALLER:
Follow this Standard Work Checklist
Thisstandardworkchecklististobeusedbytheinstallerinconjunctionwith,notinsteadof,theinstructionscontainedinthisinstallationmanual.
Customer:
Date Installed:
Lot/Address:
Location of Fireplace:
Installer:
Dealer/ Distributor Phone #:
Serial #:
Model (circle one): 31I-ACC
WARNING! Risk of Fire or Explosion! Failuretoinstallreplaceaccordingtotheseinstructionscanleadtoareorexplosion.
Appliance Install
Veriedclearancestocombustibles.(Pg.8)
Fireplaceisleveledandlinerissecuredtoappliance.(Pg.18)
Hearthextensionsize/heightdecided.(Pg.22)
Outsideairkitinstalled.(Pg.16)
Floorprotectionrequirementshavebeenmet.
Themasonrychimneyisinspectedbyaprofessionalandiscleanorthe
factorybuiltmetalchimneyisinstalledaccordingtothemanufacturer’s
instructions and clearances.
Chimney Section 4 (Pg. 11)
Chimneycongurationcomplieswithdiagrams.
Chimney installed, locked and secured in place with proper clearance.
Chimneymeetstheminimumheightrequirements.
Roofashinginstalledandsealed.
Terminationsinstalledandsealed.
Clearances Section 3 (Pg. 7)
Combustiblematerialsnotinstalledinnon-combustibleareas.
Veriedallclearancesmeetinstallationmanualrequirements.
Mantelsandwallprojectionscomplywithinstallationmanualrequirements.
Protectivehearthstripsandhearthextensioninstalledpermanualrequirements.
Appliance Setup Section 5 (Pg. 16)
Allpackagingandprotectivematerialsremoved.
Firebrick,bafeandceramicblanketinstalledcorrectly.
Alllabelshavebeenremovedfromthedoor.
Allpackagingmaterialsareremovedfrominside/underthereplace.
Manualbagandallofitscontentsareremovedfrominside/underthereplace
andgiventothepartyresponsibleforuseandoperation.
Hearth & Home Technologies recommends the following:
•Photographingtheinstallationandcopyingthischecklistforyourle.
•Thatthischecklistremainvisibleatalltimesonthereplaceuntiltheinstallationiscomplete.
Comments: Furtherdescriptionoftheissues,whoisresponsible(Installer/Builder/OtherTrades,etc.)andcorrectiveactionneeded:
Commentscommunicatedtopartyresponsible by on
(Builder/Gen.Contractor) (Installer)(Date)
Part#4017-254•RevB•01/29/13
YES IF NO, WHY?
F. Install Checklist

April 9, 2014 7044-225B 7
31-I ACC
Figure 7.1 Top View Figure 7.2 Front View
Figure 7.3 - Side View
A
B
27-5/8 in (702mm)
23-13/16 in (589mm)
38-9/16 in (979mm)
5-1/2 in (140mm)
5-11/16 in (144mm)
8-1/2 in (216mm)
C
L
7-3/4 in (197mm)
12-1/2 in
(318mm)
26-3/4 in (679mm)
23-1/4 in (591mm)
14-1/4 in
(362mm)
20-7/16 in
(519mm)
21-1/2 in
(546mm)
Surround Sizes AB
Standard 43in.(1092mm) 31in.(787mm)
Large 53in.(1346mm) 34in.(864mm)
11-7/8 in. to 15-3/16 in.
(302mm to 386mm)
4 in.
(102mm)
24-3/16 in.
(614mm)
C
L
16-5/16 in. to 19-5/8 in.
(414mm to 498mm)
Figure 7.4 - Side View With Optional Offset Adapter
3 Dimensions and Clearances
A. Appliance Dimensions NOTE:FlueCollarsizeis6inch(152mm)diameter(ID)

8 7044-225B April 9, 2014
31-I ACC
NOTE: Clearances may only be reduced by
means approved by the regulatory authority
having jurisdiction
Fire Risk.
• Complywithallminimumclearancesto
combustiblesasspecied.
• Failuretocomplymaycausehousere.
WARNING
InCanadaafulllength6inch(152mm)S635uelinerrequiredasperULCS628.
InUSAaminimum5ftlength(1.82m),6inch(152mm)diameteruelinerisrequiredasperUL1482.
SIDE TRIM
SIDE WALL
TOP TRIM
27-1/4
692mm
32-1/4
819mm
HEARTH
EXTENSION
USA 16-3/4
CANADA
24-3/4 (629mm)
40-11/16
1033mm
FIREPLACE FRONT SURFACE
USA 23-1/2
CANADA 25-1/2 (648mm)
HEARTH EXTENSION
51 7/16
1306mm
12in max
MANTEL
See next page for thermal protection
calculations
THERMAL
PROTECTION
USA
& CANADA
Floorheight0”to6-1/2”
(6mmto165mm)below
insertbase
1-1/2inch(38)of
k=3.06
Floor height greater
than6-1/2”(165mm)
belowinsertbase
1inch(25)ofk=
0.49, R = 2.04
Optional
Mantel
Deflector
FIREPLACE FRONT SURFACE
USA 23-1/2
CANADA 25-1/2 (648mm)
HEARTH EXTENSION
41 7/16
1052mm
12in max
MANTEL
See next page for thermal protection
calculations
WithoutMantelDeector WithMantelDeector
B. Clearances to Combustibles UnitedStatesandCanada(ULandULC)

April 9, 2014 7044-225B 9
31-I ACC
C. Calculating Alternate Floor Protection
Material
Thermal Conductivity: k value
Thekvalueindicatestheamountofheat(inBTU’s)thatwillow
in1hourthrough1squarefootofauniformmaterial1inchthick
foreachdegree(F)oftemperaturedifferencefromonesideof
the material to the other.
TheLOWER the kfactormeans less heatisbeing conducted
throughthenon-combustiblematerialtothecombustiblemate-
rialbeneathit.
Thekvalueofamaterialmustbeequalorsmallerthenthere-
quiredkvaluetobeacceptable.
(BTU)(inch)
(foot2(hour)(oF)
Thermal Resistance: R value
TheRvalueisameasureofamaterial’sresisteancetoheat
transfer.
Rvalueisconvenientwhenmorethanonematerialisused
sinceyoucanaddtheRvaluestogether,whereasyoucan
notdothisforkvalue.
TheHIGHERtheRfactormeanslessheatisbeingconduct-
edthroughthenon-combustiblematerialtothecombustible
materialbeneathit.
TheRvalueofamaterialmustbeequalorlargerthenthe
requiredRvaluetobeacceptable.
Converting k to R:
Divide1bykandmultiplytheresultstimesthethicknessininch-
es of the material.
 R=1/kxinchesofthickness
Converting R to k:
DividetheinchesofthicknessbyR.
 k=inchesofthickness/R
Calculatons:
Example:Floorprotectionrequireskvalueof0.84and3/4inch
thick.
Alternativematerialhasakvalueof0.6andis3/4inchthick.
Divide0.6by.75=kvalueof0.80.Thiskvalueissmallerthan
0.84andthereforeisacceptable.
Figure 9.2
ZERO
CLEARANCE
ONLY
Required
Thermal
Protection
Adj. Hearth
Support
1-1/2 inch (38mm) 1 inch (25mm)
1-1/2 inch (38mm)
0 to 6-1/2 inch
(0 to 165mm)
ZERO
CLEARANCE
ONLY
Required
Thermal
Protection
1 inch
(25mm)
1 inch (25mm)
Adj. Hearth
Support 1-1/2 inch (38mm)
6-1/2 inch
(165mm)
Figure 9.1
Zero Clearance Floor Thermal Protection

10 7044-225B April 9, 2014
31-I ACC
Figure 10.1
Recommended
Location
Marginal
Location
Location
Not
Recommended
Recommended
Location
Location NOT
Recommended
Multi-level Roofs
Windward
Leeward
Outside Air Kit Termination Cap
E.ChimneyTerminationRequirements
Followmanufacturer’sinstructionsforclearance,securing
ashingandterminatingthechimney.
•MusthaveanapprovedandListedcap
•Mustnotbelocatedwhereitwillbecomepluggedby
snow or other material
 • Mustterminateatleast3feet(91cm)abovetheroof
andatleast2feet(61cm)aboveanyportionofthe
roofwithin10feet(305cm).
 • Mustbelocatedawayfromtreesorotherstructures
D. Locating Your Stove & Chimney
Location of the appliance and chimney will affect perfor-
mance. As shown in Figure 10.1thechimneyshould:
 • Installthroughthewarmspaceenclosedbythebuild-
ingenvelope.Thishelpstoproducemoredraft,espe-
ciallyduringlightinganddiedownofthere.
 • Penetratethehighestpartoftheroof.Thisminimizes
theaffectsofwindturbulenceanddowndrafts.
 • Considertheappliancelocationinordertoavoidoor
and ceiling attic joists and rafters.
 • Locate termination cap away from trees, adjacent
structures,unevenrooflinesandotherobstructions.
Yourlocaldealeristheexpertinyourgeographicareaand
canusuallymakesuggestionsordiscoversolutionsthatwill
easilycorrectyourueproblem.
NOTICE:
• Chimneyperformancemayvary.
• Trees,buildings,rooflinesandwindconditionsaffect
performance.
• Chimneyheightmayneedadjustmentifsmokingor
overdraftoccurs.
NOTICE: Locating the appliance in a basement or in a
locationofconsiderableairmovementcancauseintermittent
smokespillagefromappliance.Donotlocateappliancenear
• Frequentlyopendoors
• Centralheatoutletsorreturns

April 9, 2014 7044-225B 11
31-I ACC
3ft.(91cm)
Minimum
Lessthan10ft.(305cm)
2ft.(61cm) 3ft.(91cm)
Minimum
10ft.(305cm) To Nearest Roofline
2ft.(61cm)
Pitched Roof
Figure 11.1
Figure 11.2
10 ft. (305cm) or more
3 ft. (91cm) Minimum
Less than 10 ft. (305cm)
2 ft. (61cm) Minimum
3 ft. (91cm) Minimum
Wall or Parapet
Flat Roof
F. 2-10-3 Rule
Thesearesafetyrequirementsandarenotmeanttoassureproperuedraft.
Thisapplianceismadewitha6inch(152mm)diameterchimneyconnectorastheuecollarontheunit.
 • Changingthediameterofthechimneycanaffectdraftandcausepoorperformance.
 • Itisnotrecommendedtouseoffsetsandelbowsataltitudesabove4000feetabovesealevelandorwhenthere
  areotherfactorsthataffectuedraft.

12 7044-225B April 9, 2014
31-I ACC
4 Chimney Systems
D. Masonry Chimney
 •MustmeetminimumstandardsofNFPA211.
 •Musthaveatleast5/8inch(16mm)reclayliningjoined
with refractory cement.   (Installations into a clay ue
without a stainless steel liner may reduce draw which
affects performance, will cause the glass to darken and
produceexcessivecreosote).
 •The masonry wall of the chimney, if brick or modular
block,mustbeaminimumof4inches(102mm)nominal
thickness.
 •A chimney of rubble stone must be at least 12 inches
(305mm)thick.
 •Cross-sectional area shall conform to NFPA 211-2006
Section 12.4.5.1.
 •Should belined witha 6inch (152mm)stainless steel
uelinertoimproveperformanceandreducecreosote
build-up.
 •Anequivalentlinermustbealistedchimneylinersystem
orotherapprovedmaterial.
 •Nodilutionairisallowedtoenterthechimney.
1. Securethereplacedamperintheopenposition.If
thiscannotbeaccomplished,itwillbenecessaryto
removethedamper
2. Seal damper area of chimney around chimney
connector with a high temperature sealant or seal
insertagainstthefaceofthereplace.
  3.Bothmethodsmustberemovableandreplaceable
for cleaning and re-installation.
 •Whenpossible,install an airtight clean-out door to the
rear of the smoke shelf.
A. Venting Systems
Chimney Connector:
Itisalsoknownasuepipeorstovepipe.Itmustbe6inches
(152mm)minimumdiameterstainlesssteelconnectorpipe.
Chimney:
Thechimneycanbeneworexisting,masonryorprefabricated
and must meet the following minimum requirements as
speciedbelow.
WARNING! Risk of Fire!
Follow venting manufacturer’s clearances and
instructionswheninstallingventingsystem.
B. Inspections
Existing chimneys should be inspected and cleaned by a
qualiedprofessionalpriortoinstallation.Thechimneymust
nothavecracks,loosemortarorothersignsofdeterioration
andblockage.Hearth&HomerecommendsaNFIorCSIA
certiedprofessionaloratechnician,underthedirectionof
a certied professional, conduct a Level II inspection per
NFPA 211.
Fire Risk
InspectionofChimney:
• Chimneymustbeingoodcondition.
• MeetsminimumstandardofNFPA211
• Factory-builtchimneymustbe6inch
(152mm)UL103HT.
WARNING
NOTICE: Check with your local building authorities
and/orconsulttheNationalFireProtectionAssociation
(NFPA211).
C. Larger Chimneys
It is recommended that chimneys with larger diameters
than6 inches(152mm) berelined.Anoversized uecan
affect draft and impair performance and will allow increased
build-upofcreosote.

April 9, 2014 7044-225B 13
31-I ACC
UL 1777 Insulated Stainless Steel
Liner or Other Approved Lining System
Follow Manufacturer’s Instructions
on Insulation and Support
For Zero or Other Non-Code Clearances,
Follow Approved Liner Manufacturer’s Specific
Insulation Requirements: Different Clearances
May Require Different Specifications
Masonry Chimney Must
Have Structural Integrity
UL 1777 Insulated Stainless Steel
Liner or Other Approved Lining System
Minimum 8 in. (203mm) Masonry
Thickness in Front of Smoke Chamber
Damper Plate Removed or
Fastened in Open Position
Seal with Non-Combustible Material
Minimum Clearance in Accordance
with Insert Listing
Floor Protection in
Accordance with Insert
Listing
Follow Manufacturer’s
Instructions for Maximum
Liner Extension Above
Chimney
Maximum 30 Degrees
Offset in Chimney
Combustible Floor
Masonry Chimney (Cont’d)
Figure 13.1
NOTE:InCanada,thisreplaceinsertmustbeinstalled
withacontinuouschimneylinerofa6inch(152mm)diam-
eterextendingfromthereplaceinserttothetopofthe
chimney.ThechimneylinermustconformtotheClass3
requirementsofCAN/ULC-S635,StandardforLiningSys-
temsforExistingMasonryorFactory-BuiltChimneysand
Vents, or CAN/ULC-S640, Standard for Lining Systems
for New Masonry Chimneys.
This insert conforms with the UL 1482 and ULC S628
(Canada) in all respects, and is approved to UL & ULC
safety standards for installation and use within a replace
with a masonry chimney in accordance with NFPA 211 and
CAN/CSA-B365-01.
Generic Insert Model Shown in Illustration

14 7044-225B April 9, 2014
31-I ACC
F. Prefabricated Metal Chimney
Figure 14 .1
E. Metal Heat Circulating Masonry
Thechimneycanbeneworexisting,masonryorprefabricated
andmustmeetthefollowingminimumrequirements:
 •Must be minimum 6 inch (152mm) inside diameter of
hightemperaturechimneylistedtoUL103HT(2100oF)
or ULC S628.
 •Mustusecomponentsrequiredbythemanufacturerfor
installation.
 •Mustmaintainclearancesrequiredbythemanufacturer
for installation.
 •Refertomanufacturersinstructionsforinstallation
 •ThisinsertislistedtoUL1482Standardandisapproved
forinstallationintolistedfactory-builtzero clearancere-
places listed to UL 127 conforming to the following spec-
icationsandinstructions:
 •The original factory-built clearance replace chimney
cap must be re-installed after installing the approved
chimney liner meeting type UL 103 HT requirements
(2100°F)perUL1777.
 •IfthechimneyisnotlistedasmeetingHTrequirements,
orifthefactorybuiltreplacewastestedpriorto1998,a
fullheightlistedchimneylinermustbeinstalledfromthe
applianceuecollartothechimneytop.
 •Thelinermustbesecurelyattachedtotheinsertuecollar
and the chimney top.
 •Theairowofthefactory-builtzero-clearancereplace
systemmust not bealtered. The ueliner topsupport
attachmentmustnotreducetheairowfortheexisting
air-cooled chimney system.
 •Nodilutionairisallowedtoenterthechimney.
1. Securethereplacedamperintheopenposition.If
thiscannotbeaccomplished,itwillbenecessaryto
removethedamper
2. Seal damper area of chimney around chimney
connector with a high temperature sealant or seal
insertagainstthefaceofthereplace.
  3.Bothmethodsmustberemovableandreplaceable
for cleaning and re-installation.
Minimum 8” (203mm) Masonry Thickness
in Front of Smoke Chamber
Damper Plate Removed or
Fastened in Open Position
Seal with Non-
Combustible Material
Minimum Clearance in Accordance with
Insert Listing
Floor Protection in
Accordance with Insert
Listing
Combustible Floor
Airtight Insulated Clean-Out
Stainless Steel Chimney Connector
Must Extend to Flue Liner
Flue Liner with Required Air Space
ThisinsertconformswiththesafetystandardUL-1482and
ULCS628(Canada)inallrespectsandisapprovedtoUL&
ULCsafetystandardsforinstallationandusewithinare-
place with masonry chimney, in accordance with NFPA 211,
withadirectuecollarconnection.
Generic Insert Model Shown in Illustration

April 9, 2014 7044-225B 15
31-I ACC
Inches Millimeters
MinimumWidthofCavityOpening-Front 29-1/16 738
MinimumWidthofCavityOpening-Rear 25-1/2 648
MinimumHeight 20-3/4 528
Minimum Depth from Front to Rear 17-9/16 446
Damper SmokeShelforBafe
EmberCatches Fire Grate
ViewingScreen/Curtain Doors
Thefollowingpartsmayberemoved:
The following modications of factory-built replaces are
permissible:
• Thereplacemustnotbealtered.Cuttinganysheetmetal
partsofthereplaceinwhichthereplaceinsertistobe
installed is prohibited perANSI Z21.88 except that the
dampermayberemovedtoaccommodateadirect-connect
starter pipe or chimney liner,
• Externaltrimpieceswhichdonotaffecttheoperationof
thereplacemayberemovedprovidingtheycanbestored
on or within the replace for reassembly if the insert is
removed.
• The permanent metal warning label provided in the
component pack must be attached to the back of the
replace,withscrewsornails,statingthatthereplacemay
havebeenalteredtoaccommodatetheinsert,andmust
bereturnedtooriginalconditionforuseasaconventional
replace.Figure 15.2.
• Ifthehearthextensionislowerthanthereplaceopening,
theportionoftheinsertextendingontothehearthmustbe
supported.
• Manufacturer designed adjustable support kit can be
ordered from your dealer.
• Finalapprovalofthisinstallationtypeiscontingentupon
theauthorityhavingjurisdiction.
Fire Risk.
Whenliningair-cooledfactory-builtchimneys:.
• RunchimneylinerapprovedtoUL1777Type
HTrequirements(2100degreesF)
• Re-installoriginalfactorybuiltchimneycap
ONLY
• DONOTblockcoolingairopeningsinchimney
• Blockingcoolingairwilloverheatthechimney
WARNING
Prefabricated Metal Chimney (Cont’d)
LINER CONNECTOR
FLUE
GAS
DIRECTION
CRIMPED
END
TOWARDS
STOVE
Figure 15.1
NOTICE: In Canada when using a factory-built chim-
ney it must be safety listed, Type UL103 HT (2100oF)
[1149oC] CLASS “A” or conforming to CAN/ULC-
S629M, STANDARD FOR 650oC FACTORY-BUILT
CHIMNEYS.
NOTE: Refer to chimney liner manufacturer for recom-
mendations on supporting the liner. Installation into
replaceswithoutapermitwillvoidthelisting.
H. Altering the Fireplace
G. Securing Chimney Components
All joints should be secured with 3 sheet metal screws or
rivetsperpipemanufacturersinstructions.Thesectionsmust
beattachedtotheinsertandtoeachotherwiththecrimped
(male)endpointingtowardtheinsert.Figure 15.1.
WARNING! Risk of Fire!
Follow venting manufacturer’s clearances and instructions
wheninstallingventingsystem.
250-2061
WARNING
THIS FIREPLACE MAY HAVE BEEN ALTERED
TO ACCOMMODATE AN INSERT. IT MUST BE
RETURNED TO ITS ORIGINAL CONDITION
BEFORE USE AS A SOLID FUEL BURNING
FIREPLACE. 250-2061
Heath & Home Technologies
250-2061
5.5 in. width x 2 in. height
NON. ANOD. ALUM BLACK LETTERS ON SILVER
with 1/8 in. holes on both sides.
Black letters
Figure 15.3

16 7044-225B April 9, 2014
31-I ACC
Ovalizing round stainless steel liners to accommodate the
linerpassingthroughthedamperregionofareplaceisan
allowableandacceptablepractice.
Ensure that the ovalization is minimized to the extent
requiredtotthroughthedamper.
J. Ovalizing Round Stainless Steel Liners
Fire Risk.
Do NOT pack insulation or other combustibles
between spacers.
• ALWAYSmaintainspeciedclearancesaround
venting and spacers.
• Installspacersasspecied.
Failure to keep insulation or other material away
fromventpipemaycausere.
WARNING
WARNING! Risk of Asphyxiation!
• DONOTCONNECTTHISAPPLIANCETO
ACHIMNEYFLUESERVICINGANOTHER
APPLIANCEORTOANYAIRDISTRIBUTION
DUCTORSYSTEM.
Thismayallowuegasestoenterthehouse.
K. Chimney Height / Rise and Run
TobesurethatyourQuadra-Fireinsertburnsproperly,the
chimneydraft(staticpressure)shouldbeapproximately-0.10
inches water column (W.C.) during a high burn and -0.04
inchesW.C.duringalowburn,measured6inches(152mm)
abovethetopoftheinsertafteronehourofoperationateach
burnsetting.
NOTE:Theseareguidelinesonly,andmayvarysomewhat
forindividualinstallations.
• This product was designed for and tested on a 6 inch
(152mm) chimney, 14 to 16 feet (4.27-4.87m) high, (in-
cludesapplianceheight)measuredfromthebaseofthe
appliance.
• Thefurtheryourstackheightordiametervariesfromthis
conguration,thepossibilityofperformanceproblemsex-
ists.
• Chimneyheightmayneedtobeincreasedby2 - 3% per
each1000feet(304.8m)abovesealevel.
• Itisnotrecommendedtouseoffsetsorelbowsataltitudes
above4000feet(1219.2m)abovesealevelorwhenthere
areotherfactorsthataffectuedraft.
I. Zero-Clearance Fireplace
Fire Risk.
This appliance relies upon natural draft to operate
properly.
• Chimneyheightsexceeding25feet(7.62m)from
base of appliance may create an over-draft
situation.
• Overdraftconditionmaycreateover-ring.
Over-ringmayignitecreosoteand/ordamage
appliance and chimney
WARNING
Apermitmayberequiredforinstallations,nalapprovalis
contingentoftheauthorityhavinglocaljurisdiction.Consult
insurance carrier, local building, re ofcials or authorities
havingjurisdictionaboutrestrictions,installationinspection,
and permits.
Inspecttheexistingreplaceandchimneyforanydamage
orawssuchasburnouts,metalorrefectorywarping.
Inspection to a minimum of NFPA 211 Level II is recom-
mended.  All repairs must be made prior to installing an
insert.Thereplacemustbestructurallysoundandbeable
to support the weight of the solid-fuel insert
Thefactory-builtchimneymustbelistedperUL127orULC
610-M87 for all installations. Install thermal protection per
thisappliancelistingrequirements.
A full height 6 inch diameter stainless steel full height
listed chimney liner must be installed meeting type HT
(2100°F)requirementsperUL1777(USA)orULCS635
with “0” clearance to masonry (Canada). The full liner
mustbeattachedtotheinsertuecollarandtothetop
of the existing chimney.
Theuelinertopsupportattachmentmustnotreducetheair
owfortheexistingair-cooledchimneysystem.Re-install
original factory-built chimney cap only. (See Section F.,
PrefabricatedMetalChimney)
To prevent room air passage to the chimney cavity of the
replace,seal eitherthedamperareaaroundthechimney
linerortheinsertsurround.Circulatingairchamber(i.e.in
asteelreplacelinerormetalhearthcirculator)maynotbe
blocked.Theairowwithinandaroundthereplaceshall
notbealtered,blockedbytheinstallationoftheinsert.(i.e.
nolouversorcoolingairinletoroutletportsmaybeblocked
bytheinsertortheinsertsurround.
See“H.AlteringtheFireplace”formodicationsallowedfor
factory-builtreplaces.

April 9, 2014 7044-225B 17
31-I ACC
Figure 17.1
Outside Air
Cover Plate
(Discard)
Rectangular Outside Air
Cover (included with Side
Panel Assembly)
Termination
Cap
Flex Adapter
A. Outside Air Kit Installation
Items Needed for Installation (not supplied)
 • 4 inch ex aluminum pipe, or if using alternate material,
thenitshallbemadefromdurable,non-combustible,heat
resistant material up to 350oF.Cutthepipetotherequired
length for your installation.
 •Phillipsheadscrewdriver
 •5/32AllenWrench
 •Siliconesealant
A source of air(oxygen) is necessaryin order forcombustion
to take place.  Whatever combustion air is consumed by the
re must be replaced. Air is replaced via air leakage around
windows and under doors. In homes that have tightly sealed
doors and windows, an outside air source is needed. An optional
OutsideAirKitisavail able.
WARNING
Donotdrawoutsidecombustionairfrom:
• Wall,oororceilingcavity
• Enclosedspacesuchasanatticorgarage
• Closeproximitytoexhaustventsor
chimneys
Fumes or odor may result
Fire Risk.
Asphyxiation Risk.
Asphyxiation Risk.
Outsideairinletmustbelocatedtopreventblock-
agefrom:
• Leaves,snow,iceorotherdebris
Blockmaycausecombustionairstarvation
Smoke spillage may set off alarms or irritate sensi-
tiveindividuals.
WARNING
Asphyxiation Risk.
LengthofoutsideairsupplyductshallNOTexceed
thelengthoftheverticalheightoftheexhaustue.
• Firewillnotburnproperly
•Smoke spillage occurs when door is opened due
toairstarvation.
WARNING
Option One - Installation Instructions
The outside air cover comes packaged with the component
pack.Itisnecessarytoremovetheblowerhousingandblock
offtheroomairwiththeoutsideaircover.
1. Removetheappliancecoverplateonoutercananddiscard
and reuse the 4 screws.
2. Install optional ex adapter to outer can with the same
screws. Do not use plastic wire ties that come with the kit
astheywillmelt.NOTE:Youmayneedtoinstalltheex
pipeintothereboxrst depending on installation.Attach
extoadapterwithatleast2screws.
3. Ensureexistingaccessholeinreplaceissufcienttofeed
the4inchex.
4. Afterslidingcanintoreplace,feedexintocutopeningto
obtainoutsidecombustionair.
5. Leveloutercanandinstallappliance.Seepage 20.
6. Remove4boltsfrombothsidesoftheblowerhousingand
removethehousing.
7. Remove2Phillipsheadscrewsfromhousingandsave.
8. Attachoutsideaircovertothebackoftheblowerusingthe
same 2 screws.
9. Ensure all wires are properly attached and then re-install
theblowerhousingtotheappliance.
Option Two - Installation Instructions
1. Removethe outside air cover plate on outer cananddis-
card and reuse the 4 screws
2. Ensureexistingaccessholeinreplacewillnotbecovered
by the outer can. Existing outside air intake hole may be
underattherearorsideofoutercan.Outsideairmayalso
enterdownexistingchimneychaseinsomesituations.
3. Repeatsteps5through9abovewithoneexception.After
installingtheapplianceintheoutercan,sealthereplace
openingandtrimpackagewithinsulationtopreventairleak-
age into the room.
5 Appliance Set-Up

18 7044-225B April 9, 2014
31-I ACC
B. Disassemble Firebox and Outer Can
For easier eld installation the outer can is installed with-
outthereboxsoconnectingtotheuehasgreateraccess.
Thereboxslidesintotheoutercanoncetheuecollaris
attachedtothestovepipe/linerandoptionaloutsideairex
pipe is installed.
1. Removethe ue collar bycuttingthewireties.Setthe
uecollarandattachmentbaraside.
2. Removethe2screwsholdingthetimerassemblyinplace
andremovethetimer.Figure18.1.
3. Removethe2Phillipsheadboltsunderneaththeashlip
whichholdsthereboxinplace.
4. Slidethereboxoutoftheoutercan.
5. Removethe2palletlagbolts.
Firebox
Timer Assembly
Outer Can
Phillips Head Bolts
Pallet
Lag
Bolts
Flue Collar
Attachment Bar
Figure18.2
Timer Screws
Figure18.1

April 9, 2014 7044-225B 19
31-I ACC
Figure 19.2
Figure 19.3
Figure 19.4
Cast Iron Flue Located on Appliance
Drill through all 8 countersunk
locations
Once distance is established, drill holes
and secure both chambers together.
Figure 19.5
C. Securing Stove Pipe/Liner to Flue Collar
1.Thereare4pre-drilledholesintheuecollar90degrees
apart.Attachtheuecollartothestovepipe/liner.Ifthe
sealisquestionableusehightemperaturesealantsuch
asstovemasticFigure 19.1.
2.Attachgaskettobottomsideofuecollarwithathincoat
of silicone.
Flue Collar Stove Pipe/Liner
Gasket
Figure 19.1
D. Optional Offset Adapter Installation
Insomeinstallationstheuecollarandstovepipe/linerdo
notalwaysalignproperly.Thissituationmayberemedied
byusingtheoptionaloffsetadapter.SeeApplianceDimen-
sions page for the amount of distance this accessory can
telescopebetweentheuecollarandstovepipe/liner.
1.Removethecastironuecollarfromtheapplianceand
ipitupsidedown.Usingthelarger#7drillbitsupplied,
drill through all 8 countersunk locations. Figure 19.2.
2.Slidethegasketovertheuecollar andattachittothe
offsetadapterusingthe8-32atheadscrewsprovided.
Figure 19.3.
3. Adjust the offset adapter to desired distance. Drill holes
through the lower chamber as shown in Figure 19.4
usingthesmalldrillbit#26provided.
4.Cutthegaskettotheproperlengthandslideinbetween
the upper and lower chambers centered on the screw
holes.Attachtheupperandlowerchamberswithscrews
provided.Figure 19.5.
5.Repeattheprocessonthebottomside.

20 7044-225B April 9, 2014
31-I ACC
Corner Brackets
Figure 20.5
Figure 20.4
Secure 2 Side Surrounds to
Top Surround
Attachment Holes to Outer Can
Figure 20.6
Top Surround
Side Surround
# 8 Screws
F. Surround & Trim Kit Installation
1. Lay surround face down on a protected surface to pre-
ventscratching.
2. Using a Phillips head screw driver attach the side sur-
roundstothetopsurroundusing2#8sheetmetalscrews
providedwiththekit. Figure 20.4.
3. Laythetrimfacedownandplacethecornerbracketsinto
position.
4. Using a standard at screw driver tighten the corner
brackets.Figure 20.5.
5. Slidethetrimoverthesurroundset.
6. Install the surround set and trim set to the outer can.
Secure the top and side surrounds as shown in Figure
20.6.
E. Installing Outer Can & Leveling Bolts
1. Alignthebackofsurfaceofoutercansidepanelstothe
front wall surface for proper placement. Figure 20.2.
Usethelevelingboltstoleveltheoutercan.Figure 20.1.
3. Thread the horizontal support bolts in until they hit the
backwallofthereplacetohelpsecureinplace. Figure
20.3.
4. It is recommended that you use the pallet mounting holes
tolagtheoutercanintothereplaceoorforextrasup-
port,howeveritisnotrequired.
Horizontal
Support Bolts
Leveling Bolts
Outer Can Side Panels
Wall
Wall
Wall
Outer Can
Side Panel
Figure 20.1
Figure 20.2
Horizontal Support
Bolts
Back Wall
Figure 20.3
