Quality Craft MW914T-24BK User manual

1
Model: MW914T-24BK
ELECTRIC FIREPLACE
HEATER
IMPORTANT:
PLEASE NOTE: WHEN YOU OPEN THE CARTON, CAREFULLY CHECK THE UNIT AND
MAKE SURE THERE IS NO DAMAGE. IF YOU HAVE ANY PROBLEMS WITH THE UNIT,
WITH HOW THE VARIOUS FUNCTIONS WORK, OR HAVE DAMAGED OR MISSING
PARTS PLEASE CALL 1-800-459-4409 (MONDAY TO FRIDAY, 8:30AM TO 5:00PM,
EST) IMMEDIATELY FOR SERVICE.
NOTE: DO NOT RETURN UNIT TO THE STORE BEFORE CALLING THE TOLL FREE
NUMBER. DO NOT DISPOSE OF YOUR CARTON UNTIL YOU ARE COMPLETELY
SATISFIED WITH YOUR NEW FIREPLACE HEATER.
NOTE: Light bulbs may become loose during shipping. If the flame effect is dim or does
not work, please check that light bulb or bulbs are finger tight in socket. See instructions for
replacing bulb or bulbs. Please do not return the sample to the store before checking light bulbs.
NOTE: The electric fireplace heater may emit a slight harmless odor when first turned on.
This is caused by activating the internal heater components for the first time and should not
occur again.
INSTRUCTION MANUAL
ATTENTION:
1. Find a location for the fireplace heater that is protected from direct sunlight.
2. Do not plug the unit into the power outlet before reading all instructions.
IMPORTANT SAFETY INSTRUCTIONS
WHEN USING ELECTRICAL APPLIANCES, BASIC PRECAUTIONS SHOULD ALWAYS
BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, AND INJURY TO
PERSONS, INCLUDING THE FOLLOWING:
1) Read all instructions before using this electric fireplace heater.
2) This electric fireplace heater is hot when in use. To avoid burns, do not let bare
skin touch hot surfaces. The grill directly in front of the heater outlet becomes
hot during heater operation. Keep combustible materials, such as furniture,
pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9 m) away from
the front of the unit and keep them away from the sides and rear.
3) Extreme caution is necessary when any heater is used by or near children
or individuals with disabilities and whenever the fireplace is left operating and
unattended.
4) Always unplug fireplace when not in use.
5) Do not operate any electric fireplace with a damaged cord or plug or after the
heater malfunctions, has been dropped or damaged in any manner.
6) Do not use outdoors.
7) This electric fireplace heater is not intended for use in bathrooms, laundry
areas and similar indoor locations. Never locate heater where it may fall into a
bathtub or other water container.
8) Do not run cord under carpeting. Do not cover cord with throw rugs, runners, or
similar coverings. Arrange cord away from traffic area and where it will not be
tripped over.
9) To disconnect fireplace, turn controls to off, then remove plug from outlet.
10) Connect to properly grounded outlets only.
11) Do not insert or allow foreign objects to enter any ventilation or exhaust
opening as this may cause an electric shock or fire, or damage the heater.
12) To prevent a possible fire, do not block air intakes or exhaust in any manner. Do
not use on soft surfaces, like a bed, where openings may become blocked.
13) A heater has hot and arcing or sparking parts inside. Do not use it in areas
where gasoline, paint, or flammable liquids are used or stored.
14) Use this fireplace heater only as described in this manual. Any other use not
recommended by the manufacturer may cause fire, electric shock, or injury to
persons.
15) Avoid the use of an extension cord because the extension cord may overheat
and cause a risk of fire. However, if you have to use an extension cord, the cord
shall be No.14 AWG minimum size and rated not less than 1875 watts.
16) Do not plug this product into a receptacle controlled by a wall switch
or dimmer.
17) When storing or transporting the unit and cord, keep in a dry place, free from
excessive vibration and store so as to avoid damage.
SAVE THESE INSTRUCTIONS FOR FUTURE USE.
CAUTION:
IF YOU USE THIS HEATER IN CONJUNCTION WITH A THERMAL CONTROL, A
PROGRAM CONTROLLER, A TIMER OR ANY OTHER DEVICE THAT SWITCHES THE
HEATER ON AUTOMATICALLY, REMEMBER TO OBSERVE ALL SAFETY WARNINGS
AT ALL TIMES. THE FIREPLACE HEATER HAS SAFETY OVERHEAT PROTECTION.
IF THE OVERHEAT PROTECTION TRIPS, SWITCH OFF ALL SWITCHES AND WAIT
APPROXIMATELY 5–10 MINUTES. IT SHOULD RESET AUTOMATICALLY ONCE THE
UNIT COOLS DOWN.
WARNING:
PROCEDURES AND TECHNIQUES, IF NOT CAREFULLY FOLLOWED, WILL RESULT
IN DAMAGE TO THE EQUIPMENT, AND WILL EXPOSE THE USER TO THE RISK OF
SERIOUS INJURY, ILLNESS OR DEATH.
THIS ELECTRIC FIREPLACE HEATER IS FOR USE ON 120 VOLTS. THE CORD HAS
A PLUG AS SHOWN AT A IN ILLUSTRATION BELOW. AN ADAPTER AS SHOWN AT
C IS AVAILABLE FOR CONNECTING THREE-BLADE GROUNDING-TYPE PLUGS TO
TWO-SLOT RECEPTACLES. THE GREEN GROUNDING PLUG EXTENDING FROM
THE ADAPTER MUST BE CONNECTED TO A PERMANENT GROUND SUCH AS A
PROPERLY GROUNDED OUTLET BOX. THE ADAPTER SHOULD NOT BE USED IF
A THREE-SLOT GROUNDED RECEPTACLE IS AVAILABLE. A 15 AMP CIRCUIT IS
REQUIRED TO OPERATE THIS HEATER. IF THE BREAKER TRIPS WHEN THE HEATER
IS USED, YOU MAY NEED TO MOVE THE HEATER TO ANOTHER LOCATION OR
UNPLUG OTHER APPLIANCES THAT ARE ON THE SAME CIRCUIT. IF YOU REQUIRE
AN EXTENSION CORD, USE ONE THAT IS RATED AT 1875 WATTS.

2
PARTS LIST
Fireplace ............................................................................................................... 1
A) Mounting screws............................................................................................... 2
B) Wall Anchors..................................................................................................... 2
TOOLS REQUIRED: LEVEL, ELECTRIC DRILL, DRILL BITS (5/16 INCH (8MM)), PHILLIPS HEAD SCREWDRIVER, HAMMER,
SAFETY GOGGLES AND GLOVES
INSTALLATION
Step 1: Select the wall location where you want to hang your electric fireplace heater. Draw a
horizontal line using a level and mark 2 drill holes as shown in Fig. A for the 2 mounting
screws. The 2 screws holes shall be spaced 260mm.
NOTE: The 2 holes are for mounting of fireplace and it must be level so that the fireplace can
be mounted properly and leveled.
Fig. A
Step 2: Drill 2 holes 5/16in (8mm) on the marked locations. For holes that do not hit stud, use
the supplied wall anchor. Install the wall anchors into the holes and gently tap them into
place with a hammer until the flange of the wall anchor is flush with the wall surface.
See Fig. B
Fig. B
Step 3: Secure the 2 mounting screws into the wall anchor as Fig. C.
Fig. C
Step 4: Mount the fireplace on the wall by the keyhole slots of metal bracket at the back of
fireplace. See Fig. D
Fig. D

3
Step 5: Make sure that the 2 mounting screws are completely engaged into the metal bracket
at the back of the fireplace. See Fig. E
Fig. E
OPERATION
After reading complete instructions, confirm all controls on fireplace are in the OFF position.
Plug the fireplace into a 15 AMP/120 Volt outlet.
OPERATION BY THE CONTROL PANEL
The controls are located at the left side behind the front glass.
LEFT SIDE
O/I: Press this button for main power. The indicator light will be on. See below for other
control switches.
: STaNdby SwITch: Press this switch once to turn on the fireplace. Press again
to turn off all functions and enter the standby mode.
: FLaME: Press this button once for flame effect. The unit will beep and the
indicator light will be ON. The bulbs for flame effect will turn ON. To adjust the
flame intensity, hold down the button – the flame optics will go higher or lower.
Once you have found the desired setting, release the button. Pressing the button
again will stop the light function.
750w: Press this button while the 0/I and standby buttons are in the ON position for
low heat. The indicator light will turn on. Press this button again to stop the low
heat function.
1500w: Press this button while the 0/I and standby buttons are in the ON position for
high heat. The indicator light will turn on. Press this button again to stop the
high heat function.
NOTE: When the O/I switch is turned OFF, all other heater functions will stop even
though the switches may be in the ON position.
OPERATION BY THE REMOTE CONTROL
Plug in your electric fireplace and turn the “0/I”
switch to “I” position. The unit will beep once
and your remote is ready to operate your electric
fireplace heater.
: STaNdby SwITch: Press this button
once, the unit becomes energized and
you can select the following functions as
desired. Press this button again, the unit
will turn off and enter the standby mode.
: FLaME: Press this button once for flame
effect. The unit will be beep and the
indicator light will be ON. The bulbs for
flame effect will turn ON. To adjust the
flame intensity, hold down the button – the
flame optics will go higher or lower. Once
you have found the desired setting, release
the button. Pressing the button again will
stop the light function.
750w: Press this button for low heat.
The unit will beep, the indicator light will
be on. The fireplace will give low heat
level. Press this button again to stop the
low heat function.
1500w: Press this button for high heat.
The unit will beep, the indicator light will
be on. The fireplace will give high heat
level. Press this button again to stop the
high heat function.
REMOTE CONTROL BATTERY REPLACEMENT
Replace with 2 AAA batteries.
WARNING: DO NOT MIX OLD AND NEW BATTERIES. DO NOT MIX
ALKALINE, STANDARD (CARBON-ZINC), OR RECHARGEABLE
(NICKEL CADMIUM) BATTERIES.

4
MAINTENANCE
WARNING: DISCONNECT POWER AND UNPLUG THE POWER CORD BEFORE
ATTEMPTING ANY MAINTENANCE OR CLEANING TO REDUCE THE RISK OF FIRE,
ELECTRIC SHOCK OR DAMAGE TO PERSONS. THE BULBS IN YOUR UNIT CAN BECOME
EXTREMELY HOT. ALLOW AT LEAST 10 MINUTES BETWEEN TURNING OFF THE UNIT
AND REMOVING THE LIGHT BULBS TO AVOID THE ACCIDENTAL BURNING OF THE
SKIN.
RISK OF FIRE: DO NOT EXCEED THE RECOMMENDED BULB WATTAGE.
REPLACING THE LIGHT BULBS
Step 1: The light bulb compartment is located at the bottom of fireplace as shown in Fig. F.
Remove 2 screws to open cover.
Fig. F
Step 2: You will find 1 X 40W Type B-10 bulb under log-set bed. See Fig. G.
Fig. G
Step 3: Loosen and remove the burnt out bulb and replace with new bulb.
See Fig. H.
Fig. H
Step 4: Close the cover and secure the 2 screws.
Step 5: Plug in the unit.
CLEANING
To clean the unit first turn off the controls on the unit and unplug the unit from power source. To
clean the glass display panel; remove dust with clean dry cloth. Remove finger prints and other
marks with clean damp cloth. Do not use abrasive cleaners or spray liquids on glass display
panel surface. Metal and metal painted parts should be cleaned with a damp cloth. Do not use
abrasive cleaners or spray liquids on these surfaces.

5
WARRANTY
Every electric fireplace heater is tested before it leaves the factory and it is guaranteed for one
year. If the unit should fail to operate correctly within one year from the date of purchase, call
customer service at 1-800-459-4409 (Monday to Friday, 8:30am to 5:00pm, EST). We will,
at our discretion, either repair or replace the unit. It will have to be returned to us freight prepaid
and we will return the repaired or replaced unit to you freight prepaid. The company’s sole
obligation is to repair or replace the unit.
This warranty is void, if in the opinion of Quality Craft, the unit has been tampered
with, altered, misused, damaged, abused or used with the wrong power source.
Light bulbs (and remote batteries) are not covered by this warranty. The warranty is
for homeowner use only and does not cover units used in commercial situations.
WARRANTY CLAIM PROCEDURE
If a claimable defect occurs, please fill out a claim form through our website at
www.qualitycraft.com or contact our customer service department at 1-800-459-4409
(Monday to Friday, 8:30am to 5:00pm, EST).
Before you make your claim call, please make sure you have:
1. The description of the electric fireplace
2. Proof of sale
3. Details regarding the defect
4. Name and address of the owner and installer
Claims must be filled out in writing and returned within six (6) months of appearance
of defect. Failure to comply with this stipulation will make the warranty null and void.
We reserve the right to a thirty-day (30) delay following receipt of claim in which to inspect the
product. We assume no responsibility for labor costs, removing/replacing
a previously installed product, transportation, or return of the product.
Imported by
Quality Craft
Laval, Quebec, Canada H7C 0A5
1-800-459-4409 (EST)
www.qualitycraft.com
Made in China
