Quantum Design KinetiZ 7L User manual

Notice
The information in this document is subject to change in order to improve reliability, design,
or function without prior notice and does not represent a commitment on the part of this
company. In no event will we be liable for direct, indirect, special, incidental, or consequen-
tial damages arising out of the use or the possibility of such damages.
All trademarks are the property of their respective owners.
If you need any further information, please visit our web-site www.qdigrp.com.
Item Checklist
Completely check your package. If you discover damaged or missing items, contact your
retailer.
KinetiZ 7L mainboard
QDI Driver CD 2000
I/O shield(optional)
1 IDE ribbon cable
1 floppy ribbon cable
1 10-pin ribbon cable with bracket for USB3 and USB4(optional)
Users manual
All manuals and user guides at all-guides.com

Declaration of conformity
QUANTUM DESIGNS(HK) LTD.
20th loor, Devon House, TaiKoo Place 979 Kings Road,
Quarry Bay, Hong Kong
declares that the product
Mainboard
KinetiZ 7L
is in conformity with
(reference to the specification under which conformity is declared in
accordance with 89/336 EEC-EMC Directive
!"EN 55022 Limits and methods of measurements of radio disturbance
characteristics of information technology equipment
!"EN 50081-1 Generic emission standard Part 1
Residential, commercial and light industry
!"EN 50082-1 Generic immunity standard Part 1
Residential, commercial and light industry
European Representative
QDI COMPUTER ( UK ) LTD QDI COMPUTER ( SCANDINAVIA ) A/S
QDI SYSTEM HANDEL GMBH QDI EUROPE B. V.
QDI COMPUTER (FRANCE) SARL QDI COMPUTER HANDELS GMBH
LEGEND QDI SPAIN S.L. QDI COMPUTER (SWEDEN) AB
Signature Place / Date HONG KONG/2001
Printed Name Lv Yan Position/ Title Assistant President
All manuals and user guides at all-guides.com

Declaration of conformity
Trade Name: QDI Computer ( U. S . A. Inc.
Model Name: KinetiZ 7L
Responsible Party: QDI Computer ( U. S. A. Inc.
Address: 41456 Christy Street
Fremont, CA 94538
Telephone: [phone]
Facsimile: (510 668-4966
Equipment Classification: FCC Class B Subassembly
Type of Product: Mainboard
Manufacturer:Quantum Designs (HK) Inc.
Address: 20/F, Devon House, TaiKoo Place
979 Kings Road, Quarry Bay, HONG
KONG
Supplementary Information:
This device complies with Part 15 of the FCC Rules. peration is subject to the
following two conditions : (1) this device may not cause harmful interference,
and (2) this device must accept any interference received, including interference
that may cause undesired operation.
Tested to comply with FCC standards.
Signature : Date : 2001
All manuals and user guides at all-guides.com

CONTENTSCONTENTS
CONTENTSCONTENTS
CONTENTS
I
Chapter 1 Introduction ................................................... 1
Overview ............................................................................................ 1
Key Features ...................................................................................... 1
Chapter2 Installation Instructions .................................. 5
External Connectors ................................................................. 5
P /2 Keyboard & P /2 Mouse Connector ............................................. 5
U B1 & U B2 and LAN connector ....................................................... 5
UART2 & U B3 ,4 ............................................................................... 6
Parallel Port , erial Port and Monitor output Connector ....................... 6
Line-in jack(or Real out jack), Microphone-in jack, peaker-out jack and
MIDI/Joystick connector ....................................................................... 7
ATX Power upply Connector & Power witch(POWER W) .............. 7
Hard Disk LED Connector (HD LED) ..................................................... 8
Reset witch (RE ET) ......................................................................... 8
peaker Connector ( PEAKER) ........................................................... 8
ACPI LED Connector (ACPI_LED) ......................................................... 8
GREEN LED Connector(GREEN_LED) .................................................. 8
Hardware Green Connector ( LEEP W) ............................................ 8
Power LED Connector(PWRLED) ......................................................... 8
Key-lock connector(KEY_L) ................................................................ 9
Infrared Header (IrDA) ........................................................................ 9
Fan Connector (CPUFAN , CH FAN, BAKFAN) .................................. 10
Chassis ecurity witch (CH EC) .................................................. 10
Audio Connectors(CD_IN, MODEM) ..................................................... 11
Audio/Modem Riser Interface Connector(AMR) ................................... 11
Wake-Up On Internal Modem (WOM) .................................................. 12
Wake-Up On LAN (WOL) ................................................................... 12
Audio Interface ................................................................................. 13
Expansion lots & I/O Ports description ............................................. 14
Jumper Settings ........................................................................... 14
Wake-up On LAN (JP10) ................................................................... 14
Clear CMO (JCC) .............................................................................. 15
BIO -ProtectEasy Jumper(JAV) ......................................................... 15
Overclocking Jumper etting (JF B) .................................................. 16
All manuals and user guides at all-guides.com

CONTENTSCONTENTS
CONTENTSCONTENTS
CONTENTS
II
Enable/Disable onboard audio(J D) ................................................... 17
Enable/Disable on_board LAN (JLAN) ................................................ 17
CPU Core Voltage etting(JP2) .......................................................... 18
Chapter3 BIOS Description ................................................. 19
Utility Support ........................................................................... 19
AWDFLA H.EXE ............................................................................... 19
AWAR BIOS escription ........................................................ 20
Entering etup ................................................................................... 20
Load Optimized Defaults .................................................................... 20
tandard CMO Features etup ...................................................... 20
CPU peedEasy etup ...................................................................... 24
Advance BIO Features etup ........................................................ 25
Advance Chipset Features etup .................................................... 28
Power Management etup............................................................... 31
PnP/PCI Configurations etup .......................................................... 34
Integrated Peripherals ...................................................................... 35
PC Health tatus ................................................................................ 38
et upervisor/User Password ......................................................... 39
Appendix A QDI Driver CD 2000 ........................................ 40
Appendix B Facilité de vitesse Initialisation(Francais) ................41
LogoEasy .......................................................................................... 45
RecoverEasy .................................................................................... 46
BIO -ProtectEasy .............................................................................. 55
Norton AntiVirus ................................................................................ 55
QDI ManageEasy ............................................................................... 56
QDI BootEasy .................................................................................... 57
All manuals and user guides at all-guides.com

Caution
1. Be sure to add some Silicone Grease between the Socket A pro-
cessor and FAN to keep them fully contact, meanwhile to meet the
heat sink requirement.
2. Because the processor could overheat and damage both the proces-
sor and the motherboard, we recommend that you should have an AM
authorized fan to prevent overheating.
3. Never run the processor without the heatsink properly and firmly
attached.
This manual is suitable for mainboards of KinetiZ 7L series.
Each mainboard is carefully designed for the PC user who
wants different features.
KinetiZ 7L: with udio without L N
KinetiZ 7L-L: with udio and L N
Note:
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
Chapter 1
Introduction
Chapter 1
Chapter 1
Introduction
Overview
The KinetiZ 7L green mainboard utilizes the VIA Apollo KLE-133 chipset, Integrated 2D/3D
Graphics accelerator with support for the ocket A AMD® DuronTM/AthlonTM processors.
The VIA®
VT686B chipset integrates software configurable AC97 audio, MC97 modem and
supports Ultra ATA33/66/100 technology. The VIA® KLE-133 chipset provides some new
features such as Ultra-Fast 200MHz F B. Equipped with two memory module sockets,
1.0GB PC100/133MHz DRAM can be supported. It also provides advanced features such
as wake-up on LAN and wake-up on internal /external modem function.
Key Features
Form factor
#"Micro ATX form factor of 244mm x220mm
Microprocessor
#upports AMD ocket A AthlonTM B type (F B is 200MHz)processors at 700MHz/
750MHz/800MHz/850MHz/900MHz/950MHz/1GHz
#upports AMD ocket A DuronTM processors at 600MHz/650MHz/700MHz/750MHZ/
800MHz/ 850MHZ/900MHz and further processors
#upports 200MHz F B
Chipset
#"Apollo KLE-133 chipset: VT8361, VT82C686B
System memory
#Provides two 3.3V 168 pin DIMM sockets, supports PC100/133 DRAM
#Minimum memory size is 16MB, maximum memory size is 1.0GB
On-chip AGP
#Integrated 2D/3D Graphics engines
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
Introduction
On-board I E
##
##
#Two fast IDE interfaces supporting four IDE devices including IDE hard disks and
CD-ROM drives
##
##
#upports Ultra ATA/33/66/100
On-chip I/O
##
##
#One floppy port supporting up to two 3.5″ or 5.25″ floppy drives with 360K/720K
/1.2M/1.44M/2.88M format
##
##
#Two high speed 16550 fast compatible UARTs(COM1/COM2/COM3/COM4 selective)
with 16-byte send/receive FIFOs
#"One joystick port
#"infrared interface
##
##
#All I/O ports can be enabled/disabled in the BIO setup
On-chip Audio
##
##
#Build in VT 2C6 6B
##
##
#Direct ound AC97 Audio
#"#"
#"#"
#" AC97 2.1 Compliant
Advanced features
##
##
#PCI 2.2 pecification compliant
##
##
#Provides Trend ChipAwayVirus® On Guard
##
##
#Provides four U B ports, on-board P /2 mouse and P /2 keyboard ports
##
##
#upports software power-down (eg. Windows 98/Windows 2000)
##
##
#upports wake-up on LAN and wake-up on internal/external modem
#" upports system monitoring(monitors CPU and system temperatures, system voltages
and fan speed).
#" Providing QDIs innovations such as RecoveryEasy, BIO -ProtectEasy(to protect the
system BIO from being attacked by severe virus such as CIH ), LogoEasy, ManageEasy
and BootEasy(new feature)
BIOS
##
##
#Licensed advanced AWARD BIO , supports Flash ROM with 2Mb memory size,
plug and play ready
##
##
#upports IDE CD-ROM or C I boot up
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
Chapter 1
Green function
##
##
#upports ACPI (Advanced Configuration and Power Interface) and ODPM (O
Directed Power Management)
#upports ACPI power status: 1, 4( TD), 5( oft-off)
Expansion slots
#1 I A slot
#3 PCI slots
#1 AMR slot
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
T-- This page is intentionally left blank --hi
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
Chapter 2
Installation Instructions
Chapter 2
Installation Instructions
This section covers External Connectors and Jumper ettings. Refer to the mainboard
layout chart for locations of all jumpers, external connectors, slots and I/O ports. Further-
more, this section lists all necessary connector pin assignments for your reference. The
particular state of the jumpers, connectors and ports are illustrated in the following figures.
Before setting the jumpers or inserting these connectors, please pay attention to the direc-
tions.
External Connectors
PS/2 Keyboard Connector, PS/2 Mouse Connector
P /2 keyboard connector is for the usage of P /2 keyboard. If using a standard AT size
keyboard, an adapter should be used to fit this connector. P /2 mouse connector is for the
usage of P /2 mouse.
USB1, USB2 and LAN Connector
Two U B ports are for connecting U B devices. The RJ-45 connector is for onboard LAN.
(LAN is optional)
chapter 2
PS/2 Mouse Connector
PS/2 Keyboard Connector
USB1
USB2
LAN
LINK Active
Be sure to unplug the AC power supply before adding or removing expansion
cards or other system peripherals, otherwise your mainboard and expansion
cards might be seriously damaged.
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
UART2, USB3,4
The serial port UART2 is not available on the back panel. Therefore, we provide a 9-pin
header and a ribbon cable with bracket for UART2 port (manufacturing option). Provides
four U B ports,U B3,4 are provided by a 10-pin ribbon cable on board.The optional ribbon
cable connects U B3,4 on the panel or the back panel.
Parallel Port , Serial Port and Monitor Output Connector
The parallel port connector can be connected to a parallel device such as a printer. The serial
port UART1 connector can be connected to a serial port device such as a serial port mouse.
You can enable/disable them and choose the IRQ or I/O address in Integrated Peripherals
from AWARD BIO ETUP. The monitor output connector is for output to a VGA-compatible
device.
Parallel Port
UAR 1
VGA
6
Installation Instruction
UART2
1
USB3,4
D1-
GND
D1+
GND
D0-
D0+
+5V
GND
GND
+5V
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
ATX Power Supply Connector & Power Switch (POWER SW)
Be sure to connect the power supply plug to this connector in its proper orientation. The
power switch (POWER W) should be connected to a momentary switch (power button).
When powering up your system, first turn on the mechanical switch of the power supply (if
one is provided), then push once the power button. When powering off the system, you
neednt turn off the mechanical switch, just Push once* the power button.
ote: * If you change soft-off by PWRBT  from default Instant-off to Delay 4
Secs in the POWER MA AGEME T SETUP section of the BIOS, the power button
should be pressed for more than 4 seconds before the system powers down.
Line-in jack, Microphone-in jack, Speaker-out jack and MIDI/Joystick
connector
The Line-in jack can be connected to devices such as a cassette or minidisc player to
playback or record. The Microphone-in jack can be connected to a microphone for voice input.
The peaker-out jack allows you to connect speakers or headphones for audio output from
the internal amplifier.The MIDI/Joystick connector allows you to connect a game joystick or a
MIDI device.
POWER
SW
POWER
SW
POWER
SW
ATX Power Supply Connector

5V 5 V -5V GND GND PSON -12V 3.3V GND
12V 5VSB 5V GND 3.3V GND
5V GND PS-OK 3.3V
GND
chapter 2
Line in(or Rear out ) jact
IDI/Joystick
Speaker out icrophone in
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
Hard Disk LED Connector (HD_LED)
The connector connects to the cases IDE indicator LED indicating the activity status of IDE
hard disk. The connector has an orientation. If one way doesnt work, try the other way.
Reset Switch (RESET)
The connector connects to the cases reset switch. Press the switch once, the system
resets.
Speaker Connector (SPEAKER)
The connector can be connected to the speaker on the case.
ACPI LED Connector (ACPI_LED)
The ACPI LED is double-color lights with three pins. Pin1&Pin2 drive different color lights. If
Pin1 drives the yellow light , Pin2 drives the green light, the following status will come out.
When the system is in power up status, the LED is green on. When the system is in suspend
status, the LED is green blink. When the system is in soft-off status, the LED is off.
GREEN LED Connector (GREEN_LED)
When the system is in power up, ACPI suspend, soft-off, the LED is off. When the system
is in APM(advanced power management) suspend, the LED is on.
Hardware Green Connector (SLEEP SW)
Push once the switch connected to this header, the system enters suspend mode.
Power LED Connector (PWRLED)
The power LED has four status. When the system is in power up status, the LED is on.
When the system is in suspend status, the LED is blink. When the system is in oft-Off
status, the LED is off.The connector has an orientation.
8
Installation Instruction
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
Key-Lock Connector(KEY_L)
The connector can be connected to the keyboard lock switch on the case for locking the
keyboard(only for DO ).
Infrared Header (IrDA)
This connector supports wireless transmitting and receiving. If using this function, set
UART 2 Mode to HP IR or A KIR and configure the settings from the INTEGRATED
PERIPHERAL  section of the BIO .
chapter 2
SPEAKER RESE GREEN LEDKEYLK
ACPI LED SLEEP
SW PWR LED
HDD LED(+) HDD LED(-)
Orange(-)
Green(-)
LED+
POWER
GND
EMP Y
EMP Y
SLEEP
GND
LED+
LED-
LED- KEYLOCK
GND
LED-
LED-
LED+
EMP Y
GND
RESE
SPKDA A
NC
GND
VCC
POWER
SW
SPEAKER RESE GREEN LED KEYLK
PWR LED
ACPI LED
HD_LED
POWER
SW
SLEEP
SW
VCC
NC
IRRX GND IR X VCC
1
9
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
Chassis Security Switch (CHSSEC)
The connector connects to the chassis security switch on the case. The system can
detect the chassis intrusion through the status of this connector. If the cased has been
opened , the system will record the status and indicate the chassis has been opened. You
can receive this information from QDI ManageEasy software.
GND
Indicate signal
an Connector (CPU AN, CHS AN, BAK AN)
Besides speed of the BAKFAN, The speeds of the CPU fan and chassis fan can be
detected and viewed in PC Health tatus section of the BIO .
10
Installation Instruction
BAKFAN
CPUFAN
FAN GND
+12V
SENSE
CHSFAN
FAN GND
+12V
SENSE
FAN GND
+12V
NC
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
Audio Connector (CD_IN, MODEM)
CD_IN is a ony standard CD audio connector, it can be connected to a CD-ROM drive
through a CD audio cable. The MODEM connector allows the onboard audio to interface
with a voice modem card with a similar connector. It allows connecting the mono_in (such
as a phone) or mono_out (such as a speaker) between the onboard audio and the voice
modem card.
Audio/Modem Riser Interface Connector (AMR)
The AMR Interface Connector is the interface between the mainboard and the Audio/Modem
Riser card. The connector provides all necessary signals which supports several different
configurations of audio and modem in the system, such as audio and modem on the Riser,
audio on the mainboard and modem on the Riser, or no audio with modem on the Riser Either
AMR (Audio/Modem Riser) card or MR (Modem Riser) card can be used on this system. This
software configurable AC97 audio and modem system gives customers an advanced,
multimedia solution at an extremely low price. The AC97 audio and modem system can be
enabled/disabled in Advance Chipset Feature etup in AWARD BIO CMO etup.
chapter 2
GND
CD_IN
Common CD Right Channel
CD Left Channel
Phone-In (from Modem) Mono-Out (to Modem)
MODEM
AMR Interface Connector
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
Wake-Up On Internal Modem (WOM)
Through the Wake-Up On Internal Modem function, the system which is in the power-off
status can be powered on by a ring signal received from the internal modem. If this function
is to be used, be sure an internal modem card which supports the function is used. Then
connect this header to the relevant connector on the modem card, set Modem Ring Resume as
Enabled in the POWER MANAGEMENT ETUP section of the BIO . ave & exit, then boot
the operating system once to make sure this function takes effect.
Wake-Up On LAN (WOL)
Through the Wake-Up On LAN function, a wake event occurring from the network can
wake up the system. If this function is to be used, please be sure an ATX 2.01 power
supply of which 5V B line is capable of delivering 720mA, and a LAN adapter which
supports this function are used. Then connect this header to the relevant connector on the
LAN adapter, set Modem Ring Resume as Enabled in the POWER MANAGEMENT ETUP
section of the BIO .( On-board RTL8100 LAN need not use this header) ave & exit, then
boot the operating system once to make sure this function takes effect.
Installation Instruction
Signal for waking up (active low)
1
+5V standby
GND
1
+5V standby
GND
Signal for waking up (active high)
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
Audio Interface
The audio interface includes three parts, one is the FrontAudio, another is the RearAudio,
the last is the ActiveAudio. Their priority level is as sequence. when the FrontAudio is
available, the RearAudio and the ActiveAudio will be cut off. when the RearAudio is
available, the ActiveAudio will be cut off. An onboard amplifier is needed for the case of
earphone plugged into. when the FrontAudio is inexistence, Pin11 and Pin12, Pin13 and
Pin14 must be short connected.
13
chapter 2
Pin
No.
Symbol Pin
No.
Symbol
1 Active LINE Out(R) 2 Active LINE Out
(
L
)
3 GND (ALO) 4 GND (ALO)
GND(+12) 6 GND(+12)
7 +12V(1A) 8 (Cut away )
9 MIC 10 GND ( MIC )
11 Front LINE Out( R ) 12 LINE Next( R )
13 Front LINE Out( L ) 14 LINE Next( L )
1 GND (FLO) 16 (Cut away )
FrontLineOutR
FrontLineOutL
LineNextR
LineNextL
GND
Speaker Out
Line in
Microphone in
Speaker
Earphone
FAUDIO
191113
15
46810
121416
2
357
All manuals and user guides at all-guides.com

Manual for KinetiZ 7L
Installation Instruction
Wake-Up On LAN (JP10)
This Jumper allows you to enable or disable the onboard LAN wake up function.If you wish
to use wake on LAN function,set the jumper JP10 as closed.Otherwise ,set JP10 as opened
for disabling this function.
14
Jumper Settings
Jumpers are located on the mainboard. Pin 1 for all jumpers are located on the side with a
thick white line ( Pin1→ ), refer to the mainboards silkscreen . Jumpers with three
pins will be shown as to represent pin1 & pin2 connected and to represent
pin2 & pin3 connected.
Disabled
Enabled
JP10
JP10
Expansion Slots & I/O Ports description
lot / Port Description
PCI 1 First PCI slot
PCI 2 econd PCI slot
PCI 3 Third PCI slot
I A First I A slot
AMR. AMR slot
IDE 1 Primary IDE port
IDE 2 econdary IDE port
DIMM1 First DIMM slot
DIMM2 econdary DIMM slot
FLOPPY Floppy Drive Port
All manuals and user guides at all-guides.com
