About this guide ix
About this guide
This guide includes information about the supported controllers and drive trays as well as key
specification information for each one. Use this guide to prepare your site for the installation of
controllers and drive trays into an industry standard cabinet.
The storage products include:
•QS1200 (12-drive chassis)
•QS2400 (24-drive chassis)
•QD6000 (60-drive chassis)
•QD7000 (60-drive chassis)
Intended audience
This guide is intended for storage customers and technicians.
NOTE: This guide is based on the assumption that your storage cabinet in already installed within
your location.
Prerequisites
Prerequisites for installing and using this product include knowledge of:
•Servers and computer networks
•Network administration
•Storage system installation and configuration
•Storage area network (SAN) management and direct attach storage (DAS)
•Fibre Channel (FC) and Ethernet protocols

xSitePlanningGuide
Document conventions and symbols
CAUTION: Indicates that failure to follow directions could result in damage to equipment or data.
IMPORTANT: Provides clarifying information or specific instructions.
NOTE: Provides additional information.
TIP: Provides helpful hints and shortcuts.
Ta b l e 1 Document conventions
Convention Element
Blue text Cross-reference links and e-mail addresses
Blue, underlined text Web site addresses
Bold text •Key names
•Text typed into a GUI element, such as into a box
•GUI elements that are clicked or selected, such as menu
and list items, buttons, and check boxes
Italic text Text em p h a sis
Monospace text •File and directory names
•System output
•Code
•Text typed at the command-line
Monospace, italic text •Code variables
•Command-line variables
Monospace, bold text Emphasis of file and directory names, system output, code,
and text typed at the command-line

QS1200 and QS2400 Systems 1
Chapter 1
QS1200 and QS2400 Systems
This chapter provides specifications for the QS1200 and QS2400 systems.
QS1200 and QS2400 Base System Components
The QS1200 and QS2400 base systems use high-density SAS 2.0 (6-Gb/s) drive enclosure available in a
rack-mount model. The QS1200 system has a capacity of twelve 3.5-in. SAS drives. The QS2400
system has a capacity of twenty-four 2.5-in. SAS drives.
The QS1200 and QS2400 base systems and expansion units provide high-capacity disk storage for
Fibre Channel, Infiniband, SAS and iSCSI environments, depending on the choice of the host interface
card.
QS1200 Base System Front View
Figure 1 provides a front view of the QS1200 base system.
Figure 1 QS1200 Base System (front)
1End caps (the Left End Cap Has the Controller-Drive Tray Summary LEDs)
2Disk drives

2SitePlanningGuide
QS2400 Base System Front View
Figure 2 provides a front view of the QS2400 base system.
Figure 2 QS2400 Base System (front)
QS1200/QS2400 Base System Rear View
Figure 3 provides a rear view of the QS1200/QS2400 base system.
Figure 3 QS1200/QS2400 Base System (rear)
1End caps (the Left End Cap Has the Controller-Drive Tray Summary LEDs)
2Disk drives
1AC Power Connector on the AC Power-Fan Canister
2AC Power Switch

QS1200 and QS2400 Systems 3
QS1200/QS2400 Base System Dimensions
This section provides dimensions for the QS1200 and QS2400 base system.
QS1200 Base System Dimensions
Figure 4 provides the dimensions of the QS1200 base system. The QS1200 base system conform to
the 48.3-cm (19.0-in.) rack standard.
Figure 4 QS1200 Base System Dimensions
QS2400 Base System Dimensions
Figure 5 provides the dimensions of the QS2400 base system. The QS2400 base system conform to
the 48.3-cm (19.0-in.) rack standard.
Figure 5 QS2400 Base System Dimensions

4SitePlanningGuide
QS1200/QS2400 Base System Weights
This section provides the weight of the QS1200 and QS2400 base system and their internal
components.
QS1200/QS2400 Base System Weight (Max/Shipping)
Tab l e 2 provides the weight of the QS1200 and QS2400 base system.
QS1200/QS2400 Base System Component Weights
Tab l e 3 provides the component weights of the QS1200 and QS2400 base system.
Ta b l e 2 QS1200/QS2400 Base System Weight
Unit Maximum Weight1Empty Weight2Shipping Weight3
QS1200 Base System with
twelve 8.89-cm (3.5-in.) SAS
disk drives
27 kg (59.52 lb) 18.60 kg (41.01 lb) 31.75 kg (70.0 lb)
QS2400 Base System with
twenty-four 6.35-cm (2.5-in.)
SAS disk drives
26 kg (57.32 lb) 21.70 kg (47.84 lb) 31.75 kg (70.0 lb)
1. Maximum weight indicates a base system/expansion unit with all of its drives and other components installed.
Because drive weights can vary greatly, this value can vary from the value specified as much as either 0.3 kg
(0.66 lb) times the maximum number of drives per controller-drive tray for 3.5-in. SAS drives or 0.08 kg (0.18
lb) times the maximum number of drives per base system/expansion unit for 2.5-in. SAS drives.
2. Empty weight indicates a controller-drive tray with the controller canisters, the power-fan canisters, and the drives
removed.
3. Shipping weight indicates the maximum weight of the controller-drive tray and all shipping material.
Ta b l e 3 QS1200/QS2400 Base System Component Weights
Component Weight
Controller canister 2.131 kg (4.70 lb)
Power-fan canister 2.500 kg (5.51 lb)
2.5-in. SAS drive 0.3 kg (0.66 lb)
3.5-in. SAS drive 1.0 kg (2.2 lb)

QS1200 and QS2400 Systems 5
QS1200/QS2400 Base System Shipping Dimensions
Tab l e 4 provides the shipping dimensions of the QS1200 and QS2400 base system.
QS1200/QS2400 Base System Temperature and Humidity
Requirements
Tab l e 5 provides the temperature and humidity requirements of the QS1200 and QS2400 base
system.
NOTE: Converting Maximum Rate of Change requires converting between Fahrenheit and Celsius
first, and then subtracting the difference.
Ta b l e 4 QS1200/QS2400 Base System Shipping Weights
Unit Height Width Depth
QS1200 Base System with
twelve 8.89-cm (3.5-in.) SAS
disk drives
24.13 cm (9.5 in.) 63.50 cm (25 in.) 58.42 cm (23 in.)
QS2400 Base System with
twenty-four 6.35-cm (2.5-in.)
SAS disk drives
24.13 cm (9.5 in.) 68.58 cm (27 in.) 58.42 cm (23 in.)
Ta b l e 5 QS1200/QS2400 Base System Temperature and Humidity Requirements
Condition Parameter Requirement
Temperature Operating range (both cabinet and
subsystem)
10°C to 40°C (50°F to 104°F)
Maximum rate of change 10°C per hour (18°F) per hour
Storage range –10°C to 50°C (14°F to 122°F)
Maximum rate of change 15°C per hour (27°F) per hour
Transit range –40°C to 60°C (–40°F to 140°F)
Maximum rate of change 20°C per hour (36°F) per hour

6SitePlanningGuide
QS1200/QS2400 Base System Altitude Ranges
Tab l e 6 provides the altitude ranges of the QS1200 and QS2400 base system.
Relative humidity (no
condensation)
Operating range (both cabinet and
subsystem)
20% to 80%
Storage range 10% to 90%
Transit range 5% to 90%
Operating gradient 10°C (50°F) per hour maximum
Storage gradient 15°C (59°F) per hour maximum
Transit gradient 20°C (68°F) per hour maximum
Maximum dew point 26°C (79°F)
Maximum gradient 10% per hour
Note: If you plan to operate a system at an altitude between 1000 m to 3000 m (3280 ft to 9842 ft) above sea
level, lower the environmental temperature 1.7°C (3.1°F) for every 1000 m (3280 ft) above sea level.
Ta b l e 5 QS1200/QS2400 Base System Temperature and Humidity Requirements
Condition Parameter Requirement
Ta b l e 6 QS1200/QS2400 Base System Altitude Ranges
Environment Altitude
Operating 30.5 m (100 ft) below sea level to 3000 m (9840 ft) above sea level
Storage 30.5 m (100 ft) below sea level to 3000 m (9840 ft) above sea level
Transit 30.5 m (100 ft) below sea level to 12,000 m (40,000 ft) above sea level

QS1200 and QS2400 Systems 7
QS1200/QS2400 Base System Airflow/Heat Dissipation and
Power Requirements
This section provides airflow, heat dissipation and power requirements for the QS1200/QS2400 base
system.
Airflow and Heat Dissipation
Allow at least 76 cm (30 in.) of clearance in front of the QS1200/QS2400 base system and 61 cm (24
in.) behind the QS1200/QS2400 base system for service clearance, ventilation, and heat dissipation.
Figure 6 provides the airflow and heat dissipation of the QS1200 base system.
Figure 6 QS1200 Base System Airflow
176 cm (30 in.) clearance in front of the cabinet
261 cm (24 in.) clearance behind the cabinet

8SitePlanningGuide
Figure 7 provides the airflow and heat dissipation of the QS2400 base system.
Figure 7 QS2400 Base System Airflow
Power Requirements
Tab l e 7 provides the power requirements for the QS1200 and QS2400 base system.
176 cm (30 in.) clearance in front of the cabinet
261 cm (24 in.) clearance behind the cabinet
Ta b l e 7 QS1200 and QS2400 Base System Power Requirements
Component Typical Operating Power Rated Power Requirement
Controller canisters with two
power-fan canisters and 12 SAS HDD
drives, each with 6-TB capacity
KVA: 0.408 KVA: 0.908
Watts: 404 Watts: 900
Btu/Hr: 1377 Btu/Hr: 3071
Controller canisters with two
power-fan canisters and 24 SAS HDD
drives, each with 1.2-TB capacity
KVA: 0.457 KVA: 0.908
Watts: 453 Watts: 900
Btu/Hr: 1545 Btu/Hr: 3071

QS1200 and QS2400 Systems 9
QS1200/QS2400 Base System Acoustic Noise Levels
Tab l e 8 provides the acoustic noise levels for the QS1200 and QS2400 base system.
QS1200/QS2400 Base System Site Wiring and Power
This section provides site wiring and power information for the QS1200 and QS2400 base systems.
Site Wiring
The QS1200 and QS2400 base systems use wide-ranging, redundant power supplies that
automatically accommodate voltages to the AC power source. The power supplies meet standard
voltage requirements for both North American (USA and Canada) operation and worldwide (except
USA and Canada) operation. The power supplies use standard industrial wiring with line-to-neutral or
line-to-line power connections.
Keep this information in mind when you prepare the installation site for the QS1200 and QS2400
base systems:
•Protective ground – Site wiring must include a protective ground connection to the AC power
source.
NOTE: Protective ground is also known as safety ground or chassis ground.
•Circuit overloading – Power circuits and associated circuit breakers must provide enough power
and overload protection.
NOTE: To prevent damage to the base system, isolate its power source from large switching loads,
such as air-conditioning motors, elevator motors, and factory loads.
•Power interruptions – The base system can withstand these applied voltage interruptions:
• Input transient – 50 percent of the nominal voltage
• Duration – One half-cycle
• Frequency – Once every 10 seconds
•Power failures – If a total power failure occurs, the base system automatically performs a
power-on recovery sequence without operator intervention.
Ta b l e 8 QS1200/QS2400 Base System Acoustic Noise Levels
Measurement Level
Sound power
(standby operation)
6.5 bels maximum
Sound pressure
(normal operation)
65 dBA maximum

10 Site Planning Guide
AC Power Input
Tab l e 9 provides the AC power input for the QS1200 and QS2400 base systems.
NOTE: Each power supply contains one 10-A slow-blow fuse.
Power Factor Correction
Power factor correction is applied within the power supply, which maintains the power factor of the
QS1200 and QS2400 base systems at greater than 0.95 with nominal input voltage.
AC Power Cords and Receptacles
Each QS1200 and QS2400 base system ships with two AC power cords, which use the standard AC
outlets in the destination country. Each AC power cord connects one of the power supplies in the
drive tray to an independent, external AC power source, such as a wall receptacle, or to any
uninterruptible power supply (UPS).
If you have a cabinet with internal power cabling, such as a ladder cord, you do not need the AC
power cords that are shipped with the QS1200 and QS2400 base system.
Ta b l e 9 AC Power Input for the QS1200 and QS2400 Base Systems
Parameter Low Range High Range
Nominal voltage 100 VAC 240 VAC
Frequency 50 to 60 Hz 50 to 60 Hz
Typical operating current for
12 drives
4.08 A * 1.70 A **
Typical operating current for
24 drives
4.57 A * 1.90 A **
Maximum operating current
for 12 drives
5.58 A * 2.33 A **
Maximum operating current
for 24 drives
6.07A * 2.53 A **
Sequential Drive Group Spin
Up
4.27 A 1.76 A
Simultaneous Drive Spin Up 6.81 A 2.71 A
System Rating Plate Label 9.0 A 3.6 A
* Typical current: 100 VAC, 60 Hz at 0.87 power supply efficiency and 0.99 power factor. These
numbers can vary significantly, depending upon the drives tested in the particular configuration.
**Typical current: 240 VAC, 60 Hz at 0.87 power supply efficiency and 0.99 power factor. These
numbers can vary significantly, depending upon the drives tested in the particular configuration.
