Quantum 6000 User manual

Owner’s Manual
1-800-800-8586 (Exeter, PA) • 1-888-570-1113 (St. Catharines, ON) • www.quantumrehab.com

www.quantumrehab.com Quantum 6000
SAFETY GUIDELINES
Copyright©2006
PrideMobilityProductsCorp.
INFMANU2969/RevC/July2006
Thesymbolsbelow areusedthroughoutthis owner'smanualandon thepowerchairto identify warningsand important
information.Itisveryimportant foryoutoread them andunderstandthemcompletely.
WARNING! Failure to follow designated procedures can cause either personal injury, component
damage, or malfunction (black symbol on yellow triangle with black border).
MANDATORY! These actions should be performed as specified. Failure to perform mandatory
actions can cause injury to personnel and/or damage to equipment (white symbol on blue dot).
PROHIBITED! These actions should be prohibited. These actions should not be performed at any
time or in any circumstances. Performing a prohibited action can cause injury to personnel and/
or damage to equipment (black symbol with red circle and red slash).

Quantum 6000 www.quantumrehab.com 3
I. INTRODUCTION.................................................................................................................................4
II. SAFETY.................................................................................................................................................6
III. YOUR POWER CHAIR....................................................................................................................15
IV. ASSEMBLY.........................................................................................................................................21
V. COMFORT ADJUSTMENTS........................................................................................................24
VI. BATTERIES AND CHARGING ....................................................................................................31
VII. OPERATION.......................................................................................................................................35
VIII.CARE AND MAINTENANCE ........................................................................................................43
IX. WARRANTY........................................................................................................................................49
CONTENTS
Thisowner’smanualiscompiledfromthelatestspecificationsandproductinformationavailableatthetimeofpublication.
We reservetherightto makechangesasthey becomenecessary.Anychanges toourproductsmay causeslightvariations
betweentheillustrationsandexplanations inthismanualandthe productyouhavepurchased.

4 www.quantumrehab.com Quantum 6000
I. INTRODUCTION
SAFETY
WELCOMEto QuantumRehab, a division of PrideMobility ProductsCorporation (Pride). Thepower chairyou have
purchasedcombines state-of-the-artcomponents withsafety,comfort, andstyling inmind.We areconfident thatthese
designfeatureswillprovideyouwiththe conveniences youexpectduringyourdailyactivities.Once you understandhow
to safelyoperateand care foryour power chair, it shouldgive you yearsof trouble freeoperation and service.
Readandfollowall instructions,warnings,andnotesinthismanual beforeattemptingtooperateyourpowerchairfor the
first time. Inaddition, your safetydepends upon you, aswell as your provider, caretaker,or healthcare professional in
usinggoodjudgement.
Ifthereisany informationinthismanual whichyoudonot understand,orifyou requireadditionalassistance for setupor
operation,pleasecontact yourQuantumRehab Specialist.Failuretofollowtheinstructionsinthismanualandthose
locatedonyourpowerchaircan leadtopersonalinjuryand/ordamagetothepowerchair,includingvoidingthe
warranty.
PURCHASER’S AGREEMENT
Byaccepting delivery ofthis product, youpromise that you will not change, alter, ormodify this product or remove or
renderinoperableorunsafeanyguards,shields,orothersafetyfeaturesofthisproduct;fail,refuse,orneglectto installany
retrofitkits fromtime totime providedby Prideto enhanceor preservethe safeuse ofthis product.
INFORMATION EXCHANGE
Wewanttohearyourquestions,comments,andsuggestionsaboutthismanual.Wewouldalsoliketohearaboutthesafety
andreliabilityof your newpowerchair, andaboutthe serviceyoureceivedfrom yourQuantumRehab Specialist.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
products,and newoptions thatcan increase your ability touse andenjoy yourpower chair.Pleasefeel freeto contactus
atthe addressbelow:
PrideMobilityProducts Corporation
Attn:CustomerCareDepartment
182SusquehannaAvenue
Exeter, PA18643-2694
[e-mail]
800-424-8205
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.

Quantum 6000 www.quantumrehab.com 5
I. INTRODUCTION
PRIDE OWNERS CLUB
Asan owner ofa Prideproduct, youare invitedto registeryour product’swarranty andenroll inthe PrideOwners Club.
You may do so by filling out and returning your enclosed product registration card or by visiting Pride's web site at
www.pridemobility.com.Asaregisteredmember,eachtimeyouvisitoursite,youwill have accesstothemostinteractive
andhonesteducationalvenueavailabletodayforpeoplewith mobilityneeds,theirfamilies,andfriends.
Fromourhome page,select“Owners Club”toenter apagededicated tocurrentand potentialPrideproduct owners.You
willgainaccessto interviews, stories,recreationideas,daily livingtips,productand fundinginformation,andinteractive
messageboards.These message boardsinviteyou tocommunicatewith otherPridecustomersas wellasPride represen-
tativeswhoare availabletoassist youwith any questionsor concernsyoumay have.
MyQuantum Rehab Specialist:
Name:_____________________________________________________________________________________
Address:___________________________________________________________________________________
Phone Number:______________________________________________________________________________
PurchaseDate:_______________________________________________________________________________

6 www.quantumrehab.com Quantum 6000
II. SAFETY
Corrosive chemicals contained in battery. Use only AGM or Gel-Cell batteries to
reduce the risk of leakage or explosive conditions.
This product has been tested and passed at an immunity level of 20 V/m.
Read and follow the information in the owner’s manual.
Maximum seating weight.
Locked and in drive mode.
Place unit on level ground and stand behind or to one side when changing from
drive mode to freewheel mode or freewheel mode to drive mode.
Unlocked and in freewheel mode.
Battery Configuration:
++
++
+ = Positive Terminal Post
- = Negative Terminal Post
Connect Red wire to positipositi
positipositi
positivv
vv
ve (+) tere (+) ter
e (+) tere (+) ter
e (+) terminalminal
minalminal
minal
Connect Black wire to negative (–) ter–) ter
–) ter–) ter
–) terminalminal
minalminal
minal
PRODUCT SAFETY SYMBOLS
Thesymbolsbelowareusedon thepowerchairtoidentifywarnings, mandatoryactions,andprohibitedactions.It isvery
importantforyou toreadand understand themcompletely.

Quantum 6000 www.quantumrehab.com 7
II. SAFETY
Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while
operating.
Avoid exposure to rain, snow, ice, salt, or standing water whenever possible.
Maintain and store in a clean and dry condition.
Removal of grounding prong can create electrical hazard. If necessary, properly
install an approved 3-pronged adapter to an electrical outlet having 2-pronged
plug access. Failure to heed could result in personal injury and/or property
damage.
Prevent personal injury and equipment damage. Do not connect an extension
cord to the AC/DC converter or the battery charger.
Disposal and recycling - Contact your authorized Pride Provider for information
on proper disposal and recycling of your Pride product and its packaging.

8 www.quantumrehab.com Quantum 6000
II. SAFETY
SAFETY
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchairisa state-of-the-artlife-enhancementdevicedesignedto increasemobility.Prideprovides anextensive
varietyof products to best fit the individual needsof the power chair user. Please be aware that thefinal selection and
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capableofmaking such adecision,and his/herhealthcareprofessional (i.e.,medicaldoctor,physicaltherapist, etc.).
Thecontentsof this manualarebased ontheexpectation thatamobility deviceexperthas properly fittedthepower chair
totheuserandhasassistedthe prescribing healthcareprofessionaland/ortheQuantumRehabSpecialist in theinstruction
processfor the use of the product.
Therearecertainsituations,includingsomemedicalconditions,wherethepowerchairuserwillneedtopracticeoperating
the power chair in the presence of a trained attendant.Atrained attendant can be defined as a family member or care
professionalspeciallytrainedinassistingapowerchairuserinvariousdailylivingactivities.
Asyoubeginusingyourpowerchairduringdailyactivities,youwillprobablyencountersituationsinwhichyouwillneed
somepractice.Simplytakeyourtimeandyouwillsoonbeinfullandconfidentcontrolasyoumaneuverthroughdoorways,
onand offof elevators, upand down ramps,and overmoderate terrain.
Belowaresomeprecautions,tips,andothersafetyconsiderationsthatwillhelpyoubecomeaccustomedtooperatingyour
powerchairsafely.
Modifications
Pridehasdesignedandengineeredyourpowerchairtoprovidemaximummobilityandutility.Awiderangeofaccessories
isavailable fromyour Quantum Rehab Specialist tofurther customizeyour powerchair tobetter suityour needsand/or
preferences.However,underno circumstances shouldyou modify,add,remove, ordisableany feature,part,or function
ofyourpower chair.
WARNING! Do not modify your power chair in any way not authorized by Pride. Unauthorized
modifications may result in personal injury and/or damage to your power chair.
Pre-Ride Safety Check
Getto knowthe feelof your powerchair andits capabilities.Pride recommendsthat you performa safetycheck before
eachuse tomake sureyour powerchair operates smoothly and safely.
Performthefollowinginspectionspriortousingyourpowerchair:
!Checkforpropertireinflation.Maintainbutdonotexceed 35psi(2.4bar)ineachtireifequippedwithpneumatictires.
!Checkall electricalconnections. Makesure theyare tightand notcorroded.
!Checkall controller connections to thepower base. Makesure they aresecured properly.
!Checkthe brakes. See VIII. “Care and Maintenance.”
!Checkbattery charge.See VI. “Batteriesand Charging.”
NOTE: If you discover a problem, contact your Quantum Rehab Specialist for assistance.

Quantum 6000 www.quantumrehab.com 9
II. SAFETY
Weight Limitations
Yourpowerchair isratedfora maximum weightcapacity.Please refer tothespecificationstable forthislimit.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal injury
and/or damage to your power chair. Pride will not be held responsible for injuries and/or property
damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may result in personal injury and/or property damage.
Tire Inflation
Ifyourpowerchair is equippedwithpneumatictires, youshouldcheckor havetheairpressure checked regularly.Proper
inflationpressureswillprolong the lifeofyourtires andhelpensurethe smoothoperationofyour power chair.
WARNING! It is important that 35 psi (2.4 bar) tire pressure be maintained in pneumatic tires at all
times. Do not underinflate or overinflate your tires. Low pressure may result in loss of control, and
overinflated tires may burst. Failure to maintain 35 psi (2.4 bar) tire pressure in pneumatic tires at
all times may result in tire and/or wheel failure, causing serious personal injury and/or damage to
your power chair.
WARNING! Inflate your power chair drive tires from a regulated air source with an available pressure
gauge. Inflating your tires from an unregulated air source could overinflate them, resulting in a
burst tire and/or personal injury.
Incline Information
Moreandmorebuildingshaveramps withspecifieddegreesofinclination,designedforeasyandsafeaccess.Someramps
mayhaveturning switchbacks(180-degreeturns) thatrequireyou tohavegood corneringskills on yourpower chair.
!Proceedwith extremecaution asyou approachthe downgradeof aramp orother incline.
!Takewide swingswithyourpowerchair’sfrontwheelsaroundanytight corners.Ifyoudothat,thepowerchair’srear
wheelswillfollow awide arc,notcut thecorner short,andnot bumpinto orgethung upon anyrailingcorners.
!When driving down a ramp, keep the power chair’s speed adjustment set to the slowest speed setting to ensure a
safelycontrolled descent. See VII. “Operation.”
!Avoid suddenstops and starts.
Whenclimbinganincline,trytokeepyourpowerchairmoving.Ifyoumuststop,startupagainslowlyandthenaccelerate
cautiously.Whendriving downan incline,set yourpower chairto theslowest settingand drive in the forwarddirection
only. If your power chair starts to move down the incline faster than you anticipated or desired, allow it to come to a
completestopby releasingthejoystick, then pushthejoystick forwardslightlyto ensureasafely controlleddescent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your power chair straight up the incline. This greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the power chair in freewheel
mode while seated on it or standing next to it. Doing so may result in personal injury and/or
damage to your power chair.
WARNING! Never travel down an incline backwards. This may result in personal injury.

10 www.quantumrehab.com Quantum 6000
II. SAFETY
Figure 1. Maximum Safe Slope (Ascending and Descending)
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated in
figure 1, do not, under any circumstances, exceed the incline guidelines or any other specifications
presented in this manual. Doing so could cause instability in your power chair, resulting in personal injury
and/or damage to your power chair.
Incompliancewith theAmericans withDisabilitiesAct of1990, allhandicap publicaccessramps arerequired tohavea
maximumslopeof 5°(8.7%). Therefore,Pride recommendsthatthe maximumslope ofanincline youattempt tosafely
ascend or descend on your power chair does not exceed 5° (8.7%). See figure 1.
WARNING! Any attempt to climb or descend a slope steeper than 5° (8.7%) may put your power
chair in an unstable position and cause it to tip, resulting in personal injury.
Braking Information
Yourpowerchair isequipped with twopowerful brakesystems:
1. Regenerative— useselectricitytorapidly slowthevehicle whenthejoystickreturns tothecenter/stop position.
2. DiscParkBrake — activatesmechanicallyafterregenerativebrakingslowsthevehicle tonearstop,orwhenpoweris
removedfromthe systemforany reason.
Cornering Information
Whileyourpowerchairisequipped withfourcasterwheels,excessivelyhighcorneringspeedscanstillcreatethepossibil-
ityoftipping.Factorswhichaffectthepossibility oftippinginclude,butarenotlimitedto: corneringspeed,steeringangle
(howsharplyyouare turning),unevenroadsurfaces, inclined roadsurfaces,riding from anareaoflow tractiontoanarea
ofhigh traction(such aspassing froma grassyarea toa pavedarea –especially athigh speedwhile turning),and abrupt
directionalchanges. Highcornering speedsare not recommended.If youfeel that you may tipover ina corner, reduce
your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your power chair from tipping.
WARNING! When cornering sharply, reduce your speed. This greatly reduces the possibility of a
tip or fall. To avoid personal injury and/or property damage, always exercise common sense when
cornering.
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your power chair. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with extreme
caution.
5 (8.7%)

Quantum 6000 www.quantumrehab.com 11
CURB
CURB
II. SAFETY
Freewheel Mode
Yourpowerchairisequippedwith twomanualfreewheelleverstoallowformanualmaneuverabilitybyatrainedattendant.
Formoreinformationabouthowtoplaceyourpowerchair intoandoutoffreewheelmode,seeIII.“YourPowerChair.”
WARNING! Do not use your power chair in freewheel mode without an attendant present. Personal
injury may result.
WARNING! Do not attempt to personally place your power chair in freewheel mode while seated
on it. Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline. The chair could
roll uncontrollably on its own, causing personal injury.
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposed
ofconcrete,blacktop,orasphalt.However,Priderecognizesthattherewillbetimeswhenyouwillencounterothersurface
types.For thisreason, yourpower chairis designed toperform admirablyon packedsoil, grass,and gravel. Feelfree to
useyour powerchair safelyon lawns andin parkareas.
!Reduceyourpower chair’sspeed whendrivingon uneventerrain and/or softsurfaces.
!Avoidtallgrassthatcanentangle therunninggear.
!Avoid looselypacked graveland sand.
!Ifyoufeelunsure aboutadrivingsurface, avoidthatsurface.
Stationary Obstacles (Steps, Curbs, etc.)
Proceedwith extreme cautionwhen driving nearraised surfaces, unprotectedledges and/or drop-offs(curbs, porches,
stairs,etc.).The correctmethod forapproachinga curbis illustrated infigure 2.
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than two inches unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed backwards down any step, curb, or
other obstacle. This may cause the power chair to tip and cause personal injury.
Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach
Stairs and Escalators
Powerchairs are notdesigned to travelup or downstairs or escalators. Always use an elevator.
WARNING! Never use your power chair to negotiate steps or escalators. You may cause injury to
yourself and to others and/or damage your power chair.

12 www.quantumrehab.com Quantum 6000
II. SAFETY
Transfers
Transferring onto and off of your power chair requires a
goodsenseofbalance.Alwayshaveanattendant or health-
careprofessionalpresent whilelearning toproperlytrans-
feryourself.
Toeliminatethepossibilityofinjury,Priderecommendsthat
youor atrained attendantperform thefollowing tasksbe-
foreattemptingatransfer:
!Turnoffthepowertothecontroller.SeeVII.“Operation.”
!Ensureyourpowerchairisnotin freewheelmode.See
III.“YourPowerChair.”
!Turnthecasterwheelstowardthetransferdestinationto
improvepowerchairstabilityduringtransfer.
!Make sure both armrests are flipped up or removed
from your power chair.
!Flipup the foot platform or move the leg rests aside;
thiswill helpto keepyour feetfrom gettingcaught on
thefootrigging duringthetransfer.
!Reduce the distance between your power chair and
theobject you are transferring onto.
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause the power
chair to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the foot riggings. Such use may cause the power
chair to tip and cause personal injury.
Doors
!Determineif thedoor openstoward oraway fromyou.
!Driveyourpowerchairgentlyand slowlyforwardtopushthedoor open.Ordriveyourpowerchair gentlyandslowly
backwardsto pull the door open.
Elevators
Modernelevators havea dooredge safetymechanism that, whenpushed, reopensthe elevatordoor(s).
!Ifyou are inthe doorway ofan elevator whenthe door(s) begin to close, push onthe rubber dooredge or allowthe
rubberdoor edge to contactthe power chair andthe door will reopen.
!Usecare that pocketbooks, packages, orpower chair accessories do not become caught in elevator doors.
Lift/Elevation Products
Ifyouwillbetravelingwithyour powerchair,youmayfindit necessary tousealift/elevationproducttoaid intransporta-
tion.Pride recommendsthat you closelyreview the instructions,specifications, andsafety information setforth by the
manufacturerofthelift/elevationproductbeforeusingthatproduct.
Figure 4.IdealTransfer Position
WARNING! Never sit on your power chair when it is being used in connection with any type of lift/
elevation product. Your power chair was not designed with such use in mind and any damage or
injury incurred from such use is not the responsibility of Pride.

Quantum 6000 www.quantumrehab.com 13
II. SAFETY
Inclement Weather Precautions
Exposureofyourpower chairtoinclement weatherconditionsshouldbe avoidedwheneverpossible. If suddenlycaught
up in rain, snow, severe cold, or heat while operating your power chair proceed to shelter at the earliest opportunity.
Thoroughlydryyourpower chairbeforestoring, charging,or operatingyourpowerchair.
WARNING! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery surfaces can
cause personal injury and/or damage to the power chair and electrical system. Maintain and store
your power chair in a dry and clean condition.
Motor Vehicle Transport
Priderecommendsthatyou donotremainseated inyourpower chair whiletravelingin amotorvehicle.The powerchair
shouldbe stowed inthe trunk of acar or in the back of atruck or van with the batteries removedand properly secured.
WARNING! Do not sit on your power chair while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Failure to do so may result in personal injury and/or damage to your power chair.
Positioning Belts
YourQuantum Rehab Specialist,therapist(s), and other healthcareprofessionals are responsiblefor determining your
requirementfora positioningbeltin ordertooperate yourpower chair safely.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely. Serious personal injury may result if you fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your power chair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.
Reaching and Bending
Neverreach,lean,orbendwhile drivingyourpowerchair.If itisabsolutelynecessarytoreach, lean,orbendwhileseated
onyour power chair, itis important to maintaina stable center ofgravity and keep thepower chair from tipping.Pride
recommendsthat the powerchair user determinehis/her personal limitationsand practice bendingand reaching in the
presenceofaqualifiedhealthcareprofessional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the floor by reaching
down between your knees. Movements such as these may change your center of gravity and the weight
distributionof thepowerchair. Thismaycause yourpowerchairtotip,possiblyresultingin personalinjury.
WARNING! Prevent personal injury! Keep your hands away from the tires when driving. Be aware
that loose fitting clothing can become caught in drive tires.
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more
informationaboutyour powerchair’sbatteries,seeVI.“Batteriesand Charging.”
WARNING! Power chair batteries are heavy. See specifications table. If you are unable to lift that
much weight, be sure to get help. Lifting beyond your capacity can result in personal injury.
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds.
Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery. Charging
a frozen battery may result in personal injury and/or damage to the battery.

14 www.quantumrehab.com Quantum 6000
II. SAFETY
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts. Personal
injury and/or damage to the power chair may result.
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EMI)
sources. Failure to do so may result in personal injury.
Prescription Drugs/Physical Limitations
Usersmustexercisecareandcommonsensewhenoperatingapowerchair.Thisincludesawarenessofsafetyissueswhen
takingprescribedorover-the-counter drugsorwhenthe userhasspecificphysical limitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or
if you have certain physical limitations. Some medications and limitations may impair your ability
to operate your power chair in a safe manner.
Alcohol
Thepowerchairusermustexercise careandcommonsensewhenoperatinghis/her powerchair.Thisincludesawareness
ofsafetyissueswhileundertheinfluenceofalcohol.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically-powered mobility vehicles.
Electromagneticand Radio Frequency Interference can come from sourcessuch as cellular phones, mobile two-way
radios(such as walkie-talkies),radio stations,TV stations,amateur radio(HAM) transmitters,wirelesscomputer links,
microwavesignals, paging transmitters,and medium-range mobiletransceivers used by emergency vehicles.In some
cases,thesewavescancauseunintendedmovementordamagetothecontrolsystem.Everyelectrically-poweredmobility
vehiclehasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.This
producthas beentested andhas passedat animmunity level of 20 V/m.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types of radio transmitters
may cause unintended movement of your electrically-powered mobility vehicle due to EMI.
Exercise caution when using any of these items while operating your mobility vehicle and avoid
coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorized by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: Forfurther informationon EMI/RFI,go to the Resource Center onwww.pridemobility.com. If unintended
motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Call Pride at 800-424-8205 to
report the incident.

Quantum 6000 www.quantumrehab.com 15
III. YOUR POWER CHAIR
THE QUANTUM 6000
TheQuantum6000hastwo mainassemblies:theseatassembly andthepowerbaseassembly. Seefigure5.Typically,the
seatassemblyincludesthe armrests,seatback,andseat base.Thepowerbase assemblyincludestwomotor/brake assem-
blies,two drivewheels, fourcaster wheels,two batteries,and wiring harnesses. See figures5, 6,and 7.
SEATBACK
DRIVE WHEEL
CASTER WHEEL
Figure 5.The Quantum 6000
POWERBASE
ASSEMBLY
SEAT ASSEMBLY
JOYSTICK
FOOTRIGGING
(FOOT PLATFORM SHOWN)
SEATBASE
CONTROLLER
(REMOTE PLUS SHOWN)
CASTER WHEEL
MANUALFREEWHEELLEVER
ARMREST

16 www.quantumrehab.com Quantum 6000
QUANTUM6000SPECIFICATIONS
Suspension: FrontandRear
DriveWheels: 14in.,pneumatic(14in.solidoptional)
CasterWheels: 6in.solid(rear);5in.solid(front)
MaximumSpeed:¹ Upto6.5mph
Upto8.25mph(withHighSpeedOption)
Brakes: “IntelligentBraking”electronicregenerative,discparkbrake
GroundClearance:² 3.5in.
MaximumSafeSlope: 5°(8.7%)
TurningRadius:² 22in.(withoutfootriggings)
OverallSize:² Length:38in.(withoutfootriggings)
Width: 25.7 in.
SeatingOptions: SpecialtySeat
SynergySeat
PowerElevatingSeat
SynergyManualTilt
SynergyManualRecline
High-backContourSeat
Medium-backContourSeat
ManualReclineHigh-backContourSeat
SynergyTRU-BalancePowerPositioningSeatingSystems
Drivetrain: Twomotor, Mid-wheel-6drive
Batteries:³ TwoGroup24batteries(standard)
Two12-volt,NF-22requiredwithPowerElevatingSeat
TwoGroup34batteriesrequiredwithTRU-BalancePowerPositioning
Range:¹ Up to 25 miles
Upto10miles(withHighSpeedOption)
BatteryCharger: 8-amp,off-board
Electronics: 100-ampRemotePlus
100-ampMicrodrive
WeightCapacity: 300lbs.
160lbs.withSynergyManualTilt
ComponentWeights: Base:170lbs.
SynergySeat:58.5lbs.
Batteries:51.5lbs.each
¹Varies with user weight, terrain type, battery amp hour rating (AH), battery charge, battery condition, and tire condition.
²Due to manufacturing tolerances and continued product improvement, this specification can be subject to variance of (+ or – ) 3%.
³AGMor Gel-Cell typerecommended.
NOTE: All specifications subject to change without notice.
III. YOUR POWER CHAIR

Quantum 6000 www.quantumrehab.com 17
III. YOUR POWER CHAIR
Electrical Components
Theelectrical components consist of the controller assembly, the batteries, and themotors.The batteries, motors, and
controller power module (if equipped) are located on the power base assembly. The controller is located on the seat
assembly. Connectivity betweenthe controller and themotors, batteries, and thebattery chargeris provided by one or
morewiringharnesses.See figure 7.
ControllerCable Connector: The controller cableconnector is wherethe controller plugs intothe power base.Each
controllerusesadifferent type ofharness.Ifthe controllerhasapower moduleinthepowerbase, theconnectorisa small
communications-typeconnector.Regardlessof which type of controlleris used,the harnessmust besecured tothe seat
assemblyand notallowed todrag on the floor.
Figure 6.The Quantum 6000 Power Base
MANUALFREEWHEELLEVER
REAR SEAT MOUNT CONNECTORS
FRONT SEAT MOUNT CONNECTORS
FRONT COVER
REARSHROUDFASTENER
(FASTENER ON OPPOSITE
SIDE NOT SHOWN)
REARSHROUD

18 www.quantumrehab.com Quantum 6000
III. YOUR POWER CHAIR
MotorConnectors:This is where the controllerconnects tothe motors.
BatteryConnector: This iswhere thecontroller connectsto thebatteries.
ControllerPowerModule:Thisenablesthe controllertocommunicate withthe batteriesandthe motors.
MainCircuit Breaker(locatedon the rearmainframe):Themain circuit breaker isa safety featurebuilt into your
powerchair.When thebatteriesand themotorsare heavilystrained(e.g., fromexcessiveloads), themaincircuit breaker
tripstopreventdamage tothemotors andtheelectronics. If thecircuittrips, allowyourpower chair to“rest”for approxi-
matelyoneminute.The circuitbreakerwillreset itself.Turnon thecontroller,andcontinuenormaloperation. Ifthemain
circuitbreakercontinues totriprepeatedly, contact yourQuantum Rehab Specialist.
Figure 7. Quantum 6000 Electrical Components
QUICKRELEASE
BATTERY CONNECTORS
MAINCIRCUITBREAKER
CONTROLLER
POWERMODULE
CONTROLLER
CABLE
TO MOTOR
CONNECTORS

Quantum 6000 www.quantumrehab.com 19
III. YOUR POWER CHAIR
Figure 9. Drive Mode (Drive Engaged)Figure 8. Freewheel Mode (Drive Disengaged)
MANUAL FREEWHEELLEVER
Dual Manual Freewheel Levers
Foryour convenience,your powerchair is equipped with dualmanual freewheellevers. Thelevers are located on each
motor,and allowyoutodisengage the drivemotorsandmaneuver thechairmanually.
WARNING! In freewheel mode, the braking system is disengaged. Only engage the freewheel
mode when on a level surface. Failure to comply could result in injury and/or damage to your
product.
WARNING! Prevent personal injury and/or equipment damage. Do not use the freewheel lever
handles as tie-down points to secure this product.
Tooperatethedualmanual freewheellevers:
1. Pushdown bothmanualfreewheellevers forfreewheelmode (drivemotordisengaged).See figure8.
2. Pullup bothmanualfreewheellevers fordrivemode (drivemotorengaged).See figure9.
NOTE: You must turn off the power before disengaging the drive motors, otherwise you may get an error code
on the controller. To clear this code, turn off the controller, place the power chair in drive mode, then turn on
the controller. The error message should be cleared. If it is not cleared, contact your Quantum Rehab Special-
ist.
NOTE: The power chair will be significantly easier to push with the power off.
!Avoidapplyingexcessiveforcetothemanualfreewheel levers.
WARNING! Do not use your foot to operate the manual freewheel levers. Do not stand on the
manual freewheel levers. Applying excessive force to the manual freewheel levers may result in
damage to the freewheel levers, motors, and brakes.
MANUAL FREEWHEELLEVER

20 www.quantumrehab.com Quantum 6000
III. YOUR POWER CHAIR
Hammer Motor Package
Yourpower chair isequippedwithtwopowerful Hammermotors.Theseareright anglemotorscapableofproducing one
horsepowerof peakoutput each.Follow thesuggestions belowto helpensure peakmotor performance.
!Maintainan even speedwhen negotiatingobstacles. Ifyou encountera situation whereyou havestalled themotors,
immediatelyreleasethejoystick.Adjustthecontrollertoa higherdriveprofileandattempt tomoveovertheobstacle.
Ifyoustillencounterastallcondition,backawayfromtheobstacle,thendriveforward,maintainingmomentumasyou
negotiateoverthe obstacle.
WARNING! Prevent motor damage! Immediately release the joystick if the motors stall. Failure to
release the joystick within 5 seconds of motor stall may cause the motors to overheat, resulting
in damage to the motors, lack of motor performance, and/or increased motor noise.
