Introduction
MANDATORY! The following information pertains to power chairs equipped with
a factory-installed Pride Transit Securement System. Read this information in
its entirety before use in a motor vehicle. If you have any questions about this
information or about using your power chair as a seat in a motor vehicle, contact
your authorized Pride/Quantum Provider.
The occupied Pride Transit Securement System conforms with the standard of ANSI/RESNA WC/Vol. 4,
Section 19/ISO 7176-19 for the purpose of enabling power chairs to be secured in certain types of motor
vehicles. The Transit Securement System, including manufacturer-installed front and rear securement
brackets and pelvic belt anchoring brackets, has been crash tested in accordance with ANSI/RESNA
WC/Vol. 4, Section 19/ISO 7176-19, Frontal Impact Test, with a 168-lb. (76.2-kg) surrogate occupant.
Notwithstanding this standard and testing conformance, many government transportation agencies,
at the time of publication, have not approved any securement system of an occupied power chair in
a motor vehicle. Therefore, it is the position of Pride Mobility Products and Quantum that the Transit
Securement System should only be utilized to secure an occupied power chair being transported in a
motor vehicle at the user’s discretion and in accordance with ANSI/RESNA WC/Vol. 4, Section 19/ISO
7176-19 standards, which are intended to increase safety, but do not suggest that compliance with the
standards will necessarily prevent serious injury or death of a secured power chair occupant during
motor vehicle transport.
In accordance with the ANSI/RESNA WC/Vol. 4, Section 19/ISO 7176-19 standards, the power chair
user should transfer into the vehicle seat and use the vehicle-installed belt restraint system if and
whenever feasible. The Transit Securement System is only available when factory-installed on new
power chairs, and cannot be retrofitted on existing power chairs or serviced in the field.
PROHIBITED! Do not modify your power chair in any way not authorized by Pride/
Quantum. Do not make alterations or substitutions to power chair structural parts
or frame components without consulting Pride/Quantum.

4
Definintions
ANSI/RESNA: American National Standards Institute/Rehabilitation Engineering and Assistive
Technology Society of North America
ISO: International Standards Organization
Transit Securement System: Equipment installed on the power chair which allows the power chair
to be anchored in a motor vehicle. The equipment consists of tie-down anchor points and may
include a pelvic belt.
Wheelchair Tie-down and Occupant Restraint System (WTORS): Equipment installed in a motor
vehicle which allows a power chair and/or a power chair-seated occupant to be anchored in the
motor vehicle for limiting occupant movement in a motor vehicle crash. The equipment consists of a
system or device for securing the power chair and a belt-type restraint system.
Securement Points: Specific structural points on the power chair base or seat frame that are
designed for attachment of a WTORS. These securement points are indicated by anchor symbols.
Label Information
Read and follow the information in the owner’s manual and all supplemental
information provided with the power chair before initial operation.
Indicates that tested and approved power chair, with similarly labeled tested and
approved seating system, conforms to ANSI/RESNA WC/Vol. 4, Section 19/ISO 7176-
19 for transport of an occupied power chair in a motor vehicle.
Indicates power chair securement points.
WARNING! Indicates a potentially hazardous condition/situation. Failure to follow
designated procedures can cause either personal injury, component damage, or
malfunction. On the product, this icon is represented as a black symbol on a yellow
triangle with a black border.
MANDATORY! These actions should be performed as specified. Failure to perform
mandatory actions can cause personal injury and/or equipment damage. On the
product, this icon is represented as a white symbol on a blue dot with a white
border.
PROHIBITED! These actions are prohibited.These actions should not be performed
at any time or in any circumstances. Performing a prohibited action can cause
personal injury and/or equipment damage. On the product, this icon is represented
as a black symbol with a red circle and red slash.
IMPORTANT! Indicates important information to remember when using this product.

5
User Safety Information
MANDATORY! Always secure the power chair and occupant in a forward-facing
position in the vehicle.
MANDATORY! The power chair should be used as indicated in the manufacturer’s
instructions. If you have any questions about the proper use of your power chair,
contact your authorized Pride/Quantum Provider.
MANDATORY! Only belt restraints that comply with the provisions of ANSI/RESNA
WC/Vol. 4, Section 19/ISO 7176-19 and that have been dynamically tested in
accordance with this standard should be installed on the power chair for use as a
restraint in a motor vehicle.
WARNING! Use only AGM or Gel-Cell batteries to reduce the risk of leakage or
explosive conditions.
WARNING! If the total power chair mass is greater than 275 lbs. (125 kg), then
transport in a motor vehicle with a gross vehicle weight greater than 8,800 lbs.
(4,000 kg) is recommended if the option exists.
Protocols and Procedures
The power chair user should transfer into the vehicle seat and use the vehicle-installed restraint system
if and whenever feasible. The power chair should then be stored and secured in the vehicle.
If it is found necessary at the user’s discretion to secure a power chair to a vehicle, the vehicle must be
equipped with a Wheelchair Tie-down and Occupant Restraint System (WTORS) that has been installed
in accordance with the tie-down manufacturer’s instructions, and is compliant with ANSI/RESNA WC/
Vol. 4, Section 18/ISO 10542 standards, and the power chair must have a transit securement system
conforming to the ANSI/RESNA WC/Vol. 4, Section 19/ISO 7176-19 standards. It is essential to use
a complete WTORS to secure the power chair to the vehicle and to provide the power chair occupant
with a properly designed and tested safety restraint system. A restraint system with both pelvic and
upper-torso belts must be used to protect the power chair occupant and minimize the likelihood of injury
caused by contact with the vehicle during a crash or sudden braking.
WARNING! Only power chairs marked with this symbol are rated for occupied use.
WARNING! If the total power chair mass is greater than 275 lbs. (125 kg), then it is
recommended that two additional ANSI/RESNA WC/Vol. 4, Section 18/ISO 10542
compliant rear securement straps be used to anchor the power chair during motor
vehicle transport.

6
Securing the Power Chair
NOTE:In addition to following the general guidelines below, be sure to follow all recommendations
and instructions provided by the WTORS manufacturer.
Always secure the power chair in a forward-facing position in the vehicle.
Attach the four tie-down straps only to designated, labeled transit securement points indicated by
anchor symbols on the power chair. See figures 1 through 12. Tighten the straps to sufficiently
remove all slack.
Never attach tie-downs to adjustable, moving, or removable parts of the power chair such as
armrests, front riggings, and wheels.
Position the anchor points for the rear tie-down straps directly behind the rear securement points on
the power chair. The front tie-down straps should anchor to floor points that are spaced wider than
the power chair to provide increased lateral stability. See figure 1.
WARNING! Ensure power chairs equipped with a transit securement system are
properly secured to the motor vehicle during transport. Power chairs that are not
properly secured can become a hazard to the user and to other vehicle passengers
in the event of a crash, sudden stopping, or swerving, as the power chair could tip
or slide out of place.
FRONT OF
VEHICLE
Figure 1. Securing the Power Chair Figure 2. Tie-down System

7
The Pride Transit Securement System includes WTORS belt restraint anchor points in conformance
with ANSI/RESNA WC/Vol. 4, Section 19/ISO 7176-19. See figures 3 and 4.
Figure 3.WTORS Belt Restraint 4-Point Securement
(Right Side Shown)
Figure 4.WTORS Belt Restraint 6-Point Securement
(Right Side Shown)

8
Occupied Transit
Securing the Power Chair Occupant (Applies to Transit Systems Rated for Occupied Use Only)
The Pride Transit Securement System includes WTORS belt restraint anchor points in conformance
with ANSI/RESNA WC/Vol. 4, Section 19/ISO 7176-19. See figures 5 through 12.
Figure 5. Securement Points for Occupied Transit on a Quantum 6000Z and Q6 Edge Z equipped with a
Synergy Seat
Figure 6. Securement Points for Occupied Transit on a Quantum 600

9
Figure 7. Securement Points for Occupied Transit on a Q6 Edge
Figure 8. Securement Points for Occupied Transit on a Q6 Edge equipped with a TRU-Balance®3

10
Figure 9. Securement Points for Occupied Transit on a Q6 Edge 2.0
Figure 10. Securement Points for Occupied Transit on a Q6 Edge 2.0

11
Figure 11 Securement Points for Occupied Transit on a Q6 Edge Z equipped with a TRU-Balance®3 with
REAC Lift
Figure 12. Securement Points for Occupied Transit on a Q6 Edge 2.0

12
Once the power chair has been properly secured, it is essential that the power chair occupant be
protected for transport.
WARNING! The power chair occupant must be secured with dynamically crash-
tested and approved pelvic and upper-torso belts or with a five-point child restraint
harness as part of WTORS.
Always secure the power chair occupant in a forward-facing position in the vehicle.
Place the pelvic belt across the front of the pelvis near the upper thighs, not high over the abdomen.
WARNING! The pelvic belt should be angled between 45 and 75 degrees to the
horizontal when viewed from the side. However, if the user cannot achieve this
standard, an optional zone of 30 to 45 degrees can be utilized safely.
Figure 13. Recommended Pelvic Belt Placement Angles

13
The frontal clear zone (FCZ) is measured from the forwardmost point on the occupant’s head and
should measure at least 26 in. (65 cm) if both a pelvic and upper-torso belt are used. See figure 14.
NOTE:The recommended frontal clear zone may not be achievable for power chair-seated vehicle
operators.
The rear clear zone (RCZ) is measured from the rearmost point on the occupant’s head and should
measure at least 16 in. (40 cm). See figure 14.
The seated head height (HHT) ranges from about 47 in. (120 cm) for a small adult female to about
61 in. (155 cm) for a tall adult male. See figure 14.
WARNING! Always allow for proper clear zones when securing an occupied power
chair in a motor vehicle.
WARNING! Allow as much clearance as possible around the power chair occupant
to reduce the possibility of contact with vehicle components and other passengers
in the event of a crash.
WARNING! Ensure all vehicle components that are in close proximity to the power
chair occupant are removed or covered with dense padding.
Figure 14. Recommended Clear Zones for Power Chair-seated Occupants

14
Some power chair components, like armrests and wheels, can interfere with proper belt fit. It may be
necessary to insert the belt between the armrest and the seatback or through openings between the
backrest and seat in order to avoid placing the pelvic belt over the armrest. See figure 15.
Pelvic restraints should
make full contact
across the front of
the body near
the junction of
the thigh
and pelvis.
Belt restraints must not be
held away from the body by
power chair components
such as armrests
or wheels.
Belt restraints must not be
held away from the body by
power chair components
such as armrests
or wheels.
Figure 15. Proper Pelvic Belt Placement
Figure 16. Proper Pelvic Belt
Placement
Place the upper-torso belt across the middle of the shoulder
and the center of the chest, and connect to the pelvic belt
near the hip of the power chair occupant. See figure 16.
WARNING! The upper-torso belt webbing
should not be worn twisted in a manner that
reduces the area of contact of the belt with
the occupant.
The upper-torso belt anchor point should be anchored above
and behind the top of the power chair occupant’s shoulder
to ensure that the occupant is properly restrained during
transport. Both the pelvic and upper-torso belt restraints
should be adjusted as snugly as possible consistent with
user comfort.
WARNING! The buckle of belt restraint
systems should not be located near power
chair components that may come in contact
with the buckle release button in the event of
a vehicle accident or collision.
If your power chair is equipped with a crash-tested pelvic
belt that is anchored to the seat frame, complete the
restraint system by attaching the lower end of the WTORS
upper-torso belt to the pelvic belt by referring to the
WTORS manufacturer’s instruction. Crash-tested power
chair-anchored pelvic belts will be labeled to indicate
compliance to the ANSI/RESNA WC/Vol 4, Section 19/ISO
7176-19 standards. See figure 16.

15
MANDATORY! A vehicle-
anchored belt restraint
system conforming to ANSI/
RESNA WC/Vol 4, Section
18/ISO 10542 must be used
if the power chair occupant
chooses not to utilize a
manufacturer-installed power
chair-anchored belt restraint
system.
WARNING! Ensure power
chairs equipped with a transit
securement system are
properly secured to the motor
vehicle during transport.
Power chairs that are not
properly secured can become
a hazard to the user and to
other vehicle passengers in
the event of a crash, sudden
stopping, or swerving, as the
power chair could tip or slide
out of place.
1. Pin
2. Belt Mounting Bracket
3. Upper-Torso Belt
4. Pelvic Belt
4
2
1
12
1
3
Figure 17. Power Chair-anchored Belt Restraint
Identification Key
1. Belt Mounting Pin
Identification Key
Figure 18. Power Chair Belt Restraint Anchor
Transit Securement System
The following components of the transit securement
system must be compliant to ANSI/RESNA WC/Vol. 4,
Section 18/ISO 10542 standards (formerly SAE J2249)
and must be installed according to the manufacturer’s
instructions.
Wheelchair Tie-down and Occupant Restraint System
(WTORS)
4-point power chair tie-down system with an integrated
3-point occupant restraint
Tie-down end fittings
WTORS securement points
Occupant restraint securement points
NOTE: To obtain a copy of ANSI/RESNA WC/Vol. 4,
Sections 18 and/or 19 visit http://www.ansi.org.
NOTE: To obtain a copy of ISO 7176-19 or ISO 10542
visit http://www.iso.org.

16
Important Points to Remember
MANDATORY! Read and follow all manufacturer’s instructions, including the
product owner’s manual.
MANDATORY! Any WTORS or power chair involved in a vehicle crash should be
replaced.
WARNING! The power chair seatback should be positioned at an angle of no more
than 30 degrees to the vertical. If a greater recline angle is required, the upper-torso
belt anchor point should be moved rearward along the vehicle’s sidewall to ensure
that the belt maintains contact with the power chair occupant’s shoulder and chest.
WARNING! Visually inspect all WTORS equipment according to WTORS
manufacturer’s instructions on a regular basis,and have worn or broken components
replaced immediately. Ensure anchorage track is free of dirt and debris.
WARNING! Remove hard trays and stow or secure them elsewhere in the vehicle to
reduce the chance of power chair occupant injury from contact with the tray.
WARNING! Consider using foam trays in place of rigid trays during vehicle transport.
If that is not possible, place dense foam padding between the power chair occupant
and the tray, and make sure that the tray is securely attached to the power chair so
that it will not break loose and cause injury to other occupants in a crash.
WARNING! Ensure the power chair occupant is properly positioned to protect the
neck during rear impact.
WARNING! Secure all removable accessories, including clothing guards, medical,
and other equipment to the power chair or vehicle to prevent injury during a crash.
WARNING! If head and neck support is required during travel, use a soft, light neck
collar as they are less likely to cause neck injury in a crash. Do not attach the soft
collar to the power chair or seating system.

17
Pride Occupied Transit Securement System Declarations
MANDATORY! A belt restraint system with both pelvic and upper-torso belts must
be used to protect the power chair occupant and minimize the likelihood of injury
caused by contact with the vehicle during a crash or sudden braking.
The occupied power chair was dynamically tested in a forward-facing position
with the surrogate occupant restrained by both pelvic and upper-torso belts and
conforms with ANSI/RESNA WC/Vol. 4, Section 19/ISO 7176-19.
The power chairs were tested with the following specifications:
Power Chair Mass Turning Radius
with Front Riggings
Seat Size Overall Rating
Quantum 6000Z 348 lbs.
(158 kg)
24.5 in.
(62.23 cm)
18 in. x 20 in.
(45.7 cm x 50.8 cm)
A
Quantum 600 294 lbs.
(133 kg)
20 in.
(50.8 cm)
18 in. x 20 in.
(45.7 cm x 50.8 cm)
A
Q6 Edge 286 lbs.
(130 kg)
23.5 in.
(59.69 cm)
18 in. x 20 in.
(45.7 cm x 50.8 cm)
A
Q6 Edge with
TRU-Balance®3
seating system
395 lbs.
(179 kg)
23.5 in.
(59.69 cm)
20 in. x 20 in.
(50.8 cm x 50.8 cm)
A
Q6 Edge 2.0 360 lbs.
(164 kg)
20.5 in.
(52.1 cm)
20 in. x 20 in.
(50.8 cm x 50.8 cm)
A
Q6 Edge 2.0 with
iLevel®
436 lbs.
(198 kg)
20.5 in.
(52.1 cm)
20 in. x 20 in.
(50.8 cm x 50.8 cm)
A
Q6 Edge Z with
TRU-Balance® 3
seating system
with REAC Lift
471 lbs.
(214 kg)
19.75 in.
(50.2 cm)
18 in. x 20 in.
(45.7 cm x 50.8 cm)
A
Appendix: Declarations

18
The overall rating of the power chair accommodating fit and use of a vehicle-anchored belt restraint
is listed on the previous page. This rating is ranked as follows:
The test for Lateral Stability Displacement for Point (P) is shown in figure 19. The average test result
for Point (P) is:
Quantum 6000Z: 0.52 in. (13.3 mm)
Quantum 600: 0.38 in. (9.7 mm)
Q6 Edge: 0.54 in. (13.6 mm)
Q6 Edge with TRU-Balance® 3 seating system: 0.78 in. (19.8 mm)
Q6 Edge 2.0: 0.78 in. (19.8 mm)
Q6 Edge 2.0 with iLevel®: 0.78 in. (19.8 mm)
Q6 Edge Z with TRU-Balance® 3 seating system with REAC Lift: 0.73 in. (18.6 mm)
Figure 19. Lateral Stability Displacement Illustration
NOTE: Rear view of the power chair and human surrogate secured on test platform and
tilted to 45°.
Rating Description
A Excellent
B Good
C Fair
D Poor

Contents
Copyright  2020
INFMANU3658/Rev F/February 2020
Introduction .........................................................................................................................................3
Label Information ................................................................................................................................4
Definitions ............................................................................................................................................4
User Safety Information ......................................................................................................................5
Protocols and Procedures ...................................................................................................................5
Securing the Power Chair ....................................................................................................................6
Occupied Transit........................................................................................................................................8
Transit Securement System ..............................................................................................................14
Important Points to Remember .........................................................................................................15
Appendix: Declarations .....................................................................................................................16

Basic Operation Instructions
Transit Securement System
USA
401 York Avenue
Duryea, PA 18642
www.quantumrehab.com
Canada
5096 South Service Road
Beamsville, Ontario L0R 1B3
www.quantumrehab.com
Australia
20-24 Apollo Drive
Hallam, Victoria 3803
www.quantumrehab.com.au
New Zealand
38 Lansford Crescent
Avondale
Auckland, New Zealand 1007
www.pridemobility.co.nz
UK
32 Wedgwood Road
Bicester, Oxfordshire OX26 4UL
www.quantumrehab.co.uk
B.V.
(Authorised EU Representative)
De Zwaan 3
1601 MS Enkhuizen
The Netherlands
www.quantumrehab.eu
Italy
Via del Progresso, ang. Via del Lavoro
Loc. Prato della Corte
00065 Fiano Romano (RM)
www.quantumrehab-italia.it
France
26 rue Monseigneur Ancel
69800 Saint-Priest
www.quantumrehab.fr
Spain
Avda de las Flores 19
Parque Empresarial El Molino
28970 Humanes (Madrid)
