Quark-Elec QK-W016 User manual

Disclaimer
It is the user’s responsibility to use this product prudently. Neither Quark-elec, nor their distributors or
dealers accept responsibility or liability either to the product user or their estate for any accident, loss, injury
or damage whatsoever arising out of the use or of liability to use this product.
V1.0(8/18)
QK-W016
We would always advise users of the windows application to run the program as
“administrator”. When starting the W016 program, right click on the program and select
‘Run as administrator’ from the drop down list.
EXAMPLE RELAY WIRING AND TEMPERATURE SETTINGS
The W016 is designed primarily for a heating setup but can also be used for cooling. The wiring is
different depending on whether you are using the relay for a heating or cooling function.
Heating:
Connect your heating equipment to the W016 in the normal open configuration as seen in the
table below.
In the Android APP, SETUP > RENAME: rename N.O. to ‘Heater ON’, and N.O. to ‘Heater OFF’.
In the Android APP, SETUP > TEMPERATURE: set your temperature ranges.
NO: the lowest heating activation temperature. (when colder than ‘xx‘, turn on.)
NC: the highest heater operating temperature. (if warmer than ‘xx‘, turn off.)
(The ON temperature must be at least 1°C lower than the OFF temperature.)
Cooling:
For cooling, reverse the way the relays are wired. Connect your cooling equipment in the Normal
closed configuration as seen in the table below.
It is important to understand that relays wired in ‘normal closed’ position will operate in
the opposite way than expected. In this setup off will turn the relay on. This needs to be
taken into account during setup.
In the Android APP, SETUP > RENAME: rename N.C. to ‘Cooler ON’, and N.O. to ‘Cooler OFF’.
In the Android APP, SETUP > TEMPERATURE: set your temperature ranges.
NC: the highest cooling activation temperature. (when warmer than ‘xx‘, turn on.)
NO:the Lowest cooling operating temperature. (if colder than ‘ xx‘, turn off.)
(The ON temperature must be at least 1°C lower than the OFF temperature.)
Example setting and wiring to maintain temperature at 25-40°C
Connected Device Heater Cooler
APP ON-OFF settings 25°C - 30°C 35°C - 40°C
Relay configuration
SET-UP GUIDE
 What You Need
 Installation Overview
 Notes
QK-W016
WIFI TEMPERATURE
CONTROLLER
All products are CE, RoHS certified
www.quark-elec.com
Please recycle your packaging

YOU WILL NEED:
1. Temperature sensors (included) which come in 1, 2 and 6 metre lengths and can be shortened
or extended (we recommend a maximum of 8 metres for best results).
2. WiFi reception in the location that the W016 will be installed (you can check this using a
mobile phone).
3. Power supply cable (included if ordered), long enough to reach your W016 location.
INSTALLATION
1. W016 location: the W016 unit (excluding sensors) must be installed in an indoors
environment, unexposed to water or high humidity.
2. Download/install your APP and/or Windows software:
 Software for Windows (only) https://www.quark-elec.com/product/qk-w016-wifi-
temperature-controller/
 Android or iOS app for mobile phones. https://www.quark-elec.com/downloads/apps/
3. Connect temperature sensors by inserting the connector block into the slots at the back of the
W016. Good practice is to label each sensor and its corresponding relay. This will help later on.
4. Connect the relay output (if required). Connect either normal closed or normal open
depending on your requirements. Check the back page of this guide for details.
QK-W016
This is an overview only. Familiarize yourself with the manual and the manuals of
any connecting devices before installation. It is always recommended that
electronic equipment be installed by an experienced installer.
Blue LED -
Network
Red LED -
System
5. Connect to power
 Check the blue NETWORK LED is
flickering. Once the W016 is powered up
the network LED will begin to flash. This
will flicker every 1 second.
 Wait for the red SYSTEM LED to stop
flickering and stay lit.
QK-W016
You are now ready to configure the W016 to work through Ad-hoc or Station mode WiFi, To do
this, follow steps 6 to 7 laid out below.
6.To connect to the W016 directly, without a router (Ad-hoc WiFi):
6.1 Use the reset function to prepare the W016 to connect through Ad-hoc WiFi
 Unplug the W016.
 Hold down the reset button on the front. Re-connect to power whilst still holding the reset
button, wait for the red LED to appear. Continue to hold for another 4 seconds once red LED
appears and then,
 Release the reset button. The blue LED will flash rapidly when it is time to release the button.
 Wait about 60 seconds. Once the red LED comes back on, the W016 is in reset and ready to
connect via Ad-hoc mode.
6.2. Connect via Ad-hoc WiFi mode
 Scan for the WiFi signal using your phone/PC and connect. The WiFi name will be similar to
‘WiFi168’ and the password is ‘88888888’. If you cannot find the WiFi name, redo step 6.1.
 If connecting to Ad hoc WiFi via your PC, also open the W016 application and type in the W016
IP address which should be ‘192.168.1.100’ and click ‘connect WiFi’. The blue LED will stay
constantly lit once the connection is successfully established.
7. If you only want the W016 to work in Ad-hoc mode, repower the device now. Otherwise, if
you want to connect through your router (station mode) or access your W016 off-site, do not
repower and simply skip to step 8.
8. To connect through your router (Station mode):
 Ensure you are connected to your W016 via Ad-hoc mode (step 6).
 Open the Android/iOS APP (Please note, although you can do this on the W016 Windows
application, if you ever intend to access your W016 through WiFi off-site or through a different
WiFi connection, you will need to do this step on the Android/iOS phone app, not the
Windows application.)
 Click on ‘Setup’
 Enter your WiFi network name (SSID) and click ‘save’, wait for feedback that it has been
saved.
 Enter network password and click ‘save’, wait for feedback that it has been saved.
 Click ‘Connect Station mode’
9. Repower the W016 to load your Station mode settings . The blue LED will stay constantly lit
once the connection is successfully established. You will now be able to connect to the W016
through your normal wireless network, and off site using your mobile data.
Ad-hoc
Mode WiFi
Repower
to use in
Ad-hoc
mode.
Station
Mode WiFi
Re-
set
Repower
to use in
Station
mode.
6.1 8
6.2
9
7
