Queclink GV75 User manual

GV75 User Manual
TRACGV75UM0010
GV75 User Manual
GSM/GPRS/GPS Tracker
TRACGV75UM001
Version: R1.03

GV75 User Manual
TRACGV75UM0011
Document Title GV75 User Manual
Version 1.03
Date 2016-04-15
Status Release
Document Control ID TRACGV75UM001
General Notes
Queclink offers this information as a service to its customers, to support application and
engineering efforts that use the products designed by Queclink. The information provided is
based upon requirements specifically provided to Queclink by the customers. Queclink has not
undertaken any independent search for additional relevant information, including any
information that may be in the customer’s possession. Furthermore, system validation of this
product designed by Queclink within a larger electronic system remains the responsibility of
the customer or the customer’s system integrator. All specifications supplied herein are subject
to change.
Copyright
This document contains proprietary technical information which is the property of Queclink
Wireless Solutions Co., Ltd. The copying of this document, distribution to others, and
communication of the contents thereof, are forbidden without express authority. Offenders
are liable to the payment of damages. All rights are reserved in the event of a patent grant or
registration of a utility model or design. All specifications supplied herein are subject to change
without notice at any time.
Queclink
Confidential

GV75 User Manual
TRACGV75UM0012
Contents
Contents ................................................................................................................................................ 2
Table Index ............................................................................................................................................ 3
Figure Index........................................................................................................................................... 4
0. Revision History................................................................................................................................. 5
1. Introduction ...................................................................................................................................... 6
1.1. Reference ............................................................................................................................... 6
1.2. Terms and Abbreviations........................................................................................................ 6
2. Product Overview.............................................................................................................................. 7
2.1. Appearance ............................................................................................................................ 7
2.2. Parts List ................................................................................................................................. 7
2.3. Interface Definition ................................................................................................................ 8
3. Getting Started.................................................................................................................................. 9
3.1. Install a SIM Card.................................................................................................................... 9
3.2. Switch on the Device............................................................................................................ 10
3.3. Power Connection................................................................................................................ 10
3.4. Ignition Detection................................................................................................................. 11
3.5. Digital Input.......................................................................................................................... 11
3.6. Digital Output....................................................................................................................... 11
3.7. UART Interface ..................................................................................................................... 12
3.8. Indicator Light Description ................................................................................................... 13
4. Troubleshooting and Safety Info ..................................................................................................... 14
4.1. Troubleshooting ................................................................................................................... 14
4.2. Safety Info ............................................................................................................................ 14
Queclink
Confidential

GV75 User Manual
TRACGV75UM0013
Table Index
TABLE 1: REFERENCE ................................................................................................................................6
TABLE 2: TERMS AND ABBREVIATIONS ....................................................................................................6
TABLE 3: PARTS LIST .................................................................................................................................7
TABLE 4: DESCRIPTION OF GV75 USER CABLE..........................................................................................8
TABLE 5: ELECTRICAL CHARACTERISTICS OF IGNITION DETECTION .......................................................11
TABLE 6: ELECTRICAL CONDITIONS OF NEGATIVE TRIGGER INPUTS ......................................................11
TABLE 7: ELECTRICAL CONDITIONS OF DIGITAL OUTPUTS .....................................................................12
TABLE 8: DEFINITION OF DEVICE STATUS AND LED................................................................................13
Queclink
Confidential

GV75 User Manual
TRACGV75UM0014
Figure Index
FIGURE 1: EXAMPLE CONNECTION FOR NEGATIVE TRIGGER INPUTS ....................................................11
FIGURE 2: THE EXAMPLE CONNECTION TO DRIVE A LED .......................................................................12
FIGURE 3: THE EXAMPLE CONNECTION TO DRIVE A RELAY ...................................................................12
FIGURE 4: THE CONNECTION OF UART WITH FEMALE DB-9 ..................................................................12
FIGURE 5: THE CONNECTION OF UART WITH EXTERNAL DEVICES.........................................................13
Queclink
Confidential

GV75 User Manual
TRACGV75UM0015
0. Revision History
Revision Date Author Description of Change
1.01 2016-01-07 BingoHuang Initial
1.02 2016-01-25 Abside Yu Add Safety Information
1.03
2016-04-15
Abside Yu
Modify “Getting Start” and product appearance
Queclink
Confidential

GV75 User Manual
TRACGV75UM0016
1. Introduction
The GV75 is a compact waterproof GPS tracker designed for a wide variety of vehicle tracking
applications. It has multiple I/O interfaces that can be used for monitoring or controlling external
devices. Its built-in GPS receiver has superior sensitivity and fast time to first fix. Its quad band
GPRS/GSM subsystem supports 850/900/1800/1900 MHz allowing the GV75's location to be
monitored in real time or periodically tracked by a backend server and mobile devices. Its built-in
3-axis accelerometer allows motion detection and extends battery life through sophisticated power
management algorithms. System integration is straightforward as complete documentation is
provided for the full featured @Track protocol. The @Track protocol supports a wide variety of
reports including emergency, geo-fence boundary crossings, driving behavior, low battery and
scheduled GPS position.
1.1. Reference
SN Document Name Remark
[1] GV75 @Track Air Interface Protocol.doc
[2] @Track Air Interface for Garmin-FMI
Protocol V1.02.pdf
Table 1: Reference
1.2. Terms and Abbreviations
Abbreviation Description
DIN Digital Input
DOUT Digital Output
GND Ground
Table 2: Terms and Abbreviations
Queclink
Confidential

GV75 User Manual
TRACGV75UM0017
2. Product Overview
2.1. Appearance
Figure 1. Appearance of GV75
2.2. Parts List
Table 3: Parts List
Name Picture
GV75 Tracker 102mm*46mm*20.5mm
GV75 Extend Cable
USB-232 Cable(optional)
12V DC Supply(optional)
GV75 Configuration Cable(optional)
Queclink
Confidential

GV75 User Manual
TRACGV75UM0018
2.3. Interface Definition
There are 8 wires on GV75user cable, which contains the connection for power, ignition input,
digital input, digital output, TXD and RXD, etc. The user cable’s definition is shown in the following
table.
Table 4: Description of GV75 User Cable
Index Colour Description Comment
1 Red Power External DC power input,8-32V
2 Black Ground System ground(connected to the vehicle’s frame directly)
3 Yellow Digital input Digital input, negative trigger
4 White Ignition Ignition input, positive trigger
5 Green Digital output2 Digital output,low side 150mA max
6 Blue Digital output1 Digital output,low side 150mA max with latch
7 Violet TXD
8 Grey RXD
Queclink
Confidential

GV75 User Manual
TRACGV75UM0019
3. Getting Started
3.1. Install a SIM Card
Step 1: Remove the top cover.
Step 2: Insert the SIMcard into the SIM card holder.
Step 3: Place the top cover on the bottom cover, and tightenboth covers until they snap.
Note: Make sure that the seal ring is in place and there is no obvious gap between covers and
seal ring.
