QuickCable RESCUE 3100 User manual

RESCUE®3100 Portable
Power Pack Instructions
Read this manual before using this product
Failure to follow instructions and safety precautions
can lead to serious injury or death.
Keep this manual in a safe location for future reference.

2
SAVE THIS MANUAL. These instructions are important, and contain operating and safety
information that can help prevent personal injury or death, and prevent damage to the
power pack itself as well as vehicles and equipment it may be connected to.
The safety information in this manual includes both a ! symbol and a signal word that
indicates the hazard.
Indicates a hazardous situation
which, if not avoided, could
result in serious injury or death.
Indicates a practice which could result in damage
to the portable power pack, the vehicle or equip-
ment it is connected to, or other property damage.
• Readentiremanualbeforeusingthisproduct.Followtheinstructionsinthismanual
and the instructions provided by the manufacturer of the battery you are connecting to
as well as the vehicle or equipment you are jump starting or powering.
• Wearsafetygoggles.
• Keepoutofreachofchildren.
• Donotuseifpowerpackcase,cables,orclampsaredamaged.
• Donotallowthepowerpackbatterytofreeze.
• Neverattempttojumpstartafrozenbattery.
• Donottouchthepowerpackclampstogetherortothesamepieceofconductivemetal.
• Donotsubmergeinwater.
• Donotdisassemble.Nouser-serviceablepartsinside.Refertoservicesectionofthis
manual.
• Useinconjunctionwithsealedleadacidbatteriesonly.Donotusewithdrycellbatteries
or other battery types such as lithium ion, nickel hydride, or others.
• Thisproductisintendedfornegativegroundapplicationsonly.DONOTUSEON
 POSITIVEGROUNDSYSTEMS.
• Wearrubberglovesandprotectiveclothingwhenworkingaroundleadacidbatteries.
• Donotsmoke.Donotallowanyopenameorsparksnearaleadacidbattery.
• Removerings,bracelets,necklaces,watchesandotherpersonalmetalitems.Alead
acid battery can produce short circuit current strong enough to weld metal items and
cause severe burns.
• Becarefulwithtoolsaroundleadacidbatteries;donotdroptoolsonbattery—sparks
and explosion could result.
• Ifbatteryacidcontactsyourskinorclothing,washwithsoapandwater.Ifacidenters
 youreye,immediatelyoodtheeyewithcoldrunningwaterfor10minutesandseek
medical attention.
• Ifbatteryacidisswallowed,drinkmilk,eggwhitesorwaterandDONOTinduce
 vomiting.Getimmediatemedicalattention.
Using Your Rescue®3100
Working Under Hood and Around Lead-Acid
Batteries
Safety Information
Risk of Electric Shock, Fire
and Explosion
Risk of electric shock, re or explosion.
Lead acid batteries generate explosive gas. They
contain sulfuric acid which is highly corrosive.

3
• Alwayswrapthecablesbackintopositionandstoretheclampsproperly.
• Donotusewhileunitisrecharging.Disconnectfromchargerbeforeuse.
• IfyourRescueportablepowerpackrequiresservice,followthedirectionsinthe
 warrantysection.Donotattempttorepairtheunitorreplaceparts.Unauthorized
repairs will void your warranty.
• Nolubricationisrecommendedorrequired.
• Avoidstoringindirectsunlight,inextremeheatorcold,orverymoistareas.
• Whenworkingunderthehood,becarefulofmovingfanblades,belts,pulleysand
other moving parts that may cause injury.
PursuanttoCaliforniaProposition65,thisproductcontainschemicalsknowntotheStateof
California to cause cancer and birth defects or other reproductive harm.
Risk of Serious Injury
Use Your Power Pack Safely
10
11 12
439
1
2
6
14
5
78
13
Components
1Positive (+) jumper cable
2 Negative(_) jumper cable
3 Voltageindicatorlights
4 Statusindicatorlights
5 Startbutton
6Power indicator
7 Digitalbatterymeter
8Internal voltage button
9 12voltaccessoryoutlet
10 Batterycharger
11 Port for charger
12 On/offswitch
13 Worklightswitch
14 Clamp light switch
TheRescue3100isacommercialgradeportablepowerpackcapableofdelivering
signicantcurrenttoprovidejumpstartingpowerforcars,trucksandcommercialequip-
ment.TheRescue3100provides12Vpower.ItfeaturesSmartPolarityprotection.These
features prevent the power pack from connecting to systems when polarity connections
are incorrect.
The Rescue®3100 Overview

TheRescue3100is
designed to use a sealed
PowerSportstypebattery
measuring6-1/2"tall,7"
longand3"deepwithtop
terminals, or a standard
U-1battery.QuickCable
recommends that this
installation be performed
by the selling dealer or
trained personnel.
Be Sure to Observe Correct Polarity
•ThecablesinsidetheRescue3100arered(positive)andblack(negative).
•Beforeconnectingtoabattery,doublecheckthebatterymarkings.
•ConnectingabatterybackwardscancausepermanentdamagetoyourRescue3100.
Battery Installation
4
Openthebackofthebatterycasebypressing
down on the two tabs at the top of the case pan-
el, and pull the panel away from the power pack.
There are two metal brackets attached to the
case with thumbscrews (a Phillips head recess
isprovidedifextraleverageisneeded).Remove
thetwobrackets.Notethatthetopbrackethasa
tab along its top edge.
Connect the red cable to the positive terminal on the battery,
and connect the black cable to the negative terminal on the
battery.PushthebatteryinplaceinsidetheRescue3100
and install the metal retaining brackets. The bracket with the
tabisthetopbracketandthetabwilltoveraU1battery.
Tighten the brackets securely.
ThereisastyrofoamspacerblockinsidetheRescue3100.
IfyouareinstallingaPowerSportsstylebattery,removethe
styrofoam block, install the battery and place the styrofoam
againstthebattery.Securewithretainingbrackets.Ifyouare
installingaU-1battery,removethestyrofoamspacerand
retain for possible future use.
Replacetheplasticbatterycover.

5
Beforeusingyourportablepower
pack, you should fully charge it.
The digital battery meter will show
when the unit is charging and when
itisfullycharged.Youcancheck
the actual battery voltage any time
by pressing the internal voltage
selector.Rechargeevery30daysor
anytime the internal battery voltage
fallsbelow11.5V.Fluctuationsin
temperature can accelerate battery
discharge. Check your unit often.
ChargeusingthesuppliedA/Cchar-
gerorusetheRescue604095in-cab
charging cord.
1. TurnonthepowerswitchonthebackoftheRescue3100.
2. Checkvehiclebatteryterminalsbeforeusingthepowerpack;cleanthemifnecessary.
3. Connect the red (positive +) clamp to the positive terminal or post on the discharged
battery.
4. Connect the black (negative –) clamp to a ground away from the battery, such as an
alternator bracket.
 •Note:Somevehiclesareequippedwithpositiveandnegativestartterminalsaway
 fromthebattery.Usetheseterminalswhenavailable.
5. VerifythegreenSmartPolaritylightison.Ifitis,pressStart.Ifitisnot,refertothe
troubleshooting section.
6. VerifythePowerlightison.Theunitisnowsupplyingjumpstartingpowerto
your vehicle.
7. Starttheengine.Afterapproximately6secondsofcontinuouscranking,ifthedisabled
vehicle fails to start, stop and wait for 2 minutes. This prevents damage to your power
pack and to your vehicle’s system from overheating.
8. Turn off the power switch on the back of the power pack and disconnect the clamps,
 rstnegativeandthenpositive.Storeclampsproperlyonunit.
9. Rechargepowerpackafteruse.
To use as a 12V Power Source
1. Connectthered(positive+)clamptothepositiveinputterminalandtheblack
(negative –) clamp to the negative input terminal on the device to be powered.
2. VerifythattheLowVoltage/SmartPolarityOfflightisilluminated.
3. PressandholdtheStartbuttonfor4seconds.Thebatterymeterdisplaywillshowa
countdown.
4. VerifythePowerlightison.Thepowerpackisnowsupplyingcurrenttoyourdevice.
5. Turn the unit off by turning the switch on the back of the power pack off, and then
disconnect the clamps.
6. Rechargepowerpackafteruse.
• IftheRescue3100isnotfullychargeditmayshutdownunderheavyloadifitcannot
 deliversufcientvoltage.
• Failuretokeepinternalbatterychargedwillleadtopermanentbatterydamage.
Using Your
Rescue®3100
Use Your Power Pack Safely
To Jump Start a Vehicle or Machine:

6
The digital display will show the external battery voltage when the power pack is connected.
If the polarity is incorrect on the battery connection, there will be no display. Pressing the in-
ternalbatteryvoltagebuttonwilldisplaytheinternalvoltage.Whenthepowerpackisbeing
recharged, the meter will show charging with the letters CH and animation speed depend-
ingontheamountofcurrentow.Whentheunitisfullycharged,thedisplaywillreadFUL.
TheyellowLowVoltageLEDindicatorlightwillilluminatewhenevertheRescue3100is
turned on and the external voltage at the clamps is low, or they are not connected. This
isnormal.SeethesectiononusingtheRescue3100asa12Vpowersource.Thevolt-
ageindicatingLEDlightswillindicateinternallowbatteryvoltagebyashing.Themore
dischargedtheinternalbatterybecomes,thefasterthelightwillash.Presstheinternal
battery voltage button to see the exact internal battery status.
The12Vauxiliaryoutletisprotectedbya15ampcircuitbreaker,whichresetsautomatically.
Digital Battery Meter
LED Indicator Lights
12V Auxiliary Power Outlet
Troubleshooting
Problem: Rescue 3100 turns off under load.
• Theinternalbatterymaybelow.
 •Checktheinternalbatteryvoltageandrechargeasneeded.
• Extremelyhighcurrentdrawispresent.Thismaybebecausethereisashortcircuit
in the system to be jump started.
 •Check the system for short circuits.
• TheloadrequiredmayexceedthecapacityoftheRescue3100.Verylargebatteriesor
battery banks may require recharging, not jump start assistance.
Problem: Green power light fails to light when the start button is pressed.
Unit is sounding a tone.
• Checkthereversepolaritylight.Ifitisilluminated,reversetheclampconnections.
• Theinternalbatteryvoltageisbelow8.5V.Checktheinternalbatteryvoltage,and
recharge the unit.
Problem: The low voltage light is lit and the unit will not engage.
• Thiscanhappenifthebatteryontheunittobestartedisseverelydischarged.
 1.Verifythattheclampsareconnectedcorrectly,positivetopositiveand
negative to ground.
 2.PressandholdtheStartbuttonfor4seconds.
 3.VerifythegreenPowerlightison.Theunitisnowconnected.
Polarity protection is not
available in this mode.

7
To Obtain Service Under This Warranty:
RESCUE®Portable Power Pack Limited Warranty
TheManufacturerwarrantsthisproductagainstdefectsinmaterialandworkmanshipfor
one(1)yearfromthedateoforiginalretailpurchase.QuickCablewill,atitsoption,repair
or replace defective units.
QuickCableencouragesyoutoregisteryourproductatwww.quickcable.com/registerand
to retain your original sales receipt with this manual for warranty purposes.
Damagecausedbymisuseorimproperconnections,failuretofollowprescribed
operating instructions, impact damage, or negligence is not covered by this warranty. The
manufacturer reserves the right to inspect units for improper use in determining warranty
coverage.
EXCEPTFORTHISLIMITEDWARRANTY,THEMANUFACTURERHASNOT
MADEANDSPECIFICALLYDISCLAIMSANYWARRANTYORREPRESENTATION
OFANYKIND,EXPRESSORIMPLIED,DIRECTORINDIRECT,INCLUDINGBUT
NOTLIMITEDTOANYIMPLIEDWARRANTYOFMERCHANTABILITY,ANDANY
IMPLIEDWARRANTYOFFITNESSFORAPARTICULARPURPOSE.THISLIMITED,
CONDITIONALWARRANTYPROVIDESTHEEXCLUSIVEREMEDYFORANYCLAIM
ORDAMAGEEXCEPTASOTHERWISEREQUIREDBYLAW.
ThiswarrantyexcludesanddoesnotcoverdefectsorfailuresofyourPORTABLEPOWER
PACKduetoanycauseotherthandefectsinmaterialorworkmanship,includingwithout
limitation any malfunctions or failures caused by repairs made by an unauthorized person,
mishandling, modifications, normal wear, improper storage and unreasonable use or
damage.
INNOEVENTSHALLTHEMANUFACTURERBELIABLEFORCONSEQUENTIALOR
INCIDENTALDAMAGES.Somestatesdonotallowtheexclusionorlimitationofincidental
or consequential damages so the above limitations or exclusions may not apply to you.
This warranty gives you specific legal rights and you may also have other rights which vary
from state to state.
AnyclaimrelatingtothePortablePowerPackmustbesubmittedwithinone(1)yearof
purchaseandmustbesenttoQuickCableintheU.S.AorCanada.
If any portion of this warranty or limitation of rights and remedies is found to be
unenforceable, then the remainder of this document shall remain in full force and effect.
1.CallTechnicalServicetollfreeinU.S.A.1(800)558-8667orinCanada1(800)728-1742.
Have your Portable Power Pack near the phone and a technician will help you diagnose
the problem.
2.Bepreparedtoestablishproofanddateofpurchase.
3.Anymisuseofthisunitwillvoidthiswarranty.

8
GUARDE ESTE MANUAL.Estasinstruccionessonimportantes,ycontienenlainformacióndefuncionamiento
y seguridad que pueden ayudar a prevenir lesiones personales o la muerte, y evitar daños en el paquete de
alimentaciónensí,asícomovehículosyequipopuedeserconectado.
Lainformacióndeseguridadenestemanualincluyeuna!símboloypalabradeadvertenciaqueindicaelpeligro.
Indicaunasituaciónpeligrosaque,de
no evitarse, puede ocasionar lesiones
graves o la muerte.
Indicaunaprácticaquepodríaresultarendañosapaquetede
alimentaciónportátil,elvehículooelequipoestáconectadoa,
u otro daño a la propiedad.
• Leatodoelmanualantesdeusaresteproducto.Sigalasinstruccionesdeestemanual
 ylasinstruccionesproporcionadasporelfabricantedelabateríaseconectaa
 asícomoelvehículooelequipoestádesaltodepartidaoencendido.
• Llevargafasprotectoras.
• Manténgasefueradelalcancedelosniños.
• Noutilizarsielcasodelpaquetedealimentacíon,cablesopinzasestándañados.
• Nopermitaquelabateríadelpaquetedealimentaciónsecongele.
• Nuncaintentearrancarunabateríacongelada.
• Notoquelaspinzasdepaquetedealimentaciónentresíoconlamismapiezademetalconductor.
• Nosumerjaenagua.
• Nodesarme.Nohaypiezasqueelusuariopuedareparar.Consultelaseccióndemantenimiento
de este manual.
• Elusoencombinaciónconacumuladoresdeplomosolamente.Noloutiliceconbateríassecasu
 otrotipodebateríatalescomoionesdelitio,hidrurodeníquel,uotros.
• Esteproductoestádiseñadosóloparaaplicacionesdetierranegativa.NOUTILIZAREN
 SISTEMASTERRENOPOSITIVO.
• Useguantesdegomayropadeproteccióncuandotrabajecercadebateríasdeplomo-ácido.
• Nofume.Nopermitaningunallamaabiertaochispascercadelabateríadeplomo-ácido.
• Retiraranillos,pulseras,collares,relojesyotrosartículosmetálicospersonales.Unplomo
 ácidodelabateríapuedeproducircorrientedecortocircuitolosucientementefuertecomopara
soldar piezas de metal y causar quemaduras graves.
• Tengacuidadoconlasherramientasalrededordelasbateríasdeplomo-ácido,nolotireherra
 mientasabatería-chispasyexplosiónpodríaterminar.
• Sielácidollegaseasupielosuropa,láveseconaguayjabón.Sielácidoentraelojo,inundarel
 ojoinmediatamenteconaguafríadurante10minutosybuscarlaatenciónmédica.
• Sisetragaácidodelabatería,bebaleche,clarasdehuevooaguaynoinducir
 vómitos.Obtengaatenciónmédicainmediata.
Uso de la Rescue®3100
Trabajando bajo el capo motor y
alrededor de plomo Baterías
Información de seguridad
Riesgo de choque eléctrico,
incendio y explosión
Riesgo de choque eléctrico, incendio o explosión.
Las baterías de plomo generan gases explosivos. Ellos
contienen ácido sulfúrico que es altamente corrosivo.

9
• Siempreenvuelvaloscablesensuposiciónyalmacenarlasabrazaderascorrectamente.
• Noutilicelaunidadmientrasseestárecargando.Desconectardelcargadorantesdeusarlo.
• SisupaquetedealimentaciónportátilRescuerequiereservicio,sigalasinstruccionesdela
 seccióndegarantía.Notratederepararlaunidadnireemplazarlaspiezas.noautorizado
 reparacionesinvalidaránlagarantía.
• Serecomiendaorequierelubricación.
• Evitealmacenarlaluzsolardirecta,elcaloroelfríoextremo,ozonasmuyhúmedas.
• Cuandosetrabajabajoelcapó,tengacuidadodemoverlasaspasdelventilador,
 correas,poleasyotraspartesmóvilesquepuedencausarlesiones.
DeconformidadconlaProposición65deCalifornia,esteproductocontienesustanciasquímicasqueel
EstadodeCaliforniacomocausantedecáncerydefectosdenacimientouotrosdañosreproductivos.
Riesgo de daño grave
Utilice su paquete de alimentación de forma segura
10
11 12
439
1
2
6
14
5
78
13
Componentes
1Cable de puente positivo (+)
2Cable de puente negativo (–)
3 Lucesindicadorasdetensión
4 Lucesindicadorasdeestado
5 ElbotónInicio
6 Indicador de encendido
7 MedidordebateríaDigital
8 Botóndetensióninterna
9 Tomacorrienteparaaccesorios12V
10 Cargadordebatería
11 Puerto para cargador
12 InterruptordeON/Off
13 Interruptor de luz de trabajo
14 Interruptor de luz de pinza
ElRescue®3100esunpaquetedealimentaciónportátildecalidadcomercialcapazdeentregar
corrientesignicativaparaproporcionarsaltopotenciadearranqueparaautomóviles,camionesy
equiposcomerciales.TheRescue®3100proporcionaalimentaciónde12V.Cuentaconprotecciónde
lapolaridadinteligente.Estascaracterísticasimpidenelpaquetedealimentacióndelaconexiónalos
sistemas cuando polaridad de las conexiones son incorrectas.
El general de Rescue®3100

10
ElRescue®3100estádis-
eñado para utilizar un tipo de
selladobateríamotorizados
medir6-1/2 " dealto,7"de
largoy3"deprofundidadcon
los principales terminales, o
selladoU-1bateríaestándar.
QuickCablerecomiendaque
estainstalaciónsearealizada
por el vendedor distribuidor o
personal capacitado.
Instalación de la batería
Asegúrese de observar la polaridad correcta
•LoscablesinternosdelRescue3100sondecolorrojo(positivo)ynegro(negativo).
•Antesdeconectaraunabatería,vuelvaacomprobarlasmarcasdebaterías.
•ConexióndeunapilaalrevéspuedecausardañopermanenteasuRescue3100.
Abralapartetraseradelacajadelabateríapresion-
ando hacia abajo las dos pestañas en la parte superior
del panel de caso y tire del panel lejos de la fuente de
alimentación.Haydossoportesmetálicosunidosala
caja con tornillos (se proporciona un rebaje cabeza
Phillipssisenecesitamayorapalancamiento).Retire
los dos soportes. Tenga en cuenta que el soporte supe-
rior tiene una pestaña a lo largo de su borde superior.
Conecteelcablerojoalterminalpositivodelabateríayconecteel
cablenegroalaterminalnegativadelabatería.Empujelabatería
ensulugardentrodelRescue3100einstalarlossoportesdere-
tencióndemetal.Elsoporteconlalengüetaeselsoportesuperior
ylalengüetaseajustasobreunabateríaU1.Aprietelasabrazad-
erasrmemente.
Hay un bloque separador de espuma de poliestireno en el interior
delRescue3100.Sivaainstalarunabateríadeestilomotoriza-
dos,retireelbloquedeespumadepoliestireno,instalelabateríay
coloquelaespumadepoliestirenoencontradelabatería.Fijecon
abrazaderasdesujeción.Siestáinstalandoa-1Ubatería,retireel
separador de espuma de poliestireno y conservar para su posible
uso en el futuro.
Vuelvaacolocarlatapadelabateríadeplástico.
