Quickie Pulse 6 BC User manual

O w n e r ’ s M a n u a l
Quickie®Pulse
6 BC, 6 SC, 6 CC
SUPPLIER: This manual must be given to the rider o this wheelchair.
RIDER: Be ore using this wheelchair read this entire manual and save
or uture re erence.
M o d e d ’ e m p l o i
Quickie®Pulse
6 BC, 6 SC, 6 CC
FOURNISSEUR: Ce manuel doit être remis à l’utilisateur / utilisatrice de
ce auteuil roulant.
UTILISATEUR / UTILISATRICE : Avant d’utiliser ce auteuil roulant, lisez
entièrement ce manuel et conservez le pour le consulter ultérieurement.
Cada una de las sillas se envía con un manual de instrucciones en inglés. El manual en español
o rancés está disponible en ormato PDF en nuestra página en Internet: www.SunriseMedical.com.
Ingrese a la página del producto especí ico para descargar el manual, o comuníquese con el
proveedor autorizado de Sunrise Medical.
M a n u a l d e
I n s t r u c c i o n e s
Quickie®Pulse
6 BC, 6 SC, 6 CC
DISTRIBUIDOR: Este manual debe ser entregado al pasajero de esta silla
de ruedas.
PASAJERO: Antes de usar esta silla de ruedas, lea este manual en su totali-
dad y guárdelo para utura re erencia.
Chaque auteuil est livré avec un manuel d’instructions en anglais. Les versions en espagnol
et en rançais sont à votre disposition en ormat PDF sur le site : www.SunriseMedical.com.
Veuillez vous rendre à la page de votre produit pour télécharger le manuel dans la langue
souhaitée, ou contactez un ournisseur agréé Sunrise Medical.
S E C T I O N
S E C T I O N E N G L I S H
PULSE

119832 Rev. A 2
ENGLISH
I. INTRODUCTION
I. INTRODUCTION
SUNRISE LISTENS
Thank you for choosing a Quickie wheelchair. We want to hear your
questions or comments about this manual, the safety and reliability of
your chair, and the service you receive from your Sunrise supplier.
Please feel free to write or call us at the address and telephone
number below:
SUNRISE MEDICAL
Customer Service Department
2842 Business Park Ave
Fresno, CA 93727
[phone] or [phone]
FOR ANSWERS TO YOUR QUESTIONS
Your authorized supplier knows your wheelchair best and can
answer most of your questions about chair safety, use and mainte-
nance. or future reference, fill in the following:
Supplier:_______________________________________________________________
Address: _______________________________________________________________
______________________________________________________________________
Telephone: _____________________________________________________________
Serial #: _______________________________________ Date/Purchased: ________
USER WARNING
WARNING
Attention wheelchair users, do not operate this wheel-
chair without first reading the owner’s manual. If you
do not understand the instructions and warnings of this
owner’s manual please contact your dealer or qualified
technician before operating this Quickie wheelchair.
Failure to do so may result in damage and/or injury.
DEALER/TECHNICIAN WARNING
WARNING
Attention dealers and qualified technicians, do not oper-
ate or service this wheelchair without first reading this
owners manual. If you do not understand the instruc-
tions and warnings of this owners manual please contact
the Quickie Technical Service Department before oper-
ating and/or servicing this Quickie wheelchair. Failure to
do so may result in damage and/or injury.
WARNING
In addition, power wheelchairs may contain printed cir-
cuit boards. Careful attention should be given to the
Printed Circuit Board Handling Techniques insert sup-
plied with the chair.
Related Documents
Listed below are additional documents which are referenced in this
owners manual.
• RNET Owners Manual
• RNET OBP Owners Manual
• RNET Omni Owners Manual
• Pulse Service Manual

119832 Rev. A
3
ENGLISH
II. TABLE OF CONTENTS
II. TABLE OF CONTENTS
I. INTRODUCTION................................................... 2
II. TAB E OF CONTENTS.......................................... 3
III. YOUR CHAIR AND ITS PARTS ............................ 4
IV. NOTICE - READ BEFORE USE.............................. 5
V. EMI (E ECTROMAGNETIC INTERFERENCE)...... 5
A.What is EMI................................................................ 5
B. What Effect Can EMI Have........................................ 5
C.Sources of EMI........................................................... 5
D.Distance rom the Source......................................... 6
E. Immunity Level........................................................... 6
. Report All Suspected EMI Incidents........................... 6
VI. GENERA WARNINGS .......................................... 7
A. Notice to Rider .......................................................... 7
B. Notice to Attendants ................................................. 7
C.Weight Limit............................................................... 7
D.Controller Settings..................................................... 7
E. EMI............................................................................. 7
. Safety Check-List ....................................................... 7
G.Changes & Adjustments............................................. 7
H.When Seated in a Parked Wheelchair........................ 8
I. Environmental Conditions ......................................... 8
J. Terrain........................................................................ 8
K.Street Use.................................................................. 8
L. Motor Vehicle Safety.................................................. 8
M.Center of Balance...................................................... 8
N.Transfers..................................................................... 8
O.Reaching or Leaning................................................... 9
P. Dressing or Changing Clothes ................................... 9
Q.Obstacles ................................................................... 9
R. Driving in Reverse...................................................... 9
S. Ramps, Slopes & Sidehills........................................... 9
T. To Reduce the Risk of alls, Tip-over or
Loss of Control .......................................................... 10
U.Ramps at Home & Work............................................ 10
V. Wheelchair Lifts ......................................................... 10
W.Curbs & Single Steps.................................................. 10
X.Stairs........................................................................... 10
Y. Escalators ................................................................... 10
VII. WARNINGS: COMPONENTS & OPTIONS.......... 11
A.Armrests .................................................................... 11
B. Batteries..................................................................... 11
C.Cushions..................................................................... 11
D. asteners.................................................................... 11
E. ootplate & ootrests................................................ 11
. Motor Locks............................................................... 11
G.On/Off Switch............................................................ 11
H.Positioning Belts......................................................... 11
I. Seating Systems.......................................................... 11
J. Upholstery abric ...................................................... 12
K.Suspension.................................................................. 12
L. Wiring......................................................................... 12
M.Power Seating ............................................................ 12
N. S.P.O.T. Power Accessory ........................................ 12
VIII. SET UP, ADJUSTMENT & USE.............................. 13
Notes ............................................................................. 13
Tools You Will Need ...................................................... 13
Check Out ..................................................................... 13
A.Battery Removal......................................................... 14
B. Center Mount Hanger Adjustment............................ 14
C.Swing-Away ootrests ............................................... 15
D.Elevating Legrest........................................................ 15
E. olding Backrest......................................................... 15
. Dual Post Height-Adjustable Armrests (option),
ixed Height (std) ...................................................... 16
G.Single Post Height-Adjustable Armrests .................... 16
H.Seat Depth ................................................................. 17
I. Transit Option ............................................................ 17
J. Manual Recline Option............................................... 17
K.Joystick....................................................................... 18
L. Joystick Retractable Mount ........................................ 18
M.ASAP II Seating Adjustment....................................... 18
N.Seat Height Adjustment............................................. 19
O.Seat Removal.............................................................. 19
P. Shroud Removal......................................................... 19
Q.Check-Out................................................................. 19
IX. OPERATING GUIDE .............................................. 20
A.Performance Control Settings ................................... 20
B. Thermal Roll-Back...................................................... 20
C.Joystick Stationary...................................................... 20
D.VR2 Joystick Assembly ............................................... 21
E. LED Joystick............................................................... 22
. Monochrome LCD Screen......................................... 23
G.Color LCD Screen ..................................................... 24
H.Brake Lever................................................................ 25
X. BATTERIES............................................................. 26
A.Introduction ............................................................... 26
B. Battery Charger ......................................................... 26
C.Acid Burns.................................................................. 26
D.Connecting Batteries in Battery Well......................... 26
E. Charging Batteries...................................................... 27
. Disposing of Batteries ................................................ 27
XI. MAINTENANCE..................................................... 28
A.Notes ......................................................................... 28
B. Cleaning ..................................................................... 28
C.Storage Tips ............................................................... 28
D.To Repair or Replace a Tire ....................................... 28
E. Motor Brushes ........................................................... 28
. Ordering Parts ........................................................... 28
G.Maintenance Chart..................................................... 28
H.Wiring Diagram.......................................................... 29
XII. SUNRISE IMITED WARRANTY .......................... 30
ESPAÑO ................................................................ 31
FRANÇAIS.............................................................. 60

III. YOUR CHAIR AND ITS PARTS
Weight
SC BC CC
complete chair: 260 lbs 235 lbs 250
w/o batteries: 182 lbs 157 lbs 172
Drive Wheels
13" Mag: Std. airless insert
Joystick
Standard – VR2 (right-hand or
left-hand mount)
Option - VR2 w/actuator control
(SC only)
Option - RNET–
LED/Monochrome/Color
Batteries
(2 deep cycle batteries required to
operate chair)
Standard - Group 22
Battery Charger
Off board 8 AMP
Shroud Colors
Red, Black, Blue
Seats, Upholstery and Style
Standard- BC & SC: A.S.A.P. II Seat rame
CC: Captain’s Seat
Sizes: 12" - 22" wide, 12" - 22" deep
Footrest:
CC- Center Mount
SC & BC: Standard- Swing away
footrests with heel loops
Option- oot platform, Manual ele-
vating legrests, Power Articulating
Legrest (ALR), Power Center Mount,
Center Mount
Backrest
SC & BC: Standard Canes Angle
Adjustable
Option- 8° Bend, Semi Recline,
olding
CC: Standard- Captain’s Seat Back
Casters (front)
Standard- 7” solid
Casters (rear)
Standard- 6” solid
Armrest
SC & BC: Standard- 14" Cantilever,
height adjustable 14" arm pad
Option- Locking, two-point arm,
Dual post Arm, Single Post arm
CC: Standard- lip-up
Suspension
Standard- all wheel
All features may not be available with some
chair setups or in conjunction with another
chair feature. Please consult your supplier
for more information. Your authorized sup-
plier can also provide you with more infor-
mation on accessories.
QUICKIE PULSE
III. YOUR CHAIR AND ITS PARTS
ENGLISH
4
119832 Rev. A
1. lip-back, height-adjustable armrest
2. VR2 controller joystick
(RNET optional)
3. Captain’s Seat
4. ront caster 7"
5. Rear stabilizing caster 6"
6. Single plate foot platform (shown);
Swing-away (optional); 70° Hangers;
Swing-away ELR hangers (optional)
7. Drive wheels
8. Brake release
9. Caster ork (front)
10. Caster ork (rear)
11. Shroud
Models
Pulse 6 BC
Pulse 6 SC
Pulse 6 CC (shown)
1
3
6
4
8
9
11 7
5
10
2

V. EMI (ELECTROMAGNETIC INTERFERENCE)
V. EMI (ELECTROMAGNETIC INTERFERENCE)
WARNING
Heed all warnings to reduce the risk of unintended
brake release or chair movement:
1. Beware of the danger from hand-held transceivers. (A
“transceiver” is a device that both sends and receives
radio wave signals). Never turn on or use a hand-held
transceiver while power to your chair is on. Use extra
care if you believe that such a device may be in use
near your chair.
2. Be aware of nearby radio or TV stations, and avoid
coming close to them.
3. If unintended movement occurs, turn your chair off as
soon as it is safe to do so.
A. WHAT IS EMI?
WARNING
1. EMI means: electromagnetic (EM) interference (I). EMI
comes from radio wave sources such as radio transmitters
and transceivers.
2. There are a number of sources of intense EMI in your daily
environment. Some of these are obvious and easy to avoid.
Others are not, and you may not be able to avoid them.
3. Powered wheelchairs may be susceptible to electromagnetic
interference (EMI) emitted from sources such as radio sta-
tions, TV stations, amateur radio (HAM) transmitters, two
way radios, and cellular phones.
4. EMI can also be produced by conducted sources or electro-
static discharge (ESD).
B. WHAT EFFECT CAN EMI HAVE?
WARNING
1. EMI can cause your chair, without warning, to:
• Release its brakes
• Move by itself
• Move in unintended directions
If any of these occurs, it could result in severe injury to you or
others.
2. EMI can damage the control system of your chair. This could
create a safety hazard, and lead to costly repairs.
C. SOURCES OF EMI
WARNING
The sources of EMI fall into three broad types:
1. Hand-Held Transceivers:
The antenna is usually mounted directly on the unit. These
include:
• Citizens band (CB) radios
• “Walkie-talkies”
• Security, fire and police radios
• Cellular phones
• Lap-top computers with phone or fax
• Other personal communication devices
NOTE– These devices can transmit signals while they are on, even if not in use.
2. Medium-Range Mobile Transceivers:
These include two-way radios used in police cars, fire trucks,
ambulances and taxi cabs. The antenna is usually mounted on the
outside of the vehicle.
C. REVIEW THIS MANUAL OFTEN
Before using this chair you, and each person who may assist you,
should read this entire Manual and make sure to follow all instruc-
tions. Review the warnings often, until they are second nature to you.
D. WARNINGS
The word “WARNING” refers to a hazard or unsafe practice that
may cause severe injury or death to you or to other persons. The
“Warnings” are in four main sections, as follows:
1. V — EMI
Here you will learn about electromagnetic interference and
how it can affect your chair.
2. VI — GENERA WARNINGS
Here you will find a safety checklist and a summary of risks
you need to be aware of before you ride this chair.
3. VII — WARNINGS — COMPONENTS & OPTIONS
Here you will learn about your chair. Consult your supplier
and your health care professional to help you choose the
best set-up and options for your safety.
4. X — BATTERIES
Here you will learn about battery and charger safety, and
how to avoid injury.
NOTE– Where they apply, you will also find “Warnings” in other sections of
this Manual.
IV. NOTICE– READ BEFORE USE
A. CHOOSE THE RIGHT CHAIR & SAFETY
OPTIONS
Sunrise provides a choice of many power wheelchair styles, sizes
and adjustments to meet the needs of the rider. However, final
selection of a wheelchair rests solely with you and your health care
professional. Choosing the best chair for you depends on such
things as:
1. Your size, disability, strength, balance and coordination.
2. Your intended use, and your level of activity.
3. The types of hazards you must overcome in daily use (in
areas where you are likely to use your chair).
4. The need for options for your safety and comfort (such as
positioning belts or special seat systems).
B. ADJUST CHAIR TO YOUR ABILITY
You need to work with your doctor, nurse or therapist, and your
supplier, to fit this chair and adjust the controller settings for your
level of function and ability.
IV. NOTICE– READ BEFORE USE
ENGLISH
5119832 Rev. A

F. REPORT ALL SUSPECTED EMI
INCIDENTS
WARNING
You should promptly report any unintended movement
or brake release. Be sure to indicate whether there was
a radio wave source near your chair at the time.
Contact: Sunrise Medical Customer Service
Department at [phone].
3. Long-Range Transceivers:
These include commercial radio and TV broadcast antenna towers
and amateur (HAM) radios. Note: The following are not likely to
cause EMI problems: Lap-top computers (without phone or fax),
Cordless phones, TV sets or AM/ M radios, CD or tape players.
D. DISTANCE FROM THE SOURCE
WARNING
EM energy rapidly becomes more intense as you get
closer to the source. For this reason, EMI from hand-
held devices is of special concern. (See C.1 above) A
person using one of these devices can bring high levels
of EM energy very close to your chair without you
knowing it.
E. IMMUNITY LEVEL
WARNING
1. The level of EM energy is measured in volts per meter (V/m).
Every power wheelchair can resist EMI up to a certain level.
This is called its “immunity level”.
2. The higher the immunity level, the less the risk of EMI. It is
believed that a 20 V/m immunity level will protect the power
wheelchair user from the more common sources of radio
waves.
3. The Quickie Pulse with the following configuration was test-
ed and found to be immune to at least 20 V/m:
Quickie Pulse power wheelchair with a right-hand mounted
RNET controller, A.S.A.P. seat, flip-back armrests, solid flip-
up footplate and Group 22 batteries.
4. The following specialty input devices have an unknown effect on
the immunity level because they have not been tested with the
Quickie Pulse and RNET control system:
WARNING
Individuals with physical limitations requiring the use of
a specialty control input device known not to be
immune to 20V/m, or not known, should exercise extra
care around known sources of EMI.
WARNING
There is no way to know the effect on EMI if you add
accessories or modify this chair. Any change to your
chair may increase the risk of EMI. Parts from other
suppliers have unknown EMI properties.
• Breath Control
• Proportional Head
Control
• Tri-Switch Head Array
• Proportional Mini-
Joystick/Chin Control
• Heavy Duty Switched
Joystick
• Buddy Button
• Treadle Switch
• Micro Light
• Ribbon Switch
• Star Board
• Proximity Head Array
• Wafer Board
• Zero Touch Switch
• Penta Switch
• 4-Zero Touch Switch
• Plate Switch
• 5-Zero Touch Switch
• Soft Switch
• Disc Switch
• Grasp Switch
• Wobble Switch
V.
ENGLISH
6
119832 Rev. A

D. CONTROLLER SETTINGS
WARNING
Be aware that you may need to adjust the controller
settings of your chair to reduce the risk of a collision,
fall or tip-over.
1. Check and adjust the settings every six to twelve months (or
more often, if needed).
2. Consult your supplier to adjust the control settings immedi-
ately if you notice any change in your ability to:
• Control the joystick.
• Hold your torso erect.
• Avoid running into objects.
E. EMI
WARNING
Read Section V to learn about EMI. To reduce the risk
of unintended brake release or chair movement:
1. Never turn on or use a hand-held transceiver while power to
your chair is on. Use extra care if you believe that such a
device may be in use near your chair.
2. Be aware of nearby radio or TV stations, and avoid coming
close to them.
3. If unintended movement or brake release occurs, turn your
chair off as soon as it is safe.
F. SAFETY CHEC -LIST
WARNING
Before each use of this chair:
1. Make sure the chair operates smoothly. Check for noise, vibra-
tion, or a change in ease of use. (They may indicate low tire
pressure, loose fasteners, or damage to your chair). If you
detect a problem, make sure to repair or adjust the chair.
Deferring repair or adjustment could increase the risk for
injury. Your supplier can help you find and correct the problem.
2. Make sure batteries are charged. Green lights on the con-
troller charge indicator will light up when charge is full.
Yellow lights indicate battery charge level is getting low. Red
lights indicate batteries are in immediate need of charging.
G. CHANGES & ADJUSTMENTS
WARNING
Never use non-Quickie parts or make changes to your
chair unless authorized by Sunrise. (Doing so will void
the Warranty and may create a safety hazard).
1. If you modify or adjust this chair it may increase the risk of a
fall or tip-over.
2. Modifications unauthorized by Sunrise constitutes remanufac-
turing of the wheelchair. This voids the warranty. The rider
then assumes all future liability for the wheelchair.
VI. GENERAL ARNINGS
WARNING
Heed all warnings in this section. If you fail to do so a
fall, tip-over or loss of control may occur and cause
severe injury to you or others.
A. NOTICE TO RIDER
WARNING
1. Before using this chair, you should be trained in its safe use
by your health care professional.
2. Every wheelchair is different. Take the time to learn the feel
of this chair before you begin riding.
3. Be aware that you must develop your own methods for the
safe use of this chair that are best suited to your level of
function and ability.
4. Have someone help you practice bending, reaching and
transferring until you learn how to do them safely.
5. Never try a new maneuver on your own unless you are sure
it is safe.
6. Get to know the areas where you plan to use your chair.
Look for hazards and learn how to avoid them.
7. Do not allow additional riders on the chair, armrests or chas-
sis. Doing so may result in injury or damage.
B. NOTICE TO ATTENDANTS
WARNING
Make sure you heed all warnings and follow all instruc-
tions in each section of this manual. (Be aware that
warnings that apply to the rider also apply to you).
Notes:
1. You need to work with the rider and the rider’s doctor,
nurse or therapist, to develop safe methods best suited to
your abilities and those of the rider.
2. To manually push the chair you must release the motor locks.
Make sure you have full control over the chair when you
release the motor locks. When you do so the chair will not
have brakes.
3. Propel this chair by the armrest supports only. If using a seat
frame, propel the chair by the push handles on the top of the
backrest. They provide secure points for you to hold the rear
of the chair to prevent a fall or tip-over.
C. WEIGHT LIMIT
WARNING
1. Never exceed a total weight of 300 pounds (136.3 kilograms)
for rider plus items carried.
2. Never use this chair for weight training if the total weight
(rider plus additional weights) exceeds 300 pounds (136.3
kilograms).
3. Exceeding the weight limit is likely to damage the seat,
frame, or fasteners and may cause severe injury to you or
others from chair failure.
4. Exceeding the weight limit will void the warranty.
VI. GENERAL ARNINGS
ENGLISH
7119832 Rev. A

VI.
H. WHEN SEATED IN A PAR ED
WHEELCHAIR
WARNING
1. Always turn off all power to your chair when you are parked,
even for a moment. This will prevent:
•Accidental movement from contact with the joystick by
you or others.
• Unintended brake release or movement from EMI
sources. (See Section V)
2. Make sure that persons who help you (for example, store
clerks) are aware of the joystick and do not touch it. If they
do, your chair may move suddenly when you do not expect it.
I. ENVIRONMENTAL CONDITIONS
WARNING
Your chair is not designed for use in a heavy rain storm,
or in snowy or icy conditions.
1. Contact with water or excessive moisture can cause an elec-
trical malfunction. The frame, motors and other chair parts
are not watertight and may rust or corrode from the inside.
To avoid a chair failure:
• Minimize exposure of your chair to a rain storm or very
wet conditions.
• Never take your chair into a shower, tub, pool or sauna.
• Do not use your chair in fresh or salt water (such as at
the edge of a stream, lake, or ocean).
• Make sure shroud cover and deck lid are secure.
• Replace joystick boot if it becomes torn or cracked.
• Make sure all electrical connections are secure.
• Dry the chair as soon as you can if it gets wet, or if you
use water to clean it.
2. Proceed slowly and use extra care if you must operate your
chair on a wet or slick surface.
• Do so only if you are sure it is safe.
• Stop if one or both main wheels lose traction. If this
occurs, you may lose control of your chair or fall.
• Never operate your chair on a slope or ramp if there is
snow, ice, water or oil film present.
• When in doubt, have someone help you.
3. When not in use, keep your chair in a clean, dry place.
J. TERRAIN
WARNING
1. This chair is designed for use on firm, even surfaces such as
concrete, asphalt and indoor flooring.
2. Do not operate your chair in sand, loose soil or over rough
terrain. Doing so may damage wheels, bearings, axles or
motors, or loosen fasteners.
. STREET USE
WARNING
In most states, power chairs are not legal for use on
public roads. Be alert to the danger of motor vehicles
on roads or in parking lots.
1. At night, or when it is hard to see, use reflective tape on
your chair and clothing.
2. It may be hard for drivers to see you. Make eye contact with
drivers before you proceed. When in doubt, yield until you
are sure it is safe.
L. MOTOR VEHICLE SAFETY
WARNING
To date, the U.S. Department of Transportation has not
approved any tie down system for transporting this
wheelchair in a motor vehicle.
1. Never sit in this chair while in a moving vehicle. In an acci-
dent or sudden stop you may be thrown from the chair.
• Wheelchair belts are designed to position the rider
only and will not protect you in an accident; further
injury may result from the belts.
2. Always move to an approved vehicle seat. You must be
secured with proper motor vehicle restraints.
3. Never transport this chair in the front seat of a vehicle. It
may shift and interfere with the driver.
4. Always secure this chair so that it cannot roll or shift.
M. CENTER OF BALANCE
WARNING
The point where this chair will tip forward, back or to
the side depends on its center of balance and stability.
The Center Of Balance Is Affected By:
1. The seat height and seat angle.
2. A change in your body position, posture or weight distribution.
3. Using this chair on a ramp or slope.
4. The use of a back pack or other options, and the amount of
added weight.
To Reduce The Risk Of A Fall Or Tip-Over:
1. Consult your supplier for information on modifications
authorized by Sunrise before you modify or adjust this chair.
NOTE– You may need to make additional changes to correct the center of
alance.
2. Use extreme care until you know the balance points of this
chair and how to avoid a fall or tip-over.
N. TRANSFERS
WARNING
It is dangerous to transfer on your own. It requires
good balance and agility. Be aware that there is a point
during every transfer when the wheelchair seat is not
below you. To avoid a fall:
1. Always turn off power before you transfer to or from your
chair. If you fail to do so you may touch the joystick and
cause your chair to move when you do not expect it.
ENGLISH
8
119832 Rev. A

VI.
P. DRESSING OR CHANGING CLOTHES
WARNING
Be aware that your weight will shift if you dress or
change clothes while seated in this chair. To make the
chair more stable, rotate the front casters until they are
forward.
Q. OBSTACLES
WARNING
Obstacles you may have to overcome in daily use
include door thresholds, lifts, ramps and hazards such as
potholes and broken pavement. These can damage your
chair and may cause a fall, tip-over or loss of control.
1. Be aware that thresholds are very dangerous. (Even a small
change in height may stop a caster wheel and cause your
chair to tip). You may need to:
• Remove or cover threshold strips between rooms.
• Install a ramp at entry or exit doors.
2. Keep your eyes moving when you ride; scan the area well
ahead of your chair.
3. Make sure the floor areas where you use this chair are level
and free of obstacles.
4. To help correct your center of balance:
• Lean your upper body forward slightly as you go up over
an obstacle.
• Press your upper body backward as you go down from a
higher to a lower level.
R. DRIVING IN REVERSE
WARNING
Use extra care when you drive your chair in reverse.
You may lose control or fall if one of the rear wheels
hits an object.
1. Operate your chair slowly and at an even speed.
2. Stop often and check to make sure your path is clear of
obstacles.
S. RAMPS, SLOPES & SIDEHILLS
WARNING
The center of balance of your chair changes when you
are on a slope.
NOTE– “Slope” includes a ramp or sidehill. Your chair is less sta le when it
is at an angle. Never use this chair on a slope unless you are sure it
is safe. When in dou t, have someone help you.
Beware Of:
1. Steep slopes. Do Not use this chair on a slope steeper than
10%. (A 10% slope means: One foot in elevation for every
ten feet of slope length).
2. Wet or slippery surfaces (such as when ice, snow, water or oil
film is present). A loss of traction may cause a fall or tip-over.
3. A change in grade on a slope (or a lip, bump or depression).
These may cause a fall or tip-over.
4. A drop-off at the bottom of a slope. (A drop-off of as small
as 3/4 inch can stop a front caster and cause the chair to tip
forward).
2. Make sure motor locks are engaged. This keeps the chair
from moving when you transfer.
3. Work with your health care professional to learn safe methods.
• Learn how to position your body and how to support
yourself during a transfer.
• Have someone help you until you are sure you can do a
safe transfer on your own.
4. Move your chair as close as you can to the seat you are
transferring to. If possible, use a transfer board.
5. Rotate the front casters until they are as far forward as
possible.
6. Be careful of the foot platform. If you can, remove or swing
it out of the way.
• Never stand on footrests when you transfer. Doing so
may damage them or cause your chair to tip.
• Make sure your feet do not “hang up” or get caught in
the space between the footrests.
7. Make sure armrests do not interfere.
8. Transfer as far back onto the seat surface as you can. This
will reduce the risk that you will miss the seat or fall.
O. REACHING OR LEANING
WARNING
Reaching or leaning affects the center of balance of your
chair. If done improperly, a fall or tip-over is likely. When in
doubt, ask for help or use a device to extend your reach.
To Reduce the Risk of injury and/or Damage to the Chair:
1. Never reach or lean if you must shift your weight sideways
or rise up off the seat.
2. Never reach or lean if you must move forward in your seat
to do so. Always keep your buttocks in contact with the
backrest.
3. Never reach with both hands (you may not be able to catch
yourself to prevent a fall if you lose your balance).
4. Never try to pick up an object from the floor by reaching
down between your knees.
5. Never put pressure on the foot platform while reaching. This
may cause the chair to tip if you lean too far.
6. Never reach or lean over the top of the seat back. This may
damage the backrest and cause you to fall.
IF YOU MUST REACH OR LEAN, DO SO AT
YOUR OWN RIS .
Remember to:
1. Move your chair as close as you can to the object you wish
to reach.
2. Rotate the front casters until they are as far forward as possi-
ble. This makes the chair more stable.
NOTE– To do this: Move your chair past the o ject you want to reach, then
ack up alongside it. Backing up will rotate the casters forward.
3. Turn off all power to your chair. If you fail to do so, you may
touch the joystick and cause your chair to move when you
do not expect it.
4. irmly grasp an armrest with one hand. This will help to pre-
vent a fall if the chair tips.
ENGLISH
9119832 Rev. A

VI.
T. TO REDUCE THE RIS OF A FALL,
TIP-OVER OR LOSS OF CONTROL
WARNING
1. Never use your chair on a slope unless you are sure you can
do so without losing traction.
2. Always go as straight up and as straight down as you can.
• Do not “cut the corner” on a slope or ramp.
• Do not turn or change direction on a slope.
3. Always stay in the center of the ramp. Make sure ramp is
wide enough that you are not at risk that a wheel may roll
off the side.
4. Lean or press your body uphill. This will help adjust for a
change in the center of balance caused by the slope.
5. Keep your chair moving at a slow, steady speed. Keep control
over the chair at all times.
• On a descent, do not let your chair accelerate beyond its
normal speed.
• If the chair picks up speed, center the joystick to slow
down or stop.
NOTE– The solid state controller of your chair has a logic system that will
help control your speed when driving on a slope or uphill.
• If you stop, re-start slowly.
U. RAMPS AT HOME & WOR
WARNING
Make sure ramps meet all Building Codes for your area.
1. or your safety, have a licensed contractor build or remodel
ramp to meet all standards.
2. NOTE– The proper design will vary, depending on such
things as: the length and height of the ramp; the need for an
intermediate platform; landing size; doors and the direction
of swing; and whether the ramp includes a turn or angle.
At A Minimum:
1. Open sides of ramp must have side rails to prevent your
chair from going over the edge.
2. Slope must not be steeper than one inch in height for every
one foot of slope length.
3. Ramp surface must be even, and have a non-skid surface.
4. You may need to add a section at the top or bottom to avoid
a lip or drop-off.
5. Ramp must be sturdy. Add bracing if needed, so ramp does
not “bow” when you ride on it.
V. WHEELCHAIR LIFTS
WARNING
Wheelchair lifts are used in vans, buses, and buildings to
help you move from one level to another.
1. Always turn off all power to your chair when you are on a lift.
If you fail to do so, you may touch the joystick by accident
and cause your chair to drive off the platform. (Be aware that
a “roll-stop” at the end of the platform may not prevent this).
2. Make sure there is not a lip or drop-off at the top or bottom
of the platform. These may cause a fall or tip-over. When in
doubt, have someone help you.
3. Always secure the rider with a positioning belt to help pre-
vent falls during transfers.
4. Avoid moving forward if a wheel is “hung up” on the lip of
the ramp. Backup, reposition the caster for a more direct
approach and slowly try again.
W. CURBS & SINGLE STEPS
WARNING
1. Your chair is not designed to drive up or down a curb or step
more than two and a half (2.5) inches high. Doing so may:
• Result in a fall or tip-over.
• Damage the frame, wheels, axles or other chair parts, or
loosen fasteners.
2. To prevent a fall or tip-over, use wheelchair access ramps or
have someone help you.
3. If you must climb or descend a curb or step alone do so at
your own risk and use extreme care.
• Go as straight up or straight down as you can. Never turn
or climb or descend at an angle as a fall or tip-over is
likely.
• Proceed slowly, at a steady speed.
4. Avoid driving along curb edges and drop-offs. A minimum
distance from the edge of 18” is recommended.
X. STAIRS
WARNING
Never use this chair to go up or down stairs, even with
an attendant. Doing so is likely to cause a fall or tip-
over.
Y. ESCALATORS
WARNING
Never take this chair on an escalator, even with an
attendant. Doing so is likely to cause a fall or tip-over.
ENGLISH
10
119832 Rev. A

• Avoid putting weight on the footplate or footrests, as the
chair may tip forward.
• lip the footplate back or swing the footrests out of the
way, if possible.
3. Never lift this chair by the footplate or footrests. ootrests
fold or detach and will not bear the weight of this chair. Lift
this chair only by non-detachable parts of the main frame.
F. MOTOR LOC S
WARNING
1. Do not engage or disengage motor locks unless power to the
chair is off.
2. Be aware that the chair will not have brakes when motor
locks are in the free-wheel position. (See Section of
Operating Guide.)
3. Make sure that the person pushing the chair has full control
when motor locks are disengaged.
G. ON/OFF SWITCH
WARNING
1. Never use the ON/O switch to stop the chair except in an
emergency. This will result in an abrupt stop and may cause
you to fall.
2. To slow your chair to a stop, return the joystick to neutral,
before turning off the chair.
H. POSITIONING BELTS
WARNING
Use a positioning belt only to help support your pos-
ture. Improper use of such belts may cause severe
injury or death.
1. Make sure you are not at risk to slide down in the wheelchair
seat. If this occurs, you may suffer chest compression or suf-
focate due to pressure from the belt.
2. A pelvic wedge or a similar device can help you from sliding
down in the seat. Consult your health care professional to
find out if you need such a device.
3. The belt must be snug, but must not be so tight that it inter-
feres with breathing. You should be able to slide your open
hand, flat, between the belt and your stomach.
4. Make sure you can easily remove the belt in an emergency.
5. Never use a positioning belt:
• In place of a motor vehicle seat belt. In an accident or
sudden stop you may be thrown from the chair. A posi-
tioning belt will not prevent this, and further injury may
result from the belt.
• As a restraint. A restraint requires a doctor’s order.
• On a rider who is comatose or agitated.
I. SEATING SYSTEMS
WARNING
1. Use of a seating system not approved by Sunrise may alter
the center of balance of this chair. This may cause a fall or
tip-over.
2. Never change the seating system of your chair unless you
consult your supplier first.
VII. ARNINGS: COMPONENTS & OPTIONS
WARNING
Note: If you use parts or make changes not authorized
by Sunrise it may create a safety hazard and will void
the Warranty.
A. ARMRESTS
WARNING
Armrests cannot be used to lift chair or the seat.
1. Never lift this chair by its armrests.
2. Lift this chair only by non-detachable parts of the main frame.
B. BATTERIES
WARNING
1. Only deep cycle sealed case construction batteries should be
used in this device.
2. To prevent an acid spill, always keep batteries upright.
(wet cell batteries only)
3. Never smoke or hold an open flame near batteries. They are
a known explosion hazard.
4. Always wear rubber gloves and safety glasses when you han-
dle batteries.
5. Read all of section X Batteries before attempting to change
or charge batteries.
C. CUSHIONS
WARNING
1. Quickie Highback seats are designed for comfort, not specifi-
cally for the relief of pressure.
2. If you suffer from pressure sores, or if you are at risk that
they will occur, you may need a special seat system such as
can be provided by the Seat rame, or a device to control
your posture.
• Consult your doctor, nurse or therapist to find out if you
need such a device for your well-being.
D. FASTENERS
WARNING
Many of the screws, bolts and nuts on this chair are spe-
cial high-strength fasteners. Use of improper fasteners
may cause your chair to fail.
1. Only use fasteners recommended by Sunrise.
2. If fasteners become loose, tighten them as soon as you can.
3. Over- or under-tightened fasteners may fail or cause damage
to chair parts.
• See Section VIII, “Set-Up, Adjustment & Use”, for proper
torque settings.
E. FOOTPLATE & FOOTRESTS
WARNING
1. At the lowest point, the foot platform and footrests should
be at least 2 1/2" off the ground. If set too LOW, it may “hang
up” on obstacles you can expect to find in normal use. This
may cause the chair to stop suddenly and tip forward.
2. To avoid a trip or fall when you transfer:
• Make sure your feet do not “hang up” or get caught in
the space surrounding or in between the footrests.
VII. ARNINGS: COMPONENTS & OPTIONS
ENGLISH
11 119832 Rev. A

119832 Rev. A 12
ENGLISH VII.
J. UPHOLSTERY FABRIC
WARNING
1. Replace worn or torn fabric of the seat as soon as you can. If
you fail to do so, the seat may fail and cause you to fall. Worn
fabrics may increase the potential for a fire hazard.
2. abric will deteriorate with age and use. Look for fraying,
thin spots, or stretching of fabric at rivet holes. Replace fabric
as required.
3. Be aware that washing may reduce flame retardation of the
fabric.
. SUSPENSION
WARNING
The suspension system does contain Dry Natural
Rubber. The suspension, or any other component on the
chair, does not contain any latex based product. The
suspension components are enclosed and inaccessible to
the user.
L. WIRING
WARNING
Never pull on cables directly. This can result in wires
breaking inside the connector or harness. To remove a
plug or connector, always grasp the plug or connector
itself. (See section XI for wiring diagram.)
M. POWER SEATING (SC only)
WARNING
1. Operation
• While driving this wheelchair in the tilted position use cau-
tion.
• Do Not attempt to operate any power seating option
while positioned on an incline.
• Do Not attempt to operate any power seating option
while this wheelchair is in motion.
• Do not attempt to operate the power seating options
around children.
2. Drive Inhibit
This power chair is designed to automatically reduce driving
speed when the power seating is tilted more than 16°.
3. Pinch points
Pinch points may occur when operating the powered seating
options on this chair. Ensure all hands and body parts are
clear of all power seating components that may result in
pinch points before operating them.
4. Tilting Power Base with Push Handles
Do not attempt to tilt power wheelchairs by pulling down on
the push handles. Power wheelchairs have heavy bases. As
such, attempting to tilt a power wheelchair to traverse
obstacles can damage components in the seating system
and/or modular actuators.
5. Remain Clear During Power Accessory Operation
Please stay clear of any powered actuator while the compo-
nent is in motion. Sunrise power mechanisms move over
large ranges of travel. Users should be aware of their sur-
roundings while components are in motion.
6. Maximum User Weight
Do not exceed the weight capacity for your specific
chair/seating system configuration. Doing so could result in
premature failure or injury.
N. S.P.O.T. (Single Power Option Tilt)
POWER ACCESSORY (SC only)
WARNING
The powered S.P.O.T. accessory for this chair has a maximum
user weight capacity of up to 300 lbs. Never exceed this
capacity while operating the powered actuator.
WARNING
The powered S.P.O.T. should not be operated for more than
three minutes of continuous use. Doing so may shorten the
life of the powered S.P.O.T..

119832 Rev. A
13
ENGLISH
VIII. SET-UP, ADJUSTMENT & USE
VIII. SET-UP, ADJUSTMENT & USE
NOTES:
1. Work Surface For Set-Up:
Use a flat surface, such as a table, to assemble, adjust and check your chair. This makes the
steps easier and helps ensure a correct set-up.
2. Fasteners:
• Many of the screws and bolts on this chair are special high-strength fasteners and may
have special coatings.
• Many nuts are of the Nylock type. They have a plastic insert to help prevent loosening.
WARNING
1. Use of improper fasteners may cause the chair to fail.
2. Over- or under-tightened fasteners may fail or cause damage to chair parts.
3. If bolts or screws become loose, tighten them as soon as you can. oose bolts
or screws can cause damage to other chair parts causing them to fail.
3. Washers & Spacers:
• Note the position of washers and spacers before disassembly.
• To avoid damage to the frame, replace all washers and spacers when you reassemble
parts.
4. Torque Settings:
• A torque setting is the optimal tightening for a particular fastener. Use a torque wrench
that measures 120 inch-pounds to secure screws, nuts and bolts on this chair.
NOTE– Unless otherwise noted, use a torque setting of 120 inch-pounds for all fasteners.
TOOLS YOU WILL NEED
1. Basic Tool it:
To set-up, adjust and maintain your chair you will need the following tools:
2. Torque Wrench:
If you plan to adjust and maintain this chair yourself, Sunrise recommends that you use a
torque wrench.
NOTE– The wrench must measure inch-pounds. You can uy a torque wrench and proper sockets from a
hardware store.
CHEC -OUT
Be sure this chair performs to your chosen operational settings. If it does not, turn the chair
off immediately and have your supplier reprogram your wheelchair as needed.
NOTE– Repeat this procedure until the chair performs to your specifications.
WARNING
When properly set up, this chair will operate smoothly. Check to see that all
components work properly. If you detect a problem, be sure to correct it
before use.
• 5mm Allen Wrench
• 6mm Allen Wrench
• 8mm Allen Wrench
• 3/8" combination wrench
• 10mm combination wrench
• 13mm combination wrench
• 18mm combination wrench
• 17mm deep socket wrench
• 19mm socket wrench
• Phillips screwdriver #2
• lat-head screwdriver
• Wire cutters
• Needle nose pliers

119832 Rev. A 14
ENGLISH
4
C
5
D
VIII.
A. BATTERY REMOVAL ( igures 1, 2)
To remove the batteries for transporting or servicing:
1. Remove Batteries
a. Carefully remove seat (see Section O. Seat Removal).
b. Remove the shroud by first removing the six fasteners ( ig. 1). Then lift up on the
shroud.
c. Unplug and remove batteries from the chair ( ig. 2).
d. Lift batteries out of the frame.
2. Battery Installation
See Section X. Batteries, D for installation.
WARNING
Batteries may weigh up to 39 lbs. Care must be taken to avoid injury when
lifting up on battery straps.
B. CENTER MOUNT HANGER ADJUSTMENT
1. Removal (Fig. 3)
a. Remove the four bolts (B) and slide the footrest out.
2. Height Adjustment (Fig. 4)
a. Remove the six securing bolts (C).
b. Move footplate to desired height.
c. Re-install bolts (C) through desired holes.
3. Calf Pad Adjustment (Fig. 5)
a. Remove the two securing bolts (D).
b. Move calf pads to desired height.
c. Re-install bolts (D) through desired holes.
2
1
B
3

119832 Rev. A
15
ENGLISH
C. SWING-AWAY FOOTRESTS
1. Installation (Fig. 6)
a. Place swing-away pivot pin (E) into the locating hole ( ) on top of the hanger mount
with the footrest facing outward from frame.
b. Rotate the footrest inward until latch plate locks (G) into place on locking bolt.
2. Removal (Fig. 7)
a. To remove footrest, press quick-release lever (H).
b. Rotate footrest outward and lift.
3. Height Adjustment (Fig. 7)
a. Remove both bolts (I) in the hanger frame tube.
b. Reposition footrest height.
c. Re-tighten all bolts (I).
D. ELEVATING LEGREST (Optional)
1. Installation
To install or remove Elevating Legrest (ELR) see instructions for Swing-away ootrest installa-
tion.
2. Adjustment (Fig. 8)
a. To raise legrest, lift to desired position. Legrest will automatically lock in place.
b. To lower legrest, while seated in chair, first lift slightly then press release lever (J)
down and lower legrest to desired position.
E. FOLDING BAC REST (optional) ( ig. 9)
1. Upright Positioning
a. Lift backrest to upright position so that latch handles (C) lock into place.
b. Backrest is ready for use.
2. Folding Backrest
a. Lift and turn backrest latch handles (C) inward
or outward.
b. old backrest forward.
WARNING
Backrest latches must be locked into place before operating wheelchair.
VIII.
I
E
F
G
H
J
6
7
8
C
9

A
B
C
9
2
6
7
1
4
3
5
8
Height-Adjustable Armrest Key
1. Inner Arm Post
2. Receiver
3. Release Lever, Locked Position
4. Armrest Pad
5. Transfer Bar
6. Side Panel
7. Tension Adjustment Set Screw
8. Outer Arm Post
9. Receiver Adjustment Bolts
11
F. DUAL-POST HEIGHT-ADJUSTABLE ARMRESTS (OPTION),
FIXED HEIGHT STANDARD ( ig. 10)
The dual-post flip-back armrest can be used as either a flip-back armrest or a removable
armrest.
1. Installing Armrest
a. Insert front and rear posts into armrest receivers.
b. Engage levers (A and B) to secure armrest.
2. Set-up for Flip-back Operation
a. Disengage lever (A) so front post is able to come free.
b. Armrest now has the ability to be flipped back without removal.
3. Set-up for Removal
a. Disengage levers (A and B) so front and rear posts are able to come free.
b. Armrest can now be easily removed for transferring.
4. Height-Adjustment (option)
a. Release the upper securing lever (C).
b. Set at desired height
c. Return securing lever to locked position.
d. Move armrest up or down to allow armrest to snap into place
G.SINGLE POST HEIGHT-ADJUSTABLE ARMRESTS (optional)
( ig. 11)
1. Installation
a. Slide the outer armpost into the receiver mounted to the wheel chair frame.
b. The armrest will automatically lock into place.
2. Height Adjustment
a. Rotate release lever to stop.
b. Slide armrest pad up or down to desired height.
c. Return lever to locked position.
d. Push arm pad until upper armpost locks firmly into place.
3. Removing Armrest
a. Rotate release lever and remove the armrest.
4. Replacing Armrest
a. Slide armrest back into receiver.
b. Return release lever to locked
position against armpost.
5. Adjusting Armrest Receiver Fit
To tighten or loosen the fit of the outer armpost in the receiver:
a. Loosen the four bolts on the sides of the receiver.
b. With the armrest in the receiver, squeeze the receiver to achieve the desired fit.
c. Tighten the four bolts.
6. Adjusting Inner Armpost Fit
a. Two set screws are installed in the outer armpost.
b. Turn the set screws in or out until the desired fit is achieved.
VIII.
ENGLISH
16
119832 Rev. A
10

AB
12
13
H.SEAT DEPTH 14" - 16", 20" - 22" only ( ig. 12)
The seat depth can be adjusted in one inch increments on standard rehab seating.
1. Seat Frame Depth Adjustment
a. To adjust, remove the two bolts (A & B) from each side of the backrest pivot plate.
b. Reposition the backrest to the desired position.
c. Replace and retighten bolts on each side of the backrest pivot plate.
2. Back Angle Adjustment on Seat Frame
a. Remove the front securing bolt (A) on the side of the backrest hinge plate.
b. Loosen the lower rear bolt (B)
c. Set at desired angle. There are five holes (in 4º increments) to choose from.
d. Reinstall the front bolt and tighten both bolts securely.
I. TRANSIT OPTION
WARNING
1. Use only Wheelchair Tie-down and Occupant Restraint Systems (WTORS) which meet
the requirements of SAE J2249 Recommended Practice– Wheelchair Tie-down and
Occupant Restraint Systems or Use in Motor Vehicles. Do not use WTORS designed
to rely on the wheelchair structure to transfer occupant restraint loads to the vehicle.
2. The wheelchair has been dynamically tested in a forward-facing mode for a 30 mph
frontal impact test. The wheelchair must be forward-facing during transport.
3. In order to reduce the potential of unjury to vehicle occupants, wheelchair-mounted
accessories, such as trays and respiratory equipment, should be removed and secured
separately.
4. Postural supports and positioning devices should not be relied on for occupant
restraint.
5. Do not alter or substitute wheelchair frame parts, components or seating.
6. Sudden stops or impacts can structurally damage your chair. Chairs involved in such
incidents should be replaced.
J. MANUAL RECLINE OPERATION
The ASAP II seating system has two manual recline options. The first is using a 16mm socket
wrench and the second can be done by turning a knob on the side of the chair ( igure 13).
To recline the chair, rotate this knob clockwise and turn the knob counter-clockwise to
return the back to a more upright position.
VIII.
ENGLISH
17 119832 Rev. A

VIII.
18
. JOYSTIC ( ig. 14, 15, 16, 17)
Controls:
• LED monochrome joystick and color display joystick ( ig. 15)
Omni Input/Display (Fig. 16)
The Omni is a universal specialty controls interface that accepts signals from many different
types of SIDs (Specialty Input Device) and translates them into commands compatible with
the PG Drives Technology RNET control system.
Mating Connectors
To connect the communication cables: ( ig. 17)
Holding the connector housing, firmly push the connector into its mate until you can
no longer see the yellow plastic. The connectors are secured using a friction system.
To disconnect the communication cables:
Holding the connector housing firmly, pull the connectors apart.
NOTE– Do not hold or pull on the ca le. Always grip the connector when connecting and disconnecting.
When the control system is first switched on after a connection, or system component
change, the timer will be displayed while the system checks itself. Then the re-start icon will
be displayed. Switch the control system off and on again to operate,
L. JOYSTIC RETRACTABLE MOUNT (Optional) ( ig. 18)
The joystick is mounted with a mechanism which allows the control to be locked in a for-
ward or retracted position using magnets.
Adjustment
a. To retract the joystick, push outward on the inside of joystick.
b. Push the joystick away from front of armrest until it locks into retracted position.
c. To return to forward position, push the joystick forward until it locks into place.
M. ASAP II SEATING ADJUSTMENT
Please refer to the Service Manual for details on how to adjust the seat depth, seat width,
armrest height, and backrest angle.
power
module
LCD screen
Profile +/-
Navigation
Mode
On/Off
LED Color
joystick
communication
cable
Omni Display
Monochrome
Joysticks
14
15
16
17
ENGLISH
18
119832 Rev. A

VIII.
21
22
24
20
23
N. SEAT HEIGHT ADJUSTMENT
( igure 19)
1. Remove seat (See Section O. Seat Removal).
2. Remove the hardware from all four seat mount posts.
3. Select the desired seat height.
4. To allow for 3° pretilt, rear seat mount should never be more than
one position lower than the front.
5. Reinsert the hardware.
WARNING
Ensure both front seat posts are positioned to the same height. Rear seat posts
should also be set to the same height.
O. SEAT REMOVAL
Remove Seat
a. Disconnect the joystick power cable in the rear of the chair. ( ig. 20)
b. Remove the hardware that attaches the seat to the front seat posts. ( ig. 21)
c. Tilt the seat back to allow access to the battery compartment ( ig. 22).
WARNING
When replacing the seat into the mounts, ensure you do not pinch your fingers.
WARNING
Always replace the safety lock-out pin to prevent inadvertent release of the seat.
P. SHROUD REMOVAL ( igure 23 & 24)
The plastic protective shroud can be removed for adjustment or servicing.
1. Remove Top Shroud
a. Remove the seat (see Section O. Seat Removal).
b. Remove the six fasteners ( ig. 23).
c. Remove shroud by lifting up.
2. Remove Rear Shroud
a. Remove two rear shroud fasteners.
b. Pull downward at the top of the rear shroud ( ig. 24) then lift up.
3. Replace Shroud
Replace shroud by reversing above instructions.
Q. CHEC -OUT
Once the wheelchair is assembled and adjusted, it should roll smoothly and easily. All acces-
sories should also perform smoothly.
After the wheelchair has been set up be sure the chair performs to your specified operational
settings (see Operating Guide). If the chair does not perform to specifications, turn the
wheelchair O immediately and contact your authorized supplier to reprogram operational
specifications using the RNET Operating Guide.
Repeat this procedure until the wheelchair performs to specifications before
attempting active use of the wheelchair.
If you have any problems, follow these procedures:
1. Review the Set-up, Adjustment & Use section and Operating Guide to make sure chair
was properly prepared.
2. If your problem persists, contact your authorized supplier. If you still have a problem
after contacting your authorized supplier, contact Sunrise customer service. See the
introduction page for details on how to contact your authorized supplier or Sunrise
customer service.
19
ENGLISH
19 119832 Rev. A

IX. OPERATING GUIDE
IX. OPERATING GUIDE
A.PERFORMANCE CONTROL SETTINGS
NOTE– Seek advice regarding checking and adjusting settings.
1. It is vital to match control settings to your level of function and ability.
2. Consult your health care professional and your supplier to select the best control set-
tings for you.
3. Check and adjust the settings every six to twelve months.
WARNING
Adjust the control settings immediately if you notice any change in your ability
to:
• Control the joystick.
• Avoid running into objects.
4. Control Settings can be adjusted by your dealer.
B. THERMAL ROLL-BAC
Your chair has a thermal roll back circuit. This protects the controller from damage due to
overheating. In extreme conditions (such as repetitive hill climbing) the circuit will decrease the
power to your motors. This allows the chair to operate at a reduced speed. When the con-
troller cools, the chair will return to normal speed.
C. JOYSTIC STATIONARY
Your chair has an available programming feature called “Joystick Stationary” which can be set
by your dealer. This feature senses when the joystick is displaced from neutral, yet left in a
steady position for a predetermined period of time. The controller will automatically turn off
if the set time has been reached. This feature is designed to protect the user, batteries and
electronics if the joystick is inadvertently displaced. There are two parameters that can be
adjusted:
1. Joystick Stationary Time:
This is the time the joystick has to remain within the stationary range before the unit
will come to a stop. It can be programmed from 0 to 60 minutes in steps of one
minute. Select 0 to disable the function. Default setting is 0 (Disabled).
2. Joystick Stationary Range:
This determines the size of a region around the present joystick position. If the joystick
remains within this region for the stationary time the controller will stop. The range
can be programmed from 1 to 50, in steps of 1. Default setting is 1.
WARNING
Before turning on or adjusting these parameters, carefully read and understand
the implications for use of these features, Joystick Stationary Time and Joystick
Stationary Range. When the “Joystick Stationary Time” is reached within the
“Joystick Stationary Range”, the drive motors on the chair will shut off. As an
example, this will happen while driving in a straight line for extended periods of
time with no joystick movement. Once the drive motors turn off, the user will
need to turn the chair off and back on to drive.
ENGLISH
20
119832 Rev. A
