QUICKO T12 User manual

OLED T12 Soldering Iron
USER MANUAL

Technical Parameters
•Power requirements: DC 12V~ 24V
•Iron tips T12 compatible
•Interface: DC5.5x2.5 (internal positive and external negative)
Do not reverse the positive and negative connections
•Temperature: 180~ 450℃continuously adjustable (the
temperature difference is plus or minus 10 degrees)
•Tin: 5 seconds (24V)
Package included
•1pc T12 Adjust control handle
•1pc T12 normal iron tip as you choose option.
Features:
•Mini T12 Portable Soldering iron
•Large power: 72W (Maximum)
•Digital OLED screen can display: power voltage / real-time
temperature / setting temperature
•Temperature adjustable from 180 degrees to 450 degrees
(Celsius)
•Power supply voltage DC 12-24V, use DC5525 plug (5.5* 2.5)
•The Knob can adjust brightness, sleep time, language, screen
display time, etc.
Pow er Supply:
DC 12-24V, the higher the voltage, the higher current; the
maximum voltage is 24V, the minimum current is 3A, and the faster
the heating speed; on the contrary, conversely, the lower voltage,
the lower the current, the minimum is 1.5A, and the heating speed
is slightly slower.

1. Functions of press key and display description
•"Push to the right" means move to the right or increase the
value.
•"Push left" means move to the left or decrease the value.
•"Press down" means confirm or enter the main menu.
2. Menu description:
ATC
HSL
DMH
LED
LVF
LAN
RTN
•ACT: Calibration - Calculation formula: calibration value =
measuring temperature - setting temperature.
•HSL: Brightness - brightness adjustable range is 2-100, 2 is
darkest, 100 is the brightest.

•DMH: Sleep - when screen is "DMH ON 5", It means that if
the does not use the soldering iron for 5 seconds the soldering
iron will stop heating, and it will start heating again after
picking it up.
•LED: Alw ays on display - when screen is "LED ON 5", it
means that after 5 seconds of no key operation, the screen
will be off
•LVF: Power - this option indicates whether the power supply
is stable.
•LAN: Language - available languages: Chinese, English.
•RTN: Return - return to main interface.
Menu:
ATC
First turn on the power and insert the soldering iron tip into the
handle, set the temperature in the "SET: 300" and the value displayed
in the real-time area is stable at "300", at this time use a temperature
measuring instrument to measure the temperature of the soldering
iron tip.
(Note * You must use a soldering iron for each calibration Measure
the same position of the tip) and record the actual temperature of
the soldering iron tip, for example, 350 degrees! Then the value after
calibration is set to 50, such as "Calibration 50".
Calculation formula: Calibration value = Actual temperature - Set
temperature.
Note: Before calibration, the value after calibration must be set to 0,
such as "Calibration 0".
Menu:
HSL 2
You can adjust the appropriate brightness according to your needs.
"100" is the brightest and "2" is the darkest. I t is recommended to
adjust it to "2" to protect the screen.
Menu:
DMH 120
When the menu is in "Sleep On 120", it means that the worker does
not use the soldering iron (automatically detects whether it is in use

for soldering) and starts to stop heating after 120 seconds, and it will
automatically heat when picked up.
When the menu is in "Sleep Off", it means that it is turned off and
automatically detects whether there is a worker using it, and the
soldering iron will always be in a heating state.
Menu:
SCR 60
When the menu is in "Off Screen On 60", it means that the screen
will be turned off for 60 seconds after the button is not operated, and
the screen will automatically light up when the button is operated.
When the menu is "Off", the display will keep displaying.
Menu:
POW 1.0
This menu indicates whether the quality of the power supply is stable.
If the power supply is unstable, the value can be adjusted
appropriately. If the main menu shows insufficient power, it is
recommended to replace the power supply.
Menu:
LAN
When you select "Language" and enter CHS ENG select the
appropriate language for display according to your needs.
Menu:
RTN
When this menu is selected and the OK button is pressed, it will return
to the main interface of temperature display
Pow er selection:
DC power supply DC12~ 24V. The higher the voltage, the higher the
current is at 24V and the lowest 3A, and the faster the heating speed.
On the contrary, the lower the voltage, the lower the current is at
least 1.5A, and the heating speed is slightly slower. Power selection
as shown below.

Table of dependence of current and pow er on input voltage
I nput voltage, Volt
( V)
Minimum current,
Ampere ( A)
Maximum pow er, Watt
( W)
12
1.50
18
13
1.63
21
14
1.70
25
15
1.88
28
16
2.00
32
17
2.13
36
18
2.25
41
19
2.38
45
20
2.50
50
21
2.63
55
22
2.75
61
23
2.88
66
24 (recommended)
3.00
72
