Quoizel MBH8407PN Mounting instructions

Package Contents
1of2
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2015 QuoizelInc. January2015
BCrossbar Assembly
x1
STEP 1 Install Shade-
A.
A Remove the Styrofoam from
inside of the shade.
B. Place Glass Shade into the Cage, secure by place the Tab into the
Cage press on the Glass Shade.
C. Set the Cage with Glass Shade into the Cap on the Fixture Body,
secure by threading the Lock Screw into the Cap, tighten until sung.
Unscrew the Lock Screw, remove the Cage, the Glass Shade and
the Tab from the Fixture Body ( ).
Figure 3
Figure 1
Mounting
Ball
Mounting
Screw
Hex Nut and
Lock Washer
STEP 2 Install Inner Backplate-
A. Pass the supply wires through the Crossbar Assembly (AA). Attach
the Crossbar Assembly (AA) to the Outlet Box with the head of the
Green Ground Screw facing you. Secure it with Outlet Box Screws
(not included). Tighten until snug.
Supply Wires with
Ground Wire
B
Outlet Box Screws
(not included)
Outlet Box
Figure 2
STEP 3 Fit Fixture Body to
Crossbar Assembly
-
A. Remove mounting balls from the
Crossbar Assembly (B). Fit the
Fixture Body (A) Crossbar
Assembly (B) and secure with
mounting balls. Note: The
backplate of the Fixture Body (A)
should be snug against the wall
surface and the mounting balls. If
not, adjust the length of the nipple
on the Crossbar Assembly (B) by
unscrewing the preassembled hex
nut and lock washer and then
screwing the mounting screws in or
out of the crossbar until the correct
length is achieved. Once the
backplate of the Fixture Body (A) is
secure, remove the mounting ball
and Fixture Body (A) and proceed
to Step 4.
B
A
AFixture Body
x1
Fixture Body
Cage
Tab
Glass Shade
Lock Screw
Pleasegoto forproductcleaningtips.Gotothe selection.
Flatheadscrewdriver, Phillips screwdriver,pliers,wirecutters,wirestrippers,electricaltape,safetyglasses.
(1)MediumBase100WMaximum,Alternatebulb(1)23WCFL
30-45minutes
Identifyandinspectallpartsbeforebeginninginstallation.Checkpackagecontentlistanddiagramsbelowtobesureallpartsare
present.Ifanypartsaremissingordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomerserviceforreplacement
parts.
www.quoizel.com Care+Maintenance
ToolsRequired:
BulbRecommended:
EstimatedAssembly Time:
Preparation:
Fixturecanonlybemountedinthedirectionindicatedonpage2.
Warnings and Cautions
Assembly Instruction Sheet #IS-MBH8407
For Style and MBH8407KMBH8407PN
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing the fixture. We strongly
recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool before removal. Do not subject
glass parts to any shock while in operation or shattering may result.
STEP 4 - Wire Connections
A. Use standard wire connectors (not included) to make all wire
connections. (Connectors are not included with fixture.) Twist
connectors until wires are tightly joined together. Wrap each
connection with approved electrical tape and carefully stuff all the
connected wires into the Outlet Box.

2of2
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2015 QuoizelInc. January2015
MBH8407PN
MBH8407K
PART NUMBER
G3840SH
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION
GLASS CLEAR SEEDY
REQ.
1
NO.
1
FINISH: PALLADIAN BRONZE
MYSTIC BLACK
Figure 4
Figure 5
STEP 5 Install Fixture Body-
A. Carefully tuck all wires into the outlet
box and position the backplate of
fixture body (A) over the outlet box.
Align the holes in the backplate with
the mounting screws. Place caulk (not
supplied) into the previously removed
mounting balls and then attach fixture
body (A) using the mounting balls.
Hand tighten until snug.
Figure 6
STEP 6 -Install Bulb
A. This fixture uses standard bulb with medium
base . Maximum 100 watts.
B. Insert bulb and screw snugly into place.
Bulb
Figure 7
STEP 7 -Apply Silicone Sealer
A. Make sure exterior wall surface
and fixture backplate are free of
dirt before applying caulk. Using
exterior grade caulk, caulk over
top of backplate and down other
side. Do not caulk bottom of
fixture backplate to ensure proper
moisture drainage.
Your fixture is now assembled and
ready to use. Enjoy!
Backplate
Fixture can only be
mounted in the
direction indicated
(1) 100W
Bulbs
(Not Supplied)
Medium
Base
Mounting
Ball
Mounting
Screw
B
A
Socket
Exterior
Grade
Caulk
6.5”
8” 7” Dia.
11”
4.5”
1
White wire
from supply White wire
from fixture
Black wire from
supply (or Red)
Black wire
from fixture
Ground wire
from supply
Ground wire
from fixture
