Quoizel GLN2006IB Mounting instructions

Part Description Quantity
A Lock Ball 2 pcs.
1pc.
B
C
D
E
F
Package Contents
Quoizel, Inc.
6 Corporate Parkway
Goose Creek, SC
29445
Customer Service
Phone [phone]
Fax [phone]
www.quoizel.com
Warnings and Cautions
Turn off electricity at circuit breaker or main fuse box before installation. Consult a licensed electrician if in doubt.
These instructions are provided for your safety. It is very important you read them completely before installing
the fixture. We strongly recommend that a licensed, professional electrician perform the installation.
Disconnect fixture from power source before replacing bulbs. Make sure bulbs are given sufficient time to cool
before removal. Do not subject glass parts to any shock while in operation or shattering may result.
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
2013 QuoizelInc.
A
B
C
D
E
Assembly Instruction Sheet #IS-GLN2006IB
For Style GLN2006IB
1of6
March2013
ToolsRequired:Flatheadscrewdriver,Phillipsscrewdriver,pliers,wirecutters,wire
strippers,electricaltape,safetyglasses.
EstimatedAssemblyTime:20-30 minutes
Preparation:Identifyandinspectallpartsbeforebeginninginstallation.Checkpackage
contentlistanddiagramsbelowtobesureallpartsarepresent.Ifanypartsaremissing
ordamaged,donotattempttoassemble,install,oroperatethefixture.Contactcustomer
serviceforreplacementparts.
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
F
1pc.
Fixture Body
BulbRecommended: edgeBase Maximum(Supplied)(1)12V 18WT5W HalogenBulb,
G
H
1pc.
G
H
1pc.
1pc.
Tube with Connector
Ground Spike
Tube
1pc.
T5 Wedge Bulb
2 pcs.
Wire Connector
Silicone Caulk
SILICONE CAULK

GLN2006IB
1
2
PART NUMBER
NOTE: ALL DIMENSIONS ARE ROUNDED UP TO THE NEAREST 1/2"
REPLACEMENT PART DESCRIPTION REQ.
NO.
2of6
FINISH: IMPERIAL BRONZE
(1)18W 12V T5 Wedge
Base Bulb
(Supplied)
Halogen
SILICONE CAULK
3
12006IBGLN
G2627SH
I832SC
1
1
1
6.5” 5”
22.5”
6”
2.5”
9”
4.5”
3”
1
2
37.5”
BASE IMPERIAL BRONZE GLN2006IB
SHADE INDIA SCAVO GLASS 6.5"D
BULB 12V 18W ARGON T5 CLEAR

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
3of6
Assembly Instruction Sheet #IS-GLN2006IB
For Style GLN2006IB
Figure 1
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
2013 QuoizelInc.
STEP 1 -Assemble Ground Spike, Tube withe
Connecter, Tube and Cage together
A. To assemble fixture, thread Tube (D) into the Shade
Cage (C), hand tighten until snug.
B. Thread the Tube with Connecter (E) into the Tube (D),
hand tighten until snug.
C. Thread the bottom of Tube with Connecter (E) into
Ground Spike (F), hand tighten until snug.
Tube
Shade
Cage
Ground Spike
Tube with
Connecter
STEP 2 -Remove Fixture Hood from Shade Cage
A. Remove the Fixture Hood from the Shade Cage by
unscrewing the Lock Balls.
B. Remove the package papers inside of the Shade Cage.
Figure 2
Fixture
Hood
Lock Ball
Shade
Cage
March2013

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
4of6
Assembly Instruction Sheet #IS-GLN2006IB
For Style GLN2006IB
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
2013 QuoizelInc.
STEP 3 -Install Bulb
A. This fixture uses 12V G . Maximum 8
watts.
B. Insert bulb and push snugly into place.
T5 Wedge Bulb ( ) 1
Socket
Bulb
Figure 3
STEP 4 Install Fixture Hood to fixture-
A. Place Fixture Hood over the Shade Cage, secure by
thread the Lock Ball onto the Bolt on the bottom Fixture
Hood. Hand tighten until snug.
Figure 4
Bolt
Fixture
Hood
Lock Ball
Shade
Cage
March2013

Transformer
Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
5of6
Assembly Instruction Sheet #IS-GLN2006IB
For Style GLN2006IB
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
2013 QuoizelInc.
STEP 5 Make Wire Connections-
A. Use standard wire connectors to make all wire connections.
(Connectors are not included with fixture.) Strip and prepare
wire ends according to instructions supplied with connectors.
B. Connect White Supply Wire from the 12V transformer (not
supplied) to ribbed side wire from fixture.
C. Connect Black (or Red) Supply Wire from the 12V transformer
(not supplied) to smooth side wire from fixture.
D. Twist connectors until wires are tightly joined together.
E. Wrap each connection with approved electrical tape and
carefully stuff all the connected wires into the Tube.
Figure 6
White wire from
12V transformer
R
from fixture
ibbed side
wire
Black wire from
(or Red)
12V transformer
Smooth side
wire from fixture
Figure 5
STEP 6 Apply Silicone Sealer to tube-
A.
Your fixture is now assembled and ready to use.
Enjoy!
Using Silicone Caulk (I) provided, inside each
connector (H).
B. Place Ground Spike (F) in predetermined location.
Figure 7
Silicone Caulk
Transformer
SILICONE CAULK
Ground
March2013

Thank you for purchasing a Quoizel product.
Need assistance with parts or assembly? Call Quoizel customer service at 1-631-273-2700
or visit us on-line at www.quoizel.com
6of6
Assembly Instruction Sheet #IS-GLN2006IB
For Style GLN2006IB
6 CORPORATE PARKWAY
GOOSE CREEK SC 29445
www quoizel com
,.
..
2013 QuoizelInc.
CAUTION FOR BULB REPLACING
A. When replace bulb, turn off power and allow lamp to cool. For safety purpose, wear gloves and eye protection.
B. If bulb is scratched or cracked, DO NOT use the lamp to avoid breakage during use or installation.
C. Use only in fixtures rated for lamps wattage and voltage.
D. Lamp operate under high pressure generating intense heat. Prevent contact with liquid and combustible
materials.
March2013
