R for Rabbit Chocolate Ride User manual

canopy
cup
Folding plastic
rear wheel
front wheel
brake
harness
foot pad
direction part
basket
tray
Removalbe front tray
Can stand up when folded brake
Front wheel shock suspenaion and can be directional
The multifunctional baby stroller instruction
WARNING: Please follow all of these instructions to ensure the
Reversible handle
R for Rabbit
Stroller-Chocolate Ride
safety of your child. Keep these instructions for future reference.
WARNING: Failure to follow these instructions could result in
serious injury or death. Avoid serious injury from falling or sliding
out.Always use the safety harness and insure that the child is
properly positioned according to these instructions.
W ARNING: Never leave child unattended.
D escription of Parts.
Three adjustable back rest
Big bottom basket,brake
Link brake
Five points safty harness
Specious body work

and front wheel brake system
c anopy downwards from both side to open and on
c ontrary to close canopy .
into the
handle firmly.
brake
①
3
②
2.Canopy installation
3.Dining plate installation
1.Open the stroller
①see the picture aboved and press plastic parts of
①See the picture aboved and insert the interface part
hole firmly on both the sides to fit dining plate.
②Press the bottom switch to put out the dining
plate.
4.Rear wheel installation
①As shown in picture above,put the front wheel shaft in the part
coming out from footrest. The clip pin will be locked.
②Press the clip pin to remove the front wheel apart.
5.Front wheel installation
6.Beverrage cup installation
Dining interface
Rear wheel tube
Rear wheel basics
Brake
Front wheel shaft
Front wheel joint
Footrest
①As shown in picture above,put the front wheel
shaft in the part coming out from footrest.The
clip pin will be locked. .
②Press the clip pin in to remove the front wheel
apart .
①As show in picture above,set the cup on
②Put the brakes on the front wheel to stop stroller
when used with reversible handle .
②See the picture above and make sure that the hands
locked in the plastic part firmly.
-pike
③Press button.
was
①See the picture above and as shown in arrow 1 Take off
from the stroller first, then replicate with another lock as arrow 2.

unlocking .
Adjust length of safety belt accordance to baby’s need. Place the
legs and buckle up the belts. To
out the straps from the buckle.
crotch belt between baby’s
release the safety belt, press both ends of the buttons and pull
There are five point seat belts could protect your baby’s safety.
Before use the seat belt, make sure that all of the buckle are
fixed as shown in the figure.
Warning: Always use the crotch strap in combination with the waist belts.
Rear wheel
①As shown in picture above use
the brake for locking and
（1）
（2）
7.Front wheel directional
①As shown in picture above,put the directional part
upwards and then clip it in the shaft directional
canal so the front wheel can be directional
instead of unlocked. .
8.Brake Set
10.Safty belt instruction
11.Backrest adjusttable
①As shown in picture pull the steel support to adjust
backrest in upward or downwards position.the
It can be adjusted in 3 position.
12.Close the stroller
9.Foot rest
Press the two buttons on the side
simultaneously of the foot rest to
move it up or down.
Shaft directional canal
Directional parts
locked
unlocked
①
③
②
As shown in picture open the covers on the side of canopy
and pull the hook inside and push forward the handle to
close the stroller. Fix the lock hook as shown in picture
and stroller will be standing position while folded.

Please strictly observe below points to avoid any accident
1.Avoid serious injury from falling or sliding out by always using safety
harness which is provided.
2.Never leave your Child Unattended.
3.Never carry stroller along with child in stroller.
4.Please avoid usage of stroller on escalators, sand beach,uneven
roads and mud.
5.Don't let child to stand on the stroller.
6. Never allow more than one child at a time in the stroller
7.Maximum weight load 15KGS.
8.Never hang anything on canopy or handle as this may
cause the stroller to become unstable.
9.Do not overload the basket. Maximum load weight is below 3KGS.
10.Ensure locking parts are locked before using stroller.
11.To prevent the stroller moving put the brakes.
12.In order to avoid baby getting injured, when the handle reversible,
don't let the child's arm to put within the scope of handle's activities.
Check carefully the handle has been fixed after it has changed forward position.
13.Regularly check all screws, bolts and nuts.
14.Do not let your stroller near by fire.
15.This is stroller is designed for a child 6 to 36 months.
POINTS TO BE TAKE CARE:
16. Executive Standard: EN1888-2003(E).
MAINTENANCE:
To avoid risk of injury to your baby, please check and
maintain the stroller periodically.
Please use soft brush to brush the stain, please use the household
soap or mild wash to wash it when it be dirty.
Regularly inspect the locking devices, breaks, wheels, harness
assembly, catches, seat adjusters, joints and fixings to ensure
they are secure and in full working order. If there is something
wrong, please change it.
Please assemble and detach it according to the instruction.
