R3D MINI User manual
Please read the Quick Operation Guide carefully
before using the product and keep it in a safe place
Run to a better 3D world
After unpacking the product, please make sure that the 3D printer is intact and confirm
whether the accessories are complete according to below list.
Soft and magnetic
bedx1
Door panelDoor buckle
Wrench
Door buckle*8
Fix the door panel on the left and right sides of the machine with door buckle.
Place the smallest piece on top of the machine.
Factory-Fanchang Economic Development Zone, Wuhu City,
AnhuiProvince, China
Tel:+86574-88037579 E-mail:[email protected]
WuhuR3D Technology Co., Ltd.
ModelNumber
BuildSize
MachineSize
ManfactureDate
150*150*220mm
325*303*428mm
2020-08
RatedPower
MaterialSupported
NetWeight
MINI InputVoltage 100V-120V
PLA1.75mm
150W
11kg
Plug the power cord into the power connector on the back of
the machine and then into the socket. Press the power switch
and the light button on the front of the machine. The startup
interface is displayed normally, indicating that the 3D printer
has started normally. Power switch
This operation is required when the nozzle is preheated to 210 °
C. In the tools submenu, click the Preheat icon enter the submenu
for loading and unloading filament. Click the down arrow marked
with E1 to perform pre-extrusion of the filament. If it is observed
that filaments are normally extruded from the nozzle, the extruder
test steps are completed. Click the back icon to go to the home
page.
Filament holder
Put the filament on the filament holder, pull the filament out, and
insert them from the feed port.
Note: unless the filament run out of or need to print another color,
there is no need to repeat the above three steps for each
subsequent printing, just start the machine and choose the file to
print.
Click the Tool menu on the home page. In the preheating menu,
click the up arrow or “Preheat” icon to preheat the nozzle. The
specified temperature can be adjusted by clicking the up arrow or
down arrow for many times. In addition, click the “Close” icon to
stop preheating.
Click the manual icon to enter the manual submenu, select 1mm or
10mm, and then click the arrow corresponding to XYZ to perform
the axis movement test. Click the Home icon to return home. In
addition, this function can also be used to make it easier to remove
the model by lowering the Z-axis platform when the model is
inconvenient.
Place the sprayed side of the glass platform face up on the printing
platform, and then fasten the buckle. Click the leveling button,
place a piece of A4 paper between the platform and the print head,
adjust the screws below the platform (about 45 ° each time), when
the A4 paper can be pulled out and there is some resistance. When
adjusting the middle point, you need to turn 4 screws at the same
time for adjustment.
Click the language function in the set menu, in the language
function, you can select the language you need.
Click the print menu on the first page to enter the print file selection
interface. After selecting the file, the printer will automatically heat
up and print.
Click on the red marker.
Select the file in STL format
and click open.
Click on the model and the
red box icon appears.
Click the rotate button, click and drag
the arc around the model, and rotate
it to the position you want.
Click the Layers icon to display the slicing
effect of the model. You can observe from
the long box that the model is piled up by
290 Layers. By dragging a small white
square, you can observe the slicing effect
of each layer. Click the Normal icon to
return to the Normal effect.
Find the USB Serial Port in “Devices
and Printers” , And check its port in
the properties interface.
After adjusting all the parameters,
please click “Print with USB” and
then start the “Print” .
Factory- Fanchang Economic Development Zone,
Wuhu City, Anhui Province
Tel: +86 574-88037579
E-mail: sales@r3dtechnology.com
Thanks for your order!
Thanks for your support!
Thanks for the chance to get your advice!
R3D 3D is a 3D printer R&D and manufacturing company in China. Since the first 3D printers was launched
in July 2012, through cooperating with scientific research teams in excellent universities of science and
technology at home and abroad, the company focuses on product development and international advanced
3D printing technology, currently has 3 invention patents, more than 20 utility model patents, more than 20
appearance patents, 6 new and high technology products.
Happy Printing! Thank you!
Best Redards,
R3D 3D Printer After Sales Service Team
