Racing RACPV18V4IN1 User manual

ORIGINAL INSTRUCTIONS >EN
INSTRUCTION MANUAL
CORDLESS TOOL 18V 4 IN 1
RACPV18V4IN1
BUILDER SAS
32, rue Aristide Bergès -ZI 31270 Cugnaux –France
IMPORTANT: Please read the instruction manual before using.

ORIGINAL INSTRUCTIONS >EN
1. APPLICATION
The cordless tool of 18 V 4 in 1 is intended for
1) Screwing screws in and out and for drilling holes in wood, metal or plastic.
2) Sawing wood, metal and plastics
3) Dry sanding of wood, plastic, putty and painting surfaces or varnished. This product is not suitable
for sanding plaster-based substrates.
The tool is not suitable for commercial use. Any other use that is not explicitly approved in these instructions
may result in damage to the equipment and represent a serious danger to the user.
The tool is designed for use by adults. Adolescents over the age of 16 may use the device only under
supervision. The manufacturer is not liable for damages caused by unspecified use or incorrect operation.
WARNING! For your own safety, read this manual and the general safety instructions carefully
before using the appliance. Your power tool should only be given to other users together with
these instructions.
2. SAFETY WARNINGS
GENERAL POWER TOOL SAFETY WARNINGS
WARNING Read all safety warnings, instructions, illustrations and specifications provided with
this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious
injury.
Save all warnings and instructions for future reference.
The term "power tool" in the warnings refers to your mains-operated (corded) power tool or battery-operated
(cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit.Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause you to lose
control.
2) Electrical safety

ORIGINAL INSTRUCTIONS >EN
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter
plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of
electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric shock if your body is earthed or grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will increase the risk
of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool. Keep
cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords increase the risk of
electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use of a
cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device (RCD)
protected supply. Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not
use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment
of inattention while operating power tools may result in serious personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment such as a
dust mask, non-skid safety shoes, hard hat or hearing protection used for appropriate conditions will reduce
personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power
source and/or battery pack, picking up or carrying the tool. Carrying power tools with your finger on the
switch or energising power tools that have the switch on invites accidents.
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left
attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the
power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair and clothing away from
moving parts. Loose clothes, jewellery or long hair can be caught in moving parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure these
are connected and properly used. Use of dust collection can reduce dust-related hazards.
h) Do not let familiarity gained from frequent use of tools allow you to become complacent and
ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.

ORIGINAL INSTRUCTIONS >EN
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct power tool
will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot be
controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or remove the battery pack, if detachable, from
the power tool before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the
power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e) Maintain power tools and accessories. Check for misalignment or binding of moving parts,
breakage of parts and any other condition that may affect the power tool’s operation. If damaged,
have the power tool repaired before use. Many accidents are caused by poorly maintained power tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting edges are less
likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions, taking
into account the working conditions and the work to be performed. Use of the power tool for operations
different from those intended could result in a hazardous situation.
h) Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery handles and
grasping surfaces do not allow for safe handling and control of the tool in unexpected situations.
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer.A charger that is suitable for one type
of battery pack may create a risk of fire when used with another battery pack.
b) Use power tools only with specifically designated battery packs. Use of any other battery packs may
create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects, that can make a connection from one terminal to
another.Shorting the battery terminals together may cause burns or a fire.
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical help.Liquid
ejected from the battery may cause irritation or burns.
e) Do not use a battery pack or tool that is damaged or modified.Damaged or modified batteries may
exhibit unpredictable behaviour resulting in fire, explosion or risk of injury.

ORIGINAL INSTRUCTIONS >EN
f) Do not expose a battery pack or tool to fire or excessive temperature.Exposure to fire or temperature
above 130 °C may cause explosion.
g) Follow all charging instructions and do not charge the battery pack or tool outside the
temperature range specified in the instructions. Charging improperly or at temperatures outside the
specified range may damage the battery and increase the risk of fire.
6) Service
a) Have your power tool serviced by a qualified repair person using only identical replacement parts.
This will ensure that the safety of the power tool is maintained.
b) Never service damaged battery packs. Service of battery packs should only be performed by the
manufacturer or authorized service providers.
SAFETY INSTRUCTIONS FOR BATTERIES AND CHARGER
Batteries
Never attempt to open for any reason.
Do not store in locations where the temperature may exceed 40°C (104°F).
Charge only at ambient temperatures between 4°C and 40°C (39.2°F and 104°F).
Charge only using the charger provided with the tool.
Store your batteries in a cool dry place (5°C-20°C/41°F-68°F). Never store batteries in discharged
state.
It is better for Li-ion batteries to discharge and reload them regularly (at least 4 times a year). The
ideal charge for long-term storage of your Li-ion battery is 40% of capacity.
When disposing of batteries, follow the instructions given in the section “Protecting the
environment”.
Do not cause short circuits. If connection is made between the positive (+) and negative (-) terminal
directly or via accidental contact with metallic objects, the battery is short circuited and an intense
current will flow causing heat generation which may lead to casing rupture or fire.
Do not heat. If batteries are heated to above 100°C (212°F), sealing and insulating separators and
other polymer components may be damaged resulting in electrolyte leakage and/or internal short
circuiting leading to heat generation causing rupture or file. Moreover do not dispose of the
batteries in fire, explosion and/or intense burning may result.
Under extreme conditions, battery leakage may occur. When you notice liquid on the battery,
proceed as follows:
Carefully wipe the liquid off using a cloth. Avoid skin contact.
In case of skin or eye contact, follow the instructions below:
• Immediately rinse with water. Neutralize with a mild acid such as lemon juice or
vinegar.
• In case of eye contact, rinse abundantly with clean water for at least 10 minutes.
Consult a physician.

ORIGINAL INSTRUCTIONS >EN
Fire hazard! Avoid short-circuiting the contacts of a detached battery. Do not incinerate
the battery.
Charger
Use the charger provided with the tool only to charge
the battery.
Never attempt to charge non-rechargeable batteries.
Have defective cords replaced immediately.
Do not expose to water.
Do not open the charger.
Do not probe the charger.
The charger is intended for indoor use only.
This charger can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance. Cleaning
and user maintenance shall not be made by children
without supervision.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly
qualified persons in order to avoid a hazard.

ORIGINAL INSTRUCTIONS >EN
CAUTION: Do not recharge non-rechargeable batteries.
ADDITIONAL SAFETY INSTRUCTIONS
Warning! Sawing or sanding can result in the formation of hazardous dusts (e.g. arising from
materials with paints containing lead, materials containing asbestos, metals or some wood types) which can
present a hazard to the operator or persons in the vicinity. Make sure that the workplace is well ventilated.
Always wear safety goggles, safety gloves and respiratory protection. Attach a dust extraction system.
Safety instructions for reciprocating saws
Hold the power tool by insulated gripping surfaces, when performing an operation where the cutting
accessory may contact hidden wiring. Cutting accessory contacting a "live" wire may make exposed
metal parts of the power tool "live" and could give the operator an electric shock.
Use clamps or another practical way to secure and support the workpiece to a stable platform.
Holding the workpiece by hand or against your body leaves it unstable and may lead to loss of control.
SPECIAL SAFETY INFORMATION FOR THE CORDLESS COMBINATION TOOL
Hold the electric tool by the insulated handle surfaces when performing work where the cutting
tool or screw may come into contact with hidden wiring. Contact with a live wire can also cause a
charge in metal parts of the appliance and result in an electric shock.
Use suitable detectors in order to find hidden supply lines or ask the local utility company.
Contact with electrical cables can lead to electric shock and fire, contact with a gas pipe can result in an
explosion. Damage to a water pipe can lead to property damaged and electric shock.
Secure the workpiece. A workpiece that is retained with clamping appliances or a vice is held more
securely than with your hand.
Be very careful when handling tools such as saws, scraper blades and drills. These are sharp and
present an injury hazard.
Wear safety gloves when changing attachments. This enables you to avoid injuries if the appliance
attachment has heated up after use.
SPECIFIC SAFETY INSTRUCTIONS WHEN SAWING
Keep hands away from the sawing area. Do not reach underneath the workpiece.Always stand to
the side of the saw when working. Upon contact with the blade there is a risk of injury.

ORIGINAL INSTRUCTIONS >EN
Only when the electric tool is turned on should the sawing blade be moved against the
workpiece. There is a risk of kickback if the tool insert jams in the workpiece.
Make sure that the footplate is securely placed against the workpiece during sawing. The
sawblade can tilt and lead to loss of control over the power tool.
After you have finished work, turn the power tool off and do not pull the sawblade out of the cut
until it has come to a standstill. In this way you will avoid any kickback and can safely put down the
power tool.
Use only undamaged sawblades in perfect condition. Bent or blunt blades can break, adversely
affect the cut or cause kickback.
Do not brake the sawblade after applying side pressure. The sawblade may be damaged, break or
cause switching the appliance off by a kickback.
Tighten the material firmly. Do not support the workpiece by hand or foot. Do not touch any
objects or the ground with the saw running.
There is a risk of kickback. Hold the power tool tightly with both hands while working and ensure
a secure footing. The power tool is guided more securely with both hands.
Wait until the power tool has stopped before placing it down. The tool insert can tilt and lead to loss
of control over the power tool.
Switch the appliance off immediately if the sawing blade jams. Spread the saw cut out and pull the
blade out carefully. This can lead to loss of control over the power tool.
SPECIAL SAFETY INFORMATION DURING SANDING AND SCRAPING
Only use the power tool for dry sanding. Do not scrape moist materials. Penetration of water into
the power tool increases the risk of electric shock.
Avoid overheating the sanded object and the sander itself. Possible fire hazard.
The workpiece gets hot during grinding. Do not touch the machined area, allow it to cool down.
There is a risk of burning. Do not use coolants or the like.
Always empty the dust container before work breaks. Sanding dust in the dust sack, micro filter,
paper sack (or in the filter sack or extraction system filter) can self-ignite under unfavourable conditions
such as lying sparks caused by grinding metals. Particular hazards are caused if the sanding dust is
mixed with paint, polyurethane residues or other chemical substances, or if the sanded object is hot
after long working periods.
RESIDUAL RISKS
Even if properly operating and handling this electric tool, some residual risks will remain. Due to its

ORIGINAL INSTRUCTIONS >EN
construction and build, this electric tool may present the following hazards:
a) Lung damage, if suitable respiratory protection is not worn;
b) Cuts
c) Ear damage if working without ear protection.
d) Eye damage if suitable eye protection is not worn.
e) Damage to your health caused by swinging your hands and arms when operating the appliance for longer
periods of time or if the unit is not held or maintained properly.
Symbols
Conforms to relevant safety standards
To reduce the risk of injury, the user must read and understand this manual
before using this product.
Wear eye protection.
Wear mask protection in dust condition.
Wear ear protectors. Exposure to noise can cause hearing loss.
Do not dispose of old appliances with domestic rubbish
Class II, double isolation(only for charger)
Ne pas exposer le chargeur ni la batterie à l’eau.
Do not incinerate the battery or charger.
Ambient temperature of 40 °C max. (only for the battery)
Use the battery and charger Indoor use only.
Recycling

ORIGINAL INSTRUCTIONS >EN
3. YOUR PRODUCT
1 Keyless chuck
2 Torque adjustment ring
3 Gear selection switch
4 Drill attachment
5 Unlocking lever for appliance
attachment
6 Motor unit
7 Direction switch
8 Handle
9 Rechargeable battery
10 Unlock button for battery
11 On/off switch
12 Jig saw attachment
13 Footplate
14 sawblade
15 Lever for unlocking sawblade
16 Multi-sander attachment
17 Stainless scraper
18 Sanding plate
19 Multi-sander attachment

ORIGINAL INSTRUCTIONS >EN
4. PACKAGE CONTENT LIST
Remove all packaging materials.
Remove remaining packaging and packing inserts (if included).
Check that the package contents are complete.
Check the appliance, the power cord, the power plug of charger and all accessories for transportation
damage or not.
Keep the packaging materials as far as possible until the end of the warranty period. Then take it to your
local waste disposal system.
WARNING! Packaging materials are not toys! Children must not play with plastic bags! There is
a danger of suffocation!
Accessories:
Drill bits (1,5/2/3/4/5/6 mm)
3 screwing bits (50mm)
Bit holder
Abrasives for mouse sander ( 2*60gr / 2*120gr & 1*240)
Accessories for jig saw : 1pcs 10mm wood Blade
Accessories for multi tool: 1pc stainless scraper;
1pc stainless blade;1pc sanding pad; 1pc wrench;
2pcs sanding paper for wood and metal
With 1 battery 2Ah + 1.5A fast charger
Note: If any parts are missing or damaged, please contact your dealer.
5. TECHNICAL DATA
Rated voltage (direct current)
18V d.c.
No load speed of motor
21000/min
Drill function
No load speed:0-450/0-1450min-1
20+1 settings, 30 N.m torque, 13mm double- sleeve
Cutting depth: Wood: 25mm, metal:10mm
Sound pressure level (LpA) ........ 83.7 dB(A),K=3 dB(A)
Sound power level (LWA) ........... 94.7 dB(A),K=3 dB(A)
Vibration (ah)
drilling in metal .....1.322 m/s2, K=1.5 m/s2
drilling in wood ....1.531 m/s2, K=1.5 m/s2

ORIGINAL INSTRUCTIONS >EN
Jig saw function
No load speed: 0-2500/min,
Stroke:18mm, Cutting depth :15cm in metal, 60mm in wood
Sound pressure level (LpA) ......... 76.4 dB(A) K= 3 dB(A)
Sound power level (LWA) ..............87.4 dB(A) K=3 dB(A)
Vibration: “Cutting board” mode: ah, B=6.7m/s2, K=1.5m/s2;
“Cutting sheet metal” mode: ah, M= 6.4m/s2, K=1.5 m/s2.
Sander function
No load speed:0-9000/min. Sanding pad 138X97mm
Sound pressure level (LpA) ......... 88.6 dB(A) K=3 dB(A)
Sound power level (LWA) ..............99.6 dB(A), K=3 dB(A)
Vibration (ah) .................................4.572 m/s2, K=1.5 m/s2
Multi-tool function
Oscillation:0-20000/min. angle 3 degree
Sound pressure level (LpA) ........ 84.8 dB(A),K=3 dB(A)
Sound power level (LWA) ........... 95.8 dB(A),K=3 dB(A)
Vibration (ah) .............................. 4.229m/s2, K=1.5 m/s2
Battery type
20V d.c. 2Ah Lithium-ion
Charger type
Input 110-240V~ 50-60Hz,0.8A
Output 21.6V d.c., 1500mA
Charging time
1.5 hours
Information
The declared vibration total value has been measured in accordance with a standard test method
and may be used for comparing one tool with another;
The declared vibration total value may also be used in a preliminary assessment of exposure.
Warning
that the vibration emission during actual use of the power tool can differ from the declared total
value depending on the ways in which the tool is used; and
of the need to identify safety measures to protect the operator that are based on an estimation of
exposure in the actual conditions of use (taking account of all parts of the operating cycle such as
the times when the tool is switched off and when it is running idle in addition to the trigger time).
Wear hearing protection.

ORIGINAL INSTRUCTIONS >EN
6. OPERATION
5.1 Charging the battery pack
IMPORTANT: The battery pack is not fully charged at the factory. Before attempting to charge them,
thoroughly read all of the safety instructions.
1) To assure that the charger you use are applicable to the battery pack.
2) Insert the charger into 110-240V~, 50/60Hz outlet. The indicator light (3) become to green light to show
the power is connected.
3) Insert the end of charger (1) into the slot of battery (2). Make sure the contact with the charger is
correct.
4) When charging the indicator light (3) become to red light.
5) When fully charged the indicator light (3) become to green light.
6).Frequently monitor the charger and battery pack while connected.
7).Unplug the charger and disconnect it from the battery pack when finished.
8).Allow the battery pack to cool completely before using it.
9).Store the charger and battery pack indoors, out of reach of children.
Note: If the battery does not fit properly, disconnect it and confirm that the battery pack is the
correct model for this charger as shown on the specification chart. Do not charge any other
battery pack or any battery pack that does not securely fit the charger.
NOTE: If battery is hot after continuous use in the tool, allow it to cool down to room
temperature before charging. This will extend the life of your batteries.
NOTE: Remove battery pack from charger stand which use your thumb or fingers, press the
battery’s release button in and pull the battery pack off at the same time.
Battery capacity indicator
There are battery capacity indicators on the battery pack; you can check the capacity status of the battery if

ORIGINAL INSTRUCTIONS >EN
you squeeze the button. Before using the machine, please press switch trigger to check if the battery is full
enough for properly working.
Those 3 LED might show the status of the capacity level of the battery: Inserting and removing the
battery.
WARNING: Before making any adjustments ensure the drill is switched off with the direction
of rotation selector in the center position
1. Remove the battery: press the battery release latch in and at the same time pull the battery pack off.
2. To insert the battery, push the battery pack onto the contacts of the tool.
5.2Replacing the appliance attachment
WARNING!
Secure the appliance against switching on (see “Switching on/off”) or remove the rechargeable battery from
the appliance. There is an injury hazard if the device is switched on accidentally.
Removing appliance attachment
1). Push the unlocking lever (5) into position as far as the stop and then hold it in this position.
2). Pull the unlocked appliance attachment off.
3. Allow the unlocking lever (5) to slide back into position.
Fitting appliance attachment
4). Push the appliance attachment along the guide rail into the motor unit (6). It locks into place audibly.
5). Allow the unlocking lever (5) to slide back into position.
6). Check that the appliance attachment is secure by pulling on it.
5.3 Switching on/off
1). Switching on: Press the on/off switch (11).By using the on/off switch (11) you can progressively control
the speed. Gentle pressure: low speed Increase pressure: higher speed.
2). Switching off: Release the on/off switch (11). If you place the direction switch (7) in the middle position,
the device is secured against being switched on.
5.4 Motor unit with drill attachment
Changing the tool
1). Rotate the keyless chuck (1) counterclockwise, until the drill chuck aperture is large enough to
accommodate the tool.
2). Insert the tool as far as possible into the keyless chuck (1).
3. Rotate the keyless chuck (1) clockwise in order to clamp the tool.
4. To remove the tool again, rotate the keyless chuck (1) and pull out the tool.
Choice of gear
WARNING! Stop appliance before changing gear to avoid the tool damage.
1). Wait for the appliance to come to a standstill.

ORIGINAL INSTRUCTIONS >EN
2) Slide the gear selector (3) into the required position:
L=> low speed
H=>high speed
Set the direction of rotation
The appliance’s direction of rotation can be changed with the rotational direction switch.
1). Wait for the appliance to come to a standstill.
2). Push the rotational direction speed (7) into the desired position:
Clockwise rotation: to drill and screw in screws.
Anticlockwise rotation: to unscrew screws.
3) If you place the direction switch (7) in the middle position, the device is secured against being switched
on.
Torque adjustment
You can preselect the maximum torque.
The torque settings are labeled 1 - 19 +
1). Wait for the appliance to come to a standstill.
2). Turn the torque adjusting ring (2) to select the desired torque:
Screws: Steps 1 - 19; Drilling: Step
3). Start with a lower torque step and increase as required.
Note: The necessary torque is dependent on:
- The type and hardness of the material to be treated;
- The type and length of the screws used.
5.5 Motor unit with sander attachment
WARNING! Secure the appliance against switching on (see “Switching on/off”). If the appliance is
switched on accidentally, there is a danger of injury!
Attaching/removing sanding sheet
The sanding plate is fitted with Velcro for rapid attachment of the sanding sheet.

ORIGINAL INSTRUCTIONS >EN
Attaching sanding sheet
1). Press the sanding sheet evenly onto the sanding plate. Ensure that the holes in the sanding sheet are
placed above the openings in the sanding plate.
Removing sanding sheet
2). Simply pull the sanding sheet off the sanding plate.
Connecting dust extraction
You can reduce dust production during sanding by attaching a dust extraction system.
1. Push the adaptor into the opening on the sander attachment as far as the stop.
2. Connect a dust extractor suction hose to the adaptor.
Note: If necessary, you can connect the suction hose of a vacuum cleaner without reducer to the adapter
Motor unit with jig saw attachment
Installing/changing the blade
WARNING! Secure the appliance against switching on (see “Switching on/off”). If the appliance is
switched on accidentally, there is a danger of injury!
Caution, risk of Injury!
- Do not use any blunt or bent blades or blades which are damaged in any other way.
- Always insert a suitable sawblade.
Installing the blade:
1). Push the lever (15) for sawblade unlocking upwards as far as the stop. Push the sawblade shaft into the
sawblade mounting slot.
2). To unlock, release the lever, it will return to the initial position.
3). Check that the sawblade is secure by pulling on it. Removing the sawblade:
4). Press the lever (15) for sawblade unlocking upwards as far as the stop and then pull the sawblade out of
the sawblade mounting.
Operating the jig saw
1) Before switching the appliance on, ensure it is not in contact with the workpiece.
2). Turn the appliance on. By using the on/off switch (11) you can progressively the stroke rate.
Gentle pressure: low stroke rate.

ORIGINAL INSTRUCTIONS >EN
Greater pressure: higher stroke rate.
The on/off switch cannot be locked.
3). Place the footplate (13) on the workpiece.
4). Cut with a uniform forward motion.
5) After completion of the work, first remove the blade from the saw cut and then switch the appliance off.
5.6 Motor unit with multifunction tool
Changing the tool
WARNING! Secure the appliance against switching on (see “Switching on/off”). If the appliance is
switched on accidentally, there is a danger of injury!
1). Push the lever for tool unlocking upwards as far as the stop.
2). Pull the unlocked tool holder off forwards.
3). Place the required tool on the arbor. 12 different positions are possible.
4). Press the tool holder back into the central mounting.
5). Push the lever (27) for tool unlocking forwards again. The tool holder is fixed to the tool.
Attaching/removing sanding sheet
The delta sanding plate is fitted with Velcro for rapid attachment of the sanding sheet.
Attaching sanding sheet
1). Press the sanding sheet evenly onto the delta sanding plate. Ensure that the holes in the sanding sheet
are placed above the openings in the sanding plate.
Removing sanding sheet
2) . Simply pull the sanding sheet off the delta sanding plate.
Practical tips
When working with the appliance, always wear suitable clothing and appropriate protective equipment.
Prior to each use it must be ensured that the appliance is working correctly.
Personal protective equipment and a fully functional appliance reduce the risk of injuries and accidents.

ORIGINAL INSTRUCTIONS >EN
Sawing
• Use only undamaged sawblades in perfect condition. Only use metal sawblades for metalworking.
• Ensure your stance is stable and hold the appliance tightly with both hands and away from your body.
• Before sawing the workpiece, check for hidden foreign objects such as nails, screws. These must be
removed.
• Plunge cuts may only be made in soft material such as wood or plasterboard.
Selection of sawblade
Wood sawblade for wood, plastic, plasterboard
Metal sawblade for metal sheets, profiles and tubes
Sanding
• Use a dust extraction system when sanding with the multi-sander attachment.
•Move the appliance against the workpiece once it is switched on.
•Clean the sanding plate before you attach a sanding sheet.
•Only work with sanding sheets in perfect condition to achieve good sanding results.
•Work using low and even pressure. This protects the appliance and the sanding sheet.
•Do not use the same sanding sheet to sand different materials (e.g. metal and then wood).
Selection of sanding sheet
Grain size P application
P 60 for pre-sanding rough wood surfaces
P 80 / 120 for plain sanding
P 240 for fine sanding of primed and painted surfaces
Scraping
•Use a high oscillation rate when scraping.
•Work using low pressure and at a low angle in order not to damage the substrate material.

ORIGINAL INSTRUCTIONS >EN
7. Cleaning/Maintenance
Note: Repair and servicing work not described in this manual should always be carried by our Service
Centre. Use only original parts. Switch off the device and remove the battery from the device before working
with or transporting it.
Note: The following cleaning and servicing should be done regularly. This will ensure a long and reliable
service life.
Cleaning:
Do not spray the appliance with water and do not immerse it in water. Electric shock hazard!
Keep clean the ventilation slots, motor housing and handles of the appliance. Use a damp cloth or a brush.
Do not use cleaning agents or solvents. You may otherwise irreparably damage the appliance.
Maintenance
•The equipment is maintenance free.
8. Storage
•Store the device in a dry place well out of reach of children.
•Remove the battery before storing the unit for longer periods of time (e.g. hibernation).
•Store the battery only in a partially charged state. The state of charge should be 40 – 60 % over a longer
storage period (two LED lights of the charge status indicator ( 9a) light up).
•During a longer storage period, check the state of charge of the battery and recharge if necessary roughly
every 3 months.
•In order to keep the battery well charged, avoid exposing the appliance to extreme heat or cold in storage.
•Store the equipment between 10°C and 25° C. During storage, avoid extreme cold or heat so the
battery does not lose power.
9. DISPOSAL
Electrical products should not be discarded with household products. According to the European
Directive 2012/19/EU on waste electrical and electronic equipment and its implementation into
national law, electrical products used must be collected separately and disposed of at collection
points provided for this purpose. Talk with your local authorities or dealer for advice on recycling.
BATTERY PACK
This product contains Li-ion. To preserve natural resources, please recycle or dispose of batteries properly.
Local, state or federal laws may prohibit disposal of Li-ion batteries in ordinary trash. Consult your local
waste authority for information regarding available recycling and/or disposal options.

ORIGINAL INSTRUCTIONS >EN
10. DELARATION OF CONFORMITY
BUILDER SAS
32, rue Aristide Bergès - ZI 31270 Cugnaux - France, declares that,
Product: CORDLESS TOOL 18V 4 IN 1
Trade mark: RACING
Model: RACPV18V4IN1
Serial number: 20201126392-20201128391
Is in conformity with the essential requirements and other relevant provisions of the applicable European
Directives, based on the application of European harmonized standards. Any unauthorized modification of
the apparatus voids this declaration.
European Directives (including, if applicable, their amendments up to the date of signature);
RoHS directive 2011/65/EU + (EU) 2015/863
2014/30/EU; 2006/42/EC
LVD Directive 2014/35/UE
European harmonized standards
EN 62841-1: 2015; EN 62841-2-1:2018+A11
EN 62841-2-4:2014;EN 62841-2-11: 2016
EN 55014-1:2017;EN 55014-2:2015
EN 61000-3-2:2014; EN 61000-3-3:2013
EN 62233:2008
EN 60335-2-29:2004+A2:2010+A11:2018
EN 60335-1:2012+A11:2014+A13:2017+A1:2019+A2:2019+A14:2019
Cugnaux, 24/11/2020
Philippe MARIE / PDG
Responsible of the technical file: Mr. Olivier Patriarca
