Radic8 Hextio User manual

Air Purifier and Sterilizer
Hextio
USER GUIDE AND INSTRUCTIONS
Sales & Design: Radic8 Ltd
Man & Scythe, 6 - 8 Churchgate Bolton, BL1 1HLL, UK
Tel : [phone], E-mail: [e-mail],
www.radic8.com
Manufacturer: INBair Co., Ltd
3F, 15, Beotkkot-ro 12-gil,Geumcheon-gu, Seoul, Korea
Tel: [phone], E-mail: [e-mail],
www.inbair.com
Made in Korea, Designed in England

Table of Contents
Important Safety Instructions…..…………………...….1
Operation Instructions …...…………………………….4
What’s Included and Optional Parts……………..……5
Key Parts and Components…………..………………..6
Hextio Functions....……………………………………...7
Filter Cleaning and Replacement…………………....11
How to Replace the Reactor Cell…......……………..12
How to Maintain and Clean the IAQ Sensor………..14
How to Replace the Fragrance Filter………………..15
Troubleshooting………………………………………..16
Customer Services………………………….…………18
Specifications…………………………………………..19
Limited Warranty Card
Important Safety Instructions
The following instructions are provided to ensure your
safety and to protect the unit from accidental damage.
• Read these instructions – All the safety and
operating instructions should be read before
this product is operated.
• Keep these instructions – The safety and
operating instructions should be retained for
future reference.
• Heed all warnings – All warnings on the
appliance and in the operating instructions
should be adhered to.
• Follow all instructions – All instructions for
use and operation should be followed.
• Warranty – included inside.
1 of 20
Warning – This symbol indicates important
safety instructions that must be followed to avoid
injury.
Caution – This symbol is to bring important
information to your attention to avoid the risk of injury
or damage to the unit.
Prohibited – This symbol indicates a forbidden
action. Adhere to these to reduce the risk of injury or
damage to the unit.
Electrical Safety
• The unit should only be connected to a main power
supply with voltage that matches that specified.
• To prevent overload, do not
share the same power supply
socket with too many other
electronic components.
• Do not place the power cord
where it could be stepped on
or tripped over.
• Do not place heavy items on
the power cord, they could
damage the wire.
• Do not allow water or moisture to enter the unit or
power adapter.
• Do not use in wet, moist areas
such as bathrooms, steamy
kitchens or near swimming
pools.
• Pull the plug out immediately and seek professional
help if the plug or power cord is damaged, liquid is
spilled onto the unit, if it is accidentally exposed to
moisture or the unit is not working normally.
2 of 20

Operation Safety
• Keep the product away from flammable gases and
liquids, candles and open
flames.
• Do not install near any heat
sources such as radiators,
stoves, or other apparatus that
produce heat.
• Do not attempt to repair or
replace any part of this
equipment unless it is
specifically recommended in
the user guide. All other
services should be referred to a qualified technician.
• Make sure the power cord is plugged
firmly and completely into the outlet.
• Hold the main plug, not the wires,
when removing from a socket.
• During a thunderstorm switch off the unit and
unplug from the socket.
• Do not handle the unit with wet hands.
• Only clean with a soft, dry cloth. Do not use solvents
or petroleum based fluids.
• Do not place heavy objects on the unit.
• Do not shake, knock or move the product while in
operation, you may damage the internal circuits.
3 of 20
Operation Instructions
• Do not use while cleaning the room
After cleaning, it is important to
properly ventilate the room before
using Hextio.
• Not to be used while cooking
Oils released while cooking may
reduce the lifespan of the
sterilizing module. After cooking,
the room should be ventilated to
remove oils. Hextio can then be
used to remove the remaining smell.
• Ensure airflow is not restricted
Do not position Hextio so that
airflow to and from the unit is
restricted by large items such
as furniture, electronic items or
curtains.
• Maintain proper ventilation
Hextio is designed to purify and sterilize your indoor
air, and will do this very effectively if used correctly.
Good indoor air quality also requires proper
ventilation. We recommend opening windows or
doors, or operating A/C units, for at least 30 minutes
a day.
Caution
• The appliance is not to be used by children or
persons with reduced physical, sensory or mental
capabilities. This appliance is not a toy. Children
should be supervised at all times.
• Never look directly at a burning ultra-violet light –
this may permanently damage your eyes. Switch off
and unplug before performing maintenance.
4 of 20

What’s Included and Optional Parts
Body and Accessory
1. Main Body
2. Bracket for Wall Mounting
3. Remote Control
4. Basket for Remote Control
5. Packet of 2 Carbon Filters
6. DC 12V Adapter
7. User Guide and Sticker
Optional Parts
8. Extra Reactor Cell
9. Fragrance Filter Case
10. Fragrance Filter
5 of 20
Key Parts and Components
1. Carbon Filter
2. UVC Lamp
3. Hexagon TiO2 Filter
4. Rubber Holder
5. Reactor Tray
6. Mirrored Chamber
7. BLDC Sirocco Fan
8. Dust/Germ/VOC Sensor
9. UVC Ballast
10. Logo LED
11. Remote Control Sensor
12. Power Switch
13. Control Board
6 of 20

Hextio Functions
Logo LED Power Switch
DC Jack 5.5 x 2.5mm Remote Sensor
Display and Alarm – the Logo LED functions
The mode is indicated by the color of the Logo LED
as follows:
1. Blue – automatic mode. Indicates good air
quality and normal fan speed of 20%
2. Red – automatic mode. Indicates poor air
quality and high fan speed of 100%
3. Green – manual mode. Fan power can be
set to 3 speeds; low 20%, medium 50%, or
high 100%
4. Red, flashing continuously – indicates
reactor cell replacement is due.
7 of 20
Remote Control
Automatic Operation Mode:
When the unit is switched on, either by the power
switch on body or the on/off button on the remote
control, the product is in automatic mode. Blue LED
lights are displayed and the fan speed is normal
(20%). If dust, germs or VOC’s are detected by the
sensor, the fan switches to full power and red LED
lights are displayed. When the dust, germ or VOC
levels return to healthy levels, the unit automatically
returns to 20% fan speed and displays the blue
color.
Note - When the unit is switched on the Indoor Air
Quality (IAQ) sensor takes up to 5 minutes to
calibrate.
Press “on/off” button.
Manual Operation Mode:
If you wish to manually control the fan speed, press
the manual button on the remote control. The green
LED light is displayed to indicate manual mode.
Press “speed” “+” or “–“ to change the fan speed.
The settings are low 20%, medium 50% and high
100%.
8 of 20

Press “MANUAL” button.
Press “SPEED” “+” or “–” button”.
9 of 20
Sleep Mode:
When sleep button is pressed, the fan switches to
very low (10%) and all LED lights are switched off.
Press “SLEEP” button.
Indirect LED Light
In addition to the Logo LED, there are also indirect
LED lights inside Hextio. When the LED button is
pressed, the indirect LEDs are switched off or on.
Press “LED” button.
10 of 20

Filter Cleaning and Replacement
The TiO2 Carbon Filter
One side of the carbon filter is coated with TiO₂
(titanium dioxide) to increase the photo catalytic power
of Hextio. This side (shown on the right) is pale grey /
silver and should be placed face down. The black side
should face up, as shown below.
Caution:
• Switch off and unplug the unit before
performing maintenance.
• Never look directly at a burning ultra-violet
light.
It is good practice to check the carbon filter once per
month and clean it using a vacuum cleaner if
necessary. The carbon filter should be changed every
6 months at least. Simply unscrew the two screws on
top of the grill to remove and replace the filter.
11 of 20
How to Replace the Reactor Cell
The Reactor Cell should be replaced when the usage
time has reached a total of 8000 hours. Hextio will
indicate this is due by displaying red flashing Logo LED
lights.
Caution:
• Switch off and unplug the unit before
performing maintenance.
• Never look directly at a burning ultra-violet
light.
Procedure to Replace Reactor Cell:
1. Open filter case and loosen 2 screws at top.
.
12 of 20

2. Detach 4 rubber feet and loosen 4 screws.
.
3. Open the body and loosen 4 screws surrounding
Reactor Cell.
4. Detach wire connector.
5. Replace with new reactor cell and assemble in
reverse order. The used reactor cell is fully
recyclable, as a consumer it is your responsibility to
ensure it is disposed of properly.
Important:
After replacing reactor cell, press and hold the
power button on the body for 10 seconds. This
resets the operation time to zero.
13 of 20
How to Maintain and Clean the IAQ Sensor
The IAQ sensor is a very delicate instrument that uses
light scattering to detect pollution. It therefore needs a
clean lens to work effectively. Regular maintenance
(every 6 months) should be carried out to keep the lens
clean.
Important – Only use pure water and allow to dry
completely before replacing. To avoid damage to the
plastic lens do not use chemicals such as benzene or
alcohol (found in some cleaning products).
Procedure to maintain and clean the IAQ Sensor:
1. Open the body as shown in the previous image.
2. Detach wire connector attached to IAQ sensor.
3. Clean lens with a clean cotton swab dampened with
pure water.
4. Dry lens and IAQ sensor.
5. Assemble in reverse order.
Caution:
• Do not place in direct sunlight.
• Do not spray water or perfume near the
sensor.
14 of 20

How to Replace the Fragrance Filter
To open the Fragrance Filter case, grip the lid and pull
firmly. You may need to inset a thin object between the
base and lid to release the inner hooks. Please take
care if using a knife. Replace fragrance pouch, click lid
and base back together and simply place on top of
Hextio body.
Caution:
• The Fragrance Filter is designed for use
with dried natural flowers, herbs and
spices. These should always be contained
within a pouch or bag, such as the one
provided.
• Do not use oils or other liquids in the
Fragrance Filter. They may drip down into
the unit and damage it.
15 of 20
Troubleshooting
Before you call for service, review this list. It may save
you time and expense. This list includes common
occurrences that are not the result of defect in
workmanship or materials.
Problem – Product will not turn on.
Possible Cause
Is power cord correctly connected to outlet?
Solution
Ensure power cord is properly inserted into Hextio and
socket.
Possible Cause
Check remote controller?
Solution
Change / reinstall batteries correctly according to the
polarity.
Possible Cause
Check if the voltage of DC adaptor is too low?
Solution
This product should be used with a DC 12V 1.5A
adaptor.
Problem – Weak wind volume or noise from the
product.
Possible Cause
Check if dust has accumulated in the filter?
Solution
Filter should be replaced at the appropriate time,
(approximately every 6 months) and cleaned regularly.
16 of 20

Problem – The air purifying function does not work well
Possible Cause
Check if indoor air is seriously contaminated?
Solution
Ventilate properly, minimum 30 minutes.
Possible Cause
Check if airflow is restricted?
Solution
Make sure there is sufficient clearance around the
product and that the air inlet and outlet are not blocked
by furniture, curtains etc.
Problem – Strange smell is emitted from the air outlet.
Possible cause
Is this a ‘new product’ smell?
Solution
It may be an antimicrobial smell emitted by the
sterilizing module or filters and will disappear over a
short period of operation (1-2 weeks). It is completely
harmless to humans and animals.
Possible cause
Has the unit been used during or shortly after cooking?
Solution
Food odors can permeate into the filter or the sterilizing
module. Use only after sufficient ventilation.
Possible cause
Has the unit been used where there are heavy
emissions of smoke or odors?
Solution
In areas emitting smoke or odors, the performance of
the sterilizing module may be affected. Use only after
ventilation.
17 of 20
Customer Services
In this manual, you will find a card containing
details of your limited warranty and contact details
for your local customer services center, to whom
all enquiries and warranty claims should be
directed.
All warranties are rendered void and the cost of
repair will be payable by the user in the case of:
1. Damages caused by putting foreign
objects (such as water, soft drink, coffee,
fragrance oils or toy etc.) in or on the unit.
2. Damages caused by transportation or
handling.
3. Damages caused by use of products such
as benzene or thinner.
4. Damages caused by incorrect power
supply.
5. Breakdown or loss of parts caused by
unauthorized disassembling or
modification.
6. Repair or replacement undertaken by
unauthorized persons.
7. Damages caused by non-adherence to the
instructions provided in this user guide,
and as given by the local customer service
center.
8. Damages caused by careless or improper
use.
9. Damages caused by operating the product
in a corrosive or moist environment.
18 of 20
