Radio System Corporation PetSafe SNS-BK-C Setup guide

PLEASE READ THIS ENTIRE GUIDE BEFORE BEGINNING
Gentle Spray®
Anti-Bark Collar
operating and training guide
Model Number
SNS-BK-C

2 1-800-732-2677
Important Safety Information
Explanation of Attention Words and Symbols used in this guide
This is the safety alert symbol. It is used to alert you to potential personal injury hazards.
Obey all safety messages that follow this symbol to avoid possible injury or death.
WARNING indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION, used with the safety alert symbol, indicates a hazardous
situation which, if not avoided, could result in minor or moderate injury.
CAUTION, used without the safety alert symbol, indicates a hazardous
situation which, if not avoided, could result in harm to your pet.
Not for use with aggressive dogs. Do not use this Product if your dog is
aggressive, or if your dog is prone to aggressive behavior. Aggressive dogs
can cause severe injury and even death to their owner and others. If you are unsure whether
this product is appropriate for your dog, please consult your veterinarian or certified trainer.
AEROSOLS:
UÊKeep out of reach of children.
UÊContents of the refill can and the spray collar are under pressure.
UÊUse only in a well ventilated area. Use only as directed.
UÊMay explode if heated, do not heat. Do not expose to temperatures over 113°F or 45°C.
UÊDo not burn. Do not dispose of in fire, even when empty.
UÊKeep out of direct sunlight.
UÊDo not leave the aerosol can in a vehicle where temperature could exceed 113°F or 45°C.
UÊStore in a cool location.
UÊKeep away from sparks or flame. Do not smoke while refilling.
UÊDo not puncture. Contact of liquid propellant with skin may cause frostbite.
UÊDo not ingest. In case of accident, seek medical care. If swallowed, call a poison control
center immediately.
Do not expose the device to freezing temperatures -32°F or 0°C or to
conditions warmer than 113°F or 45°C. Do not leave the unit in direct sunlight.
Never leave the unit in a car where the device can heat up to high temperatures 113°F or 45°C.
The PetSafe®GentleSpray®Anti-Bark Collar is not a toy. Keep it away from the reach of children.
Use it only for its bark stopping purpose.
Risk of skin damage. Please read and follow the instructions in this manual.
Proper fit of the collar is important. A collar worn for too long or made too tight
on the pet’s neck may cause skin damage. Ranging from redness to pressure ulcers; this
condition is commonly known as bed sores.
UÊAvoid leaving the collar on the dog for more than 12 hours per day.
UÊ When possible, reposition the collar on the pet’s neck every 1 to 2 hours.
UÊ Check the fit to prevent excessive pressure; follow the instructions in this manual.
UÊ Never connect a lead to the electronic collar.
UÊ When using a separate collar for a lead, don’t put pressure on the electronic collar.

www.petsafe.net 3
UÊ Wash the dog’s neck area and the contact area of the collar weekly with a damp cloth.
UÊ Examine the contact area daily for signs of a rash or a sore.
UÊ If a rash or sore is found, discontinue use of the collar until the skin has healed.
UÊIf the condition persists beyond 48 hours, see your veterinarian.
UÊFor additional information on bed sores and pressure necrosis, please visit our website.
These steps will help keep your pet safe and comfortable. Some pets are sensitive to contact
pressure. You may find after some time that your pet is very tolerant of the collar. If so, you may
relax some of these precautions. It is important to continue daily checks of the contact area. If
redness or sores are found, discontinue use until the skin has fully healed.
PetSafe®Bark Control collars must be used only on healthy dogs. We recommend that you take
your dog to a veterinarian before using the collar if he is not in good health.

4 1-800-732-2677
Thank you for choosing the PetSafe®brand. You and your pet deserve a
companionship that includes memorable moments and a shared understanding
together. Our products and training tools promote a lifestyle of protection,
teaching, and love—essentials that influence memories for a lifetime. If you have
any questions about our products or training your pet, please visit our website at
www.petsafe.net or contact our Customer Care Center at 1-800-732-2677.
To get the most protection out of your warranty, please register your product within
30 days at www.petsafe.net. By registering and keeping your receipt, you will enjoy
the product’s full warranty and should you ever need to call the Customer Care
Center, we will be able to help you faster. Most importantly, PetSafe®will never
give or sell your valuable information to anyone. Complete warranty information is
available online at www.petsafe.net.
Table of Contents
Components................................................................................................................. 5
Other Items You May Need .......................................................................................... 5
How the System Works................................................................................................ 5
Key Definitions ............................................................................................................. 5
Fit the Bark Control Collar............................................................................................ 6
Preparing the Collar...................................................................................................... 6
On/Off........................................................................................................................... 7
To Fill and Refill the Spray ............................................................................................ 7
Ensure a Proper Spray Pattern..................................................................................... 8
What to Expect During Use of the Spray Bark Control Collar...................................... 8
Tips and Maintenance.................................................................................................. 8
Frequently Asked Questions ................................................................................... 10
Troubleshooting........................................................................................................ 10
Customer Care International ...................................................................................... 10
Terms of Use and Limitation of Liability ..................................................................... 11
Compliance ................................................................................................................ 11
Perchlorate Battery..................................................................................................... 12

www.petsafe.net 5
Components
PetSafe®GentleSpray®
Anti-Bark Collar
Citronella Spray
PAC19-12069
Operating Guide
Battery
(PetSafe®RFA-18)
Other Items You May Need
UÊScissors
UÊLighter
How the System Works
The GentleSpray®Anti-Bark Collar uses a proven method to deliver a harmless burst of citronella
spray to interrupt your dog’s barking. Citronella is a unique scent that most dogs don’t normally
encounter. It’s non-offensive to humans, yet unusual enough to distract your dog and interrupt
the unwanted behavior.
Key Definitions
Spray Nozzle: Where the spray
ejects when your dog’s bark
is detected.
Microphone: Detects the sound of
your dog’s bark.
Refill Port: Where the spray
is refilled.
On/Off Switch: Turns the collar on
and off.
Spray Nozzle
Rell Port
Microphone
Battery Cover
ON/OFF Switch
(Bottom View)

6 1-800-732-2677
Fit the Bark Control Collar
Important: The proper fit and placement of your bark control collar is important for
effective operation.
To assure a proper fit, please follow these steps:
1. Make sure that the bark control collar is turned off.
2. Start with your dog standing comfortably (A).
3. Place the collar on your dog’s neck close to the ears. Center the
Microphone on your dog’s neck, touching the skin (B). Make sure
the PetSafe®logo in the front of the unit is upright and the Spray
Nozzle is pointed toward your dog's snout.
SÍ
NO
A
4. Check the tightness of the bark control collar by
inserting one finger between the collar and your dog’s
neck (C). The fit should be snug but not constricting.
5. Allow your dog to wear the collar for several minutes,
then recheck the fit. Check the fit again as your dog
becomes more comfortable with the Bark Control Collar.
6. Trim the collar as follows: (D)
a. Mark the desired length of the collar with a pen.
Allow for growth if your dog is young or grows a
thick winter coat.
b. Remove the Bark Control Collar from your dog and
cut off excess.
c. Before placing the Bark Control Collar back onto
your dog, seal the edge of the cut collar by applying
a flame along the frayed edge.
The Bark Control Collar should not
be worn for more than 12 hours out
of every 24-hour period. Leaving the
collar on too long could lead to Skin
Irritation. Please refer to page 2 for
additional information.
B
C
D
Preparing the Collar
To Insert and Remove the Battery
Note: Do not install the battery while the bark control collar is on your dog.
1. Slide off the battery cover.
2. Insert the 6-volt alkaline battery.
3. Keep the polarity in mind (+ and -).
4. Slide the cover back on.
A replacement battery (6-volt alkaline) can be found at many retailers. Contact the Customer
Care Center or visit our web site to locate a retailer near you.
Battery Life
Average battery life is 2 to 4 months, depending on how often your dog barks. However, due to
greater use during your dog’s training, your first battery may not last as long as replacement batteries.

www.petsafe.net 7
On/Off
UÊTo activate the unit, slide the On/Off switch to the ON position.
UÊTo turn the unit off, slide the switch to the OFF position
UÊBefore every use, it is best to test the device. Holding the unit
about 3-4 inches from your face, point the spray nozzle away from
you and blow into the Microphone.
To Fill and Refill the Spray
UÊRemove the collar from your dog and turn the unit OFF.
UÊSet the device on a flat surface with the Refill Port (deepest
cavity) turned upwards.
UÊHold the Refill Spray can upright and firmly press the nozzle down
into the Refill Port. Hold down firmly for 10 seconds and release.
Press down for another 10 seconds, then release again. You
cannot overfill the device.
Note: If spray leaks out, you may need to
press harder to complete the seal.
UÊTurn the unit ON.

8 1-800-732-2677
Ensure a Proper Spray Pattern
For the PetSafe
®
GentleSpray
®
Anti-Bark Collar to perform properly, the nozzle must be positioned
correctly and there must be a clear path from the Spray Nozzle to your dog’s snout.
Follow these steps:
1. Make sure the Spray Nozzle is upright and pointing
towards the dog’s snout.
2. For long-haired dogs, it may be necessary to trim the
neck hairs along the path of the spray. It is important that
the spray reaches the dog’s snout to be effective.
Do not shave the pet’s neck as this may
increase the risk of skin irritation.
What to Expect During Use of the Spray Bark
Control Collar
Important: Do not leave your dog alone the first few times he wears the Bark Control Collar.
Place the
GentleSpray
®
Anti-Bark Collar properly on your dog and wait nearby until he barks.
Most dogs will understand very quickly that the bark control collar is disrupting their urge to
bark and will relax and stop barking. Because the burst of spray from the bark control collar
may be surprising or startling at first, some dogs may bark more at the initial correction.
On rare occasions, a dog may get into a bark-spray-bark-spray cycle. If this happens, reassure
your dog with calm, soothing tones. As your dog relaxes, he will understand that if he becomes
quiet, he will not receive any more spray bursts. The small minority of dogs that have this
reaction should only have it the first time they wear the spray bark control collar.
You should notice a reduction in your dog’s barking within the first couple of days that he wears
the
GentleSpray
®
Anti-Bark Collar . At this point, it is important to remember the learning process is
still not complete. Dogs will “test” this new learning experience and will increase their attempts to
bark. This usually occurs during the second week a dog wears the bark control collar. If this does
occur, remain consistent and do not alter your use of the bark control collar. You must place the
collar on your dog in every situation when you expect him to be quiet. If your dog is not wearing
the collar, he may resume barking and his learning would suffer a setback.
Tips and Maintenance
UÊBefore playing with your dog, turn the unit off and remove the bark control collar. The activity
may cause your dog to bark, which could lead to him associating the play with the burst of spray.
UÊThe collar must be filled to maximum capacity before placing it around your dog’s neck.
UÊNever fill the device while your dog is wearing it because it may damage the Refill Port.
UÊTo ensure that your dog does not make the connection between you and the spray collar,
don’t let him see you prepare the device for the first try, or for subsequent use. Keep your dog
away while you prepare the device as well as when you fill it or change the battery.

www.petsafe.net 9
UÊIt is important that your dog’s hair doesn’t block the Spray Nozzle. Try tying a bandanna
(handkerchief) around your dog’s neck, then place the spray collar above it. If necessary, you
may also consider trimming a little of the long hair around the dog’s neck for better spray effect.
UÊRemove all other collars with metallic parts or tags. These could create noise that may
needlessly activate the spraying device.
UÊAvoid letting your dog wear the device with an empty reservoir. Make sure it is always full.
UÊTurn OFF the device while not in use.
UÊThe
PetSafe
®
GentleSpray
®
Anti-Bark Collar should only be used with pets that are over 6
months of age.
UÊYour spray collar is splash-proof but not completely watertight. Remove it before letting your
dog go for a swim.
UÊKeep the device clean at all times. Do not immerse it in water when cleaning. Simply use a
dry cloth to wipe away dirt. You may lightly brush with an old toothbrush if dirt accumulated in
front of the Microphone grid.
UÊDo not leave your device unattended where your dog could accidentally damage it through
chewing.
UÊEnsure the batteries you are using are still adequate to operate the device. The device
requires 6-volt alkaline batteries, readily available from www.petsafe.net. You may also use
longer life lithium batteries.
UÊThe Microphone is calibrated so it won’t be activated by nearby sounds. However, the barking
of another dog at close range could cause the device to spray.
UÊNever fill the
PetSafe
®
GentleSpray
®
Anti-Bark Collar with any substance other than the one
provided by the manufacturer. PetSafe
®
Citronella and Unscented Spray Refills are available
at www.petsafe.net. Using another substance, as well as opening the device, will void the
manufacturer’s warranty.
UÊAlways make sure that you are not mistakenly trying to fill the reservoir through the
Microphone opening. This would damage the device.
UÊIf your dog tries to take off the device, a harness can be used instead of the collar provided in
the kit.
UÊDo not attempt to repair the device yourself. This will invalidate the warranty and make repairs
more difficult.

10 1-800-732-2677
Frequently Asked Questions
Will the PetSafe®GentleSpray®
Anti-Bark Collar work for my dog?
UÊThe GentleSpray®Anti-Bark Collar is safe and effective
for all breeds and sizes of dogs.
Will this work with long-haired
dogs?
UÊYes. It may be necessary to trim the hair on your
dog’s neck so it does not block the spray from
reaching his snout.
Does the spray need to hit my
dog’s nose?
UÊNo. The spray is very fine and simply creates a mist in
the region of the snout.
Troubleshooting
The GentleSpray®Anti-Bark
Collar
does not spray.
UÊEnsure that the battery is properly installed.
UÊReplace the battery.
UÊRefill the spray.
UÊEnsure the unit is turned ON.
UÊIf the bark control collar still does not spray, contact
the Customer Care Center.
My bark control collar sprays, but
my dog keeps barking (does not
respond to the burst of spray).
UÊCheck to make sure the Spray Nozzle points towards
the dog’s snout.
UÊMake sure your dog’s hair does not block the spray. If
so, trim the hair so the spray can reach the snout area.
UÊIf your dog still does not respond, contact the
Customer Care Center.
When I try to refill the
Citronella Spray, the spray
leaks out around the Spray
Nozzle.
UÊHold the spray can upright. If it is held at an angle, it
will not create a good seal.
UÊPress firmly on the spray can to create a good seal.
UÊIf the spray continues to leak, contact the Customer
Care Center.
Customer Care International
USA & Canada - Tel: [phone]
Monday - Friday 8 AM - 8 PM / Saturday 9 AM – 5 PM
Australia - Tel: [phone]
Monday - Friday 7:30 AM - 5 PM
New Zealand - Tel: [phone]
Monday - Friday 10:30 AM - 7 PM
This product has the benefit of a limited manufacturer’s warranty. Details of the warranty applicable to
this product and its terms can be found at www.petsafe.net and/or are available by sending a stamped
addressed envelope to PetSafe
®
Ltd. Redthorn House, Unit 9, Chorley West Business Park, Ackhurst Road,
Chorley, Lancashire PR7 1NL, United Kingdom.

www.petsafe.net 11
Terms of Use and Limitation of Liability
1. Terms of Use
This Product is offered to you conditioned upon your acceptance without modification of the terms,
conditions and notices contained herein. Usage of this product implies acceptance of all such
terms, conditions, and notices.
2. Proper Use
This Product is designed for use with pets where training is desired. The specific temperament of
your pet may not work with this product. We recommend that you not use this product if your pet
is less than 8 lb or under 6 months old, or if your pet is aggressive. If you are unsure whether this is
appropriate for your pet, please consult your veterinarian, certified trainer or contact our Customer
Care Center or visit our website at www.petsafe.net.
Proper use includes reviewing the entire Operating and Training Guide provided with your
product and any specific Caution statements.
3. No Unlawful or Prohibited Use
This Product is designed for use with pets only. This pet training device is not intended to harm,
injure, or provoke. Using this product in a way that is not intended could result in violation of
Federal, State or local laws.
4. Limitation of Liability
In no event shall Radio Systems
®
Corporation be liable for any direct, indirect, punitive, incidental,
special or consequential damages, or any damages whatsoever arising out of or connected with the
use or misuse of this Product. Buyer assumes all risks and liability from the use of this Product.
5. Modification of Terms and Conditions
Radio Systems
®
Corporation reserves the right to change the terms, conditions and notices under
which this Product is offered.
Compliance
FCC- United States
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions:
(1) This device may not cause harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
This Class B digital apparatus complies with Canadian ICES-003. This equipment has been tested and
found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These
limits are designed to provide reasonable protection against harmful interference when the equipment is
operated in a residential environment. This equipment generates, uses, and can radiate radio frequency
energy and, if not installed and used in accordance with the instruction guide, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
practical installation. If this equipment causes harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
UÊRelocate the interfered receiving antenna.
UÊIncrease the separation between the equipment and receiver.
UÊConnect the equipment into an outlet on a circuit different to that to which the receiver is connected.
UÊContact the Customer Care Center.

IC- Canada
This Class B digital apparatus complies with Canadian ICES-003.
Cet appareil numérique de la classe B est con forme à la norme NMB-003 du Canada.
Perchlorate Battery
Perchlorate Material – special handling may apply.
See www.dtsc.ca.gov/hazardouswaste/perchlorate.
Radio Systems®Corporation
10427 PetSafe Way
Knoxville, TN 37932
1-800-732-2677
www.petsafe.net
400-1266
©2011 Radio Systems Corporation
