Radiocrafts RC1180DK-MBUS User manual

Radiocrafts
Embedded Wireless Solutions
RC1180DK-MBUS
2008 Radiocrafts AS RC1180DK-MBUS Quick Start (rev. 1.1) Page 1 of 2
RC1180DK-MBUS Quick Start
Quick Start Guide
1. Set up each board as illustrated in the picture
2. Download the latest version of RCTools-MBUS from www.radiocrafts.com and install
as described in the RCTools Installation Guide.
Connect to
serial port
Connect to
power
Ensure that RXD
and TXD jumper
are mounted
Ensure that the
power jumper is
mounted
Connect the
antenna

Radiocrafts
Embedded Wireless Solutions
RC1180DK-MBUS
2008 Radiocrafts AS RC1180DK-MBUS Quick Start (rev. 1.1) Page 2 of 2
3. Open MBUS-CCT and follow the step-by-step guideline to send a MBUS message.
For details please see CCT User Manual or the RCTools Help file.
Contact Information
Radiocrafts AS
Sandakerveien 64
NO-0484 OSLO
NORWAY
www.radiocrafts.com
[e-mail]
[e-mail]
[e-mail]
Tel: [phone]
Fax: [phone]
1.Connect to
the correct
COM port
2.Enter
Configuration
mode
3.Change
MBUS mode
if needed.
See RC1180-
MBUS data
sheet for
details
4.Enter
Normal Mode
5.Type in the
MBUS
message to
send. Start
with length
byte. See
RC1180-
MBUS data
sheet for
details.
6.Send the
MBUS
packet.
7. Messages received from the other
RC1180-MBUS board will appear in
this window.
