Radiolink A560 Installation instructions

A560 3D Fixed Wing

Vertical Flight with 1 Switch

Assembly & Disassembly Instruction

All electronic components of A560 are already set. If it’s the RTF version(with transmitter T8S and receiver packed), all you need to do after unpacking the box is to

assemble the wing, and then fly it.

Note: If it is the PNP version(without transmitter T8S and receiver packed), please follow the instruction manual of A560 to set channel 5 and channel 7 in your

transmitter.

A560 Introduction：

RTF A560 Spare Part List：

Note: Please refer to the sales interface for the actual spare part list.

A560 Assembly Steps：

1. Install the wing

2. Connect tail support rods 3. Connect aileron drawbars 4. Install the landing gear 5. Install the propeller

A560 Disassembly Steps：

After the flight, please disconnect the battery first, and then refer to the above assembly steps to disassemble the parts of A560 in turn. The disassembly steps are

as follows:

1. Disassemble the propeller and landing gear. Please see Note①

2. Disassemble the the drawbars and tail support rods. Please see Note②

3. Diassemble the buttons to fix the wing. Remove the slotted fuselage vane and wing. Insert the slotted fuselage vane back.

4. Arrange all the spare parts and put them into the bag in turn. Keep all drawbars and rods parallel to the fuselage when packing it. Please see Note③

Disassembly Notes：

①When disassembling the landing gear,

please push the two metal rods of the landing

gear in opposite directions at the same time,

and then push the metal rods to make it out of

the slot.

③when packing the fuselage in the bag,

please keep all drawbars and support rods

parallel to the fuselage to avoid damage to the

drawbar/rod caused by improper placement.

②When disassembling the drawbars or

support rods, please put the screwdriver in the
