Radomir Bednar 160NB User manual

Radomír Bednář, production of fishing tackle and
metal-working production
V kotlině16, 77900 Olomouc, Czech Republic, IČO: 13239449
tel. [phone], e-mail: radomir.b[email protected]
web: http://www.r-bednar.cz
Control panel 160NB
CONTENT: Description
Operating Instructions
Safety Instructions
Technical Data
Troubleshooting
DESCRIPTION
Control panel is designed for adjusting the AC voltage from electric generator (230V) for fishing purposes.
AC from electric generator is adjusted using the phase-controlledone-wayrectifier,which ishandled using
the power potentiometer. Specific shape DC pulses temporarily stupefy fish but don’t hurt them.
On the control panel, there is:
1. Main switch
2. Power scale switch (I, II)
3. Peak modulation switch
4. Power control switch
5. Pulse frequency regulation knob
6. Fuse case with 8A fuse
The ammeter shows mean values of output current (peak value is higher) and those values are of
informative character for the operator and for the instrument operation. Output current value directly
corresponds to fishing environment properties (water conductivity, etc.). Voltmeter shows mean values of
output voltage. On the side of the control panel, there are sockets for connecting the anode (+ sign) and
cathode (- sign).
Basic instruments for electrofishing are: fishing handle with extensionandelectriclanding net (anode),
cable and cable drum, drum support, cathode, grounding pin and dielectric gloves.
Control panel 160NB is suitable for waters of water conductivity 50-1500µS.
The product complies with the technicalrequirementsonproductsas pertheActNo. 22/1997 Coll.,
Government Regulation No. 168/1997 Coll., and Government Regulation No. 169/1997 Coll. and
a Declaration of Conformity was issued for the product.
OPERATING INSTRUCTIONS

Important:
The control panel is designed only for operating together with the electrofisher.Itisnotallowedto
connect it to the electric grid. If done so, there is a threat of electric current injury (ČSN 33 2000-4-
41).
A: FISHING IN RUNNING WATER - gear is located on the shore
1. Connect the control panel with the electric generator by putting cable’s plug into a socket of electric
generator output.
2. Complete the fishing equipment. Connect anode (cable and cable drum, fishing handle, extension,
electric landing net) to the red-labelled + socket. Connect cathode (1.5 –2 m long flat copper net) to the -
socket.
3. Start the electric generator according to its own manual, switch on the breaker on the generator output
(next to sockets).
4. Switch on the main switch of control panel 160NB.
5. Change the power scale according to fishing conditions. Switch position I is forconductivitygreater than
250 µS. The output voltage in this position is 325V. Position II with output voltage 650V is for extremely
clean, therefore low conductivitywater. This position is to be used above all in mountain brooks with stony
or rocky beds. It is not recommended to use the II position for valley rivers or for fishponds with high
conductivities. It is not considerate towards living organisms and also the gear might get overloaded and
cause the fuse outage.
6. The gear is also equipped with the power control switch. This switch can be used to vary the output
pulse length by four levels. This way, the “delivered energy” of one pulse can be varied.
In practice (especially when it is not possible to measure the conductivity of the fishing environment) the
power scale switch is first set to position I or II. Afterwards the ammeter is used to measure the output
current and the power control switch is used to control the output current and therefore the fishing
efficiency. By combining those two settings a vast scale of fishing environment can be covered.
7. The gear has also a “modulation” switch. For better galvanotaxis and for selective effect on different fish
type and size, the basic frequency (set by potentiometer and measured by the frequency meter) is
combined with lower frequencies. The frequencyis digitallyderived from the basic frequencyand its value
is 1/16, 1/8, 3/16 and 1/4 of the basic frequency. By proper choice of voltage, power control, basic
frequency and its modulation, it is possible to achieve outstanding selection of fishing effects.In general, it
is recommended to use lower voltage for bigger fish, also lower basic frequency and lower modulation
frequency (1/16).
8. Test the device function by putting both electrodes into the water (at least 3m from each other, mutual
contact is prohibited) and press the fishing handle button. From the movement of ammeter indicator, it is
possible to learn whether the gear is working.
Generally said, in the low conductivity water the ammeter shows lower current and vice versa.
9. When fishing in running water, always move upstream only.
10. After finishing the fishing, switch off the main switch of the control panel first, then turn off the
generator. Always roll-up the cable only when the gear is not working.
B: FISHING IN STANDING WATER - gear is located on the boat
Use the above mentioned points 1-8 of fishing in running water. The cable and cable drum are replaced
with a short cable (5m) with PK27 plug. The cable can be delivered with the equipment. When fishing in
higher conductivity waters, it is necessary to replace the default cathode (1.5 m long copper net) with
shorter one (0.5 m long copper net).
9.
1
Fishing boat should not be made of metal but of non-conductive material such as wood or laminate. It
should also be sufficient in stability and capacity.
10. Cathode always has to be positioned in order to avoid the contact of the operator with its active part
(flat copper net). In the case of motor boat, winding of the cathode onto the propeller must be avoided.Itis
recommended to fasten the active part of cathode onto the polystyrene; this way the cathode flows on the
water and cannot get stuck.
11. The fisher with anode (electric landing net) is always on the stem of the boat and should have a helper
who can collect fish using a landing net: its handle must be from a non-conductive material.
12. When fishing in standing water the gear is effective to the water depth of about 1.5-2m. It is necessary
to realize that it is not a depth gear but equipment designed especially for running water.
1
Česká verze má jiné číslování – pokračuje číslem „10“

For all ways of fishing there is always one common rule: set the power supply high enough for fishing
effects to be sufficient and low enough for fish not to be stunned for too long. When setting too high power
supply you can restrain the fish galvanotaxis (an ability of anode to attract fish) and the fish will remain
stunned at the bed.
SAFETY INSTRUCTIONS
To ensure the safety when using the electrofishing gear, it is necessary to follow instructions given in the
generator manual and also following instructions:
1. The person managing the fishing process has to be familiar with operation of the electrofishing gear,
with the fishing procedure and with safety rules (branch standards ON 341740 and ON 341741). The
instrument can’t be operated by children, only by adult persons.
2. Fishing person and also co-operating persons in the water must wear rubber gloves and rubber fishing
boots.
3. Electrofishing in rain is p r o h i b i t e d!
4. Gear must be properly grounded before its function is started.
5. All persons participating in fishing have to be instructed in main principles of work safety during
electrofishing.
6. During the whole time of fishing there must be a well-instructed person who manages the electrofishing
gear according to the instructions and who makes sure nobody enters the dangerous area, especially in
the cathode vicinity.
7. Input cable must not be firmly twisted around a part of someone’s body (wrist, shoulders, etc.), cable
and cable drum is prohibited from being carried around when fishing.
8. The sampled fish must not be hand-collected from the electric landing-net.
9. In case of any failure, defect or incorrect operation, the gear has tobeplugged out from the current input
and it can’t be utilized anymore until the gear safety is confirmed by the producer.
10. Onlyone control panel can be used together with the generator. If two control panels were used, there
is a risk of failure.
TECHNICAL DATA
Manufacturer: Radomír Bednář, production of fishing tackle and
metal-working production, V kotlině16, 77900 Olomouc, Czech Republic, tel.:
[phone]
Output voltage (peak level): 325-650V
Output current (peak level): max.8A (depends on environmental conductivity)
Current frequency: 50-95Hz
Pulse amplitude: Sheer starting edge, exponential run-down
Protection: 8A
IP code: IP44
TROUBLESHOOTING
1. There is no current between electrodes.
Possible defect: a) Control panel is not connected to the gear
b) Incorrect connection of electrodes to the control panel (+ -)
c) Defective micro button in the fishing handle
d) Inlet cable is cut off
e) Worn out carbon segments on cable drum
Remedy: a) Connect the control panel to the gear (in turned off state)
b) Correctly connect anode (+) and cathode (-) to the control panel
c) Unfasten the bolt under the rubber cover of the fishing handle, eject the inner part
and replace the switch
d) Replace the inlet cable

e) Dismantle the carbon segment holder and replace carbon segments with newones
2. The fishing effectiveness of the device is not sufficient.
Possible defect: a) Improper settings of the rotor rotation speed
b) Improper electrodes (size, technical condition)
c) Extreme requirements, unfavourable parameters of the fishing environment
d) Inlet cable isolation failure
Remedy: a) Move the engine control lever to the left
b) Replace electrodes
c) Use another gear
d) Replace the inlet cable
3. The engine does not start.
Possible defect: a) Lack of fuel in the tank, closed fuel feed
b) Lack of oil supply (the low oil level sensor does not allow the engine to start up in
order to avoid engine seizure)
c) Defective spark plug
d) Dirt in the fuel system
Remedy: a) Open the fuel feed and fill the tank
b) Refill the oil according to the engine manual
c) Take the spark plug out and clean it, if necessary, replace it
d) Clean the fuel system, it is recommended to have an expert take care of this
Repairs of small defects or replacements can be conducted only after the generator is turned off.
It is recommended that the repairs of the control panel or the gear are conducted by the manufacturer.
After each repair, the instrument is always adjusted and checked.
It is necessary to use the fuse type recommended bythe manufacturer, do notreplacewithfuses of higher
value!
For four-stroke engines, it is necessary to replace the engine oil at least once ayear –thiswaytheworking
life of the engine is prolonged.
W a r n i n g:
Anymanipulation with built-on elements in the control panel is unacceptable if the engine is running,there
is a danger of electric current injury! Specialized repairs can be carried out onlybythe producer. Producer
is not responsible for faultscausedbynoncomplianceproducer’s advice or by unprofessionalmanipulation.
The usage of the gear must comply with §10 of Fishing Act No. 102/1963.
