Rail King 2-8-0 Steam Freight/ Passenger Set User manual

2-8-0 Steam Freight Set
2-8-0SteamFreightSet
OperationManual
www.railking.com
ThankyouforpurchasingthisRailKingproduct.
PLEASEREADBEFOREUSEANDSAVE

Table of Contents
SetUpChecklist..........................................3
GettingStarted...........................................4
AssemblingRealTrax.....................................4
PluggingintheTransformer................................4
LubricatingtheEngine....................................5
PrimingtheSmokeUnit...................................5
CouplingtheEngineandCars...............................5
RemoteControl..........................................6
BasicOperation ..........................................7
OperationButtons........................................7
SpeedControl...........................................7
DirectionLock...........................................8
Proto-CastandProto-Dispatch..............................8
ManualVolumeControl ...................................9
Maintenance............................................10
CareofRemoteControl ..................................10
Lubrication and Greasing Instructions . . . . . . . . . . . . . . . . . . . . . . . 10
Cleaning the Wheels, Tires and Track. . . . . . . . . . . . . . . . . . . . . . . . 11
Locomotive Traction Tire Replacement . . . . . . . . . . . . . . . . . . . . . . 11
CDROM ............................14
Troubleshooting.........................................15
Compatibility...........................................16
Transformer Compatibility Chart . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Parts...................................................17
Service and Warranty Information . . . . . . . . . . . . . . . . . . . . . . . . . .23
SmokeUnitMaintenance.................................12
Locomotive Light Bulb Replacement . . . . . . . . . . . . . . . . . . . . . . . . 13
CabooseLightBulbReplacement...........................13
RailWare Interactive
RailKing 2-8-0 Steam Freight Set with Loco-Sound™
2
CAUTION: ELECTRICALLY OPERATED PRODUCT:
Not recommended for children under 10 years of age. M.T.H. recommends adult supervision with children ages 10 -
16. As with all electric products, precautions should be observed during handling and use to reduce the risk of electric
shock.
WARNING:When usingelectricalproducts,basicsafetyprecautionsshouldbeobserved,includingthe following:
Readthismanualthoroughlybeforeusingthis device.
lM.T.H. recommends that all users and persons supervising use examine the hobby transformer and other electronic equipment
periodically for conditions that may result in the risk of fire, electric shock, or injury to persons, such as damage to the primary
cord, plug blades, housing, output jacks or other parts. In the event such conditions exist, the train set should not be used until
properlyrepaired.
lDo not operate your layout unattended. Obstructed accessories or stalled trains may overheat, resulting in damage to your
layout.
lThistrainsetisintendedforindoor use. Donotuse ifwateris present. Seriousinjuryor fatalitymayresult.
lDonotoperatethehobbytransformerwith damagedcord,plug, switches,buttonsor case.
lThetransformerwasdesigned to operate on regular US household current(120volt,50-60Hertz). Donot connect to any other
sourceofpower.
lToavoid the risk ofelectricalshock, do not disassemblethetransformer unit. There are nouser-serviceableparts inside. If the
unitisdamagedcontactM.T.H.Servicefor instructions.
lThe transformer is equipped with an internal circuit protector. If the circuit protector trips, unplug the power cord from the
electrical wall outlet, check your layout for any short circuits. The circuit breaker will reset automatically when the short is
removedfromthecircuit.
lUnplugthetransformerfromtheelectricalwall outletwhennot inuse.
lDonotusethistransformerforother thanitsintended purpose.
Transformer Ratings:
Input: 120 VAC, 60 Hz Only, Outpu
This product may be protected by one or more of the following patents: 6,019,289; 6,280,278; 6,281,606; 6,291,263;
6,457,681; 6,491,263; 6,604,641; 6,619,594; 6,624,537; 6,655,640. ©2004, M.T.H. Electric Trains, Columbia, MD 21046
t: 14 VAC 80W or 18VAC 100W

Z Controller and
Transformer
Set Up Checklist
®
rAssemble RealTrax
rConnect the transformer
rLubricate the engine
rPrime the Smoke Unit
rPlace the engine and cars on the track and couple them together
rPosition remote lock-on lens
rApply power to run as described in the Basic Operation section of
these instructions.
Set Includes
Steam Engine with Loco-Sound™
Tools Needed
Cotton Swab or Rag
Philips Screwdriver RailKing Maintenance Kit or
Light Household Oil and Bearing Grease
Optional Equipment
Cassette PlayerMicrophone w/1/8” Plug 1/8” Male to Male Plug
DVD/CD-Rom
3
You can obtain replacement parts and replacement instructions from the
M.T.H. Parts Department
e-mail: [email protected]
phone: [phone]
mail: 7020 Columbia Gateway Drive, Columbia MD 21046-1532
Pliers
RailKing 2-8-0 Steam Freight Set with Loco-Sound™
Scissors
8-Pieces
O-31 Curve RealTrax
Steam Tender
N5C (PRR only) or Steel Caboose
Stock Car Tank Car or Gondola
4-Pieces
10” Straight RealTrax
Lighted Lock-On

Getting Started
®
Assembling RealTrax
The quick connectors and built-in roadbed allow you to set up RealTrax anywhere,
including carpeted surfaces.
Connecting the Transformer
The transformer included with this set provides an easy-to-use, safe power source for AC-
powered trains and accessories.
To complete the connection between the track and the transformer, simply plug in the
color-coded wire harness that was included in your set and plug the transformer into your
wall outlet.
• Plug the wire from the transformer into the Z-Controller’s center port.
!Connect the Wires from the Z-Controller to the Lighted Lock-On, being sure that the
!wires are connected from red-to-red and black-to-black.
!Unplug when not in use
4RailKing 2-8-0 Steam Freight Set with Loco-Sound™
Gently push together RealTrax
Insert lock-on into
knock-out tab
(Lock-on is the interface between
the track and transformer)
Make sure the metal
contacts line up. Align Quick
Connect Plugs
Knock-out must be removed
before remote lock-on can
be installed
Remove knock-out from
outer edge of track by
holding and twisting up
with a pair of pliers
REMOVE TAB
FROM OUTER EDGE
STEP
11STEP 22STEP 33
STEP
44STEP 55STEP 66
-750
DIRECTION
BELL
HORN
WHISTLE
POWER
AILING
RK
ByMTHElectricTrains
®
TRANSFORMER CONTROLLER
OFF
FULL
POWER
Also functions as a binding post.
Red Harness
Wire/Plug
Red Harness
Wire/Plug
Black Harness
Wire/Plug Black Harness
Wire/Plug

Lubricating the Engine
Lubricate all exposed moving parts before operating, using a multi-purpose,
plastic-compatible oil (available with M.T.H.'s Maintenance Kit, sold
separately) or a light household oil. Follow the lubrication points.
Priming the Smoke Unit
You should prime the smoke unit with smoke fluid before
operating. Add 15-20 drops of smoke fluid from the
included pipette through the smokestack, then gently blow
into the stack to eliminate any air bubbles in the fluid.
If you choose not to prime the unit with fluid, turn the
smoke unit switch located under the tender to the OFF
position. Running the engine without a primed smoke
unit may cause damage. See the "ProtoSmoke Unit
Operation" section of this book for more information
on smoke unit maintenance.
DO NOT
OVER OIL
DO NOT
OVER OIL
DO NOT
OVER OIL
Lubricate Valve Gear Lubricate Pick-Up Rollers
(Do Not Oil the Flat Part of
Pick-Up Rollers)
Lubricate Side Rods
Position
armature
for proper
operation
Incorrect
Position Place the engine and cars
on the track.
Open couplers by
pressing down on plunger.
Push cars together to
couple.
5
RailKing 2-8-0 Steam Freight Set with Loco-Sound™
STEP
11STEP 22STEP 33
Running the engine without a primed
smoke unit may cause damage
Smoke Unit
ON/OFF Switch
Add 15-20 Drops
Smoke Fluid

!Plug tender plug into boiler socket at the back of cab.
!Connect the draw bar between the engine and tender.
DO NOT CONNECT
This Engine To A
Tender From
Another Engine; It May
Cause Serious Damage.
Look at the bottom of the
engine and tender where
each will have a color-coded
stamp. If they match you
may connect those two
pieces; if not, don't.
6RailKing 2-8-0 Steam Freight Set with Loco-Sound™
CABLE CURVES
UPWARD

7
RailKing 2-8-0 Steam Freight Set with Loco-Sound™
Basic Operation
The Throttle knob controls how fast your train will travel.
!Turn the throttle knob up ½-way, until the engine and caboose lights shine bright.
!Put the engine into motion by pressing the Direction button on your transformer once.
(hold it for approximately 1 second)
If the engine does not begin to move as soon as you firmly press the Direction button, you
may not have sent enough voltage to the track to make the train move. Turn the throttle up
a bit higher until the train begins to move.
Operation Buttons
Throttle To increase or decrease track voltage, and therefore train speed, turn the throttle
control knob. Turning it clockwise will increase voltage and speed, while turning it
counterclockwise will decrease voltage and speed. The engine will maintain the speed
you set after you release the throttle until you turn it again to change the voltage and
speed.
Horn/Whistle - To sound the whistle, firmly press the Horn/Whistle button. The horn will
sound for as long as you continue to depress the button. It will stop when you release the
button.
Bell - To sound the bell, firmly press the bell button. The bell sound will continue until
the bell button is firmly pressed a second time.
Direction Your train is programmed to start in neutral. The
train will always cycle neutral-forward-neutral-reverse with
each press and release of the direction button. The engine is
programmed to restart in neutral each time the track voltage
is turned off for 25 seconds or more.
Speed Control
M.T.H. engines equipped with Loco-Sound have speed control capabilities that allow the
engine to maintain a constant speed up and down grades and around curves, much like an
automobile cruise control. You can add or drop cars on the run, and the engine will
maintain the speed you set.
While the engine is programmed to start with the speed control feature activated, you can
opt to turn it off. This means the engine's speed will fall as it labors up a hill and increase
as it travels downward. It is also affected by the addition or releasing of cars while on the
run. To maintain a constant speed when speed control is turned off, you need to adjust
track voltage yourself.
To turn speed control on and off,put the engine in neutral, then quickly tap the
transformer's Whistle button one time then quickly tap the Bell button two times, allowing
approximately ½ second to lapse between each quick button press. Repeat the 1 whistle, 2
bells code to return it to the other condition. You will want to do this during the initial
neutral upon start-up if you ever couple this engine to another engine that is not
equipped with speed control to avoid damaging the motors in either engine. Each
time you shut down the engine completely, it will automatically turn speed control on.

Direction Lock
You can lock your engine into a direction (forward, neutral, or reverse) so that it will not
change directions. To do this, put the engine into the direction you want or into neutral, to
lock it into neutral, run it at a very slow crawl (as slowly as it will move without halting),
and quickly but firmly tap the Whistle button once followed by three quick taps of the
Bell button, allowing approximately ½ second to lapse between each quick button press.
The engine will not change direction (including going into neutral) until you repeat the 1
whistle, 3 bells code to return the engine to its normal condition, even if the engine is kept
without power for extended periods of time.
Proto-Cast and Proto-Dispatch:
When used with the remote lock-on included in this set, Loco-Sound equipped engines
™™
gain Proto-Cast and Proto-Dispatch features.
Proto-Cast: Allows you to play audio recordings through your engine's speaker.
Your set includes an audio source (a small portable CD/tape player) and
a male-to-male mini cable (1/8" plug) to connect the audio source to the
remote lock-on.
To use Proto-Cast
!Plug the mini-cable first into your audio source (into the headphone jack)
!Plug Cable into the "Audio" port on the right side of the remote lock-on.
!Adjust the volume. If engine sounds keep breaking through the recorded sounds,
increase the volume on the audio source.
8RailKing 2-8-0 Steam Freight Set with Loco-Sound™
Timing Chart
Total Time Lapse: 1 Seconds½
Press
Whistle
Short &
Firm
½ Sec.
Pause ½ Sec. Pause
Press
Bell
Short &
Firm
Press
Bell
Short &
Firm
Whistle
Place
Engine into
Neutral
Bell Bell
Speed Control
Repeat to Return
to Normal Condition
=
Place
Engine into
Desired
Direction
Whistle
Bell Bell Bell
Direction Lock
Repeat to Return
to Normal Condition
=
1/8" plug
+
=
Proto-Cast
+
Proto-Dispatch Proto-Cast

Proto-Dispatch: This feature allows you to broadcast your own voice through your
engine's speaker You must supply the microphone for use with the mini cable (1/8”
plug) in this set to connect your microphone to the remote lock-on.
To use Proto-Dispatch
!Connect the microphone to the mini-cable with 1/8” plug included in this set..
!Plug the ”Cable" into the proto-dispatch port on the left side of the remote lock-on
and speak into the microphone.
When these features are in use, the locomotive's own sounds (engine sounds and bells,
whistles, and horns) will be muted so that only the sounds you broadcast will be heard.
Because Proto-Cast and Proto-Dispatch are voice activated, there will be a several second
delay after you stop speaking into the microphone or turn off the audio source before the
engine sounds resume. To stop using the feature and return to normal operation, unplug
the cable from the lock-on jack.
If using parallel tracks with multiple Loco-Sound equipped engines, Proto-Cast and
Proto-Dispatch transmissions from one track may be picked up by the other nearby
engines.
If you experience popping and interference when using Proto-Cast or Proto-Dispatch, try
cleaning the track as described in the "Cleaning the Wheels, Tires and Track" section of
this booklet.
Manual Volume Control
To adjust the volume of all sounds made by this engine, turn the master volume control
knob located under the tender clockwise to increase the volume and counter-clockwise to
decrease the volume.
9
RailKing 2-8-0 Steam Freight Set with Loco-Sound™
1/8" plug
+ = Proto-Dispatch
Proto-Dispatch
Proto-Dispatch
NOTE: M.T.H. does not recommend using Proto-Cast
and Proto-Dispatch at the same time.
increase

Maintenance
Lubrication Instructions
The engine should be oiled and greased in order to run properly.
Regularly lubricate all side rods and linkage components and pickup rollers to prevent
squeaking. Use light household oil, such as that found in M.T.H.'s maintenance kit. Do
not over oil. Use only a drop or two on each pivot point.
Greasing Instructions
The locomotive's internal gearing was greased at the factory. Grease engine every 50
hours of use or one year. Use a lithium based grease and follow the greasing instructions.
Cleaning the Wheels, Tires and Track
Periodically check the locomotive wheels and pickups for dirt
and buildup, which can cause poor electrical contact and
traction and prematurely wear out the neoprene traction tires.
Wheels and tires can be cleaned using denatured (not rubbing)
alcohol applied with a cotton swab.
To clean the track, use RailKing Track Cleaning Fluid or
denatured (not rubbing) alcohol and a clean rag. Unplug the
transformer and wipe the rails of the track, turning the rag frequently to ensure that you
are using clean cloth on the rails. Because the manufacturing process leaves a coating on
RealTrax center rail, you should clean the rails after the first 30 minutes of use (you may
notice an electrical smell during initial use as the coating wears off; this is normal).
Thereafter, keep an eye on the track and clean it when it gets dirty to ensure good
electrical contact and to lengthen the life of the tires.
10 RailKing 2-8-0 Steam Freight Set with Loco-Sound™
DO NOT
OVER OIL
DO NOT
OVER OIL
DO NOT
OVER OIL
Lubricate Valve Gear Lubricate Pick-Up Rollers
(Do Not Oil the Flat Part of
Pick-Up Rollers)
Lubricate Side Rods
!Remove the screw from the chassis to open
the grease port.
!Insert the grease tube tip into the port and
squeeze the tube once or twice to add grease
to the gearbox.
!Wipe off any excess grease and replace the
phillips screw securely.
GREASE
GREASE

TractionTire Replacement Instructions
Your locomotive is equipped with two neoprene rubber traction tires on the rear set of
flanged drivers. While these tires are extremely durable, they may need occasionally
need to be replaced.
11
RailKing 2-8-0 Steam Freight Set with Loco-Sound™
!Remove the side rod screws (the rods that connect each drive wheel to the other)
from the wheels in order to slip the old tire off of the grooved drive wheel. These
screws can be loosened with a 5mm nutdriver.
!Clean the groove using a cotton swab and denatured alcohol.
!Make sure the old tire has been completely removed from the groove in the drive
wheel, using a razor blade or small flathead screwdriver to pry away any remains.
!Clean the groove using a cotton swab and denatured alcohol.
!Slip the new tire onto the wheel. You may find it useful to use two small flathead
screwdrivers to stretch the tire over the wheel.
!If you twist the tire while stretching it over the wheel, you will need to remove and
reinstall the tire. Otherwise your engine will wobble while operating.
!Make sure the tire is fully seated inside the groove. Use a razor blade to trim away
any excess tire that doesn't seat itself inside the groove properly.
STEP
11
STEP
22

®
ProtoSmoke Unit Operation
This steam locomotive contains a smoke unit that outputs
smoke through the smokestack on the boiler of the
engine. The smoke unit is essentially a small heating
element and wick that soaks up and then heats a mineral
oil-based fluid that emits a harmless smoke. The smoke
is then forced out of the stack by a small electric fan.
With a few easy maintenance steps, you should enjoy
trouble-free smoke unit operation for years.
!When preparing to run this engine, add 15-20
drops of smoke fluid through the smokestack.
We recommend M.T.H. ProtoSmoke, Seuthe, LGB,
or LVTS fluids (a small pipette of ProtoSmoke fluid
is included). Do not overfill the unit or the fluid
may leak out and coat the interior engine components.
!If you choose not to add the fluid (or have already
added the fluid but choose to run smoke-free), turn
off the smoke unit switch located under the tender
body. Failure either to add fluid to the unit or
to turn it off may damage the smoke unit heating
element and/or wicking material.
When the smoke output while running the engine
begins to diminish, add another 10-15 drops of
smoke fluid or turn the smoke unit off.
!When storing the unit for long periods of time, you
may want to add about 15 drops of fluid to prevent
the wick from drying out.
!After removing the engine from storage, add another
25 drops of fluid, letting the wick soak up the fluid
for 15 minutes prior to operation.
If you experience poor or no smoke output when the
smoke unit is on and has fluid, check the wick to see if it
has become hard, blackened, and unabsorbent around the
heating element. Remove the boiler as shown below. Remove the smoke unit inspection
cover from the locomotive's body (see right). After removing the chassis and inspection
cover screws, lift the inspection plate away and inspect the wick. If it is darkly
discolored and hard, it should be replaced. When priming new wick add 40 drops.
!
12 RailKing 2-8-0 Steam Freight Set with Loco-Sound™
Wick in
Poor
Condition
Wick in
Good
Condition
Smoke Unit Cover
Add 15-20 Drops
Smoke Fluid
Add 15-20 Drops
Smoke Fluid
Smoke Unit
ON/OFF Switch
Running the engine without a primed
smoke unit may cause damage

Locomotive Light Bulb Replacement
Caboose Light Bulb Replacement
To replace the interior light bulbs follow these instructions and see the diagrams below.
To replace the light bulb in the locomotive, follow the boiler removal instructions below.
13
RailKing 2-8-0 Steam Freight Set with Loco-Sound™
Remove the six Phillips screws from the chassis then lift the body away from the chassis.
STEP
11
Replace Headlight Bulb
STEP
22Once the locomotive boiler has been removed
from its chassis, locate the bulb bracket as seen in
the illustration on the right and rotate the
headlight bulb counter-clockwise to remove.
Remove the four (4)
screws located
under the caboose's
Lower the chassis from
the shell, taking care not
to pull the wires out.
Carefully loosen
the end frames
on both ends
from the step
platform.
Then grasp the
end frame by the
bottom and pivot
outward 5
Lower the
chassis
from the
shell, taking
care not to
pull the
wires out.
Step Platform
End
Frame
Bayonet Bulb
(Part #CI-0000015)
1
2
Replace a Bayonet Bulb by turning
and pushing up, pulling the bulb
from its socket.
STEP
11STEP 22
STEP
33STEP
44
STEP
55

RailKing 2-8-0 Steam Freight Set with Loco-Sound™
Quick-Start DVD
The included Quick-Start DVD demonstrates the start-up and basic operation of this set
as well as other information about model railroading. You may find it helpful to view the
DVD before operating this set.
RailWare Interactive CD ROM
M.T.H. provides a free RailWare CD ROM in each Ready-To-Run set. It is full of
helpful information on M.T.H. product history, track planning software, a dealer finder,
and information and video clips on Loco-Sound and Proto-Sound 2.0. Follow the
directions below to use the CD ROM.
Minimum System Requirements: Pentium 100, 16MB RAM, Windows 95 or later, CD
ROM drive, Sound Card, display properties set to greater than 256 colors. The CD will
®
not work on a Mac OS unless you run VirtualPC .
Running RR-Track Software
You may run the RR-Track software directly off of the CD ROM or you may install the
software to your hard drive.
1. On the Desktop, click on the icon that says My Computer.
2. Find your CD ROM drive.
3. With the M.T.H. CD ROM in the drive, double click on the icon for the CD ROM
drive.
4. Find the folder on the CD ROM entitled INSTALLATION.
5. Choose the folder inside entitled RRTRAXSETUP.
6. Run the file in that folder called SETUP.EXE and follow the directions it provides.
The program may ask you for a registration code. If it does type in "M.T.H." and it will
run.
Additional track libraries can be obtained directly from RR-Track. See their website for
more information www.rrtrack.com.
Installing Adobe Acrobat Software
To read some of the electronic documents included on the CD ROM, you will need to
®
install the Adobe Acrobat Reader if it is not already on your computer. To install the
software:
1. On the Desktop, click on the icon that says My Computer.
2. Find your CD ROM drive.
3. With the MTH CD ROM in the drive, double click on the icon for the CD ROM
drive.
4. Find the folder on the CD ROM entitled INSTALLATION.
5. Choose the folder inside entitled ACROBAT READER.
*If you are running Windows 95, 98 or NT choose the folder 32 BIT. Run the file
AR32E301.EXE and follow the directions it provides.
If you have problems you cannot resolve by using these directions, contact
[email protected] or call 410-381-2580 for further help.
14

™
Troubleshooting Loco-Sound Problems
Although Loco-Sound has been designed and engineered for ease of use, you may have
some questions during initial operation. The following table should answer most
questions. If your problem cannot be resolved with this table, contact M.T.H. for
assistance (e-mail: [email protected]; telephone: [phone];
fax: [phone]; mail: 7020 Columbia Gateway Drive, Columbia MD 21046-1532).
RailKing 2-8-0 Steam Freight Set with Loco-Sound™ 15
Starting Up
Whistle
Bell
Remedy
Remedy
Remedy
When I first turn the power on, the
enginewillnotbegintorun.
The engine will not start after I press
theDirectionbutton.
I can't get the whistle to blow when I
pressthewhistlebutton.
I can't get the bell to ring when I press
thebellbutton.
You may be pressing the button too quickly. Try pressing
the whistle button more slowly, taking approximately one
fullsecondtofullydepressthebutton.
You may be pressing the button too quickly. Try pressing
the bell button more slowly, taking approximately one full
secondtofullydepressthebutton.
This is normal behavior. To prevent accidental high-speed
start-ups, Loco-Sound is programmed to start up in neutral
anytimetrackpower has beenturnedoffforseveralseconds.
Seethe"BasicOperation"sectionformoredetails.
You may not be sending enough power to the track to power
the engine. Press the throttle up for a few more seconds to
increasetrackpower.
Lock-out Remedy
I can't get the engine to run after I
power up the transformer. It sits still
withtheenginesoundsrunning.
The engine won't lock into forward,
neutral,orreverse.
The engine may be locked into the neutral position. Follow
the procedure in the "Lock into a Direction" section to
unlocktheengine'sdirection.
Enginespeed must bebelow 10scale mph (approx. 10 volts
orlessinconventionalmode).
Volume Remedy
The sounds seem distorted,
especially when the Horn or bell is
activated.
No sound.
Loco-Sound volume is set too high. Turn the volume
control knob on the bottom of the tender counter-clockwise
toreducethevolume.
Volume is set too low, adjust volume control knob on the
bottom of the chassis clockwise to increase the volume or
checkconnectortospeaker.
Proto-Cast and -Dispatch
Proto-Cast and -Dispatch Remedy
Clean the track with denatured alcohol, as described in the
"Cleaning the Wheels, Tires, and Track" section of this
book.
Unplug the cable between the audio source and the remote
lock-on. Re-plug it into the audio source first, then into the
lock-on, pushing firmly to make sure it is fully installed.
Your recording may be playing too quietly to trigger the
engine to stop playing its own sound set. Turn up the
volume of the audio source you are using.
This is normal behavior. Because Loco-Sound uses radio
waves to transmit the sound to the engine, other Loco-
Sound engines in the same range will also pick up the
sound. Try moving one of the sets.
When I try to play music or my
voice through my engine's speakers,
there is popping and interference.
My Proto-Cast sounds play too
quietly or unclearly.
When I try to play Proto-Cast, the
engine's sounds keep breaking in on
my recording.
When I run two Loco-Sound
engines on tracks near each other,
the Proto-Cast and Dispatch sounds
play from both engines, not just
from the one connected to the audio
source or microphone.

Compatibility
While this Ready-To-Run set is equipped with everything you need to operate it, the
design allows flexibility. The train will operate on any traditional O-31 or larger O
®
Gauge track system, including the RealTrax included with this set or traditional tubular
track. It is also compatible with most standard AC transformers, including the hobby
transformer packaged with your set.
TransformerCompatibility and Wiring Chart
Note that many of the operational commands described in these instructions require a
bell button, so if you are using a transformer other than the one included in this set and
your transformer does not have its own bell button, you should consider adding one to
get the full benefit of the system.
RailKing 2-8-0 Steam Freight Set with Loco-Sound™
16
Transformer
Model Center Rail Outside Rail Min/Max. Voltage Power Rating Transformer Type
Lionel 1032 U A 5-16v 90-Watt Standard
Lionel 1032M U A 5-16v 90-Watt Standard
Lionel 1033 U A 5-16v 90-Watt Standard
Lionel 1043 U A 5-16v 90-Watt Standard
Lionel 1043M U A 5-16v 90-Watt Standard
Lionel 1044 U A 5-16v 90-Watt Standard
Lionel 1053 U A 8-17v 60-Watt Standard
Lionel 1063 U A 8-17v 60-Watt Standard
All-Trol Left Terminal Right Terminal 0-24v 300-Watt Electronic
Dallee Hostler Left Terminal Right Terminal Electronic
Lionel LW A U 8-18v 75-Watt Standard
Lionel KW A or B U 6-20v 190-Watt Standard
Lionel MW Outside Track
Terminal Inside Track Terminal 5-16v 50V.A. Electronic
Lionel RS-1 Red Terminal Black Terminal 0-18v 50V.A. Electronic
Electronic
Lionel RW U A 9-19v 110-Watt Standard
Lionel SW U A Unknown 130-Watt Standard
Lionel TW U A 8-18v 175-Watt Standard
Lionel ZW
Lionel Post-War
Celebration
Series ZW
A,B,C or D
A,B,C or D
U
Common
8-20v
0-20v
275-Watt
135/190 Watt
Standard
MTH Z-500 Red Terminal Black Terminal 0-18v 50-Watt Electronic
MTH Z-750 Red Terminal Black Terminal 0-21v 75-Watt Electronic
MTH Z-4000 Red Terminal Black Terminal 0-22v 390-Watt Electronic
MTH Z-1000 Red Terminal Black Terminal 0-14v
0-18v 80-Watt 100-Watt Electronic

2-8-0 Steam Locomotive Engine Parts
Name and Number Part #
1.) Stanchion ( black ) FB-1200242
( plastic )( 3.0mm long )
2.) Handrail ( nickel )( boiler ) FB-1200099
3.) Bell ( nickel ) FB-1200101
4.) Boiler Shell ( PRR cab# 8014, #30-4103-0E ) FB-1200331
( SF cab# 2512, #30-4119-0E ) FB-1200337
5.) Lens ( green )( marker ) FA-1230025
6.) Lens ( clear )( headlight ) FA-1230022
7.) Number board ( PRR cab #8014 ) FB-1200332
(SF cab #2512) FB-1200338
8.) Smoke unit AA-0000029
( 7.0x8.0x2.0x3.7mm brass cup )( 7.5mm long posts )
( Proto-Sound 2.0® & Loco Sound™ )
9.) Bulb ( clear )( headlight ) CA-0000038
( 6V )( small globe )( screw base)
10.) Bracket ( black ) IH-0000085
( smoke unit / headlight )
11.) Screw IA-0000003
( 4/40x6.0mm )( roundhead )
12.) Crosshead ( blackened finish ) EC-1250036
( 38.8mm long )
13.) Drive rod ( blackened finish ) EC-1250037
14.) Drive block (black)(4 axle) DF-1200018
15.) Bolt ( blackened finish ) IA-0000373
( hex head 5.0mm )( M3x9.5mm long )
( 4.0x2.5mm shoulder )
16.) Side rod ( blackened finish ) EC-1250038
( 116.0mm long )( 4 holes )
17.) Traction tires DE-0000023
18.) Insulator ( black ) BD-0000026
( top )( square )( pick-up )
19.) Screw ( nickel ) IA-0000015
( M3x6.0mm )( roundhead )
20.) Wire strap ( white ) IH-0000103
( metal )( tab bends over wires )
21.) Tach board AG-0000048
( no spacer between board and optical sensor )
( has a tiny resister on backside of tach board )
22.) Motor ( RS-365SH ) BE-0000076
( 8.0x21.0mm gear shaft )( 13.0mm gear threads )
( 9.0x30.0mm white flywheel w/ black stripes )
( tach board mounting strap )
23.) Screw IA-0000050
( 6/32x8.0mm )( roundhead )
24.) Motor mount ( black ) BI-0000034
RailKing 2-8-0 Steam Freight Set with Loco-Sound™ 17

RailKing 2-8-0 Steam Freight Set with Loco-Sound™
18
26.) Wire nut ( yellow ) BI-4500003
27.) PC board ( green ) AG-0000039
( w/ 10 pin female plug )
28.) Draw bar ( black ) FB-1200079
( 67.5mm long )
29.) Spring IE-0000061
( 6.5x10.0mm )( w/ 0.6mm thick wire )
30.) Screw IA-0000028
( 4/40x6.0mm )( washer head )
31.) Nut ( nickel )( 2.5x5.0x10.0mm ) IC-0000005
32.) Insulator ( black ) BD-0000024
( pick-up )( bottom )( flat )( square )
33.) Pick-up BD-0000050
( 8.0x11.0mm roller )( 24.0mm long )
34.) Bolt ( nickel ) IA-0000253
( M3x9.5mm long )( 4.0x2.5mm shoulder )
( 5.0mm hex head )
35.) Truck ( lead )( single axle ) DA-1230013
36.) E-clip ( 2.5x6.0x0.5mm ) IF-0000004
37.) Washer ( 3.0x7.0x0.4mm ) ID-0000028
38.) Spring IE-0000007
( 6.5x11.0mm )( w/ 0.4mm thick wire )
39.) Pin IG-0000007
( 3.0x9.0mm )( flathead )( 1 e-clip groove )
40.) Pivot plate ( nickel ) IH-0000021
( for lead truck )
41.) Bracket ( black ) IH-0000211
( metal )( 18.6x32.4x40.5mm )( T shaped )
42.) Ferrite bead AI-0000030
43.) Capacitor ( blue )( .01 uF ) AI-0000031
( 16.0x2.0mm )( w/ 2 wires )
44.) Steam dome ( black ) FB-1200247
45.) Sand dome ( black ) FB-1200246
46.) Washer ( black ) ID-0000040
( 3.0x6.0x0.4mm )( fiber )

RailKing 2-8-0 Steam Freight Set with Loco-Sound™ 19
2-8-0 Steam Locomotive Engine Parts
23
17
16
13
40
17
39
38 37
36 35
34
12
19
33
32
31
5
6
12
13
15
14
15
9
8
15
16
10
2
2
30
29
28
26
42 43
27
22
21
5
4
20
3
44
11
46
23
41
45
11
23
11
19
18
11
23
25
11
23
1
1
24
7
15
15

RailKing 2-8-0 Steam Freight Set with Loco-Sound™
20
2-8-0 Steam Engine Tender Parts
Name and Number Part #
1.) Tender Shell ( PRR, # 30-4103-0E ) GA-1200125
(SF, # 30-4119-0E) GA-1200128
2.) Board AE-0000003
( Loco-Sound™ )( steam/turbine )
3.) Screw IA-0000011
( 4/40x8.0mm )( roundhead )
4.) Insulator ( white ) ID-0000025
( washer )( 3.0x6.0x3.0mm )( plastic )
5.) Insulator ( clear ) ID-0000024
( 13.0x19.0x0.1mm )( single hole )
6.) Screw IA-0000010
( M3x4.0mm )( roundhead )
7.) Screw IA-0000016
( M3x6.0mm )( roundhead )
8.) Wire nut ( yellow ) BI-4500003
9.) Speaker cone ( black ) BF-0000020
( 44.0x48.3x37.0mm )( plastic )( 2 screw hole tabs )
10.) Speaker (8 ohm) BF-0000015
11.) Wire harness ( black ) BC-1200103
12.) Screw IA-0000058
( M2x4.0mm )( roundhead )
13.) Switch ( small ) BB-0000009
14.) Screw IA-0000003
( 4/40x6.0mm )( roundhead )
15.) Bracket ( Aluminum ) IH-0000212
( for Loco-Sound™ board )
( 14.0x76.0x24.7mm )( 5.0mm step )
16.) Screw IA-0000035
( M3x8.0mm )( roundhead )
17.) Volume pot ( small ) BI-0000040
( blue w/ green board )
18.) Spacer ( black ) ID-0000071
( 3.0x6.0x4.0mm )( plastic )
19.) Chassis ( black ) GB-1200047
( 58.0x175.0mm )( has new hole for battery jack )
20.) Screw IA-0000025
( M3x16.0mm )( washer head )( self-drilling threads )
21.) T-bar IG-0000001
22.) Coupler ( black ) DD-0000039
( mechanical )( 51.5mm long )
23.) Armature ( black ) DD-0000040
( 45.0mm long )
24.) Spring IE-0000007
( 6.5x11.0mm )( w/ 0.4mm thick wire )
