RAILKING 4-6-2 K-4
STEAM ENGINE
OPERATING
INSTRUCTIONS
This RailKing Steam Engine contains M.T.H.’s Loco-Sound™ sound and train control
system. The locomotive is easy to operate with any compatible standard AC transformer
(see the compatibility chart on page
14 ), and is completely compatible with most other
3-rail locomotives, rolling stock, and accessories.
M.T.H. takes pride in manufacturing high quality products like your RailKing steam
engine, and we hope that you will enjoy it for a long time. Please read all the
accompanying instructions carefully before setting up and operating your locomotive.
With proper care, this engine should yield years of trouble-free performance.

2
RailKing 4-6-2 K-4 Steam Engine
Table of Contents
Set Up 3
Basic Operation 4
Throttle 4
Operation Buttons 4
Speed Control 5
Direction Lock 5
Proto-Cast and Proto-Dispatch 6
VolumeControl 7
Maintenance 8
Lubrication and Greasing Instructions 8
Cleaning the Wheels, Tires and Track 9
Locomotive Traction Tire Replacement 9
Smoke Unit Maintenance 10
Locomotive Light Bulb Replacement 11
Troubleshooting 12
Compatibility 13
Transformer Compatibility Chart 14
Safety Precautions 15
Service and Warranty Information 16

3
RailKing 4-6-2 K-4 Steam Engine
Set Up
There are a few simple steps you
must take before operating this RailKing
steamer.
• You should prime the operating smoke unit with smoke fluid before
operating. Add 15-20 drops of smoke fluid through the smokestack, then
gently blow into the stack to eliminate any air bubbles in the fluid. See Fig.
4.
• If you choose not to prime the unit with fluid, turn the smoke unit switch
located under the engine to the OFF position (Fig.
5). Running the engine
without a primed smoke unit may cause damage. See the “ProtoSmoke Unit
Operation” section of this book for more information on smoke unit
maintenance.
• You should lubricate all side rods and linkage components and pickup rollers
to prevent them from squeaking. Lightly grease the outside idler and drive
gears (marked “G” in Fig.
3on page 8) to prevent them from squeaking. Use
light household oil and follow the lubrication points marked “L” in Fig.
2on p.
8
. Do not over-oil. Use only a drop or two on each pivot point.
• Put your engine on the track and insert the reverse unit plug that extends out
of the tender into the receptacle at the back of the engine. WARNING: DO
NOT CONNECT THIS ENGINE TO A TENDER FROM ANOTHER
ENGINE; IT MAY CAUSE SERIOUS DAMAGE.
• Connect the draw bar between the engine and tender. If there are two holes
in the draw bar, the hole located farthest from the tender is for the minimum
track operation, such as O-31 circles of track. The second hole is for O-72 or
larger operation.
At this point, you are ready to begin running your engine.

4
RailKing 4-6-2 K-4 Steam Engine
Basic Operation
Throttle – Throttle up the power to your track by either firmly pressing the
Direction button on your transformer or remote once or quickly dropping and
advancing the throttle to put the engine in forward.
Operation Buttons
Use the operation buttons on your transformer as described below.
Horn/Whistle - To sound the whistle, firmly press the Horn/Whistle button.
The whistle will sound for as long as you continue to depress the button. It
will stop when you release the button.
Bell - To sound the bell, firmly press and release the Bell button. To turn the
bell off, press and release the Bell button again. The bell will continue to ring
from the time your turn it on until you press and release the button again to
turn it off.
·Direction – Your train is programmed to start in neutral. To put the engine
into forward and then to change the direction of the train or to put it into
neutral, firmly press and release the Direction button on your transformer. Just
as you must stop your car between forward and reverse, this engine will not go
directly from forward to reverse; it goes into neutral between directions. If the
train has been moving forward, the first press of the Direction button will put
the train from forward into neutral, the second press into reverse, the third
press back into neutral, and the fourth back into forward.To prevent accidental
high-speed start-ups, this engine is programmed to restart in neutral each time
the track voltage is turned off for 25 seconds or more.

5
RailKing 4-6-2 K-4 Steam Engine
Speed Control:
M.T.H. engines equipped with Loco-Sound have speed control capabilities that
allow the engine to maintain a constant speed up and down grades and around
curves, much like an automobile cruise control. You can add or drop cars on
the run, and the engine will maintain the speed you set.
While the engine is programmed to start with the speed control feature
activated, you can opt to turn it off. This means the engine’s speed will fall as
it labors up a hill and increase as it travels downward. It is also affected by the
addition or releasing of cars while on the run.
To turn speed control on and off,
put the engine in neutral, then press the
transformer’s Whistle button firmly but quickly one time then immediately
press the Bell button two times. Repeat the 1 whistle, 2 bells code to return it
to the other state.
You will want to do this during the initial neutral upon
start-up if you ever couple this engine to another engine that is not
equipped with speed control to avoid damaging the motors in either
engine.
Each time you shut down the engine completely, it will automatically
turn speed control on.
Direction Lock:
You can lock your engine into a directional state (forward, neutral, or reverse)
so that it will not change directions. To do this, put the engine into the
direction you want or into neutral, to lock it into neutral, run it at a very slow
speed (< 10 scale mph), and quickly but firmly press your transformer’s
Whistle button once followed immediately by three presses of the Bell button.
The engine will not change direction (including going into neutral) until you
repeat the 1 whistle, 3 bells code to return the engine to its normal state.
Feature to Be Activated:
SpeedControlOn/Off
Lock into a Direction/Unlock
Button Code:
1 Whistle, 2 Bells
1 Whistle, 3 Bells

6
RailKing 4-6-2 K-4 Steam Engine
Proto-Cast and Proto-Dispatch:
When used with the RailKing Remote Lock-on (sold separately),
Loco-Sound-equipped engines gain Proto-Cast™and Proto-Dispatch™
features.
Proto-Cast: This feature allows you to play audio recordings through your
engine’s speakers. You must supply the audio source (a small portable is
sufficient) and a male-to-male mini cable (1/8” plug, like that used for the
headset with a portable CD/tape player) to connect your audio source to the
remote lock-on. To use Proto-Cast, simply plug the mini-cable into your
audio source (usually into the headphone jack) and into the “Audio” port on
the right side of the remote lock-on and adjust the volume.
Proto-Dispatch: This feature allows you to broadcast your own voice
through your engine’s speakers. You must supply the microphone and a mini
cable (1/8” plug, like that used for the headset with a portable CD/tape player)
to connect your microphone to the remote lock-on. To use Proto-Dispatch,
simply plug the mini-cable into the microphone and into the “Mic” port on the
left side of the remote lock-on and speak into the microphone.
When these features are in use, the locomotive’s own sounds (engine sounds
and bells, whistles, and horns) will be muted so that only the sounds you
broadcast will be heard. Because these two features are voice activated, there
will be a 10-15 second delay after you stop speaking into the microphone or
turn off the audio source before the engine sounds resume. To stop using the
feature and return to normal operation, unplug the cable from the lock-on jack.
If using parallel tracks with multiple Loco-Sound-equipped engines,
Proto-Cast and Proto-Dispatch transmissions from one track may be picked up
by the other nearby engines.
If you experience popping and interference, try cleaning the track with
denatured alcohol as described in the “Cleaning the Wheels, Tires and Track”
section of this booklet.
Note: M.T.H. does not recommend using Proto-Cast and Proto-Dispatch
at the same time.

7
RailKing 4-6-2 K-4 Steam Engine
Volume Control
–To adjust the volume of all sounds made by this engine,
turn the master volume control knob located under the engine clockwise to
increase the volume and counter-clockwise to decrease the volume (see Fig. 1).
Proto-Sound 2.0
VolumeAdjustmentKnob
Figure 1. Location of the Proto-Sound 2.0 Volume Adjustment Knob

8
RailKing 4-6-2 K-4 Steam Engine
Maintenance:
Lubrication and Greasing Instructions
The engine should be oiled and greased in order to run properly.
You should regularly lubricate all side rods and linkage components and
pickup rollers to prevent them from squeaking. Use light household oil and
follow the lubrication points marked “L” in Fig. 2. Do not over oil. Use only
a drop or two on each pivot point.
Engine-mounted PCB:
The locomotive’s internal gearing was greased at the factory and should not
need additional grease until after 50 hours of operation or one year, whichever
comes first. To access the gear box, do the following:
• Unscrew the chassis screws as shown in Fig. 3and remove the boiler.
• Once the boiler is removed, you need to remove the two screws that screws
the PCB board and bracket to the motor mounting bracket.
x2
x1
Grease Drive Gear (G)
Body Mount Screws Body Mount Screws
Figure 3. Locations of Body Mount Screws and Diagram for Greasing the
Drive Gear
Lubricate Siderods (L)
Lubricate Pick Up Rollers (L)
Lubricate Pivot Point
Figure 2. Lubricating the Engine

9
RailKing 4-6-2 K-4 Steam Engine
•
Carefully lift the PCB board and bracket to access the gear box.
•
Open the gear box by unscrewing the screws on the plate located in front of
the motor.
•
Use a grease tube dispenser to put a small amount of lithium-based grease
into the gearbox.
•
Reassemble the engine in reverse order.
Cleaning the Wheels, Tires and Track
Periodically check the locomotive wheels and pickups for dirt and buildup,
which can cause poor electrical contact and traction and prematurely wear out
the neoprene traction tires. Wheels and tires can be cleaned using denatured
alcohol (not rubbing alcohol), which can be found in home improvement
stores, applied with a cotton swab.
Occasional cleaning of the track will also help to ensure good electrical contact
and to prolong the life of your engine’s tires. To clean the track, use a clean
rag and denatured alcohol (not rubbing alcohol). Unplug the transformer and
wipe the rails of the track, turning the rag frequently to ensure that you are
using clean cloth on the rails.
Traction Tire Replacement Instructions
Your locomotive is equipped with two neoprene rubber traction tires on the
rear set of flanged drivers. While these tires are extremely durable, you may
need to replace them at some point.
•
Remove the side rods (the rods that connect each drive wheel to the other)
from the wheels in order to slip the new tire over the grooved drive wheel.
This screw can be loosened with a 5mm nutdriver.
•
Make sure the old tire has been completely removed from the groove in the
drive wheel, using a razor blade or small flathead screwdriver to pry away any
remains.
•
Slip the new tire onto the wheel. You may find it useful to use two small
flathead screwdrivers to stretch the tire over the wheel.
• If you twist the tire while stretching it over the wheel, you will need to
remove and reinstall the tire. Otherwise your engine will wobble while
operating.

10
RailKing 4-6-2 K-4 Steam Engine
•Make sure the tire is fully seated inside the groove. Use a razor blade to trim
away any excess tire that doesn’t seat itself inside the groove properly.
One set of replacement tires is included with the model. Additional tires are
available directly from the M.T.H. Parts Department (phone: [phone];
fax: [phone]; e-mail: [email protected]; mail: 7020 Columbia
Gateway Drive, Columbia MD 21046-1532).
ProtoSmoke®Unit Operation
This steam locomotive contains a smoke unit that outputs smoke through the
smokestack on the boiler of the engine. The smoke unit is essentially a small
heating element and wick that soaks up and then heats a mineral oil-based fluid
that emits a harmless smoke. The smoke is then forced out of the stack by a
small electric fan.
With a few easy maintenance steps, you should
enjoy trouble-free smoke unit operation for years.
•When preparing to run this engine, add 15-20
drops of smoke fluid through the smokestack (see
Fig. 4). We recommend M.T.H. ProtoSmoke,
Seuthe, LGB, or LVTS fluids (a small pipette of
ProtoSmoke fluid is included). Do not overfill the
unit or the fluid may leak out and coat the interior
engine components.
•If you choose not to add the fluid (or have
already added the fluid but choose to run
smoke-free), turn off the smoke unit switch located
under the enginebody (see Fig. 5). Failure either
to add fluid to the unit or to turn it off may damage
the smoke unit heating element and/or wicking
material.
•When the smoke output while running the engine
begins to diminish, add another 10-15 drops of
smoke fluid or turn the smoke unit off.
•When storing the unit for long periods of time,
you may want to add about 15 drops of fluid to prevent the wick from drying
out.
Proto-Smoke
ON/OFF Switch
Figure 5. Location of the
Proto-Smoke Switch
Add Smoke
Fluid Here
Figure 4. Add Smoke
Fluid Through the Smoke
Stack

11
RailKing 4-6-2 K-4 Steam Engine
•
After removing the engine from storage, add
another 25 drops of fluid, letting the wick soak up
the fluid for 15 minutes prior to operation.
If you experience poor or no smoke output when the
smoke unit is on and has fluid, check the wick to see
if it has become hard, blackened, and unabsorbent
around the heating element. Remove the smoke unit
inspection cover from the locomotive’s body (see
Fig.
6). After removing the chassis and inspection
cover screws, lift the inspection plate away and
inspect the wick. If it is darkly discolored and hard,
it should be replaced.
You can obtain replacement parts directly from the M.T.H. Parts Department.
Locomotive Light Bulb Replacement
To replace the light bulb in the locomotive, follow these instructions and see
the diagrams below:
Remove the locomotive boiler from its chassis as shown in Figure
3. Once the
body has been removed, rotate the headlight bulb counter-clockwise as seen in
Figure
7to remove.
You can obtain replacement bulbs directly from the M.T.H. Parts Department.
Location of the
headlamp bulb
Figure 7. Location of the Headlight Bulb
Remove These
Four Screws to
Inspect the Smoke Wick
Figure 6. Removing the
Smoke Unit Cover

12
RailKing 4-6-2 K-4 Steam Engine
Troubleshooting Loco-Sound™Problems
Although Loco-Sound has been designed and engineered for ease of use, you
may have some questions during initial operation. The following table should
answer most questions. If your problem cannot be resolved with this table,
contact M.T.H. for assistance (telephone: [phone]; fax: [phone];
[email protected], 7020 Columbia Gateway Drive, Columbia MD
21046-1532).
Starting Up
Horn
Bell
Remedy
Remedy
Remedy
Remedy
When I first turn the power on, the
engine will not begin to run. I have to
turn the throttle off and then on again
to get the engine to operate.
I can’t get the horn to blow when I
press the whistle button.
I can’t get the bell to ring when I press
the bell button.
You may be pressing the button too
quickly. Try pressing the whistle button
more slowly, taking approximately one
full second to fully depress the button.
You may be pressing the button too
quickly. Try pressing the bell button
more slowly, taking approximately one
full second to fully depress the button.
This is normal behavior. To prevent
accidental high-speed start-ups, Loco-
Sound is programmed to start up in
neutral anytime track power has been
turned off for several seconds. See
the "Basic Operation" section for more
details.
Lock-out Remedy
I can’t get the engine to run after I
power up the transformer. It sits still
with the engine sounds running.
The engine won’t lock into forward,
neutral, or reverse.
The engine is locked into the neutral
position. Follow the procedure in the
“Lock into a Direction” section.
Engine speed must be below 10 scale
mph (approx. 10 volts or less in
conventional mode).

13
RailKing 4-6-2 K-4 Steam Engine
Compatibility
This engine will operate on any traditional O-31 or larger O Gauge track
system, including M.T.H.’s RealTrax
®or ScaleTrax™or traditional tubular
track. It is also compatible with virtually any standard AC transformer. (See
page
14 for a complete list of compatible transformers and wiring
instructions.)
Volume Remedy
The sounds seem distorted, especially
when the whistle or bell is activated. Loco-Sound volume is set too high.
Turn the volume control knob on the
bottom of the chassis counter-
clockwise to reduce the volume.

14
RailKing 4-6-2 K-4 Steam Engine
Transformer Compatibility and Wiring Chart
Note that many of the operational commands described in these instructions
require a bell button, so if your transformer does not have its own bell button,
you should consider adding one to get the full benefit of the system.
Transformer
Model Center Rail Outside Rail Min/Max. Voltage Power Rating Transformer Type
Lionel1032 U A 5-16v 90-Watt Standard
Lionel 1032M U A 5-16v 90-Watt Standard
Lionel1033 U A 5-16v 90-Watt Standard
Lionel1043 U A 5-16v 90-Watt Standard
Lionel 1043M U A 5-16v 90-Watt Standard
Lionel1044 U A 5-16v 90-Watt Standard
Lionel1053 U A 8-17v 60-Watt Standard
Lionel1063 U A 8-17v 60-Watt Standard
All-Trol Left Terminal Right Terminal 0-24v 300-Watt Electronic
Dallee Hostler Left Terminal Right Terminal Electronic
Lionel LW A U 8-18v 75-Watt Standard
Lionel KW A or B U6-20v 190-Watt Standard
LionelMW Outside Track
Terminal Inside Track Terminal 5-16v 50V.A. Electronic
Lionel RS-1 Red Terminal Black Terminal 0-18v 50V.A. Electronic
Electronic
Lionel RW U A 9-19v 110-Watt Standard
Lionel SW U A Unknown 130-Watt Standard
Lionel TW U A 8-18v 175-Watt Standard
Lionel ZW
Lionel Post-War
Celebration
Series ZW
A,B,C or D
A,B,C or D
U
Common
8-20v
0-20v
275-Watt
135/190 Watt
Standard
MTH Z-500 RedTerminal Black Terminal 0-18v 50-Watt Electronic
MTH Z-750 RedTerminal Black Terminal 0-21v 75-Watt Electronic
MTH Z-4000 RedTerminal Black Terminal 0-22v 390-Watt Electronic
* Conventional Mode Only

15
RailKing 4-6-2 K-4 Steam Engine
CAUTION: Electrically Operated Product:
Not recommended for children under 10 years of age. M.T.H. recommends
adult supervision with children ages 10 - 16. As with all electric products,
precautions should be observed during handling and use to reduce the risk of
electric shock.
WARNING: When using electrical products, basic safety precautions should
be followed including the following:
• Read this manual thoroughly before using this device.
• M.T.H. recommends that all users and persons supervising use examine the
hobby transformer periodically for conditions that may result in the risk of
fire, electric shock, or injury to persons, such as damage to the primary cord,
plug blades, housing, output jacks or other parts. In the event such conditions
exist, the transformer should not be used until properly repaired.

SERVICE & WARRANTY INFORMATION
HOW TO GET SERVICE UNDER THE TERMS OF THE
LIMITED ONE YEAR WARRANTY
For warranty repair, do not return your product to the place of purchase.
Instead, follow the instructions below to obtain warranty service as our dealer
network is not prepared to service the product under the terms of this warranty.
1. First write, call, email or FAX MTH Electric Trains, 7020 Columbia Gateway Drive,
Columbia, MD 21046, 410-381-2580 (FAX No. 410-423-0009), or on the internet at
[email protected] or our web site, www.mthtrains.com, stating which product
you have, when it was purchased and what seems to be the problem. You will be given a
return authorization number to assure that your merchandise will be properly handled
upon its receipt at MTH.
2. CAUTION: Make sure the product is packed in its original factory packaging
including its foam and plastic wrapping material so as to prevent damage to the
merchandise. The shipment must be prepaid and we recommend that it be insured. A
cover letter, including your name, address, daytime phone number, a copy of your sales
receipt, the Return Authorization number and a full description of the problem, must be
included to facilitate the repairs. Please include the description regardless of whether or
not you discussed the problem with one of our service technicians when contacting MTH
for your Return Authorization number.
3. Please make sure you have followed the instructions carefully before
returning any merchandise for service.
LIMITED ONE YEAR WARRANTY
This item is warranted for one year from the date of purchase against defects in
material or workmanship. We will repair or replace (at our option) the defective
part without charge for parts or labor, if the item is returned to the address below
within one year of the original date of purchase. This warranty does not cover
items that have been abused or damaged by careless handling. Transportation
costs incurred by the customer are not covered under this warranty.
This warranty gives you specific legal rights and you may have other rights
which vary from state to state.
ProtoSounds® is a trademark of MTH Electric Trains. DCRU® is a registered
copyright of QS Industries, Inc. Lionel® and Railsound® are registered trademarks of
Lionel L.L.C.
