Rain Bird EZ1-D Installation manual

1
TO SET CLOCK DAY
EZ1-D
PROGRAMMING INSTRUCTIONS
Press SET
CLOCK &
PROGRAM .Press OR until number corresponding to cur-
rent day appears in display
MON
1TUE 2WED 3THU 4FRI 5SAT 6SUN 7
Display will indicate: Day Wed
TO SET CLOCK HOUR AND MINUTE (MILITARY TIME)
Hour:
Press .Press OR until current hour appears in display
Display will indicate Hour:
Minute:
Press .Press OR until current minute appears in display
Display will indicate Minute: Clock Time Military Time Clock Time Military Time
12:00 Midnight (A.M.) 0000 12:00 Noon 1200
1:00 AM 0100 1:00 PM 1300
2:00 0200 2:00 1400
3:00 0300 3:00 1500
4:00 0400 4:00 1600
5:00 0500 5:00 1700
6:00 0600 6:00 1800
7:00 0700 7:00 1900
8:00 0800 8:00 2000
9:00 0900 9:00 2100
10:00 1000 10:00 2200
11:00 1100 11:00 2300
PGM A/C
SET
CLOCK &
PROGRAM PGM A/C
SET
CLOCK &
PROGRAM PGM A/C
SET
CLOCK &
PROGRAM
STATION
RUN
TIME
WHICH
DAYS TO
WATER
MANUAL
ON/STA.
ADVANCE
TIME OF
DAY TO
WATER PGM A/C
SYSTEM
OFF/AUTO

2
TO CALL UP A PROGRAM
Press SET
CLOCK &
PROGRAM a fourth time until display reads:
Display will indicate
Day:(Mon) Watering will
occur for the “A” Pro-
gram
Press WHICH
DAYS TO
WATER .Press OR until display indicates ON if you wish
Display will indicate:
For program “A.”
which you want to program. Having two programs is like having two controllers; you
can water lawns and shrubs on different days or separate drip irrigation stations from
sprinkler stations. Because the "A" program has the default settings, it is best to use
"A" as your primary program and set it first, then set schedule "C" if you need the sec-
ond program.
VARIABLE DAY CYCLE
The EZ1-D Controller comes from the factory with a preset 7-day cycle. (This means
the controller will operate as programmed for 7 days, then repeat the cycle beginning
with day 1.)
If you want a 3-day cycle, for example, program days 1,2 and 3 only as above, and
then proceed as shown below.
SET
CLOCK &
PROGRAM
STATION
RUN
TIME
WHICH
DAYS TO
WATER
MANUAL
ON/STA.
ADVANCE
TIME OF
DAY TO
WATER PGM A/C
SYSTEM
OFF/AUTO
TO SET DAYS OF THE WEEK
to water, or OF if you do not wish to water on this day. Repeat for each day of the week.
OR
Display will indicate
Day:(Mon) Watering will
NOT occur for the “A”
Program
Now press Display will indicate:
Press and keep depressed for at least 2 seconds. Display will indi-
WHICH
DAYS TO
WATER
PGM A/C
By repeatedly pressing you can access program "A" or "C," depending on
PGM A/C

3
This indicates that Day 4 and all succeeding days through Day 7 will not operate. For
both the "A" and "C" programs the cycle will repeat after Day 3. Though both the "A"
and "C” programs are in the 3-day cycle, they can be set for the same or differing wa-
tering days.
To return to a 7-day cycle, press WHICH
DAYS TO
WATER
Then press
TO SET TIME OF DAY TO START WATERING
SET
CLOCK &
PROGRAM
STATION
RUN
TIME
WHICH
DAYS TO
WATER
MANUAL
ON/STA.
ADVANCE
TIME OF
DAY TO
WATER PGM A/C
SYSTEM
OFF/AUTO
1st Start Time for “A” Program
Press TIME OF
DAY TO
WATER .Press OR until the hour at which watering
Display will indicate:
begin, appears in the display. (Start times are on the hour.)
PGM A/C
Watering will start at 8:00 a.m.
Repeat for remaining two start times, if desired.
2nd Start Time for “A” Program
Display will indicate:
Indicates no start time set
To eliminate a start time, press and
until Day 4 appears in the display.
: Day 4 and all succeeding days through Day 7 will now be operable.
PGM A/C
until digits at right change to:
PGM A/C

4
You can now schedule WHICH DAYS TO WATER. TIME OF DAY TO WATER, and,
STATION RUN TIMES for program "C" by using the same steps you did for program
"A."
TO SET WATERING TIME FOR EACH STATION
SET
CLOCK &
PROGRAM
STATION
RUN
TIME
WHICH
DAYS TO
WATER
MANUAL
ON/STA.
ADVANCE
TIME OF
DAY TO
WATER PGM A/C
SYSTEM
OFF/AUTO
Station #1, “A” Program
Press STATION
RUN
TIME .Press OR until the display indicates the number
Display will indicate:
of minutes (from 1-99) you wish for Station #1 to water.
PGM A/C
Will water for 10 minutes
Repeat for remaining five stations. To skip a station, set that station’s watering time to 0
Current station # in “A” Program
Display will indicate:
Indicates no watering
After programming station #6, Press: STATION
RUN
TIME
If the display reads:
SET
CLOCK &
PROGRAM
SET
CLOCK &
PROGRAM
Flashing digits indicate controller is in
monitor mode.
to return to the display of the current time of day.
The programming for program "A" is now complete.
If you want to use the "C" program, push repeatedly to get to the "PA" display,
and then press to display "PC."
PGM A/C
Press
it confirms that no station is active.

5
MANUAL WATERING FOR A PROGRAM
SET
CLOCK &
PROGRAM
STATION
RUN
TIME
WHICH
DAYS TO
WATER
MANUAL
ON/STA.
ADVANCE
TIME OF
DAY TO
WATER PGM A/C
SYSTEM
OFF/AUTO
Station #1, “C” Program
Press SET
CLOCK &
PROGRAM repeatedly to get the “PA” display. Then, if you only want to start
Display will indicate:
program “C” press PGM A/C
Indicates watering will occur, and will count down until watering time is complete.
Note: When a station is watering, the station number and program will appear as the
first two digits in the display. The digit(s) to the right will blink throughout the watering
time. The manually started program will water all stations on that program and then re-
turn to automatic mode and await the next scheduled automatic start.
ADVANCING TO THE NEXT STATION OF A PROGRAM
(BEFORE PROGRAMMED WATERING IS COMPLETED)
SET
CLOCK &
PROGRAM
STATION
RUN
TIME
WHICH
DAYS TO
WATER
MANUAL
ON/STA.
ADVANCE
TIME OF
DAY TO
WATER PGM A/C
SYSTEM
OFF/AUTO
SET
CLOCK &
PROGRAM
STATION
RUN
TIME
WHICH
DAYS TO
WATER
MANUAL
ON/STA.
ADVANCE
TIME OF
DAY TO
WATER PGM A/C
SYSTEM
OFF/AUTO
Press MANUAL
ON/STA.
ADVANCE .The station which was watering
will stop. The next station in sequence that is as-
signed to the program, will begin watering and
continue through its programmed watering time.
Digits at right of display will blink and count down
until cycle is completed. If digits at right do not
MONITORING STATION
OPERATION
to display the “PC.” to start the program.Next, press MANUAL
ON/STA.
ADVANCE
blink, then press repeatedly until desired
station number appears at left of display again.
Digits at right should now blink.
STATION
RUN
TIME

6
TO PREVENT STARTS, OR CANCEL CYCLE DURING OPERATION
(RAIN SHUT-OFF)
SET
CLOCK &
PROGRAM
STATION
RUN
TIME
WHICH
DAYS TO
WATER
MANUAL
ON/STA.
ADVANCE
TIME OF
DAY TO
WATER PGM A/C
SYSTEM
OFF/AUTO
Prevent Starts: Press
Sheduled watering cycles will not occur until sys-
tem is returned to automatic operation; last digit
60 HZ (USA: 220, 240, 260 V) and 50 HZ (European)
TRANSFORMER CONNECTION
Attach a 3/4" conduit to the left most wiring hole in the bottom of the controller. Route
the power wires through the conduit and into the wiring cavity.
Use wire nuts to connect the "NEUTRAL" wire to the white transformer wire and the
"HOT" wire to the appropriately colored wire on the transformer. Use the "BLK" wire
for 220V, the "BRN" wire for 240V and the "ORN" wire for 260V.
Tape the two unused transformer wires so that they can't make contact with each
other or with the conduit. See the wiring schematic provided on the body of the 50 HZ
transformer and the figure below.
SYSTEM
OFF/AUTO
SYSTEM
OFF/AUTO
EZ1 CONTROLLER
CABINET
3-TAP TRANSFORMER
260V-240V-260V
AC-50 HZ
TRANSFORMER
260V-50 HZ
“HOT” WIRE (ORANGE)
TRANSFORMER
240V-50 HZ
“HOT” WIRE (BROWN)
TRANSFORMER “COMMON”
WIRE (WHITE)
WIRE NUTS
“COMMON” FROM
POWER SOURCE
“HOT” FROM POWER
SOURCE TRANSFORMER
220V-50 HZ
“HOT” WIRE (BLACK)
WIRE NUTS
WRAPPED
WITH PLASTIC
ELECTRICAL
TAPE SYSTEM VALVE “COMMON”
TO OTHER CONTROL
VALVES
STATION #1 CONTROL
WIRE
NOTE: THE “COMMON” CAN ALSO BE RE-
FERRED TO AS THE “NEUTRAL.”
YELLOW-DUAL LOW VOLTAGE “COMMON”
RED-9.5 VOLT “HOT”
BLUE-24.5 VOLT “HOT”
IC CHIP
DISPLAY
FUSE
M.V.
TYPICAL SYSTEM CONTROL VALVE
TYPICAL CONTROL
WIRE TO
OTHER CONTROL VALVES
NOTE: BE SURE TO USE A WIRE NUT AND PROPERLY TAPE EACH OF THE REMAINING “HOT” WIRES FROM THE TRANS-
FORMER (TWO WIRES) TO COMPLETELY ISOLATE THEM AND PREVENT “SHORTING OUT.”
.
To return to automatic operation, press
last digit at right will stop blinking. ;

7
IN CASE OF TROUBLE, CHECK HERE
Sometimes when problems occur, they can be easily solved by carefully checking
some seemingly apparent, but often overlooked possibilities. Check here before you
call your professional contractor or Rain Bird distributor. It could save you time and
money.
IF YOU'RE HAVING THIS KIND OF
TROUBLE CHECK THESE THINGS:
• Automatic cycle does not occur • If display is blank, check fuse in EZ1.
• If last digit blinks, EZ1 is in the Rain Shut-
Down mode.
• Entire display is blank • Check fuse in EZ1; it probably needs replace-
ment.
• Entire display blinks • 9V battery needs replacing. After new battery
is installed, reprogram controller.
• Last digit in display blinks • EZ1 is in the Rain Shut-Down mode.
• Last two digits in display blink • EZ1 is counting down the time remaining on
station currently in operation.
• Clock loses (gains) a few minutes
every week or month • Intermittent power fluctuations are most likely responsible. Simply reset clock to correct time.
• Fuse blows too often (display goes
blank) • There is a short in the wiring between the controller and the valves.
Have bare wires, non-water tight connections,
and/or bad valve solenoids replaced.
