Service Manual
TOP NEXT
ORDER NO. KM70104623C0
G14
High Speed Scanner
● KV-S2065L/KV-S2065W
© 2001 Kyushu Matsushita Electric Co., Ltd. All rights reserved. Unauthorized copying and distribution is a violation of law.
TOP NEXT
file://///serwer/instr/CD/900-999/CD945/KV-S2065L_A...g/SGML_VIEW_DATA/ALL/KV-S2065L/SVC/s0000000000.html [2010-08-24 21:07:46]

file://///serwer/instr/CD/900-999/CD945/KV-S2065L_ALL_SVC/Viewing/SGML_VIEW_DATA/ALL/KV-S2065L/SVC/s0100000000x.html
1 GENERAL PRECAUTIONS
TOP PREVIOUS NEXT
1.1 Safety Precautions
1.2 Electrical Tests
1.3 For Service Technicians
TOP PREVIOUS NEXT
file://///serwer/instr/CD/900-999/CD945/KV-S2065L_A.../SGML_VIEW_DATA/ALL/KV-S2065L/SVC/s0100000000x.html [2010-08-24 21:08:32]

file://///serwer/instr/CD/900-999/CD945/KV-S2065L_ALL_SVC/Viewing/SGML_VIEW_DATA/ALL/KV-S2065L/SVC/s0101000000.html
1.1 Safety Precautions
TOP PREVIOUS NEXT
1. Before servicing, unplug the power cord to prevent electrical shock hazard.
2. When replacing parts, user only manufactures recommended components for safety.
3. Check the condition of power cord. Replace if wear or damage is evident.
4. After servicing, be sure to restore the lead dress, insulation barriers, insulation papers, shields,
etc.
5. Before returning the serviced equipment to the customer, perform the following electrical tests
to prevent shock hazard.
TOP PREVIOUS NEXT
file://///serwer/instr/CD/900-999/CD945/KV-S2065L_A...g/SGML_VIEW_DATA/ALL/KV-S2065L/SVC/s0101000000.html [2010-08-24 21:08:37]

file://///serwer/instr/CD/900-999/CD945/KV-S2065L_ALL_SVC/Viewing/SGML_VIEW_DATA/ALL/KV-S2065L/SVC/s0102000000.html
1.2 Electrical Tests
TOP PREVIOUS NEXT
1. Unplug the power cord and check for continuity between the earth ground connection on the
plug and the Interface Board Cover. There should be zero ohm resistance
2. With the unit unplugged, short the AC live-neutral of the plug with a jumper wire.
3. Turn ON the power switch.
4. Measure the resistance value with an ohmmeter between the jumpered AC plug and an exposed
metal cabinet part, such as screwheads, etc. (Refer to Fig.2)
Note:
Some exposed parts may be isolated from the chassis by design. They read infinity.
5. If the measurement is less than 1MΩ, a possibility for electric shock may exit.
Note:
This hazardous condition must be corrected before the unit is returned to the end user.
TOP PREVIOUS NEXT
file://///serwer/instr/CD/900-999/CD945/KV-S2065L_A...g/SGML_VIEW_DATA/ALL/KV-S2065L/SVC/s0102000000.html [2010-08-24 21:08:39]

file://///serwer/instr/CD/900-999/CD945/KV-S2065L_ALL_SVC/Viewing/SGML_VIEW_DATA/ALL/KV-S2065L/SVC/s0103000000.html
1.3 For Service Technicians
TOP PREVIOUS NEXT
ICs and LSIs are vulnerable to static electricity. When repairing, the following precautions will help
to prevent recurring malfunctions.
1. Cover the plastic parts with aluminum foil.
2. Ground the soldering irons.
3. Use a conductive mat on the worktable.
4. Do not grasp IC or LSI pins with bare fingers.
TOP PREVIOUS NEXT
file://///serwer/instr/CD/900-999/CD945/KV-S2065L_A...g/SGML_VIEW_DATA/ALL/KV-S2065L/SVC/s0103000000.html [2010-08-24 21:08:39]

file://///serwer/instr/CD/900-999/CD945/KV-S2065L_ALL_SVC/Viewing/SGML_VIEW_DATA/ALL/KV-S2065L/SVC/s0200000000x.html
2 SPECIFICATION
TOP PREVIOUS NEXT
Item Model No.
KV-S2065L KV-S2065W
Scanner Scanning face Duplex scanning
Scanning method Front side: CIS (Contact Type Image Sensor)
Back side: CIS (Contact Type Image Sensor)
Scanning speed Simplex scanning: Approx. 60 ppm (Letter, fed lengthwise,
200 dpi)
Duplex scanning: Approx. 110 ipm (Letter, fed lengthwise,
200 dpi)
Resolution Main scanning direction: 100-600 dpi (1 dpi step)
Sub-scanning direction: 100-600 dpi (1 dpi step) (Same as
main scanning direction)
Optical resolution is 400 dpi.
Tonal gradation Binary mode, Grayscale mode (4/8 bit), 64-step gradation
(dither) mode, 64-step gradation (error diffusion) mode
Image control Image emphasis, Dynamic threshold (DIMM required),
Automatic threshold, Automatic separation, Monochrome
reversing, Automatic back control
Compression MH, MR, MMR
Paper Size Scanning size: 48 x 70mm
(1.9 x 2.75 in.) to 216 x
431mm (8.5 x 17 in.)
Feeding size: 48 x 70mm
(1.9 x 2.75 in.) to 305 x
838mm (12 x 33 in.)
Scanning size: 48 x 70mm
(1.9 x 2.75 in.) to 298 x
431mm (11.7 x 17 in.)
Feeding size: 48 x 70mm
(1.9 x 2.75 in.) to 305 x
838mm (12 x 33 in.)
Thickness Single paper feeding: 0.025 to 0.2mm (1.0 to 7.9 mils)
Continuous paper feeding: 0.06 to 0.2mm (2.4 to 7.9 mils)
Note: 1 mil=1/1000 in.
Weight Single paper feeding: 20 to 157g/m2 (5.3 to 42 lbs.)
Continuous paper feeding: 50 to 157g/m2 (13 to 42 lbs.)
Interface (Transfer rate) SCSI 3 (20MB/sec), 50pin
Unit External dimensions(WidthxDepthxHeight) 495 x 575 x 246mm (19.5 x 22.6 x 9.7 in.)
Mass (Weight) 19kg (41.8 lbs.)
Power requirement AC100-120V, 50/60Hz
AC220-240V, 50/60Hz
Power consumption Maximum(Scanning) 1.3A (AC100-120V)/98W0.8A (AC220-240V)/98W
Minimum(Standby) 0.5A (AC100-120V)/30W0.3A (AC220-240V)/30W
Sleep mode 0.13A (AC100-120V)/11W 0.07A (AC220-240V)/11W
Operating Environment Operating temperature and humidity 15°C to 30°C (59°F to 86°F), 30% to 80% RH
Storage Environment Storage temperature and humidity 0°C to 35°C (32°F to 95°F), 10% to 80% RH
