Rapidline EC070CM User manual

Assembly Instructions:
Tools Required:
Screwdriver, Electric Drill, Pencil, Measuring tape/Ruler
*Tools are not included.
Skill Required:
The Assembly Skill Rating is a 5-point system that shows the degree of eort needed in assembling
a specic product. With 1 being easy for the average person and 5 requiring an expert.
For most products, two persons are recommended.
Please note, as this is a commercial product, some intermediate skills are required.
*No pre-drill holes or markings are provided on tops.
Time Required:
10 minutes
Easy Hard
Product Code : EC070CM
Product Name: EC070CM Medium Back Operator Chair
NOTE
• As this is a commercial product, some intermediate skills may be required.
• No pre-drill holes or markings are provided on our table or desk tops.
• Please check you have all hardware before assembling.
• If you are missing any hardware, please contact your Rapidline reseller. Please ensure you have the name of the item,
required hardware part and quantity.
• Please retain your receipt as proof of purchase to validate your warranty.
• Assemble on a clean, at, smooth surface such as a rug or carpet to avoid parts from being scratched.
• Remove all wrapping materials, including staples and packing straps before you start to assemble
• Keep all hardware parts out of reach of children.
CAUTION
• Heavy product. Do not attempt to lift or move without help
• Do not tighten screws and bolts until completely assembled.
• Do not use this product unless all bolts and screws are rmly secured and tightened.
WARNING
• If parts are missing, broken, damaged or worn stop using the product until all repairs are made.
• Failure to follow these warnings could result in serious injury.

A.
Back
B.
Seat
C.
Castors
D.
Plastic Lug
E.
Bellows
F.
Gas li
1.
• Insert gas li into the base with
castors
• Place the bellows over the gas li
and press down
2.
• Fit the seat on top of the gas li
3.
• Slide the bar of the back into the
insert slot of the mechanism at
the back of seat, but rst pull out
the plastic lug then slide the bar
in
4.
• Place the plastic
lug back into
place
• Tighten the knob
once reached the
desired height
EC070CM
