CC-SG E1 Quick Setup Guide 1
QSG-CCE1-0K-v5.4.0-E 255-80-5400-01-RoHS
CommandCenter Secure
Gateway E1 Models
Quick Setup Guide
Thank you for your purchase of the CommandCenter Secure Gateway™, Raritan's management software platform
engineered to consolidate secure access and control of IT devices. This Quick Setup Guide explains how to install and
configure the CommandCenter Secure Gateway.
For additional information on any aspect of the CommandCenter Secure Gateway, see the accompanying online help
accessed from the CommandCenter Secure Gateway or the CommandCenter Secure Gateway help in PDF format,
which can be downloaded from the Firmware and Documentation section of Raritan's website
(http://www.raritan.com/support/firmware-and-documentation/).
Diagram Key
1
LAN ports
2
Power
3
KVM ports
4
Extra LAN ports
Do not use
I. Unpack CC-SG
With your shipment, you should receive:
(1) CommandCenter Secure Gateway E1 unit
(1) CommandCenter Secure Gateway E1 front bezel
(1) Rack mount kit
(2) Power supply cord
(1) CAT 5 network cable
(1) Printed Quick Setup Guide
(1) Registration and Warranty papers
Determine Rack Location
Decide on a location in the rack for CC-SG, in a clean,
dust-free, well-ventilated area. Avoid areas where heat,
electrical noise, and electromagnetic fields are generated and
place it near a grounded power outlet.
QSR ule
II. Rack-mount CC-SG
Before rack-mounting CC-SG, unplug all power cords and
remove all external cables and devices.
The rack mount kit contains:
2 pairs of rack rails

CC-SG E1 Quick Setup Guide 2
QSG-CCE1-0K-v5.4.0-E 255-80-5400-01-RoHS
Each pair consists of two sections: an inner rail that
attaches to the CC-SG unit, and an outer rail that
attaches to the rack. A sliding rail guide is positioned
between the inner and outer rails. The sliding rail guide
should remain attached to the outer rail.
1 pair of short front brackets
1 pair of long rear brackets
Short screws, Long screws
Washers
Install Inner Rails onto CC-SG Unit
1. Slide the inner rail out from the outer rail as far as it will
go. Press the locking tab to release the inner rail from the
outer rail and then pull the inner rail completely out. Do
this for both pairs of rack rails.
2. There are five holes on each inner rail that correspond to
the five rail hooks on each side of the CC-SG unit. Align
each inner rail's holes with the rail hooks, and then press
each rail against the unit to attach it.
3. Slide each rail toward the front of the unit until you hear a
click.
4. Attach the inner rails to the CC-SG unit with short screws.
Install Outer Rails onto Rack
1. The outer rails attach to the rack. The outer rails will fit
racks that are 28-32 inches deep.
2. Attach the short front brackets to each outer rail with short
screws. Note the up/Front indication on the brackets when
attaching them.
3. Slide each long rear bracket into the opposite end of each
outer rail. Attach the long rear brackets to the outer rails
with short screws. Note the up/Rear indication on the
brackets when attaching them.
4. Adjust the entire rail unit length to fit the rack depth.
5. Attach each bracketed end of the outer rail to the rack with
washers and long screws.
Install CC-SG into the Rack
Once the rails are attached to both the CC-SG unit and the
rack, install CC-SG into the rack.
1. Fully extend the rack rails, and then line up the rear of the
inner rails with the front of the rack rails.
2. Slide the CC-SG unit into the rack until you hear a click.
You may have to depress the locking tabs when inserting
the CC-SG unit into the rack.
Locking Tabs Information
Both inner rails have a locking tab:
To lock the CC-SG unit into place when pushed fully into
the rack.
To lock the CC-SG unit into place when extended from the
rack.
QSR ule
III. Connect Cables
Once the CC-SG unit is installed into the rack, you can
connect cables. See the diagrams on page 1.
1. Connect the CAT 5 network LAN cable to the LAN 1 port
on the rear panel of the CC-SG unit. It is strongly
recommended to connect a second CAT 5 network LAN
cable to the LAN 2 port. Connect the other end of each
CAT 5 cable to the network.
2. Attach the 2 included AC power cords to the power ports
on the rear panel of the CC-SG unit. Plug the other ends
of the AC power cords into independent UPS protected
outlets.
3. Connect KVM cables to the corresponding ports on the
rear panel of the CC-SG unit.
QSR ule
IV. Log in to Local Console to Set CC-SG IP
Address
1. Power ON CC-SG by pressing the POWER button on the
front of the CC-SG unit.
2. Attach the front bezel by snapping it onto the front of the
CC-SG unit.
3. Log in as admin/raritan. Usernames and passwords are
case-sensitive.
4. You will be prompted to change the local console
password.
a. Type the default password (raritan) again.
b. Type and then confirm the new password. The new
password must be a strong password consisting of at
least eight characters that are a combination of letters
and numbers.
5. Press CTRL+X when you see the Welcome screen.
6. Choose Operation > Network Interfaces > Network
Interface Config. The Administrator Console appears.
7. In the Configuration field, select DHCP or Static. If you
select Static, type a static IP address. If needed, specify
DNS servers, netmask, and gateway address.
8. Select Save. Wait a few minutes as CC-SG restarts.
Default CC-SG Settings
IP Address: 192.168.0.192

CC-SG E1 Quick Setup Guide 3
QSG-CCE1-0K-v5.4.0-E 255-80-5400-01-RoHS
Subnet Mask: 255.255.255.0
Username/Password: admin/raritan
QSR ule
V. Get Your License
1. The license administrator designated at time of purchase
will receive an email from Raritan Licensing Portal from
the email address [email protected], with the subject
line Thank You for Registering.
2. Click the link in the email to go to the Software License
Key Login page on Raritan's website. Create a user
account and login. The username is your email address.
The licensing account information page opens. Your
license files will be available shortly.
3. Check your email for another message from Raritan
Licensing Portal from the email address
[email protected], with the subject line Your Raritan
Commandcenter SG Software License Key is Available.
4. Click the link in the email to go to the Software License
Key Login page on Raritan's website and login with the
user account just created.
5. Click the Product License tab. The licenses you purchased
display in a list. You may have only 1 license, or multiple
licenses.
6. To get each license, click Create next to the item in the
list, then enter the CommandCenter Secure Gateway Host
ID. You can copy and paste the Host ID from the License
Management page. See Find Your Host ID (on page 4).
7. Click Create License. The details you entered display in a
pop-up. Verify that your Host ID is correct.
Warning: Make sure the Host ID is correct! A license
created with an incorrect Host ID is not valid and requires
Raritan Technical Support's help to fix.
8. Click OK. The license file is created.
9. Click Download Now and save the license file.
QSR ule
VI. Log in to CC-SG
Once CC-SG has restarted, you can log in to CC-SG from a
remote client.
1. Launch a supported browser and type the URL of the
CC-SG: https://<IP address>/admin.
For example, https://192.168.0.192/admin.
Note: The default setting for browser connections is
HTTPS/SSL encrypted.
2. When the security alert window appears, accept the
connection.
3. You will be warned if you are using an unsupported Java
Runtime Environment version. Follow the prompts to
either download the correct version, or continue. The
Login window appears.
4. Type the default username (admin) and password (raritan)
and click Login.

CC-SG E1 Quick Setup Guide 4
QSG-CCE1-0K-v5.4.0-E 255-80-5400-01-RoHS
The CC-SG Admin Client opens.
Find Your Host ID
1. Choose Administration > License Management.
2. The Host ID of the CommandCenter Secure Gateway unit
you are logged into displays in the License Management
page. You can copy and paste the Host ID.
QSR ule
VII. Install and Check Out Your License
1. Choose Administration > License Management.
2. Click Add License.
3. Read the license agreement and scroll down the whole
text area, then select the I Agree checkbox.
4. If you have multiple licenses, such as a "base"appliance
license plus Add-On license for additional nodes or
WS-API, you must upload the physical appliance license
first. Click Browse, then select the license file to upload.
5. Click Open. The license appears in the list. Repeat for
Add-On licenses.
You must check out licenses to activate the features.
6. Select a license from the list then click Check Out. Check
out all the licenses you want to activate.
See the CC-SG Administrators Guide for more details about
licenses.
QSR ule
VIII. Next Steps
See the CommandCenter Secure Gateway Deployment Guide
for information on deploying other Raritan devices for CC-SG
management.
See the CommandCenter Secure Gateway Administrator
Guide for information on configuring CC-SG.
Additional Information
For more information about the CommandCenter Secure
Gateway™and the entire Raritan product line, see Raritan's
website (www.raritan.com). For technical issues, contact
Raritan Technical Support. See the Contact Support page in
the Support section on Raritan's website for technical support
contact information worldwide.
